Dell OptiPlex 780-USFF User manual

TECHNICAL GUIDEBOOK
INSIDE THE OPTIPLEX 780
TM
TM
DELL
OPTIPLEX 780

OVERVIEW
Mini Tower Computer (MT) View 3
Desktop Computer (DT) View 4
Small Form Factor Computer (SFF) View 5
Ultra Small Form Factor Computer (USFF) View 6
M ARKET IN G SY S TE M CO N FI G UR AT IO N S
Operating System, Chipset 7
Processor 8
Advanced System Manageability Modes, Memory 9
Drives and Removable Storage, System Board Connectors 10-11
Graphics/Video Controller 12
External Ports/Connectors 12
Communications—Network Adapter (NIC), Modem 13
Audio and Speakers, Keyboard and Mouse 13
Security, Service and Support, Software 14
DETA IL E D E N G I N E ERING SPE C I F I C A TIO N S
System Dimensions (Physical) 15
System Board Connector Maximum Allowable Dimensions 15
System Level Environmental and Operating Conditions 16
Power 17
Audio 18
Communications 18-22
Graphics/Video Controller 23-26
Hard Drives 27-39
Optical Drive 40-42
BIOS Defaults 43-44
Chassis Enclosure and Ventilation Requirements 45
Acoustic Noise Emission Information 46-49
TABLE OF CONTENTS

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
3
FRONT VIEW
1 Optical Drive (optional) 7 Power Button, Power
Light
2 Optical Drive Eject Button 8 Diagnostic Lights (4)
3 Optical Drive Bay 9 Headphone Connector
4 Media Card Reader
(optional)
10 Microphone Connector
5 USB 2.0 Connectors (2) 11 Network Connectivity
Light
6 Hard Drive Activity Light
BACK VIEW
1 Power Connector 4 Power-Supply Vent
2 Back-Panel Connectors 5 Chassis Lock Loop
3 Expansion Card Slots (4) 6 Cover Release Latch
BACK PANEL CONNECTORS
1 Parallel Connector 7 Line-in Connector
2 Serial Connector 8 USB 2.0 Connectors
(6)
3 Link Integrity Light 9 VGA Video Connector
4 Network Connector 10 eSATA Connector
5 Network Activity Light 11 DisplayPort Connector
6 Line-out Connector
MI N I T OWER COMP U TER (MT) VIEW

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
4
FRONT VIEW
1 Optical Drive (optional) 7 Network Connectivity
Light
2 Optical Drive Eject Button 8 Microphone Connector
3 USB 2.0 Connectors (2) 9 Headphone Connector
4 Hard Drive Activity Light 10 Media Card Reader
(optional)
5 Power Button, Power
Light
6 Diagnostic Lights (4)
BACK VIEW
1 Expansion Card Slots (3) 4 Chassis Lock Loop
2 Air Vent 5 Power Connector
3 Cover Release Latch 6 Back-Panel Connectors
BACK PANEL CONNECTORS
1 Parallel Connector 7 Line-in Connector
2 Serial Connector 8 USB 2.0 Connectors
(6)
3 Link Integrity Light 9 VGA Video Connector
4 Network Connector 10 eSATA Connector
5 Network Activity Light 11 DisplayPort Connector
6 Line-out Connector
DE S KTOP COMPUTER ( DT) VIE W

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
5
FRONT VIEW
1 Optical Drive (optional) 7 Power Button, Power
Light
2 Optical Drive Eject Button 8 Microphone Connector
3 USB 2.0 Connectors (2) 9 Headphone Connector
4 Network Connectivity
Light
10 Media Card Reader
(optional)
5 Diagnostic Lights (4)
6 Hard Drive Activity Light
BACK VIEW
1 Chassis Lock Loop 4 Back-Panel Connectors
2 Cover Release Latch 5 Expansion Card Slots (2)
3 Power Connector
BACK PANEL CONNECTORS
1 Parallel Connector 7 Line-in Connector
2 Serial Connector 8 USB 2.0 Connectors
(6)
3 Link Integrity Light 9 VGA Video Connector
4 Network Connector 10 eSATA Connector
5 Network Activity Light 11 DisplayPort Connector
6 Line-out Connector
SM A L L FORM FACTOR C O MPUTER (SFF) VIE W

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
6
BACK VIEW
1 Network Activity Light 9 Display Port Connector
2 Captive Thumbscrew 10 VGA Video Connector
3 Padlock Ring 11 Serial Connector
4 Security Cable Slot 12 USB Connector 2.0 (5)
5 Power Connector 13 Network Connector
6 Line-Out Connector 14 Link Integrity Light
7 Line-in/ Microphone Connector 15 WiFi Antenna (optional)
8 eSATA Connector
FRONT VIEW
1 Optical Drive 7 Headphone Connector
2 Power Button, Power Light 8 Microphone Connector
3 Drive Activity Light 9 USB Connector 2.0 (2)
4 Diagnostic Lights (4)
5 Network Connectivity Light
6 WiFi Activity Light (optional)
ULT RA SMALL FORM FAC TOR C O MPUTER (USFF) VI E W

