Dell Latitude 3440 User guide

Precision 3440 Small Form Factor
Setup and specifications guide
Regulatory Model: D15S
Regulatory Type: D15S003
May 2020
Rev. A00

Chapter 1: Set up your computer......................................................................................................4
Chapter 2: Chassis overview............................................................................................................ 9
Front view...............................................................................................................................................................................9
Back view.............................................................................................................................................................................. 10
System board layout.............................................................................................................................................................11
Chapter 3: Specifications of Precision 3440 Small Form Factor......................................................... 12
System specifications.......................................................................................................................................................... 12
Dimensions and weight..................................................................................................................................................12
Chipset.............................................................................................................................................................................12
Processors.......................................................................................................................................................................13
Operating system........................................................................................................................................................... 14
Memory............................................................................................................................................................................14
Storage............................................................................................................................................................................ 15
Audio and Speaker......................................................................................................................................................... 15
Video................................................................................................................................................................................ 16
Communications............................................................................................................................................................. 17
Ports and connectors.....................................................................................................................................................17
Power supply...................................................................................................................................................................18
Security............................................................................................................................................................................18
Security Software.......................................................................................................................................................... 19
CAC/PIV Module ...........................................................................................................................................................19
Out of Band Systems Management Intel Standard Manageability......................................................................... 20
Computer environment.................................................................................................................................................20
Service and support....................................................................................................................................................... 21
Support policy...................................................................................................................................................................... 22
Energy Star and Trusted Platform Module (TPM)......................................................................................................... 22
Accessories...........................................................................................................................................................................22
Add-in cards......................................................................................................................................................................... 22
Chapter 4: Getting help................................................................................................................. 23
Contacting Dell.....................................................................................................................................................................23
Contents
2 Contents

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2020 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may
be trademarks of their respective owners.

Set up your computer
Steps
1. Connect the keyboard and mouse.
2. Connect to your network using a cable, or connect to a wireless network.
1
4 Set up your computer

3. Connect the display.
4. Connect the power cable.
Set up your computer 5

5. Press the power button.
6Set up your computer

6. Finish operating system setup.
For Ubuntu:
Follow the on-screen instructions to complete the setup. For more information about installing and configuring Ubuntu, see the
knowledge base articles SLN151664 and SLN151748 at www.dell.com/support.
For Windows:Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you:
• Connect to a network for Windows updates.
NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when
prompted.
• If connected to the internet, sign in with or create a Microsoft account. If not connected to the internet, create an offline account.
• On the Support and Protection screen, enter your contact details.
7. Locate and use Dell apps from the Windows Start menu—Recommended
Table 1. Locate Dell apps
Dell apps Details
Dell Product Registration
Register your computer with Dell.
Dell Help & Support
Access help and support for your computer.
Set up your computer 7

Table 1. Locate Dell apps (continued)
Dell apps Details
SupportAssist
Proactively checks the health of your computer’s hardware and
software.
NOTE: Renew or upgrade your warranty by clicking the
warranty expiry date in SupportAssist.
Dell Update
Updates your computer with critical fixes and important device
drivers as they become available.
Dell Digital Delivery
Download software applications including software that is
purchased but not preinstalled on your computer.
8 Set up your computer

Chassis overview
Topics:
•Front view
•Back view
•System board layout
Front view
1. Power button and power light
2. SD card reader (Optional)
3. Hard drive activity light
4. Universal audio jack port
5. USB 2.0 Type-A port with PowerShare
6. USB 2.0 Type-A port
7. USB 3.2 Gen 2 Type-C port with PowerDelivery
8. USB 3.2 Gen2 Type-A port
9. Optical disk drive
2
Chassis overview 9

Back view
1. Line -in/out retasking
2. Two DisplayPort 1.4 ports
3. Serial Port
4. PS/2 Keyboard port
5. USB 3.2 Gen 2 Type-A port
6. Two USB 2.0 ports with Power On
7. Expansion card slots
8. Power connector port
9. Power supply diagnostic light
10. Padlock loop
11. Network port
12. Three USB 3.2 Gen 1 Type-A ports
13. Kensington security-cable slot
14. PS/2 Mouse port
15. Release latch
10 Chassis overview

