Short Form Specifications
Top is constructed of one-piece 16-gauge stainless steel, with integral 2.12”
(5.4 cm) square nosing on front and 4” (10.1 cm) high by 2” (5.0 cm) thick
backsplash on rear. Top to be insulated and have raised rim opening(s) provid-
ed with cover. Cover(s) are insulated, folding and removable.
Interior is constructed of 22-gauge stainless steel. Liner is insulated with
2.5” (6.4 cm) foamed-in-place polyurethane. Unit has cold wall refrigera-
tion system provided with adjustable expansion valve and is designed to
maintain 0°F (-18°C) to 5°F (-15°C).
Exterior front has 22-gauge stainless steel front panel(s). Exterior ends are
constructed of 18-gauge galvanized steel. Unit has condensing unit on right
end of cabinet and is wired with cord and plug. Housing for condensing unit
has a louvered front panel. A low pressure control, with adjustment knob,
regulates temperature in cabinet.
Electrical connections are 115 volt, 60 Hertz, single phase.
Unit is mounted on 6.13” (15.6 cm) high adjustable stainless steel legs.
Optional Accessories and modifications
505B Stainless steel back
906A Stainless steel end
505F Laminate facing
505A Laminate back
906E Laminate end
717M Sink and dipperwell (consult factory)
717N Dipperwell
717O Sink (consult factory)
213 *220V/50 cycle electrical
*Inclusion of this option will alter
electrical specifications.
®
Built to NSF7 standards.
Model F13WC56
31.5”(80cm)DeepSelf-ContainedLowTemp,IceCreamCabinets
The Delfield Company, P.O. Box 470, Mt Pleasant, MI 48804-0470, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2001 The Delfield Company. All rights reserved. Printed in U.S.A.
PROJECT
ITEM #
QUANTITY DATE
APPROVAL
F13WC

Mechanical Data–Standard Unit
MODEL GALLON NUMBER OF VOLTS/HERTZ BTU DESIGN BTU SHIP
NUMBER CAPACITY COVERS H.P. PHASE AMPS LOAD SYS. CAP. WEIGHT
F13WC32
12 2 1/3 115/60/1 8.0 322 818 311 lbs/ 141 kg
F13WC44
24 4 1/3 115/60/1 8.0 506 983 380 lbs/ 173 kg
F13WC56
36 6 1/3 115/60/1 8.0 638 1073 408 lbs/ 185 kg
F13WC68
48 8 1/3 115/60/1 8.0 796 1160 475 lbs/ 216 kg
5-15P NEMA plug used on all lengths.
40"
(101.6)
31.5"
(81.6)
12.5"
(31.8)
LID DETAIL
ALL MODELS
SIDE VIEW
ALL MODELS
J
VEXPANSION VALVE IN BACK OF FRONT PANEL 12" A.F.F.
LEGEND
CONDENSING UNIT WIRED TO J-BOX 25"
A.F.F.. J-BOX TO HAVE ON/OFF SWITCH
AND 8' CORD AND PLUG ATTACHED,
REAR OF COMP. OPEN TO EXIT CORD
18" (15.7)
32" (81.3)
30" (76.2)
44" (111.8) 56" (142.2)
42" (106.7)
68" (172.7)
54" (137.2)
14"
(35.6)
PLAN
F13WC32
PLAN
F13WC44
PLAN
F13WC56
PLAN
F13WC68
ELEVATION
F13WC32
ELEVATION
F13WC44
ELEVATION
F13WC56
ELEVATION
F13WC68
14"
(35.6)
14"
(35.6)
14"
(35.6)
J
17"
(43.2)
44" (111.8)
32" (81.3)
56" (142.2)
68" (172.7)
V
6.12"
(15.6)
7.62"
(19.4)
21.31"
(54.1)
36"
(91.4)
23.75"
(60.3)
14.44"
(36.7cm)
31.5"
(80)
40"
(101.6)
F13WC
The Delfield Company, P.O. Box 470, Mt Pleasant, MI 48804-0470, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2001 The Delfield Company. All rights reserved. Printed in U.S.A.
DS13WC 01/01
31.5”(80cm)DeepSelf-ContainedLowTemp,IceCreamCabinets
