Delfield Enodis 400 Series User manual

Part Number: 9294486 06/17
International Work Top &
Undercounter Refrigerators & Freezers
Original Instructions
Installation, Operation and Maintenance Manual
This manual is updated as new information and models are released. Visit our website for the latest manual.

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
2
WARNING Read This Manual Thoroughly Before Operating, Installing, Or Performing Maintenance On The Equipment.
WARNING Failure To Follow Instructions In This Manual Can Cause Property Damage, Injury Or Death.
WARNING Do Not Store Or Use Gasoline Or Other Flammable Vapors Or Liquids In The Vicinity Of This Or Any Other
Appliance.
WARNING Unless All Cover And Access Panels Are In Place And Properly Secured, Do Not Operate This Equipment.
WARNING This Appliance Is Not Intended For Use By Persons Who Lack Experience Or Knowledge, Unless They Have
Been Given Supervision Or Instruction Concerning Use Of The Appliance By A Person Responsible For Their
Safety.
WARNING This Appliance Is Not To Be Played With.
WARNING Do Not Clean With Water Jet.
WARNING Do Not Use Electrical Appliances Inside The Food Storage Compartment Of This Appliance.
CAUTION Observe the following:
• Minimum clearances must be maintained from all walls and combustible materials.
• Keep the equipment area free and clear of combustible material.
• Allow adequate clearance for air openings.
• Operate equipment only on the type of electricity indicated on the specification plate.
• Unplug the unit before making any repairs.
• Retain this manual for future reference.
Important Warning And Safety Information

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
3
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
Serial Number Location................................................................. 3
Warranty Information ................................................................... 3
Regulatory Certifications............................................................... 3
Refrigeration Specifications........................................................... 4
Freezer Specifications.................................................................... 4
Installation..................................................................................... 5
Caster Or Leg Installation .............................................................. 6
Caster & Leg Mounting Detail ....................................................... 6
Refrigerator Temperature Control Operation................................ 7
Freezer Models 4148 Temperature Control Operation................. 7
Freezer Models 403 & 407 Temperature Control Operation ........ 8
Evaporator Fan Operation ............................................................. 8
Maintenance ............................................................................ 9-10
Refrigerator Wiring Diagram ....................................................... 11
Refrigerator Replacement Parts Lists .......................................... 12
Freezer Wiring Diagrams ........................................................ 13-14
Freezer Replacement Parts Lists.................................................. 15
Contents
The serial number on 400 and 4000 series refrigerators and
freezers is printed on the left interior side wall.
Always have the serial number of your unit available when
calling for parts or service. A complete list of authorized
Delfield parts depots is on www.delfield.com.
This manual covers standard units only. If you have a custom
unit, consult the customer service department at 1-800-733-
8829
Serial Number Location
Regulatory Certifications
Warranty Information

Naonal Sanitaon Foundaon (NSF)
European Conformity
Visit www.delfield.com/warranty to:
• Register your product for warranty.
• Verify warranty information.
• View and download a copy of your warranty.