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
7
MARKETING SYSTEM CONFIGURATIONS
N O T E : O f f e r i n g s m a y v a r y b y r e g i o n . F o r m o r e i n f o r m a t i o n r e g a r d i n g t h e c o n f i g u r a t i o n o f y o u r c o m p u t e r , c l i c k
S t a r t > H e l p a n d S u p p o r t an d s e l e c t t h e o p t i o n t o v i e w i n f o r m a t i o n a b o u t yo u r c o m p u t e r .
OPE RATING SYSTEM
N O T E : O n e o f t h e f o l l o w i n g O p e r a t i n g S y s t e m s w i l l b e p r e i n s t a l l e d .
MT DT SFF USFF
Windows 7® operating system
Microsoft® Windows 7® Basic; Microsoft® Windows 7® Home Pre-
mium; Microsoft® Windows 7® Professional (32 and 64 bit); Micro-
soft® Windows 7® Ultimate (32 and 64 bit)
Windows Vista® operating system
Windows Vista® Business SP2 (32 and 64 bit), Windows Vista® Home
Basic SP2 (32 bit), Windows Vista® Business SP2 (32 bit) via Win-
dows 7 Professional Downgrade Rights, Windows Vista® Ultimate
SP2 (32 bit) via Windows 7 Ultimate Downgrade Rights,
Windows XP® operating system
Windows®XP Professional SP3 via Windows Vista® Business or Ulti-
mate Downgrade Rights (32 bit), Windows®XP Professional SP3 via
Microsoft® Windows 7® Professional or Microsoft® Windows 7® Ulti-
mate Downgrade Rights (32 bit)
Other FreeDOS for (N-series), Ubuntu® Linux (China only)
OS Media Support X X X X
CHIPSET
MT DT SFF USFF
Chipset Intel Q45 Express Chipset w/ICH10DO
Non-volatile memory on chipset
BIOS Configuration SPI (Serial Peripheral Interface) 64Mbit (8MB) located at SPI_FLASH on chipset
TPM 1.2 Security Device (Trusted Platform Module)116KB located at TPM1.2 on chipset
TCM (Trusted Computing Module) Available in China only
Non-TPM Available in select countries
NIC EEPROM LOM configuration contained within SPI_FLASH –no dedicated LOM
EEPROM

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
8
PR O CESSOR
NOTE: Global Standard Products (GSP) are a subset of Dell’s relationship products that are managed for availability and synchro-
nized transitions on a worldwide basis. They ensure the same platform is available for purchase globally. This allows customers to
reduce the number of configurations managed on a worldwide basis, thereby reducing their costs. They also enable companies to
implement global IT standards by locking in specific product configurations worldwide. The following GSP processors identified below
will be made available to Dell customers.
NOTE: Processor numbers are not a measure of performance. Processor availability subject to change and may vary by region/
country.
MT DT SFF USFF
Intel® Core™ 2 Quad Processors
Intel® Core™ 2 Quad Q9650/3.00GHz, 12M, 1333FSB X-GSP X-GSP X-GSP
Intel® Core™ 2 Quad Q9550/2.83GHz, 12M, 1333FSB X-GSP X-GSP X-GSP
Intel® Core™ 2 Quad Q9400/2.66GHz, 6M, 1333FSB X-GSP X-GSP X-GSP
Intel® Core™ 2 Quad Q8400/2.66GHz, 4M, 1333FSB X X X
Intel® Core™ 2 Quad Q8300/2.50GHz, 4M, 1333FSB X X X
Intel® Core™ 2 Duo and Pentium® Dual Core Processors
Intel® Core™ 2 Duo E8600/3.33GHz, 6M, 1333FSB X-GSP X-GSP X-GSP X-GSP
Intel® Core™ 2 Duo E8500/3.16GHz, 6M, 1333FSB X-GSP X-GSP X-GSP X-GSP
Intel® Core™ 2 Duo E8400/3.0GHz, 6M, 1333FSB X-GSP X-GSP X-GSP X-GSP
Intel® Core™ 2 Duo E7600/3.06GHz, 3M, 1066FSB XXXX
Intel® Core™ 2 Duo E7500/2.93GHz, 3M, 1066FSB XXXX
Intel® Pentium® Dual-Core E6700/3.2GHz, 2M, 1066FSB XXXX
Intel® Pentium® Dual-Core E6500/2.93GHz, 2M, 1066FSB XXXX
Intel® Pentium® Dual-Core E6300/2.8GHz, 2M, 1066FSB XXXX
Intel® Pentium® Dual-Core E5500/2.8GHz, 2M, 800FSB XXXX
Intel® Pentium® Dual-Core E5400/2.7GHz, 2M, 800FSB XXXX
Intel® Pentium® Dual-Core E5300/2.60GHz, 2M, 800FSB XXXX
Intel® Celeron® Processors
Intel® Celeron® Dual-Core 3300/2.50GHz, 1M, 800FSB XXXX
Intel® Celeron® Dual-Core 3200/2.40GHz, 1M, 800FSB XXXX
Intel® Celeron® Dual-Core 1600/2.40GHz, 512K, 800FSB XXXX
Intel® Celeron® Dual-Core 1500/2.20GHz, 512K, 800FSB XXXX
Intel® Celeron® 450/2.20GHz, 512K, 800FSB XXXX

