Installation Manual
4-2298-01 Rev.B
Ozone + UV Sanitation
[phone]
o3inf[email protected]
www.delozone.com
EPA Estab. No. 071472-CA-001

IMPORTANT SAFETY INSTRUCTIONS
When installing and operating the DEL Spa Solar Eclipse, basic precautions
should always be followed:
READ AND FOLLOW ALL INSTRUCTIONS
• Read this manual completely before attempting installation.
• All permanent electrical connections should be made by a qualified
electrician.
• Follow all applicable electrical codes.
• Be sure the electrical power is shut OFF at the main circuit breaker before
installing the Spa Solar Eclipse.
• If the Spa Solar Eclipse electrical connection is to be attached to the
spa controls, be sure the spa controls are protected by a Ground Fault
Circuit Interrupter (G.F.C.I.). If the Spa Solar Eclipse is connected to an
independent electrical supply, then a G.F.C.I. must be installed between
the Spa Solar Eclipse and the electrical supply.
•WARNING: To reduce the risk of electrical shock, if the power cord
is damaged, replace the entire unit immediately.
• The Spa Solar Eclipse must be mounted under the spa skirt sheltered
from enviornmental elements (rain, sun, sprinklers).
• Plastic ozone supply tubing is available with the Spa Solar Eclipse. Never
replace this tubing with metal tubing.
• Do not operate the Spa Solar Eclipse unless sufficient water flow is being
drawn through the unit.
• WARNING: Short term inhalation of high concentrations of ozone and
long term inhalations of low concentrations of ozone can cause harmful
physiological effects. Do not inhale ozone gas produced by this device.
• WARNING: Exposure to UV light from this device is harmful to skin and
eyes. Do not attempt to remove or service the UV lamp while it is lit.
SAVE THESE INSTRUCTIONS!

TABLE OF CONTENTS
Installation Instructions
1. Overview .............................................................................................. 1
2. Mounting .............................................................................................. 1
3. Plumbing .............................................................................................. 1
4. Electrical............................................................................................... 2
5. Operation ............................................................................................. 2
6. Maintenance......................................................................................... 3
Warranty................................................................................................... 7

SES Installation & Operations Manual
1
INSTALLATION INSTRUCTIONS
1. Overview
The Spa Solar Eclipse is a UV/Ozone sanitation unit designed for use
in portable spas and to be controlled by the spa’s equipment pack.
Please contact DEL Customer Support if the Spa Solar Eclipse is
used in an application other than a portable spa.
2. Mounting
a. Use the two mounting holes located internally on the back panel of
the Spa Solar Eclipse (Figure 1).
b. Mount the Spa Solar Eclipse to the spa frame with #8 hardware.
The preferred mounting orientation is shown in Figure 2. Connect
water inlet at the bottom. Contact DEL Ozone for other installation
options.
3. Plumbing
DEL Ozone recommends that the Ozone Injector be installed
upstream of the Spa Solar Eclipse so the ozone can interact with the
UV light. This interaction leads to Advanced Oxidation Process which
will improve sanitation. However, the Spa Solar Eclipse will function
properly if the Ozone Injector is installed downstream.
a. Connect ozone compatible tubing (1/4” internal diameter) to the
open hose barb on the Spa Solar Eclipse
b. Run tubing to the Ozone Injector or appropriate vacuum source.
i. If the Spa Solar Eclipse is mounted above the water line,
tubing may be run directly to the vacuum source.
Figure 1: System Overview
Allow vertical clearance
for lamp removal
(approximately 12”)
Mounting Hole
Power LED
UV LED
Ozone Indicators
(2x)
Air Intake Filter
Ozone Out
Bonding Lugs Inlet
Mounting Hole
Outlet

SES Installation & Operations Manual
2
ii. If the Spa Solar Eclipse is mounted below the water line, run
tubing to a point above the water line and back down to the
vacuum source.
c. Install the check valve in the tubing above the water line. Ensure
flow direction is from the Spa Solar Eclipse to the vacuum source.
d. Secure all tubing connections with hose clamps.
4. Electrical
a. Verify that there is no power to the spa and connect the Spa Solar
Eclipse cord into the mating connector(s) on the Spa Controller.
b. Where possible, route the Spa Solar Eclipse power cord away from
other electrical lines. Avoid routing the power cord parallel to any
low-voltage signal wires.
c. Use a minimum 8 AWG solid copper conductor to connect the
bonding lug provided on the Enclosure Base to the spa equipment
ground.
5. Operation
If installed correctly, the Spa Solar Eclipse will turn on and off as
required by the Spa Controller. After installation, turn the spa on and
verify that the POWER ON (green) and UV LAMP ON (blue) indicator
lights are illuminated. Repair any leaks in the water or ozone lines and
Figure 2: Spa Solar Eclipse System Diagram
Isolation Valves
(Recommended)
Injector
Water from Spa
Water Return
to Spa
Check Valve