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
4
Model Volume
Ft.3/L
Shelves
Ft.2/cm2H.P. R404A Charge
Global
Warming
Potential
V, Hz, Ph Amp Plug Ship
Weight
CO2
Equivalent
Work Top Refrigerator Bases With Stainless Steel Top & Backsplash
402-CE 5.7/161 4.6/4274 1/5 7.0oz
(198g) 3922 230-240, 50, 1 1.8 CEE 7/7 176lbs
(80kg) .778
ST4048-CE 10.80/306 8.0/7432 1/5 7.0oz
(198g) 3922 230-240, 50, 1 1.8 CEE 7/7 234lbs
(106kg) .778
Undercounter Refrigerator Bases With Stainless Steel Top
406-CE 5.7/161 4.6/4274 1/5 7.0oz
(198g) 3922 230-240, 50, 1 1.8 CEE 7/7 176lbs
(80kg) .778
UC4048-CE 10.80/306 8.0/7432 1/5 7.0oz
(198g) 3922 230-240, 50, 1 1.8 CEE 7/7 236lbs
(107kg) .778
Undercounter Refrigerator With Subtop And 3.75” Casters
406CA-CE 5.7/161 4.6/4274 1/5 7.0oz
(198g) 3922 230-240, 50, 1 1.8 CEE 7/7 168lbs
(76kg) .778
Refrigerator Specifications
Model Volume
Ft.3/L
Shelves
Ft.2/cm2H.P. R404A
Charge
Global
Warming
Potential
V, Hz, Ph Amp Plug Ship
Weight
CO2
Equivalent
Work Top Freezer Bases With Stainless Steel Top & Backsplash
403-CE 5.7/161 4.6/4274 1/5 6.5oz
(184g) 3922 230-240, 50, 1 2.1 CEE 7/7 184lbs
(83kg) .723
ST4148-CE 10.80/306 8.0/7432 1/3 9.5oz
(269g) 3922 230-240, 50, 1 4.7 CEE 7/7 242lbs
(110kg) 1.056
Undercounter Freezer Bases With Stainless Steel Top
407-CE 5.7/161 4.6/4274 1/5 6.5oz
(184g) 3922 230-240, 50, 1 2.1 CEE 7/7 176lbs
(80kg) .723
UC4148-CE 10.80/306 8.0/7432 1/3 9.5oz
(269g) 3922 230-240, 50, 1 4.7 CEE 7/7 236lbs
(107kg) 1.056
Undercounter Freezer With Subtop And 3.75” Casters
407CA-CE 5.7/161 4.6/4274 1/5 6.5oz
(184g) 3922 230-240, 50, 1 2.1 CEE 7/7 168lbs
(76kg) .723
Freezer Specifications

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
5
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
Location
Units represented in this manual are intended for indoor use
only. Be sure the location chosen has a floor strong enough to
support the total weight of the cabinet and contents. Reinforce
the floor as necessary to provide for maximum loading.
For the most efficient refrigeration, be sure to provide good air
circulation inside and out.
Inside cabinet: Do not pack refrigerator so full that air cannot
circulate.
Outside cabinet: Be sure that the unit has access to ample air.
On all 400 and 4000 Series equipment a minimum space of
3” (7.6cm) at the back of the unit and 1” (2.5cm) at the top
and sides is required to conform to Underwriters Laboratories’
standards. On undercounter units it is imperative that the
proper air flow be maintained. The refrigeration system is
designed so air will flow under the unit, over the compressor/
condenser area, and out at the top rear of the unit. Avoid hot
corners and locations near stoves and ovens.
Any restriction of the proper air flow outlined
above, total or partial, will void the warranty on
the unit.
Leveling
A level cabinet will perform better because the drain pan will
drain properly, the doors will line up with the frames and the
cabinet will not be subject to undue strain.
All four legs are adjustable. Adjust each leg until the unit is
stable and level left to right. If necessary adjusting the front legs
slightly higher than the rear by about 1/8” (0.3cm) will help the
door remain closed.
If the unit is supplied with casters, no adjustments are available.
Ensure the floor where the unit is to be located is level.
Never stand on the unit! Doing so may result in bodily
injury. They are not designed to hold the weight of an
adult and will collapse if misused in this manner.
Stabilizing
Some models are supplied on casters for your convenience, for
ease of cleaning underneath and mobility.
The unit must be installed in a stable condition with
the front wheels locked. Locking the front casters
after installation is the owner’s responsibility.
Plumbing
Self-contained models are standard with a condensate
evaporator. If, for some reason, a unit does not have a condensate
evaporator, or the evaporator fails, the unit’s drain must have an
outlet to an appropriate drainage area or container.
Moisture collecting from improper drainage can
create a slippery surface on the floor and a hazard to
employees. It is the owner’s responsibility to provide
a container or outlet for drainage.
Electrical connection
Refer to the amperage data on page 3, the serial tag, your
local code or the National Electrical Code to be sure the unit is
connected to the proper power source. A protected circuit of
the correct voltage and amperage must be run for connection of
the line cord, or permanent connection to the unit.
A 6’ (1.8 m) long grounded supply cord and plug are provided
with standard units. Simply plug the unit in to begin operation.
The thermostat must be turned to OFF and
the unit disconnected from the power source
whenever performing service, maintenance
functions or cleaning the refrigerated area.
Stacked 400 series electrical connection
Models 406 and 407 may be stacked using a stacking
collar, Delfield model 409. In this case two 6’ (1.8m) long
grounded supply cords and plugs are standard. Simply plug
them in to begin operation.
For Cord Connected Units - Risk of Electric Shock.
This equipment has two power supply cords.
Unplug all cords before moving or servicing this
equipment.
CAUTION
Installation
DANGER

