MERIDIAN SERIES® GLASS DOOR PASS-THROUGH FREEZERS
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
MERIDIAN SERIES®
Glass Door Pass-Through Freezers
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
Approval _________________
Date____________________
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be aluminum. Facing
of shroud shall be easily removable without the use of
tools.
Cabinet interior shall be anodized aluminum. Bottom
& top of liner shall be die-stamped to provide
radius corners and a recessed bottom. Base shall be
fully insulated with high-density foamed in place
polyurethane.
Interior shall have three epoxy-coated wire shelves per
door section. Shelf support pilasters shall be heavy-duty
with shelves adjustable at 1.0” (2.5 cm) increments.
Units are mounted on 6” (15.24 cm) metal legs.
Doors: Unit is provided with hinged glass front door(s).
Doors on freezer units are constructed with double-pane
low-E, Argon filled tempered themopane glass. Glass
doors are constructed with a combination of extruded
aluminum & PVC, and are provided with magnetic
gaskets. Doors will have self-closing hinges and continuous
handle along vertical dimension of door(s). Glass door
constructed to eliminate need for heater wires.
• Please specify right or left hand hinging at time of order
Mechanical controls shall be located behind a removable
shroud facing.
Freezers: Refrigeration system shall use R404A
refrigerant. System shall be completely outside food zone
to maximize internal storage space. System shall utilize a
dual diversion high ow air distribution system, and shall be
a high capacity design. Evaporator coils shall have deep-
corrugated, staged n construction for maximum efciency
with fewer defrost cycles. Cabinet shall maintain 00F internal
temperature.
Single Voltage Models Only: Electrical connections
shall be 115 volt, 60 hertz, single phase, with an
eight ft. (2.4m) long electrical cord & plug as shown
on reference chart. Cord & plug shall be wired to the
junction box on top of the unit.
Dual Voltage Models Only: Electrical connections
shall be 115/208-230 volt, 60 hertz, single phase, and
must be hard-wired to the junction box located on top
of the unit.
MODELS:
 MFPT2R-G Single section
Full height doors
Remote only
 MFPT2R-GH Single section
Full height doors
Remote only
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to nd, don’t intrude into
kitchen trafc
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with
minimal energy cost
• Easy to read dial thermometer
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Epoxy coated shelves—corrosion resistant, 300-lb.
capacity. Flexible placement on 1” centers allows
maximum storage
• Aluminum interior stands up to food acids without
corroding
• Lots of interior storage space for the money
• Rugged metal legs, adjustable to compensate for
uneven oors
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Stainless steel kick plate
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 TXV
 Chrome Shelves
 Tray Slides
 220/50/1 electrical
 Electronic control
 Stainless steel legs
 Casters
MFPT2R-GH

MECHANICAL DATA
REMOTE SHELVES NO UNIT BTU/HR CAB BTU/HR SHIP NEMA
MODEL # VOLTAGE AMPS STORAGE SQ. FT. SHELVES H.P.* LOAD SYSTEM CAP WEIGHT PLUG
FREEZERS
MFPT2R-G 115 10.5 55.42 27.54 6 1 1/2* 4740 — 700 —
MFPT2R-GH 115 10.9 55.42 27.54 6 1 1/2* 4740 — 700 —
MFPT2R-GS 115 10.9 55.42 27.54 6 1 1/2* 4740 — 700 —
*Recommended
Meridian Series® Glass Door Pass-Through Freezers
Model #__________
CSI Section 11400
Printed in the USA.
08/03
DSMPTG_F
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
PLAN VIEW MFPT2R-G
ELEVATION VIEW MFPT2R-G
DOOR CLEARANCE DETAIL
ALL MODELS
56”
142.2cm
27.25”
69.22cm
36.25”
92.1cm
52”
132.1cm
END
SECTION VIEW
ALL MODELS
PERSPECTIVE VIEW
ALL MODELS
81”
205.7cm
6.00”
15.2cm
56.76”
144.2cm
12.14”
30.8cm
36.25”
92.1cm
26.48”
67.3cm
3.80”
9.7cm
Remote units supplied with: Evaporator coil, solenoid valve, expansion valve and temperature control. Condensing units to be sized and supplied with others.
J-BOX LOCATED
75" AFF FOR ST'D BOXES
83" AFF FOR RI/RT'S
8" (1) door units
11" (2&3) door units
6" (1) door units
23" (2) door units
39" (3) door units
Front of unit
MECHANICAL DETAIL