SES Installation & Operations Manual
3
verify that small bubbles can be seen in the return flow. Finally, turn
the Spa off and make sure that the POWER and UV indicator lights
are not illuminated.
6. Maintenance
WARNING: Before performing any maintenance on the Spa Solar
Eclipse, make sure the spa is shut down.
6A. UV Lamp Removal (see Figure 3)
If the Green Power Indicator is on, but the Blue UV Lamp Indicator is
off, the UV lamp needs to be replaced. For maximum UV sanitation
effect, replace the UV Lamp every 18 months.
i. Make sure the unit is disconnected from power and the lamp
has cooled before starting maintenance.
ii. Open the Spa Solar Eclipse by removing the two front screws
and loosening the two Enclosure Screws on the Upper
Enclosure Assembly. Pull the Cover from the Enclosure Base.
iii. Disconnect the Lamp Connector attached to the lamp wires.
iv. Gently pull on the Lamp Wires until the top of the UV Lamp is
out of the Lamp Retainer. Grasp the white ceramic end of the
UV Lamp and pull until it is fully removed. If the UV Lamp will
be reused, AVOID TOUCHING THE UV LAMP GLASS WITH
YOUR BARE HANDS. Handle the lamp carefully and set aside.
If discarding, dispose of properly (see the following note).
Figure 3: Spa Solar Eclipse Exploded View
UV Lamp
Sealing Ring
Quartz Tube
Lamp Retainer
Retainer Screw

SES Installation & Operations Manual
4
NOTE: UV Lamp CONTAINS MERCURY. Manage in accordance with
disposal laws. See www.lamprecycle.org.
6B. Installing the UV Lamp
i. Make sure to handle the new lamp by the ceramic endcaps
and clean the UV Lamp before installation if needed.
ii. Slowly place the UV Lamp into the Lamp Retainer until the top
of the UV Lamp is pushed past the tabs on the Lamp Retainer.
iii. Connect the Lamp Connector to its corresponding part in the
Ballast Assembly.
6C. UV Reactor Service and Maintenance
The UV Lamp is housed in a Quartz Tube. If the Quartz Tube
becomes dirty, its ability to transmit rays from the UV Lamp will be
diminished and decrease system performance. The Quartz Tube
should be removed from the UV Reactor at least once a year or
during a routine spa water change for inspection and cleaning if
necessary.
6D. Quartz Tube Removal and Cleaning
CAUTION: Wear proper eye and skin protection for servicing
glass components.
NOTE: Damage caused by broken quartz tubes is not covered under
the Spa Solar Eclipse Limited Warranty.
CAUTION: If broken glass is trapped in the pool system, do not
operate the pool. Contact a service professional to have the
glass removed.
i. Make sure the pool is shut down and the system has cooled
before performing maintenance on the Quartz Tube. If you have
installed Isolation Valves, close them before servicing. If you
do not have Isolation Valves, the pool must be drained below
where the Spa Solar Eclipse is mounted.
ii. Remove the Enclosure Cover and UV Lamp as described in
Section 4C and set aside.

SES Installation & Operations Manual
5
iii. Remove the two Retainer Screws and Retainer Washer from the
top of the Lamp Retainer and pull the Lamp Retainer out of the
UV Chamber Cap.
NOTE: Any water remaining in the system above the level of the
Spa Solar Eclipse will flow out of the UV Housing once the Lamp
Retainer is removed.
iv. Grasp the inside of the Quartz Tube and pull it out of the
housing. Make sure the Sealing Ring does not get lost during
Quartz Tube removal.
v. Inspect the Quartz Tube for cracks and replace if cracks are
found. Inspect the Sealing Ring for nicks or hardness and
replace if necessary.
vi. Clean the Quartz Tube exterior with a mild solution of muriatic
acid and water in a ratio of four parts water to one part acid
(4:1). DO NOT USE ABRASIVE CLEANERS.
CAUTION: Follow the directions for safe use and handling of
muriatic acid on the acid bottle label. Never add water to acid.
Always add acid to water.
vii. After cleaning the Quartz Tube, wash it off with water and wipe
dry with a soft towel.
viii. Make sure the inside of the Quartz Tube is dry before installing
the UV Lamp.Make sure the inside of the Quartz Tube is dry
before replacing the UV Lamp(s).
6E. Quartz Tube Installation
i. Place the Sealing Ring on the Quartz Tube 3/4 inch from the
open end.
ii. Insert the Quartz Tube partially into the UV Chamber. Place the
Lamp Retainer over the open end of the Quartz Tube and slowly
push in until it is touching the UV Chamber Cap.
iii. Place the Retainer Washers onto the Retainer Screws and
screw the Lamp Retainer Screws until the Lamp Retainer is
completely seated against the UV Chamber Cap.
iv. After pool is refilled, turn the pool ON and check the seal around
the Lamp Retainer for leaks.
v. If the unit leaks, please contact DEL Customer Support at