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
6
2”, 3” and 5” Caster and Leg Mounting Detail
A universal bolt hole pattern is provided on the bottom of the cabinet. It will accommodate any leg or caster. Simply line up the
plate holes with the corresponding cabinet holes.
NOTE:
    
matches the one above mount in
inner set of holes.
2” Caster - 3234148
NOTE:
    
matches the one above mount in
middle set of holes.
3” Caster - 3234024
5” Caster - 3234161
6” Leg - 3234791
NOTE:
    
matches the one above mount
in outer set of holes.
6” Leg - 3234569
2.38”
6cm
3.40”
9cm
1.75”
4cm
2.82”
7cm
0.94”
2cm
2.14”
5cm
1. Carefully place the unit on its back (see illustration at right).
2. Located at each caster mounting location are 4 Phillips head
screws, for a total of 16 screws. Remove them.
3. Place a locking plate caster or leg over one of the front holes,
matching the 4 mounting holes to the pre-drilled holes in
the underside of the unit. Insert 4 Phillips head screws and
tighten. Repeat with the other locking front caster or leg.
4. Repeat step 3 with the non-locking casters or legs in the rear
of the unit.
5. Carefully lift the unit upright.
After installing casters or legs, the unit must stand
upright for twenty-four (24) hours before being
powered up to assure oil return to the compressor
sump.
Plate Casters
W/Locks
Plate Casters
W/O Locks
Screws
Plate caster installation, 400 & 4000 Series.
Caster Or Leg Installation - 400 & 4000 Series
WARNING

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
7
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
After the unit is connected to power it will automatically
begin operating. With the doors closed, the temperature
of the cabinet should reach 36°F to 40°F (2°C to 4°C) on
refrigerators in about one hour.
A thermostat located in the evaporator housing on interior
rear of the unit, controls the temperature in the box. The
factory setting for the control is “4” and maintains about
38°F (3°C) in the box. Set toward “1” for higher temperatures
and toward “7” for lower temperatures.
Continuous opening and closing of the doors will hamper the
unit’s ability to maintain optimum refrigeration temperature.
Refrigerators defrost automatically with every cycle of the
compressor. The water generated is routed to a pan on the
rear of the unit and is evaporated by the heat given off by
the compressor.
Service Alert
During normal operation the evaporator fan may cycle
and/or pulse independently of the compressor. Consult
the service manual or contact Technical Support at
1-800-733-8829 if you are unsure of the proper function.
Refrigerator Temperature Control Operation
Freezer Model 4148 Temperature Control Operation
After the unit is connected to power it will automatically
begin operating. With the doors closed, the temperature
of the cabinet should reach 0°F (-18°C) on freezers in about
one hour.
A thermostat located in the evaporator housing on interior
rear of the unit, controls the temperature in the box. The
factory setting for the control is “4” and maintains about -3°F
(-19°C) in the box. Set toward “1” for higher temperatures
and toward “7” for lower temperatures.
Continuous opening and closing of the doors will hamper the
unit’s ability to maintain optimum refrigeration temperature.
When the mechanical timer initiates a defrost cycle, power to
the condensing unit and evaporator fans is interrupted and
the defrost heater is energized. The defrost heater warms
the evaporator coil thereby melting all frost accumulated
during the previous refrigeration cycle. Once all frost is
eliminated, the temperature of the coil continues to rise
until it reaches 27 minutes. The defrost control switches to
refrigeration mode. Defrost will initiate every six hours.
Turn the defrost timer screw ONLY in a clockwise
direction, turning the screw counter-clockwise
will break the cam motor.
Service Alert
During normal operation the evaporator fan may cycle
and/or pulse independently of the compressor. Consult
the service manual or contact Technical Support at
1-800-733-8829 if you are unsure of the proper function.