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
9
ME MORY
M e m o r y m o d u l e s s h o u l d b e i n s t a l l e d i n p a i r s o f m a t c h e d m e m o r y s i z e , s p e e d , a n d t e c h n o l o g y . I f t h e m e m o r y
m o d u l e s a r e n o t i n s t a l l e d i n m a t c h e d p a i r s , a s l i g h t r e d u c t i o n i n p e r f o r m a n c e m a y o c c u r .
N O T E : T h i s s y s t e m s u p p o r t s b o t h 1 0 6 6 M H z a n d 1 3 3 3 M H z D D R 3 m e m o r y , h o w e v e r t h e m e m o r y w i l l o p e r a t e a t
1 0 6 6 M H z s p e e d d u e t o c h i p s e t s p e c i f i c a t i o n s .
ADVANCED SYSTEM MANA GEAB I LITY MODES
N O T E : H a r d w a r e m a n a g e m e n t m o d e o p t i o n s a l l o w y o u t o s e l e c t t h e r i g h t s y s t e m s m a n a g e m e n t f e a t u r e s u p p o r t
f o r yo u r e n t e r p r i s e . D e l l’ s i n n o v a t i v e a p p r o a c h t o s c a l a b l e r e m o t e c l i e n t m a n a g e m e n t o f f e r s y o u a c h o i c e o f
b u i l t - i n h a r d w a r e m a n a g e m e n t c a p a b i l i t i e s a c r o s s p l a t f o r m o f f e r i n g s .
T h e O p t i P l e x 7 8 0 s u p p o r t s I n t e l ®v P r o ™ t e c h n o l o g y an d I n t e l ®S t a n d a r d M a n a g e a b i l i t y w h i c h s u p p o r t s t h e f o l -
l o w i n g f e a t u r e s : A s s e t r e p o r t i n g a n d i n v e n t o r y c a p a b i l i t i e s , R e m o t e t r o u b l e s h o o t i n g a n d r e p a i r , C l i e n t S y s t e m
I s o l a t i o n , R e m o t e p a t c h i n g / u p d a t i n g
I n t e l ® vPr o ™ t e c h n o l o g y a d d s t h e s e a d d i t i o n a l fe a t u r e s : Cl i e n t i n i t i a l e d “ F a s t C a l l fo r H e l p ” / b e y o n d f i r ew a l l
s y s t e m s m a n a g e m e n t c a p a b i l i t y , M i c r o s o f t N AP s u p p o r t , H a r d e n e d s e c u r i t y m o n i t o r i n g , S u p p o r t f o r t h e l a t e s t
g e n e r a t i o n o f I n t e l ® C o r e ™ 2 P r o c e s s o r s
MT DT SFF USFF
Intel® vPro Technology Enabled* (iAMT 5.x) X X X X
Intel® vPro Technology DIsabled * (iAMT 5.x) X X X X
Intel® Standard Manageability * X X X X
No Out-of-Band Systems Management X X X X
MT DT SFF USFF
Type: DDR3 Synch DRAM Non-ECC Memory 1066MHz and 1333MHz
DIMM Slots 4 4 4 2
DIMM Capacities Up to 4GB Up to 4GB Up to 4GB Up to 4GB
Minimum Memory 1GB 1GB 1GB 1GB
Maximum System Memory 16GB116GB116GB18GB
Memory configurations
16GB1DDR3, 1066MHz/1333MHz, (4 DIMM) X X X
8GB1DDR3, 1066MHz/1333MHz, (2 DIMM) X X X X
8GB1DDR3, 1066MHz/1333MHz, (4 DIMM) X X X
4GB1DDR3, 1066MHz/1333MHz, (4 DIMM) X X X
4GB1DDR3, 1066MHz/1333MHz, (2 DIMM) X X X X
4GB1DDR3, 1066MHz/1333MHz, (1 DIMM) X X X X
3GB DDR3, 1066MHz/1333MHz, (3 DIMM) X X X
3GB DDR3, 1066MHz/1333MHz, (2 DIMM) X X X X
2GB DDR3, 1066MHz/1333MHz, (2 DIMM) X X X X
2GB DDR3, 1066MHz/1333MHz, (1 DIMM) X X X X
1GB DDR3, 1066MHz/1333MHz, (1 DIMM) X X X X
1 The total amount of available memory will be less than 4GB. The amount less depends on the actual system configuration. To fully utilize 4GB or
more of memory requires a 64-bit enabled processor and 64-bit operating system.
* T h e f u n c t i o n a l i t y d e s c r i b e d a b o v e r e q u i r e s a n a p p r o p r i a t e s o f t w a r e m a n a g e m e n t c o n s o l e
- I n t e l v P r o T e c h n o l o g y E n a b l e d : T h i s o p t i o n e n a b l e s f u l l v P r o o u t o f b a n d f u n c t i o n a l i t y . R e q u i r e s a v P r o p r o c e s s o r .
- I n t e l v P r o T e c h n o l o g y D i s a b l e d : T h i s o p t i o n d i s a b l e s v P r o t e c h n o l o g y b u t a l l o w s f o r t h e l a t e r e na b l e m e n t o f v P r o a s d e -
s i r e d . R e q u i r e s a v Pr o p r o c e s s o r
- I n t e l S t a n d a r d M a n a g e a b i l i t y : T h i s o p t i o n d e l i v e r s a p o r t i o n o f b a s i c o u t o f b a n d c a p a b i l i t i e s ( s e e a b o v e )
- N o O u t o f B an d S y s t e m s M a n a g e m e n t : T h i s o p t i o n d o e s n o t s u p p o r t o u t o f b a n d m a n a g e m e n t . C a n n o t b e e n a b l e d a f t e r
p o i n t o f s a l e .

