Dell Alienware Aurora R15 User manual

Alienware Aurora R15
Antenna Installation Guide
Regulatory Model: D30M
Regulatory Type: D30M004
October 2022
Rev. A00

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2022 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its subsidiaries.
Other trademarks may be trademarks of their respective owners.

Contents
Chapter 1: Before working inside your computer...................................................................................4
Chapter 2: Antenna.................................................................................................................................. 5
Chapter 3: Antenna placement................................................................................................................ 6
Chapter 4: SMA antenna-cable............................................................................................................... 7
Chapter 5: Getting help and contacting Alienware................................................................................8
3

Before working inside your computer
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
1. Save and close all open files and exit all open applications.
2. Shut down your computer. Click Start > Power > Shut down.
NOTE: If you are using a different operating system, see the documentation of your operating system for shut-down
instructions.
3. Disconnect your computer and all attached devices from their electrical outlets.
4. Disconnect all attached network devices and peripherals, such as keyboard, mouse, and monitor from your computer.
CAUTION: To disconnect a network cable, first unplug the cable from your computer and then unplug the cable from
the network device.
5. Remove any media card and optical disc from your computer, if applicable.
4

Antenna
1. Follow the procedure in Before working inside your computer.
2. Align and connect the antenna cables to the SMA connectors on the chassis.
3. Tighten the bolts to secure the antenna cables to the SMA connectors on the chassis.
5

Antenna placement
Place the antenna in a suitable location.
6

SMA antenna-cable
For more information about the SMA antenna-cable removal and installation procedures, see Service Manual at Dell.com/support.