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
8
Cooling Cycle Defrost Cycle
Compressor On  
Evap Fan
On
Evap Fan

Evap Fan
On
Evap Fan

Evap Fan
On
Evap Fan

400 Refrigerator X X X
400 Freezer X X X
4000 Refrigerator X X X
4000 Freezer X X X
Freezer Models 403 & 407 Temperature Control Operation
After the unit is connected to power it will automatically
begin operating. With the doors closed, the temperature
of the cabinet should reach 0°F (-18°C) on freezers in about
one hour. Continuous opening and closing of the doors will
hamper the unit’s ability to maintain optimum temperature.
The electronic temperature control constantly monitors
box temperature as well as evaporator coil temperature
to maintain consistent product temperatures. As an added
energy-saving feature, the electronic controller will switch
the evaporator fan motor on and off with the compressor
and condenser fan motor.
At initial start-up or anytime power is disconnected, then
reconnected to the unit, the control will delay all operations
for a short time (up to 10 minutes.) While in this delay
period, the control initializes the control parameters and
confirms that the temperature sensors and circuits are
operational.
Service Alert: During normal operation the evaporator fan
may cycle and/or pulse independently of the compressor.
Consult the service manual or contact Technical Support at
1-800-733-8829 if you are unsure of the proper function.
IMPORTANT NOTE REGARDING FREEZERS:
After initializing, the control will immediately enter a
DEFROST mode. The compressor and condenser fan as well
as the evaporator fan will remain off until initial defrost
is complete. This initial defrost cycle may take up to 15
minutes to complete, at which time the freezing cycle will
begin.
Whenever the freezer is plugged in, and the control has
completed initializing including the initial defrost cycle
(see above), the electronic temperature control will cycle
the compressor, evaporator fan motor, and condenser fan
motor to maintain box temperature at the control setting.
Freezer Automatic Defrost
The control also monitors compressor total running time
and will enter a defrost cycle after total compressor running
time is greater than 5-hours since the last defrost cycle OR
if evaporator coil temperature drops below -34°F (indicating
excessive frost on the coil).
Freezer Manual Defrost
If a manual defrost is desired, simply unplug the unit for
several seconds, then plug unit back in. This will cause the
control to re-initialize and then enter a defrost cycle.
When the control enters the defrost mode, whether manual
or automatic, it switches off the evaporator fan motor,
compressor and condenser fan motor, and switches on the
defrost heater to warm the evaporator coil and melt all frost
accumulated during the previous refrigeration cycle. The
control will continue the defrost cycle for a MINIMUM of 8
minutes and a MAXIMUM of 30 minutes depending on the
amount of frost accumulated on the evaporator coil.
After the defrost cycle is complete, the control returns
to a normal refrigeration cycle, however the evaporator
fan motor will not switch on for 2 minutes AFTER the
compressor and condenser fan motor have begun operating.
Electronic Temperature Control Location & Adjustment
Never turn the knob more than 1 dial number and always
allow 8 hours for temperature stabilization before making
any additional adjustments. The control is located in the
control box at the rear of the unit (see photo). It is
factory set at mid-range to maintain about -3°F (-18°C) box
temperature. To adjust for colder temperatures, turn the
knob clockwise. For warmer temperatures, turn the knob
counter-clockwise. Turn the knob fully counter-clockwise to
turn the refrigeration system off.
Evaporator Fan Operation

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
9
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
Never hose down interior or exterior of units
with water. This will void the warranty. Wipe
interior dry of any water accumulation.
The thermostat must be turned to OFF and
the unit disconnected from the power source
whenever performing service, maintenance
functions or cleaning the refrigerated area.
Refrigerators and Freezers
The interior and exterior can be cleaned using soap and
 
or a nonabrasive liquid cleaner. When cleaning the exterior,
always rub with the “grain” of the stainless steel to avoid

Do not use an abrasive cleaner because it will scratch the

and gaskets.
Cleaning the Condenser Coil
The condenser coil requires regular cleaning, recommended
           
that there is a large amount of debris and dust or grease

the condenser coil should be cleaned every 30 days.
If the build up on the coil consists of only light dust and debris
the condenser coil can be cleaned with a simple brush, heavier
dust build up may require a vacuum or even compressed air
to blow through the condenser coil.
If heavy grease is present there are de-greasing agents
       
condenser coils. The condenser coil may require a spray
with the de-greasing agent and then blown through with
compressed air.