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
10
DRIVES AND REMOVAB LE STOR A GE
MT DT SFF USFF
Bays:
3.5-inch bay (External 19-1 Media Card Reader) 1 1 1 (slim-line)
5.25-inch bay (External Optical) 2 1 1 (slim-line)
Hard Drives Supported (Internal and External) 2 2 2 1
Optical Drives Supported 2 1 1 1
Interface:
SATA 4 3 3 2
3.5” Hard Drives:
160GB1SATA 10K RPM HDD X X X
80GB1SATA 10K RPM HDD X X X
1TB1SATA 7200 RPM HDD X X X
500GB1SATA 7200 RPM HDD X X X
320GB1SATA 7200 RPM HDD X X X
250GB1SATA 7200 RPM HDD X X X
160GB1SATA 7200 RPM HDD X X X
2.5” Hard Drives:
320GB1SATA 7200 RPM HDD X X X X
250GB1SATA 7200 RPM HDD X X X X
160GB1SATA 7200 RPM HDD X X X X
250GB1SATA Full Disk Encryption HDD X X X X
160GB1SATA Full Disk Encryption HDD X X X X
128GB1SATA Solid State Drive X X X X
64GB1SATA Solid State Drive X X X X
RAID 1 Data Protection: (includes two matching capacity/speed hard drives)
160GB1SATA 10K RPM HDD (3.5”) X
80GB1SATA 10K RPM HDD (3.5”) X
1TB1SATA 7200 RPM HDD (3.5”) X
500GB1SATA 7200 RPM HDD (3.5”) X
320GB1SATA 7200 RPM HDD (3.5”) X
250GB1SATA 7200 RPM HDD (3.5”) X
160GB1SATA 7200 RPM HDD (3.5”) X
320GB1SATA 7200 RPM HDD (2.5”) X X X
250GB1SATA 7200 RPM HDD (2.5”) X X X
160GB1SATA 7200 RPM HDD (2.5”) X X X

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
11
DRIVES AND REMOVAB LE STOR A GE
MT DT SFF USFF
RAID 0 Performance: (includes two matching capacity/speed hard drives)
320GB1SATA 10K RPM HDD (3.5”) X
160GB1SATA 10K RPM HDD (3.5”) X
2TB1SATA 7200 RPM HDD (3.5”) X
1TB1SATA 7200 RPM HDD (3.5”) X
640GB1SATA 7200 RPM HDD (3.5”) X
500GB1SATA 7200 RPM HDD (3.5”) X
320GB1SATA 7200 RPM HDD (3.5”) X
640GB1SATA 7200 RPM HDD (2.5”) X X X
500GB1SATA 7200 RPM HDD (2.5”) X X X
320GB1SATA 7200 RPM HDD (2.5”) X X X
Optical Drive: (SFF/USFF require slim-line optical drive)
Blu-ray Writer (available in 2H 2010) SATA
1.5Gbit/s
SATA
1.5Gbit/s
SATA
1.5Gbit/s
SATA
1.5Gbit/s
DVD+/-RW2SATA
1.5Gbit/s
SATA
1.5Gbit/s
SATA
1.5Gbit/s
SATA
1.5Gbit/s
DVD-ROM3SATA
1.5Gbit/s
SATA
1.5Gbit/s
SATA
1.5Gbit/s
SATA
1.5Gbit/s
Media Card Reader:
Dell 19 in 1 Media Card Reader 480Mb/s
1For hard drives, GB means 1 billion bytes; actual capacity varies with preloaded material and operating environment and will be less.
2Discs burned with this drive may not be compatible with some existing drives and players; using DVD+R media provides maximum compatibility.
3DVD-ROM drives may have write-capable hardware that has been disabled via firmware modifications.
SY ST EM B OA RD C ON NE CT O RS
N O T E : S e e D e t a i l e d E n g i n e e r i n g S p e c i f i c a t i o n s f o r m a x i m u m c a r d d i m e n s i o n s .
MT DT SFF USFF
PCI Slot(s): number of 2 2 1
PCIe x16 Slot: number of 1 1 1
PCIe x1 Slot: number of 1 0 0
Flexbay 1 1 1
Serial ATA (SATA) 4 3 3 2

