MERIDIAN SERIES®SOLID DOOR NARROW REACH-IN FREEZERS
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
MERIDIAN SERIES®
Solid Door Narrow Reach-In Freezers
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
Approval _________________
Date____________________
MRR1N-S
Shown with optional 4th
shelf and left-hand hinging.
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be aluminum.
Facing of shroud shall be easily removable without the
use of tools.
Cabinet interior shall be anodized aluminum. Bottom
& top of liner shall be die-stamped to provide
radius corners and a recessed bottom. Base shall be
fully insulated with high-density foamed in place
polyurethane.
Interior shall have three epoxy-coated wire shelves
per door section. Shelf support pilasters shall be
heavy-duty with shelves adjustable at 1.0” (2.5 cm)
increments. Unit are mounted on 6” (15.24cm) metal
legs.
Doors: Solid doors shall have a 22-gauge stainless
steel exterior & anodized aluminum interior liner.
Doors shall be fully insulated with high density foamed
in place polyurethane. Each door shall have two
self-closing, cam-lift style hinges. Doors shall be easily
removable without use of tools. Door gaskets shall be
magnetic snap-in style to allow simple replacement.
Door handles shall be recessed.
• Please specify right or left hand hinging at time of
order.
Mechanical controls shall be located behind a
removable shroud facing.
Freezers: All components are mounted to the
exterior cabinet ceiling, outside the food zone and are
assembled as one piece and can be removed as one
piece. Environmentally friendly R404A refrigerant
is used. System has the capability of maintaining
between -5˚F and 0˚F in heavy use food service
operations. Refrigerant is metered using a highly
responsive thermostatic expansion valve. Evaporator
defrost is automatic using a time initiated, time/
temperature terminated system with electric heaters.
Evaporator condensate is eliminated using an energy
efficient hot gas system.
Single Voltage Models Only: Electrical connections
shall be 115 volt, 60 hertz, single phase, with an
eight ft. (2.4m) long electrical cord & plug as shown
on reference chart. Cord & plug shall be wired to the
junction box on top of the unit.
Dual Voltage Models Only: Electrical connections
shall be 115/208-230 volt, 60 hertz, single phase, and
must be hard-wired to the junction box located on top
of the unit.
MODELS:
 MFRN1-S Single section  MFR2N-S Two section
Full height door Full height doors
 MFRN1R-S Remote  MFR2NR-S Remote
 MFRN1-SH Single section  MFR2N-SH Two section freezer
Half height door Half height doors
 MFRN1R-SH Remote  MFR2NR-SH Remote
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to find, don’t intrude into
kitchen traffic
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with minimal
energy cost
• Exterior digital thermometer with high/low temperature
alarm
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Epoxy coated shelves—corrosion resistant, 300-lb. capacity.
Flexible placement on 1” centers allows maximum storage
• Aluminum interior stands up to food acids without
corroding
• Lots of interior storage space for the money
• Rugged metal legs, adjustable to compensate for
uneven floors
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Stainless steel kick plate
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 TXV
 Chrome Shelves
 Tray Slides
 220/50/1 electrical
 Electronic control
 Stainless steel legs
 Casters

Meridian Series®Solid Door Narrow Reach-In Freezers
Model #__________
CSI Section11400
Printed in the USA.
03/07
DSMRN_F
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
MECHANICAL DATA
SHELVES NO UNIT BTU/HR SHIP NEMA
MODEL VOLTAGE AMPS STORAGE SQ. FT. SHELVES H.P. SYSTEM CAP WEIGHT PLUG
FREEZERS
MFR1N-S 115 9.0 20.97 10.59 3 1/2 1516 376 5-15P
MFR1N-SH 115 9.0 20.97 10.59 3 1/2 1516 376 5-15P
MFR2N-S 115 14.9 43.94 23.10 6 3/4 3326 656 5-20P
MFR2N-SH 115 14.9 43.94 23.10 6 3/4 3326 656 5-20P
PLAN VIEW MFR1N-S PLAN VIEW MFR2N-S
ELEVATION VIEW MFR2N-S
ELEVATION VIEW MFR1N-S
DOOR CLEARANCE DETAIL
ALL MODELS
34”
86.36cm
25”
63.5cm 48”
121.9cm
81”
205.7cm
23.25”
69.0cm
34”
86.4cm
END SECTION VIEW
ALL MODELS
PERSPECTIVE VIEW
ALL MODELS
56.76”
144.2cm
12.14”
30.9cm
34.0”
86.4cm
16.02”
40.7cm
19.75”
50.2cm
23.75”
60.3cm
3.80”
9.7cm
26.48”
67.3cm
56.50”
143.5cm
21”
53.3cm 44”
111.8cm
6.00
15.2cm
Remote units supplied with: Evaporator coil, solenoid valve, expansion valve and temperature control. Condensing units to be sized and supplied with others.
REMOTE SHELVES NO UNIT BTU/HR SHIP NEMA
MODEL # VOLTAGE AMPS STORAGE SQ. FT. SHELVES H.P.* SYSTEM CAP WEIGHT PLUG
FREEZERS
MFR1NR-S 115 10.1 20.97 10.59 3 1/2 — 376 —
MFR1NR-SH 115 10.2 20.97 10.59 3 1/2 — 376 —
MFR2NR-S 115 9.0 43.94 23.10 6 3/4 — 656 —
MFR2NR-SH 115 9.2 43.94 23.10 6 3/4 — 656 —
*Recommended
MECHANICAL DETAIL