      


       
compressor or cost to replace the compressor.
Never use a high pressure water wash for this cleaning
procedure as water can damage the electrical
components located near or at the condenser
coil.
     

and grease regularly. It is recommended that this be done

condenser is totally blocked in three months, the frequency
of cleaning should be increased. Clean the condenser
           
commercially available condenser cleaner may be required.
Stainless Steel Care and Cleaning
        
important steps need to be taken. First, we need to

contains 70-80% iron which will rust. It also contains 12-30%
        
steels surface which acts as a shield against corrosion. As


begin to breakdown the steel and begin to form rust of

        

NEVER USE STEEL PADS, WIRE BRUSHES OR
SCRAPERS!

cleaners. Any cleaner containing chlorides will damage the
         
commonly found in hard water, salts, and household and
industrial cleaners. If cleaners containing chlorides are
used be sure to rinse repeatedly and dry thoroughly upon


water. Extreme stains or grease should be cleaned with a

to rub with the grain of the steel. There are also stainless
steel cleaners available which can restore and preserve the

Early signs of stainless steel breakdown can consist of small
pits and cracks. If this has begun, clean thoroughly and start
         
passivity of the steel.
Never use an acid based cleaning soluon!
Many food products have an acidic content
which can deteriorate the nish. Be sure to
clean the stainless steel surfaces of ALL food
products. Common items include, tomatoes,
peppers and other vegetables.
If your freezer seems to vibrate excessively when the
compressor is running, loosen (but do not remove) the
bolts on the compressor. Semi hermec models should be
loosened before operang.
CAUTION
CAUTION
CAUTION
Maintenance
CAUTION

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
10
Gasket Maintenance
Gaskets require regular cleaning to prevent mold and mildew

cleaning can be done with the use of warm soapy water.
Avoid full strength cleaning products on gaskets as this can

never use sharp tools or knives to scrape or clean the gasket
which could possibly tear the gasket and rip the bellows.
Gaskets can easily be replaced and do not require the use of
tools or authorized service persons. The gaskets are “Dart”
style and can be pulled out of the grove in the door and new
gaskets can be “pressed” back into place.
Doors/Hinges

             

hinge brackets to the frame of the unit. If the doors are loose
or sagging this can cause the hinge to pull out of the frame
which may damage both the doors and the door hinges.
         
maintenance personnel.
If it becomes necessary to adjust a door, follow these

1. If the door needs lowering at the handle, use a 5/16”
wrench to loosen the hinge screws and install a spacer
        
screws.
2. If the door needs to be higher at the handle, use a 5/16”
wrench to loosen the hinge screws and install a spacer

Drain Maintenance
Each unit has a drain located inside the unit which removes

at an external condensate evaporator pan. Each drain can
become loose or disconnected from moving or bumping the
         
inside of the unit be sure the drain tube is connected from
the evaporator housing to the condensate evaporator drain
pan. If water is collected underneath the unit you may want
to check the condensate evaporator drain tube to be sure
            
unit is important as the units are designed to drain properly
            
also cause drain problems. Be sure all drain lines are free of
       

Service Alert
During normal operation the evaporator fan may cycle
and/or pulse independently of the compressor. Consult
the service manual or contact Technical Support at
1-800-733-8829 if you are unsure of the proper function.
Illustration 1:
spacer outside
Illustration 2:
spacer inside
Maintenance, continued

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
11
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
Refrigerator Wiring Diagram - 400 and 4000 Series
3) UNIT SHOWN WITH COMPRESSOR
RUNNING AND DOORS CLOSED
2) THIS UNIT MUST BE GROUNDED
1) USE COPPER CONDUCTORS ONLY
NOTES:
REVISIONS
RELEASE TO PRODUCTION1
REV DESCRIPTION
2/28/2012
DATE
L ENNIS
APPROVED
LABEL,WIRING,406/4048,230V/50HZ,CE
COVINGTON, TN
ENODIS
1
Reach-in Divison
REV.LOCATION
DIMENSIONS ARE IN INCHES
TOLERANCES
ALL PARTS TO BE DEBURRED AND EDGES
UNLESS OTHERWISE SPECIFIED
THIRD ANGLE
PROJECTION
The contents of this document are
PROPRIETARY TO THE DELFIELD COMPANY
and are not to be disclosed to others
intended without the written approval
or used for purposes other than
PROPRIETARY
of The Deleld Company.
MATERIAL
BROKEN .010 MAXIMUM.
ANG. ±
.XXX ±
.XX ±
.X ±
.010
1
.03
.1
C
DO NOT SCALE DRAWING
SCALE
CHECKED:
L ENNIS
DRAWN:
MFG:
QA:
PURCH:
SIGNATURE DATE
2/28/2012
DESCRIPTION
SIZE
9294483
SHEET
1 OF 1
DWG. NO.
LINE VOLTAGE
220V/50Hz/1Ph
SEE NAMEPLATE FOR MAXIMUM
FUSE SIZE
BLOCK
TERMINAL
COMPRESSOR
CONDENSOR FAN
M
EVAPORATOR FAN
TEMPERATURE
CONTROL
M
M
BROWN
BLUE
ORANGE
GRN-YEL
LNG