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
12
MT DT SFF USFF
Integrated Intel GMA 4500 Integrated on system board
Enhanced Graphic/Video Options
DVI (Digital) Adapter Card Optional card
1GB NVIDIA GeForce GT330 with DVI or VGA and S-Video Out
(adapters convert to dual DVI or dual VGA) Optional card
512MB ATI RADEON HD 4550 Graphics with dual DVI or VGA
and S-Video Out (adapters convert to dual DVI or dual VGA) Optional card
256MB ATI RADEON HD 3450 Graphics with dual DVI or VGA
and S-Video Out (adapters convert to dual DVI or dual VGA) Optional card
256MB ATI RADEON HD 3470 Graphics with Dual DP (adapters
convert to dual DVI or dual VGA) Optional card
256MB NVIDIA GeForce 9300 GE with dual DVI or VGA and S-
Video Out (adapters convert to dual DVI or dual VGA) Optional card
NVIDIA Quadro NVS 420 (adapters covert to quad DVI or DP) Optional card
G RAP H ICS / VI DE O C ON TR O LL ER
N O T E : M T s u p p o r t s f u l l h e i g h t c a r d , D T s u p p o r t s l o w p r o f i l e c a r d o r f u l l h e i g h t c a r d w i t h o p t i o n a l r i s e r . S F F
s u p p o r t s l o w p r o f i l e c a r d .
See chassis diagrams section for port/connector locations MT DT SFF USFF
USB 2.0 2 Front, 6 Rear, 1 Internal 2 Front, 5
Rear
Serial 1 rear, second port optional via card 1 Rear
eSATA 1 Rear 1 Rear
Parallel 1 Rear
Network Connector (RJ-45) 1 Rear
PS/2 Optional via add-in card
1394 Controller Optional via add-in card
Video:
VGA 1 Rear
DVI-I Optional via add-in card
DisplayPort 1 Rear
Audio:
Line in for microphone 1 Front
Line in for microphone or stereo 1 Rear
Line out for headphones or speakers 1 Front, 1 Rear
Risers: (replaces 1 PCI slot and 1 PCIe slot on DT system board)
Combo full height riser with 1 PCI and 1 PCIe connector X
Dual full height riser with 2 PCI connectors X
EX TE RN AL P OR TS /C ON NE CT OR S
N O T E : M T s u p p o r t s f u l l h e i g h t c a r d , D T s u p p o r t s l o w p r o f i l e c a r d o r f u l l h e i g h t c a r d w i t h o p t i o n a l r i s e r . S F F
s u p p o r t s l o w p r o f i l e c a r d .

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
13
COM MUNICA T IONS –MOD EM
N O T E : M T s u p p o r t s f u l l h e i g h t c a r d , D T s u p p o r t s l o w p r o f i l e c a r d o r f u l l h e i g h t c a r d w i t h o p t i o n a l r i s e r .
MT DT SFF USFF
Intel® 82567LM Gigabit1Ethernet LAN 10/100/1000 (Remote
Wake Up, PXE support and Intel Active Management Technol-
ogy support)
Integrated on system board
Broadcom NetXtreme 10/100/1000 PCIe Gigabit Networking
Card Optional via add-in card
1This term does not connote an actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network
infrastructure is required.
MT DT SFF USFF
V.92 Data/Fax Controllerless Modem Optional via add-in card
MT DT SFF USFF
Dell Wireless 1505 PCIe WLAN card (802.11n) Optional via add-in card
Dell Wireless 1510 miniPCIe WLAN card (802.11n) Optional
Dell Wireless 1520 miniPCIe WLAN card (802.11n) Optional via add-in card
COM MUNICA T IONS –WIRE LESS
MT DT SFF USFF
ADI 1984A High Definition Audio Codec Integrated on system board
Internal Dell Business Audio Speaker Optional
Dell AX210 2.0 Desktop Speakers Optional
Dell AX510/AX510PA Flat Panel Soundbar Speakers Optional
Dell AY410 30W 2.1 Stereo Speakers with Subwoofer Optional
AUD IO AND SPEAKERS
MT DT SFF USFF
Dell USB Entry Keyboard with optional palmrest Standard
Dell QuietKey Keyboard with optional palmrest Optional
Dell Multimedia Pro Keyboard Optional
Dell Smartcard Keyboard Optional
Dell USB Optical Mouse Optional
Dell Laser Mouse Optional
Dell Logo Mouse Pad Optional
KEY B OARD AND M O USE
COM MUNICA T IONS - NETWORK ADAPTER ( NIC)
N O T E : M T s u p p o r t s f u l l h e i g h t c a r d , D T s u p p o r t s l o w p r o f i l e c a r d o r f u l l h e i g h t c a r d w i t h o p t i o n a l r i s e r . S F F
s u p p o r t s l o w p r o f i l e c a r d .