System board layout
1. Video connector 2. Intrusion switch connector (Intruder)
3. CPU power connector (ATX_CPU) 4. CPU fan connector
5. Memory slots (DIMM1, DIMM2, DIMM3, DIMM4) 6. M.2 Solid-state drive connector
7. Power switch connector (PWR_SW) 8. Remote PWR switch connector
9. Media card reader connector (Card_reader) 10. M.2 WLAN connector
11. System fan connector 12. SATA 1 connector
13. M.2 Soild-state drive connector 14. SATA 2 connector
15. PSU connector 16. SATA 3 connector
17. Internal speaker connector 18. SATA power connector
19. PCI-e connectors 20. Coin cell battery
21. USB Type-C connector 22. Processor socket (CPU)
Chassis overview 11

Specifications of Precision 3440 Small Form
Factor
Topics:
•System specifications
•Support policy
•Energy Star and Trusted Platform Module (TPM)
•Accessories
•Add-in cards
System specifications
NOTE: Offerings may vary by region. The following specifications are only those required by law to ship with your
computer. For more information about the configuration of your computer, go to Help and Support in your Windows
operating system and select the option to view information about your computer.
Dimensions and weight
Table 2. Dimensions and weight
Description Values
Height:
Front 290 mm (11.42 in.)
Rear 290 mm (11.42 in.)
Width 92.6 mm (3.65 in.)
Depth 292.8 mm (11.53 in.)
Weight (maximum) 5.59 kg (12.32 lb)
NOTE: The weight of your computer depends on the
configuration ordered and the manufacturing variability.
Chipset
Table 3. Chipset
Description Values
Chipset Intel W480
Processor 10th Generation Intel Core i3/i5/i7/i9/Xeon
DRAM bus width Two channels, 128-bit
Flash EPROM 32 MB
3
12 Specifications of Precision 3440 Small Form Factor

Table 3. Chipset (continued)
Description Values
PCIe bus Upto Gen 3
Non-volatile memory Yes
BIOS Configuration Serial Peripheral Interface (SPI) 256 Mbit (32 MB) located at SPI_FLASH on chipset
Trusted Platform Module (Discrete TPM Enabled) 24 KB located at TPM 2.0 on chipset
Firmware TPM (Discrete TPM Disabled) By default the Platform Trust Technology feature is visible to the
OS
NIC EEPROM LOM configuration contained within SPI flash ROM instead of
LOM e-fuse
Processors
NOTE: Global Standard Products (GSP) are a subset of Dell’s relationship products that are managed for availability and
synchronized transitions on a worldwide basis. They ensure the same platform is available for purchase globally. This
allows customers to reduce the number of configurations managed on a worldwide basis, thereby reducing their costs.
They also enable companies to implement global IT standards by locking in specific product configurations worldwide.
Device Guard (DG) and Credential Guard (CG) are the new security features that are only available on Windows 10 Enterprise today.
Device Guard is a combination of enterprise-related hardware and software security features that, when configured together, will lock a
device down so that it can only run trusted applications. If it is not a trusted application, it cannot run.
Credential Guard uses virtualization-based security to isolate secrets (credentials) so that only privileged system software can access
them. Unauthorized access to these secrets can lead to credential theft attacks. Credential Guard prevents these attacks by protecting
NTLM password hashes and Kerberos Ticket Granting Tickets.
NOTE: Processor numbers are not a measure of performance. Processor availability is subject to change and may vary
by region/country.
Table 4. Processors
Processors Wattage Core
count
Thre
ad
coun
t
Speed Cache Integrated graphics GSP DG/CG
Ready
10th
Generation
Intel Core
i3-10100
65 W 4 8 3.6 GHz to 4.3
GHz
6 MB Intel UHD Graphics 630 No Yes
10th
Generation
Intel Core
i5-10500
65 W 6 12 3.1 GHz to 4.5
GHz
12 MB Intel UHD Graphics 630 Yes Yes
10th
Generation
Intel Core
i5-10600
65 W 6 12 3.3 GHz to 4.8
GHz
12 MB Intel UHD Graphics 630 Yes Yes
10th
Generation
Intel Core
i7-10700
65 W 8 16 2.9 GHz to 4.7
GHz
16 MB Intel UHD Graphics 630 Yes Yes
Specifications of Precision 3440 Small Form Factor 13