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
12
Refrigerator Replacement Parts List
402/406 Series Refrigerator, 230V/50Hz/1Ph
Part # Description
3234025 3” Caster, brake
3234024 3” Caster, no brake
3234160 5” Caster, no brake
3234161 5” Caster, brake
3234791 6” Leg
0074057 Capillary tube, .044” id x 144”
3526994 Compressor, 230-240V R404A
3516451 Compressor start capacitor
3516452 Compressor start relay
158-ATA-0050 Condensate coil, hot gas
149-AWM-0040 Condensate pan
3516275 Condenser coil
3516172 Condenser Fan Blade, 5.56”, CCW, Clear
3516173 Condenser fan guard
2162692 Condenser fan motor, 230-240V
000-B3I-0031 Door assembly, 27”, left hand
000-B3I-0032 Door assembly, 27”, right hand
1702623 Door gasket
3516116 Evaporator coil
3516172 Evaporator Fan Blade, 5.56”, CCW, Clear
3516173 Evaporator fan guard
2162692 Evaporator fan motor, 230-240V
3516321 Filter drier
 
3978271 Shelf
3235014 Shelf clip
2194759KT Temperature control
(includes control, knob and dial plate)
2194761 Temperature control knob only
3516135 Thermometer, hanging
4048 Series Refrigerator, 230V/50Hz/1Ph
Part # Descripon
3234025 3” Caster, brake
3234024 3” Caster, no brake
3234160 5” Caster, no brake
3234161 5” Caster, brake
3234791 6” Leg
0074057 Capillary tube, .044 id x 144”
3526994 Compressor, 230-240V R404A
3516451 Compressor start capacitor
3516452 Compressor start relay
158-ATA-0050 Condensate coil, hot gas
149-AWM-0040 Condensate pan
3516275 Condenser coil
3516172 Condenser Fan Blade, 5.56”, CCW, Clear
3516173 Condenser fan guard
2162692 Condenser fan motor, 230-240V
 
000-B3I-0034 Door assembly, 24”, right hand
1702622 Door gasket
3516116 Evaporator coil
3516172 Evaporator Fan Blade, 5.56”, CCW, Clear
3516173 Evaporator fan guard
2162692 Evaporator fan motor, 230-240V
3516321 Filter drier
 
3978272 Shelf
2194759KT Temp control
(includes control, knob and dial plate)
2194761 Temperature control knob only

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
13
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
Freezer Wiring Diagram - 400 Series
3) UNIT SHOWN WITH COMPRESSOR
RUNNING AND DOORS CLOSED
2) THIS UNIT MUST BE GROUNDED
1) USE COPPER CONDUCTORS ONLY
NOTES:
CONDENSOR FAN
DEFROST
EVAPORATOR FAN
HEATER RELAY
1.1,2,3 2.1,2,3 3.1,2,3
COMPRESSOR
RELAY
CONTROL
TEMPERATURE
LED DISPLAY
(IF USED)
3
L
EVAP COIL
SENSOR
SENSOR
CABINET AIR
1
C
FAN RELAY
CIRCUIT
CONTROL
4
H
6
F
5
N
COMPRESSOR
M
M
M
HI-LIMIT HEATER
REVISIONS
RELEASE TO PRODUCTION1
REV DESCRIPTION
2/28/2012
DATE
L ENNIS
APPROVED
LABEL,WIRING,400 FRZ,230V/50HZ,CE
COVINGTON, TN
ENODIS
1
Reach-in Divison
RE V.LOCATION
DIMENSIONS ARE IN INCHES
TOLERANCES
ALL PARTS TO BE DEBURRED AND EDGES
UNLESS OTHERWISE SPECIFIED
THIRD ANGLE
PROJECTION
The contents of this document are
PROPRIETARY TO THE DELFIELD COMPANY
and are not to be disclosed to others
intended without the written approval
or used for purposes other than
PROPRIETARY
of The Deleld Company.
MATERIAL
BROKEN .010 MAXIMUM.
ANG. ±
.XXX ±
.XX ±
.X ±
.010
1
.03
.1
C
DO NOT SCALE DRAWING
SCALE
CHECKED:
L ENNIS
DRAWN:
MFG:
QA:
PURCH:
SIGNATURE DATE
2/28/2012
DESCRIPTION
SIZE
9294484
SHEET
1 OF 1
DWG. NO.
LINE VOLTAGE
220V/50Hz/1Ph
SEE NAMEPLATE FOR MAXIMUM
FUSE SIZE
BLOCK
TERMINAL
BROWN
L G
GRN-YEL
BLUE
N
YELLOW
ORANGE
VIOLET