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
14
SE C URITY
SE R VICE AND SUPPORT
N O T E : F o r m o r e d e t a i l s o n D e l l S e r v i c e P l a n s p l e a s e t o g o t o : www.dell.com/service/service_plans
SOFTWARE
MT DT SFF USFF
Trusted Platform Module (TPM) 1.21Integrated on system board
Trusted Computing Module (TCM) Integrated on system board (China only)
Chassis Intrusion Switch Optional
Dell Smartcard Keyboard Optional
Chassis lock slot and loop support Standard
1TPM is not available in all countries. Depending on your country regulations, TCM or No-TPM system boards will be made available.
MT DT SFF USFF
3 Year Warranty1 Next Business Day On-site2(3-3-3) Standard
ProSupport Optional
1For a copy of our guarantees or limited warranties, please write Dell USA L.P., Attn: Warranties, One Dell Way, Round Rock, TX 78682. For more
information, visit www.dell.com/warranty.
2Service may be provided by third-party. Technician will be dispatched if necessary following phone-based troubleshooting. Subject to parts availabil-
ity, geographical restrictions and terms of service contract. Service timing dependent upon time of day call placed to Dell. U.S. only.
MT DT SFF USFF
Dell Client Manager Available via Dell.com
Dell ControlPoint Standard
Norton 2009 Internet Security 30 Day Trial or Optional Subscription
McAfee 10 SecurityCenter 30 Day Trial or Optional Subscription

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
15
DETAILED ENGINEERING SPECIFICATIONS
SY STEM DIME NSIONS ( P HYSIC A L)
N O T E : S y s t e m W e i g h t a n d S h i p p i n g W e i g h t i s b a s e d o n a t y p i c a l c o n f i g u r a t i o n a n d m a y v a r y b a s e d o n P C
c o n f i g u r a t i o n . A t y p i c a l c o n f i g u r a t i o n i n c l u d e s : i n t e g r a t e d g r a p h i c s , o n e h a r d d r i v e , o n e o p t i c a l d r i v e , a n d
o n e d i s k e t t e d r i v e .
SY STEM BOARD CO NNECT O R MAXIMUM A LLOWAB LE DIME NSIONS
MT DT SFF USFF
Chassis Volume (liters) 33.0 16.0 10.7 3.7
Chassis Weight (pounds/kilograms) 25.8 / 11.7 18.2 / 8.26 15 / 6.80 7.0/ 3.2
Chassis Dimensions: (HxWxD)
Height (inches/centimeters) 16.1 / 40.8 4.5 / 11.4 3.65 / 9.26 9.40/ 23.9
Width (inches/centimeters) 7.4 / 18.7 15.7 / 39.9 12.4 / 31.4 2.60/ 6.50
Depth (inches/centimeters) 17.0 / 43.3 13.9 / 35.3 13.4 / 34 9.30/ 23.6
Shipping Weight (pounds/kilograms - includes packaging materials) 43.5 / 19.73 28 / 12.7 21.3 / 9.66 13.5/ 6.12
Packaging Parameters (HxWxD)
Height (inches/centimeters) 22.38/56.85 20.63 / 52.4 20.88/50.04 18.69/47.5
Width (inches/centimeters) 22.25/56.52 20.31/51.59 19.38/49.23 15.75/40.0
Depth (inches/centimeters) 14.25 / 36.2 11.75/29.85 10.63 / 27 7.75/19.7
MT DT SFF USFF
PCI Slots 2 2 1
Height (inches/centimeters) 4.376 /
11.115 2.731 / 6.89
Length (inches/centimeters) 7.4 / 18.796* 6.6 / 16.764
PCIe x16 Slots 1 1 1
Height (inches/centimeters) 4.376 /
11.115 2.731 / 6.89
Length (inches/centimeters) 7.4 / 18.796* 6.6 / 16.764
PCIe x1 Slots 1
Height (inches/centimeters) 4.376 /
11.115
Length (inches/centimeters) 7.4 / 18.796*
Risers: (replaces 1 PCI slot and 1 PCIe slot on DT system board)
Combo Full Height Riser with 1 PCI and 1 PCIe connector (HxL) 1
Height (inches/centimeters) 4.376 /
11.115
Length (inches/centimeters)*,** 6.6 /
16.764
Dual Full Height Riser with 2 PCI connectors (HxL) 1
Height (inches/centimeters) 4.376 /
11.115
Length (inches/centimeters)*,** 6.6 /
16.764
* Card length can be longer than standard Half-Length Card but cannot be a Full-Length Card.
** 6.9/17.53 in/cm is longer than the standard Half-Length Card

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
16
SY STEM LEVEL ENVI RON MENT A L AND OPERAT ING CO NDITION S
MT DT SFF USFF
Temperature
Operating 10° to 35° C (50° to 95° F)
Non-Operating (Storage) -40° to 65° C (-40° to -149° F)
Relative Humidity 20% to 80% (non-condensing)
Maximum vibration
Operating 0.25 G at 3 to 200 Hz at 0.5 octave/min
Non-Operating 0.5 G at 3 to 200 Hz at 1 octave/min
Maximum Shock
Operating Bottom half-sine pulse with a change in velocity of
50.8 cm/sec (20 inches/sec)
Non-Operating 27-G faired square wave with a velocity change of
508 cm/sec (200 inches/sec)
Maximum Altitude
Operating –15.2 to 3048 m (–50 to 10,000 ft)
Non-Operating –15.2 to 10,668 m (–50 to 35,000 ft)

