Drop-Ins

Drop-Ins
Drop-in product solutions
Delfi eld’s large variety of drop-in products is the best in the market. All models are stocked standard for quick
shipment or can be customized with available options to suit your needs. Whether for planned projects or un-
foreseen replacement needs, Delfi eld is ready to provide a solution. Each model can be ordered as individual
component or as part of Component Crafted Custom or Shelley Mobile Counters.
Safety:
UL and NSF
All Delfi eld Drop-in products are UL approved and NSF
certifi ed. Which means you can count on safe, consistent
construction and performance every time.
Convenience:
Delfi eld Drop-in products are easy to install into any new
or existing counter. A press fi t gasket comes pre-installed
making the units ready to drop-in immediately.
Quality:
Delfi eld Drop-in products have an unmatched level of
quality. The units are reliably built by the best in the in-
dustry and come standard with a 90-day labor and 1-year
parts warranty.
Construction:
Delfi eld Drop-in products are constructed with stainless steel tops and interiors. Cold
units are insulated with high-density polyurethane foam and hot units are insulated with
fi berglass.
Refrigeration lines are secured to the liner with stainless steel spot clips and thermal
transfer compound is applied to improve heat transfer and cool the food product better.
N8100B N8000 8100-EF N8100-FA N8200G

N8100B 8100-EF
Delfi eld’s standard cold pans are built to suit your
needs. Superb operation and construction combine to
give you what you need, safe product temperatures.
LiquiTec® is better than the average cold pan!
Traditional cold pans are ineffi cient due to lack of contact
between the refrigeration lines and the interior liner
side. LiquiTec® takes what is usually on about 1/16”
contact per wrap and magnifi es it to 100% contact on
all 5 sides of the interior liner. An eutectic fl uid is used
to completely surround the interior liner of the pan. The
fl uid is harmless and sealed in by a stainless steel exterior
liner. The result is improved cooling ability that allows the
unit to have fl ush mount pans and still maintain NSF-7
certifi ed temperatures.
N8000
Mechanically Cooled Cold Pans
• Integral “V” shaped pan rest: no thumbscrews,
clips or hard to clean messes.
• Insulated with high density polyurethane foam.
• Pre-installed press fi t fl ange gasket for easy
installation into counters.
• HFC-134 refrigerant.
• Stainless steel louver is provided.
• Adapter bars for 12”x20” pans included.
• 1” drain provided.
• NSF-7 certifi ed.
• Thermostat control with OFF position.
• 8’ cord with plug is standard.
Ice Cooled Cold Pans
• Integral “V” shaped pan rest: no thumbscrews,
clips or hard to clean messes.
• Insulated with high density polyurethane foam.
• Pre-installed press fi t fl ange gasket for easy
installation into counters.
• Adapter bars for 12”x20” pans included.
• 1” drain provided.
• Perforated false bottom is standard.
• NSF-2 certifi ed.
LiquiTec® Cold Pans
• NSF-7 certifi ed fl ush mount design.
• Insulated with high density polyurethane foam.
• Preinstalled press fi t fl ange gasket for easy
installation into counters.
• HFC-404A refrigerant.
• Stainless steel louver provided.
• 12”x20” pan confi gurations.
• 1” drain provided.
• Thermostat control with OFF position.
• Better Merchandising
• Better Ergonomics
• Better Labor Effi ciency
• Better Energy Effi ciency
• Better Food Retention
100%
cold contact
<2mm
cold contact
LiquiTec® Pan
Traditional Wrap Pan
100%
cold contact
<2mm
cold contact

