Delfield SADBR1-SH User manual

SPECIFICATION LINE: SOLID DOOR SINGLE SECTION DUAL TEMP REFRIGERATOR/FREEZER REACH-INS
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
SPECIFICATION LINE
Solid Door Single Section Dual Temp Refrigerator/Freezer
Reach-Ins
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfi eld.com
Phone: [phone]
Fax: [phone]
Email: info@delfi eld.com
Approval _________________
Date ____________________
SPECIFICATIONS
Exterior: Top and bottom are constructed of
heavy gauge galvinized steel. Sides and upper
shroud are heavy gauge stainless steel.
Interior: Liner is heavy gauge, corrosion
resistant, stainless steel (SS) or heavy gauge
aluminum (SA models). Two wire shelves per
section are supported by stainless steel shelf clips
which are placed in stainless steel pilasters and
are adjustable on 1” centers. Shelves are rated
at 250lb. load capacity each.
Doors: Unit is provided with two half height
hinged doors. Doors are provided with locks;
magnetic door gasket, easily removable without
tools; cam lift, self closing, edge mount door
hinges.
Refrigeration Systems: Each compartment has
its own separate refrigeration system. Condensing
units are located on top of the cabinet, outside the
food zone, behind the removable upper shroud.
Evaporator coils are located inside the cabinet
mounted to the interior ceiling of each compartment.
Defrost is automatic. Condensate travels down a
tube in the cabinet side wall to a recepticle mounted
to the exterior bottom of the cabinet where it
evaporates with the aid of an electric heater. Each
compartment’s temperature is individually monitored
and controlled. Two exterior digital themometers
monitor temperature. Refrigerator compartment
maintains temperature between 33˚F and 41˚F.
Freezer compartment maintains temperature between
+0˚F and -5˚F.
Miscellaneous: Unit comes with one 10’ cord
and plug with single point connection to all
cabinet and refrigeration system electronics. Each
compartment is illuminated by a door switch
activated, 25 watt, incondescent light mounted to
the interior ceiling. Unit comes standard with four,
adjustable stainless steel legs, mounted in the fi eld.
Unit is standard with a two year parts, two year
labor warranty and additional three year parts
warranty only on the compressor part.
MODELS
❑ SSDTR1-SH Refrigerator top/freezer bottom, stainless interior
❑ SADTR1-SH Refrigerator top/freezer bottom, aluminum interior
❑ SSDBR1-SH Freezer top/refrigerator bottom, stainless interior
❑ SADBR1-SH Freezer top/refrigerator bottom, aluminum interior
STANDARD FEATURES
• Stainless steel exterior and interior (SS)
• Tri-seal door gaskets
• Stainless steel exterior, aluminum interior (SA)
• Chrome plated shelves - two per section
• Two seperate, top mounted condensing units, one for
each compartment
• Interior, ceiling mounted evaporator coil in each
compartment
• Automatic condensate removal
• High density polyurethane foam insulation
• Heavy duty hinges with stay open feature
• Easy to read exterior digital themometers
• Built in door locks with heavy duty strikes
• Recessed door handles
• Easy access “fl ip up” shroud
• Tough ABS interior door liners
• 6” adjustable stainless steel legs
• Stainless steel breaker strips
• Two year parts & labor warranty
OPTIONS AND ACCESSORIES
❑ Laminate ends
❑ Laminate doors & shroud
❑ Extra shelves
❑ Stainless steel wall trim
❑ Security package
❑ 220-50-1 electrical
❑ 220-60-1 electrical
❑ Casters
❑ Tray slides
❑ One glass door/one solid door confi guration
❑ Stainless steel door liner
❑ Bottom mount electrical
❑ Heat shield end
❑ Stainless steel back
SDBR1-SH









 


 











SPECIFICATION LINE: Solid door single section dual temp refrigerator/freezer reach-ins
Model #__________
CSI Section 11400
Printed in the USA.
09/05
DSSSD1SH
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice.
Mechanical Data
MODEL
NUMBER
VOLTAGE AMPS STORAGE
CAPACITY
NUMBER OF
SHELVES
H.P. BTU CABINET BTU SYSTEM SHIP WEIGHT NEMA PLUG
SSDTR1-SH/SADTR1-SH
Refrigerator 115/60/1 14 11.52ft32 1/5 455 1543 545 lbs. 5-20-P
Freezer 115/60/1 Total 11.52ft32 1/3 744 1260 Total
SSDBR1-SH/SADBR1-SH
Freezer 115/60/1 14 11.52ft32 1/3 744 1260 545 lbs. 5-20-P
Refrigerator 115/60/1 Total 11.52ft32 1/5 455 1543 Total
14
Total
14
Total
545 lbs.
Total
545 lbs.
Total 5-20P
5-20P
ELEVATION VIEW
PLAN VIEW
END SECTION VIEW








  