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
17
POW ER
N O T E : T h e s e f o r m f a c t o r s u t i l i z e a m o r e e f f i c i e n t A c t i v e P o w e r F a c t o r C o r r e c t i o n ( A P F C ) p o w e r s u p p l y . D e l l
r e c o m m e n d s o n l y U n i v e r s a l P o w e r S u p p l i e s ( U P S ) b a s e d o n S i n e W a v e o u t p u t f o r A P F C P S U s , n o t a n a p p r o x i -
m a t i o n o f a S i n e W a v e , S q u a r e W a v e , o r q u a s i - S q u a r e W a v e . I f y o u h a v e q u e s t i o n s , p l e a s e c o n t a c t t h e m a n u -
f a c t u r e t o c o n f i r m t h e o u t p u t t y p e .
MT
APFC EPA
DT
APFC EPA
SFF
APFC EPA
USFF
EPA
Power Supply Watt-
age 305W 255W High
Efficiency 255W 255 W High Efficiency 235W 235W High Efficiency
180W High
Efficiency
AC input Voltage
Range
90 –
264Vac
90 –
264Vac
90 –
264Vac
90 –
264Vac
90 –
264Vac
90 –
264Vac 90 –264Vac
AC input current (low
ac range/high AC
range)
5.6A / 2.8A 3.6A / 1.8A 5.0A / 2.5A 4.0A / 2.0A 4.5A /
2.25A
3.5A /
1.75A 2.6A / 1.3A
AC input Frequency 47HZ /
63HZ
47HZ /
63HZ
47HZ /
63HZ
47HZ /
63HZ
47HZ /
63HZ
47HZ /
63HZ 47 –63 Hz
AC holdup time (80%
load) 16MSEC 16MSEC 16MSEC 16MSEC 16MSEC 16MSEC 16 ms
Average Efficiency
(Energy Star 5.0 Com-
pliant)
87 –90 –
87% @ 20
–50 –
100% load
87 –90 –
87% @ 20
–50 –
100% load
87 –90 –
87% @ 20
–50 –
100% load
87 –90 –
87% @ 20 –
50 –100%
load
Typical Efficiency
(Active PFC) 65% 65% 65% N/A
DC parameters
+3.3v output 8.0A 8.0A 7.0 A 7.0 A 5A 5A N/A
+5.0v output 16A 16A 15A 15A 16A 16A N/A
+12.0v output 12vA/15A;
12VB/10A
12VA/13A;
12VB/7A 18A 18A 17A 17A
+12VA -
9.0 A &
+12VB - 7.0
A
Note: +12VB
Rated at
0.4A when in
Standby
Mode.
+5.0v auxiliary output 4.0A 4.0A 4.0 4.0 4.0A 4.0A N/A
-12.0v output 0.5A 0.5A 0.5A 0.5A 0.5A 0.5A 0.1 A
Max total power 305W 255W 255W 255W 235W 235W 180W
Max combined +3.3v /
+5.0v power 80W 80W 91.5W 91.5W 88W 88W N/A
Max combined 12.0v
power (note: only if
more than one 12v rail)
240W 240W N/A N/A N/A N/A 180W
BTUs/h (based on PSU
max wattage) 1603 BTU 1000 BTU 1341 BTU 1000 BTU 1235 BTU 921 BTU 723 BTU
3.3v CMOS battery (type and estimated battery life)
Power Supply Fan 80*25mm 80*25mm 92*25mm 92*25mm 80*15mm 80*15mm N/A
Compliance:
1watt requirement Yes Yes Yes Yes Yes Yes Yes
Blue Angel Compliant Select Select Select Select Select Select Select
Climate Savers /
80Plus Compliant No Yes No Yes No Yes Yes
FEMP (CECP) Standby
Power Compliant No Yes No Yes No Yes Yes

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
18
AUD IO
COM MUNICA T IONS - NET WORK AD APTER (NIC)
N O T E : M T s u p p o r t s f u l l h e i g h t c a r d , D T s u p p o r t s l o w p r o f i l e c a r d o r f u l l h e i g h t c a r d w i t h o p t i o n a l r i s e r . S F F
s u p p o r t s l o w p r o f i l e c a r d .
INTEGRATED ADI 1984A HIGH DEFINITION AUDIO MT DT SFF USFF
High Definition Stereo support X X X X
Number of channels 2
Number of Bits / Audio resolution 16, 20, and 24-bit resolution
Sampling rate (recording/playback) Independent 8, 11.025, 16, 22.05, 32, 44.1,
48, 88.2, 96, 176.4, and 192 kHz sample rates
Signal to Noise Ratio 96+ dB audio outputs, 90+ dB audio inputs
Analog Audio X X X X
Dolby Digital
THX
Digital out (S/PDIF)
Audio Jack Impedance
Microphone 150 kΩ
Line-In 150 kΩ
Line-Out 190 Ω
Headphone .5 Ω
Internal Speaker Power Rating 2W
INTEGRATED INTEL® 82567 GIGABIT1
ETHERNET LAN 10/100/1000 MT DT SFF USFF
External Connector Type RJ45
Data Rates supported 10/100/1000 Mbps
Controller Details
Controller bus architecture (example PCIe 1.0a x1) Intel Gigabit LAN Connect Interface (GLCI) and
LAN Connect Interface (LCI)
Integrated memory N/A
Data transfer mode (example Bus-Master DMA) N/A
Power consumption (full operation per data rate connection speed) 680mW (Max.)
Power consumption (standby operation) 141mW (Max.)
IEEE standards compliance (example 802.1P) 802.3
Hardware Certifications (example FCC, B, GS mark…) N/A
Boot ROM Support EEPROM (located in SPI)
Network Transfer Mode (example Full Duplex, Half Duplex)
Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
10 Mb (full/half-duplex)
100 Mb (full/half-duplex)
1000 Mb (full-duplex)