N8100-FA N8200G
The N8100-FA cold pans are ideal for merchan-
dising your product. The fl ush mount air-screen
design keeps your product cool and in view of
your customers.
Delfi eld frost tops are ideal for product presen-
tation while maintaining product temperatures.
Whether the granite or stainless steel tops are
desired, these units will help merchandise your
quick turn products.
Forced-Air Cold Pans
• Merchandise product in fl ush mount pans.
• Air screen over pans for NSF-7 certifi ed
temperatures.
• Air curtain assembley is easily removable
without tools for cleaning.
• Insulated with high density polyurethane foam.
• Pre-installed press fi t fl ange gasket for easy
installation into counters.
• 1” drain provided.
• HFC-404A refrigerant.
• Stainless steel louver is provided.
• Adapter bars for 12”x20” pans included.
Granite Frost Top
• “Absolute Black” granite top.
• Insulated with high density polyurethane foam.
• Drain trough around perimeter of top with
3/4” stainless steel drain.
• HFC-404A refrigerant.
• Stainless steel louver provided.
• On/Off switch.
• NSF-2 certifi ed.
N8200
Frost Top
• Insulated with high density polyurethane foam.
• 1” raised top with slope to drain trough.
• Drain trough around perimeter of top with 1/2”
stainless steel drain.
• Preinstalled press fi t fl ange gasket for easy
installation into counters.
• HFC-404A refrigerant.
• Stainless steel louver provided.
• On/Off switch.
• NSF-2 certifi ed.

N8600 N8700-D
At the flip of a switch it’s two units in one! The
N8600 Hot and Cold Combination models provide
the needed functionality of both hot and cold
operations without having to add additional space to
your operation. The unit may be utilized in different
operations throughout the day or week as the menu
dictates. When flexibility is a concern, this is the unit
for the job
Delfield offers both individual well and single
tank models to suit your operation. Heavy duty
construction and easy installation make a nice
combination for any counter.
Hot and Cold Combination Pan
• NSF-4 and NSF-7 certified.
• 2 units in one, hot and cold operation.
• Insulated with high density polyurethane foam.
• Flush mount design for hot operation or recess
2” for cold operation.
• Single tank well with stainless steel immersion
heater(s).
• HFC-404A refrigerant.
• Preinstalled press fit flange gasket for easy
installation into counters.
• Remote control box with thermostat for hot
operation, indicator light and a 3-way power
switch for operation selection.
• Thermostat for cold operation is mounted next
to the compressor section.
Individual Well Hot Pans
• NSF-4 certified.
• Flush mount individual 12”x20” wells.
• Fiberglass insulation.
• 1/2” stainless steel drain with manifold and gate
valve.
• Preinstalled press fit flange gasket for easy
installation into counters.
• Remote panel with individual temperature
controls for each well.
• Utilize for wet or dry operation.
N8800
Open Well Hot Pans
• NSF-4 certified.
• Fiberglass insulation.
• 1/2” stainless steel drain.
• Preinstalled press fit flange gasket for easy
installation into counters.
• Remote thermostat control for mounting in
counter.
• Single tank with 12”x20” openings.
• Utilize for wet or dry operation.

N225/N227 F5
Delfield’s N225 and N227 models make serving
ice cream cool! These units make adding ice
cream to any menu possible.
The F5 Serview display case can be used to
merchandise everything from drinks to desserts.
Whether in the back counter for full service
operation or front counter for self-service
operation, the product is in your customer’s
sight.
Ice Cream Cabinets
• NSF-7 certified.
• Preinstalled press fit flange gasket for easy
installation into counters.
• Insulated with high density polyurethane foam.
• Thermostat temperature control.
200/300
Water and Ice Stations
• Glass and pitcher fillers.
• Ice chests.
• Combination units.
Serview Display Cases
• NSF-7 certified.
• Insulated with high density polyurethane foam.
• Thermostat temperature control.
• Sliding glass doors.
• See-through back, mirrored back and pass-thru
models available.
• Interior light with exterior mounted On/Off switch.
• Several dish dispenser, cup dispenser and tray
dispenser models available.
• Dish dispensers available as heated or non-heated.
Shelleymatic
Dispensers

