MERIDIAN SERIES®GLASS DOOR ROLL-IN REFRIGERATORS
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
MERIDIAN SERIES®
Glass Door Roll-In Refrigerators
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: 800-733-8948
Fax: 800-669-0619
Email: info@delfield.com
Approval _________________
Date____________________
MRRI2-G
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be aluminum. Facing
of shroud shall be easily removable without the use of
tools.
Cabinet interior shall be anodized aluminum. Bottom
& top of liner shall be die-stamped to provide radius
corners and a recessed bottom. Cabinet shall be
fully insulated with high-density foamed in place
polyurethane.
Doors: Unit is provided with hinged glass front door(s).
Doors on refrigerated units are constructed with double-
pane tempered thermopane glass. Glass doors are
constructed with a combination of extruded aluminum
& PVC, and are provided with magnetic gaskets. Doors
will have self-closing hinges and continuous handle
along vertical dimension of door(s). Glass door
constructed to eliminate need for heater wires.
• Please specify right or left hand hinging at time of order.
Mechanical controls shall be located behind a removable
shroud facing.
Refrigeration: All components are mounted to the
exterior cabinet ceiling, outside the food zone and are
assembled as one piece and can be removed as one piece.
Environmentally friendly R404A refrigerant is used.
System has the capability of maintaining between 27˚F and
40˚F in heavy use food service operations. Refrigerant is
metered using a highly responsive thermostatic expansion
valve. System is controlled using Delfield’s ACT-Advanced
Control Technology electronic temperature control, which
provides improved pull down times, reducing compressor
cycling and longer compressor life with lower energy
consumption.
Control system uses adaptive defrost to assure evaporator
coil is free of ice and operating at optimum efficiency.
Evaporator condensate is eliminated using an energy
efficient hot gas system.
Single Voltage Models Only: Electrical connections shall
be 115 volt, 60 hertz, single phase. Self contained models
have a ten foot (3m) long electrical cord and plug as shown
on the reference chart. Cord and plug shall be wired to the
junction box on top of the unit.
Dual Voltage Models Only: Electrical connections shall
be 115/208-230 volt, 60 hertz, single phase and must be
hard wired to the junction box located on top of the unit.
Notes: Bottom to be reinforced with 14-gauge channels.
All units to be supplied with easily – attachable 16-gauge
stainless steel ramps, one per door opening. Wiper gasket
shall be provided on bottom of door for seal to ramp.
MODELS:
 MRRI1-G Single section  MRRI2-G Two section  MRRI3-G Three section
Glass full height door Glass full height doors Glass full height doors
 MRRI1R-G Remote  MRRI2R-G Remote  MRRI3R-G Remote
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to find, don’t intrude into
kitchen traffic
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with minimal
energy cost
• Exterior digital thermometer with high/low temperature
alarm
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Aluminum interior stands up to food acids without corroding
• Lots of interior storage space for the money
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 TXV
 220/50/1 electrical
 Electronic control
Meridian Series®Glass Door Roll-In Refrigerators
Model #__________
CSI Section 11400
Printed in the USA.
03/07
DSMRLG_R
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: 800-733-8948
Fax: 800-669-0619
Email: info@delfield.com
MECHANICAL DATA
CU. FT. SHELVES # of RACK UNIT BTU/HR SHIP NEMA
MODEL VOLTAGE AMPS STORAGE SQ. FT. SHELVES CAP. H.P. SYSTEM CAP WEIGHT PLUG
REFRIGERATORS
MRRI1-G 115 7.0 36.15 NA NA 1 1/3 2488 467 5-15P
MRRI2-G 115 12.0 74.72 NA NA 2 1/2 4046 698 5-15P
MRRI3-G 115/208-230 14.0 113.28 NA NA 3 3/4 7569 771 —
PLAN VIEW MRRI1-G PLAN VIEW MRRI2-G PLAN VIEW MRRI3-G
34”
86.4cm
34”
86.4cm
34”
86.4cm
66”
167.7cm
34”
86.4cm
98”
248.9cm
ELEVATION VIEW MRRI3-GELEVATION VIEW MRRI2-GELEVATION VIEW MRRI1-G
DOOR CLEARANCE DETAIL
ALL MODELS
32.25”
81.9cm
END SECTION VIEW
ALL MODELS
89
226.1cm
89”
226.1cm
12.14”
30.8cm
73.28”
186.1cm
34”
86.4cm
70.75”
179.1cm
28.20”
71.6cm
PERSPECTIVE VIEW
ALL MODELS
29.12”
74cm
Ramp Width
3.80”
9.7cm
29.75”
75.6cm
37.68”
95.7cm
REMOTE CU. FT. SHELVES # of RACK UNIT BTU/HR SHIP NEMA
MODEL VOLTAGE AMPS STORAGE SQ. FT. SHELVES CAP. H.P.* SYSTEM CAP WEIGHT PLUG
REFRIGERATORS
MRRI1R-G 115 3.2 36.15 NA NA 1 1/3 — 467 —
MRRI2R-G 115 4.8 74.72 NA NA 2 1/2 — 698 —
MRRI3R-G 115 5.6 113.28 NA NA 3 3/4 — 771 —
*Recommended
Remote units supplied with: Evaporator coil, solenoid valve, expansion valve and temperature control. Condensing units to be sized and supplied with others.
MECHANICAL DETAIL
Ramp dimensions
see below
5.92”
15.04cm
1.06”
2.69cm
RAMP DIMENSIONS
(Not to scale)

This manual suits for next models

5