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
19
COM MUNICA T IONS - N ET WORK AD APTER (NIC) ( CONT.)
COM MUNICA T IONS –INTE G RATED LA N
N O T E : M T s u p p o r t s f u l l h e i g h t c a r d , D T s u p p o r t s l o w p r o f i l e c a r d o r f u l l h e i g h t c a r d w i t h o p t i o n a l r i s e r . S F F
s u p p o r t s l o w p r o f i l e c a r d .
INTEGRATED INTEL® 82567 GIGABIT1
ETHERNET LAN 10/100/1000 (CONT.) MT DT SFF USFF
Environmental
Operating temperature 0° C to 70° C (32° F to 158° F)
Operating humidity 20% to 80% (non-condensing)
Operating System Driver Support
Windows® XP, Windows Vista® Ultimate, Win-
dows Vista® Business 32 bit/64 bit, Windows Vista
Home Basic
Manageability (examples WOL, PXE) WOL, PXE 2.1
Management Capabilities Alerting Intel® Standard Manageability, Intel Core 2 Duo/
Quad Processor with vPro Technology
1This term does not connote an actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network
infrastructure is required.
Broadcom NetXtreme 10/100/1000 PCIe Gigabit1Networking Card MT DT SFF USFF
Connector Type RJ45
Data Rates supported 10/100/1000 Mbps Half/Full duplex
Controller Details
Controller bus architecture (example PCIe 1.0a x1) PCIe c1.0a x1
Integrated memory 64KBytes RX, 8KBytes TX
Data transfer mode (example Bus-Master DMA) Bus-Master DMA
Power consumption (full operation per data rate connection speed) 2.84W (860mA @ +3.3V)
Power consumption (standby operation) Less than 300mW
IEEE standards compliance (example 802.1P) 802.3, 802.2, 802.3x, 802.1p
Hardware Certifications (example FCC, B, GS mark…) FCC B, VCCI B, CE
Boot ROM Support No
Network Transfer Mode (example Full Duplex, Half Duplex) Full Duplex/Half Duplex
Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
10BASE-T (full-duplex) 20 Mbps Max*
100BASE-TX (half-duplex) 100 Mbps Max*
100BASE-TX (full-duplex) 200 MbpsMax*
1000BASE-T (full-duplex) 2000 Mbps Max*
* Depends on the system environment.
1This term does not connote an actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network
infrastructure is required.

DELL™ OPTIPLEX™ 780 TECHNICAL GUIDEBOOK V2.0
20
COM MUNICA T IONS –INTE G RATED LA N (CONT.)
BROADCOM NETXTREME 10/100/1000
PCIE GIGABIT1NETWORKING CARD (CONT.) MT DT SFF USFF
Environmental
Operating temperature 0° C to 55° C (32° F - 131° F)
Operating humidity 5% ~ 85% (non-condensing)
Operating System Driver Support
Windows® 7, Windows® XP, Windows Vista®
Ultimate, Windows Vista® Business 32 bit/64 bit,
Windows Vista Home Basic, Linux
Manageability (examples WOL, PXE) WOL, PXE2.1, ACPI
Management Capabilities Alerting (example ASF 2.0) None
1This term does not connote an actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network
infrastructure is required.
COM MUNICA T IONS –MOD EM
V.92 DATA/FAX CONTROLLERLESS MODEM MT DT SFF USFF
Bus PCI
External Connector RJ-11
Data Transmission PCM - Pulse Coded Modulation (V.92/V.90)
TCM - Trellis Coded Modulation (V.90/V.34/V.32 bis/V.32)
Data Speeds 56kbps receive, 48kbps transmit
Data Standards ITU V.92/V.90, V.34/V.32 bis/V.32
Fax Speeds 14.4kbps
Fax Mode Capabilities 2-wire, half-duplex, synchronous
Error Correction and Data Compression V.44, V.42, V.42bis, MNP 2-4, MNP 5
Power Management WOR (wake on ring) capable
Upgradeability Driver upgradeable
Video
V.80 Synchronous Access Mode (SAM) can be supported
by
software applications (not driver)
Operating Temperature 0~50 degree C
Operating Humidity 45 degree C 90% max
Operating System Support Windows 7,Vista 32/64, Windows XP 32/64
Operating System Driver Support Windows 7,Vista 32/64, Windows XP 32/64
Power Requirements +3.0V~+3.6V, 116.6mW max
Chipset Conexant SmartHSFs/LF (CX11256 & CX20493)
Dimensions of full height card inches/centimeters (L X H)
L:
5.25/13.325
H:
4.73/12.002
Dimensions of low profile card inches/centimeters (L X H)
L: 5.26/13.366
H: 3.12/7.923