Options
Drop-in units can be customized to suit your needs! Everything from custom counter
protectors to custom pan sizes are available. Let us know what your requirements are and we’ll
provide the solution.
Options for Drop-Ins
Additional adaptor bars
or plates.
Single and double service
sneezeguards.
Custom counter
protectors.
220V/50C electrical.
Mullion fan assembly.
Extended warranties.
Remote refrigeration or
relocate the compressor.
Add/omit drains,
manifolds and valves.
Custom sizes.
N8600 N8700-D N225/N227 F5 Shelleymatic








              







 

REACH-INS / PREP TABLES / SHELLEY® SERVING COUNTERS / DROP-INS / COMPONENT CRAFTED EQUIPMENT
PHONE: [phone] / FAX: [phone] / WEB: WWW.DELFIELD.COM
Mechanically Cooled Cold Pan Cutout Size
N8118B 17" X 25"
N8130B 29.75 X25"
N8143B 42.50 X 25"
N8156B 55.25 X 25"
N8169B 68" X 25"
N8181B 80.75" X 25"
Mechanically Cooled Narrow Cold Pan Cutout Size
N8146NB 45.75" X 17"
N8168NB 66.5" 17"
Ice Cooled Cold Pan Cutout Size
N8018 17" X 25"
N8030 29.75 X25"
N8043 42.50 X 25"
N8056 55.25 X 25"
N8069 68" X 25"
N8081 80.75" X 25"
Ice Cooled Narrow Cold Pan Cutout Size
N8046N 45.75" X 17"
N8068N 66.5" 17"
Forced-Air Cold Pan Cutout Size
N8131-FA 30.25" X 25.5"
N8144-FA 43" X 25.5"
N8157-FA 55.75" X 25.5"
N8169-FA 68.5" X 25.5"
N8182-FA 81.25" X 25.5"
LiquiTec Mechanically Cooled Cold Pan Cutout Size
8118-EF 17" X 25"
8132-EF 30.75" X 25"
8145-EF 44.25" X 25"
8159-EF 57.87" X 25"
8172-EF 71.5" X 25"
8186-EF 85" X 25"
DBDROPINS
04/06
LiquiTec Mechanically Cooled Narrow
Cold Pan
Cutout Size
8148-EFN 46.88" X 17.25"
8169-EFN 68.5" X 17.25"
8191-EFN 90" X 17.25"
Granite Frost Top Cutout Size
N8231G 30.75" X 25"
N8245G 44.63" X 25"
N8259G 58.5" X 25"
N8273G 72.38" X 25"
Stainless Steel Frost Top Cutout Size
N8231 30.75" X 25"
N8245 44.63" X 25"
N8259 58.5" X 25"
N8273 72.38" X 25"
N8287 86.25" X 25"
Combination Hot/Cold Food Well Cutout Size
N8630 29.75 X25"
N8643 42.50 X 25"
N8656 55.25 X 25"
N8669 68" X 25"
N8681 80.75" X 25"
Individually Heated Food Wells Cutout Size
N8717-D 16.88" X 25"
N8731-D 30.75" X 25"
N8745-D 44.62" X 25"
N8759-D 58.5" X 25"
N8773-D 72.37" 25"
N8787-D 86.25" X 25"
Individually Heated Narrow Food Wells Cutout Size
N8746N 44.62" X 15"
N8768N 66.5" X 15"
Single Tank Heated Food Well Cutout Size
N8831 30.75" X 25"
N8845 44.63" X 25"
N8859 58.5" X 25"
N8873 72.38" X 25"
N8887 86.25" X 25"
Ice Cream Freezers with S/S Lid Cutout Size
N225 26.37" X 15.37"
N227 26.37" X 28.56"
Ice Cream Freezers with Lexan Lid Cutout Size
225L 26.37" X 15.37"
227L 26.37" X 28.56"
200/300 Ice & Water Stations Cutout Size
See specs for details
F5 Display Cases Cutout Size
See specs for details
ShelleyMatic Cutout Size
See specs for details