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
14
Freezer Wiring Diagram - 4100 Series

International Work Top & Undercounter Refrigerators & Freezers Original User Manual
15
For customer service, call [phone], [phone], Fax [phone], www.deleld.com
Freezer Replacement Parts List
403/407 Series Freezer, 230V/50Hz/1Ph
Part # Descripon
3234025 3” Caster, brake
3234024 3” Caster, no brake
3234160 5” Caster, no brake
3234161 5” Caster, brake
3234791 6” Leg
0074058 Capillary tube, .036 id x 168”
3527013 Compressor, 220-240V, R-404a
2194820 Compressor relay
2194821 Compressor start capacitor
158-ATA-0050 Condensate coil, hot gas
149-AWM-0040 Condensate pan
3516275 Condenser coil
3516172 Condenser Fan Blade, 5.56”, CCW, Clear
3516173 Condenser fan guard
2162692 Condenser fan motor. 230V
000-CZ0-004GKT-S Control, Frz, 230V, 407, Kit
2198633 Defrost heater
000-B3I-0031 Door assembly, 27”, left hand
000-B3I-0032 Door assembly, 27”, right hand
1702623 Door gasket
3516418 Evaporator Coil
3516172 Evaporator Fan Blade, 5.56”, CCW, Clear
3516173 Evaporator fan guard
2162692 Evaporator fan motor, 230V
3516321 Filter Drier
3978055 Heater guard, 18”
 
3978271 Shelf
3235014 Shelf clip
4148 Series Freezer, 230V/50Hz/1Ph
Part # Descripon
3234025 3” Caster, brake
3234024 3” Caster, no brake
3234160 5” Caster, no brake
3234161 5” Caster, brake
3234791 6” Leg
000-CIN-0127 Capillary tube (.042 id x 120”)
3527011 Compressor
2162755 Compressor start capacitor
2184822 Compressor start relay
158-ATA-0050 Condensate coil, hot gas
149-AWM-0040 Condensate pan
3516276 Condenser coil
3516172 Condenser Fan Blade, 5.56”, CCW, Clear
2162719 Condenser fan motor
2194688 Defrost heater
 
 
000-B3I-0034 Door, 24” right hand
1702622 Door gasket
3516418 Evaporator coil
3517356 Evaporator fan blade, black
3516173 Evaporator fan guard
2162692 Evaporator fan motor
3516321 Filter drier
3978055 Heater guard, 18”
 
3978272 Shelf
3516043 Thermostat, Mechanical, Freezer


Part Number: 9294486 06/17
DELFIELD
980 SOUTH ISABELLA ROAD, MOUNT PLEASANT, MI 48858

WWW.DELFIELD.COM
Welbilt provides the world’s top chefs, and premier chain operators or growing independents with industry leading equipment and solutions.
Our cutting-edge designs and lean manufacturing tactics are powered by deep knowledge, operator insights, and culinary expertise.
All of our products are backed by KitchenCare® – our aftermarket, repair, and parts service.
CLEVELAND
CONVOTHERM®
DELFIELD®
FITKITCHEN™
FRYMASTER®
GARLAND
KOLPAK®
LINCOLN
MANITOWOC®
MERCO®
MERRYCHEF®
MULTIPLEX®
WWW.WELBILT.COM