SES Installation & Operations Manual
6
following number: 1-800-676-1335.
vi. SHUT DOWN the pool once you have confirmed that there are
no leaks.
vii. Install the UV Lamp as described in Section 4.
viii. Reinstall the Upper Enclosure Assembly to the Enclosure Base.
ix. The unit is now ready for normal operation.
6F. Standard Replacement Parts List
i. Replacement UV Lamp Assembly 9-1100-01
ii. Quartz Tube Replacement Kit 9-1204-01
iii. Sealing Ring 7-1871-01

SES Installation & Operations Manual
7
DEL OZONE
LIMITED ONE YEAR WARRANTY
The limited warranty set forth below applies to products manufactured by DEL OZONE and sold by DEL OZONE or its
authorized dealers. This limited warranty is given only to the first retail purchaser of such products and is not transferable
to any subsequent owners or purchasers of such products.
DEL Ozone warrants that it or its authorized dealers will repair or replace, at its option, any part of such products proven
to be defective in materials or workmanship within ONE (1) year from the date of retail purchase of such products. (All
parts) ANY REPAIR OR REPLACEMENT WILL BE WARRANTED ONLY FOR THE BALANCE OF THE ORIGINAL
WARRANTY PERIOD OR NINETY (90) DAYS, Whichever is greater.
NOTE: USE ONLY DEL AUTHORIZED DEL REPLACEMENT PARTS. USE OF ANY OTHER PART(S) WILL VOID
THIS WARRANTY.
Any replaced parts must be returned to DEL OZONE for warranty evaluation.
THIS LIMITED WARRANTY DOES NOT INCLUDE ANY OF THE FOLLOWING:
(a) Any labor charges for troubleshooting, removal, or installation of such parts.
(b) Any repair or replacement of such parts necessitated by faulty installation, improper maintenance, improper
operation, misuse, abuse, negligence, accident, fire, flood, repair materials, and/or unauthorized accessories.
(c) Any such products installed without regard to required local codes and accepted trade practices.
(d) Damage to unit caused by water backflow.
(e) Any implied warranty of merchantability or implied warranty of fitness for particular purpose, and such
warranties are hereby disclaimed.
(f) DEL Ozone shall not be liable under any circumstances for loss of use of such product, loss of profits,direct
damages, indirect damages, consequential damages, and / or incidental damages.
This warranty gives you specific legal rights. You may have other rights which vary from state to state.
TO OBTAIN WARRANTY SERVICE:
DEL OZONE
Customer Service Number: [phone]
Fax Number: [phone]
E mail warranty[email protected]om (residential)
[e-mail] (commercial)
PROVIDE:
1. Customer name, mailing address,and telephone.
2. Installer/Mechanical Contractor or Dealer name.
3. Unit Part Number, Serial Number or Manufacture Date, and date of purchase.
4. The date of failure.
5. A description of the failure.
After this information is provided, DEL Ozone may release a RETURN GOODS AUTHORIZATION (RGA) NUMBER. After receiving the RGA number
the part in question must be returned to DEL Ozone, freight prepaid, with the RGA number clearly marked on the outside of the package. All
preauthorized defective parts must be returned to DEL Ozone within thirty (30) days. Under no circumstances may any product be returned to DEL
Ozone without prior authorization. Returns without the assigned RGA number on the outside of the package will be refused and shipped back to the
sender at their expense. Upon receipt of preauthorized returned goods, DEL Ozone will repair or replace, at DEL Ozone’s option, the defective product(s)
and return them (freight prepaid for products under warranty). Buyer’s acceptance of the product and use thereof constitutes acceptance of these terms.
4-1353-01_Rev.E

[phone]
o3inf[email protected]
www.delozone.com
EPA Estab. No. 071472-CA-001