Table 4. Processors (continued)
Processors Wattage Core
count
Thre
ad
coun
t
Speed Cache Integrated graphics GSP DG/CG
Ready
10th
Generation
Intel Core
i9-10900
65 W 10 20 2.8 GHz to 4.6
GHz
20 MB Intel UHD Graphics 630 Yes Yes
Intel Xeon
W-1250
80 W 6 12 3.3 GHz to 4.4
GHz
12 MB Intel UHD Graphics 630 Yes Yes
Intel Xeon
W-1270
80 W 8 16 3.2 GHz to 4.7
GHz
16 MB Intel UHD Graphics 630 Yes Yes
Intel Xeon
W-1290
80 W 10 20 3.7 GHz to 4.9
GHz
20 MB Intel UHD Graphics 630 Yes Yes
Operating system
• Windows 10 Home (64-bit)
• Windows 10 Enterprise (64-bit)
• Windows 10 Professional (64-bit)
• Windows 10 Pro Education (64-bit)
• Windows 10 LTSC (64-bit)
• Ubuntu 18.04
Memory
Table 5. Memory specifications
Description Values
Slots 4 DIMM slots
Type DDR4
Speed • 2666 MHz for Intel Core i3/i5/Xeon W-1250 processors, 2933
MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors
Maximum memory 128 GB
Minimum memory 4 GB
Memory size per slot 4 GB, 8 GB, 16 GB, 32 GB
Configurations supported • 4 GB, 1 x 4 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon
W-1270/W-1290 processors
• 8 GB, 2 x 4 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon
W-1270/W-1290 processors
• 8 GB, 1 x 8 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon
W-1270/W-1290 processors
14 Specifications of Precision 3440 Small Form Factor

Table 5. Memory specifications (continued)
Description Values
• 16 GB, 2 x 8 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon
W-1270/W-1290 processors
• 32 GB, 4 x 8 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon
W-1270/W-1290 processors
• 32 GB, 2 x 16 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon
W-1270/W-1290 processors
• 64 GB, 4 x 16 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon
W-1270/W-1290 processors
• 128 GB, 4 x 32 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon
W-1270/W-1290 processors
Storage
Your computer supports one of the following configurations:
• One 2.5-inch hard-disk drive
• Two 2.5-inch hard-disk drives
• One 3.5-inch hard-disk drive
• One 2.5-inch hard-disk drive and one 3.5-inch hard-disk drive
• One M.2 2230 or 2280 solid-state drive (class 40)
• One M.2 2230 or 2280 solid-state drive (class 40) and one 3.5-inch hard-disk drive
• One M.2 2230 or 2280 solid-state drive (class 40) and one 2.5-inch hard-disk drive
• One M.2 2230 or 2280 solid-state drive (class 40) and two 2.5-inch hard-disk drives
Table 6. Storage specifications
Storage type Interface type Capacity
2.5 in. hard-disk drive, 5400 RPM SATA Upto 2 TB
2.5 in. hard-disk drive, 7200 RPM SATA Upto 1 TB
2.5 in. hard-disk drive, 7200 RPM, FIPS Self Encrypting
Opal 2.0
SATA Upto 500 GB
3.5 in, hard-disk drive, 5400 RPM SATA Upto 4 TB
3.5 in, hard-disk drive, 7200 RPM SATA Upto 2 TB
M.2 2280 solid-state drive Gen 3 PCIe x4 NVMe, Class 40 Upto 2 TB
M.2 2280 Opal Self-Encrypting solid-state drive Gen 3 PCIe x4 NVMe, Class 40 Upto 1 TB
Audio and Speaker
Table 7. Audio specifications
Description Values
Type 4 Channel High Definition Audio
Specifications of Precision 3440 Small Form Factor 15

Table 7. Audio specifications (continued)
Description Values
Controller Realtek ALC3246
Stereo conversion Supported
Internal interface High definition audio interface
External interface Universal Audio Jack
Speakers 2
Internal speaker amplifier Integrated in ALC3246 (Class-D 2 W)
External volume controls Keyboard shortcut controls
Speaker output average 2 W
Speaker output peak 2.5 W
Subwoofer output Not Supported
Microphone Not Supported
Video
Table 8. Discrete graphics specifications
Discrete graphics
Controller External display support Memory size Memory Type
AMD Radeon R5 430 • Two DisplayPort 1.2 2 GB DDR3
AMD Radeon Pro WX 2100 • One DisplayPort 1.4
• Two Mini DisplayPort 1.4
2 GB GDDR5
AMD Radeon Pro WX 3200 • Four Mini DisplayPort 1.4 4 GB GDDR5
NVIDIA Quadro P400 • Three Mini DisplayPort 1.4 2 GB GDDR5
NVIDIA Quadro P620 • Four Mini DisplayPort 1.4 2 GB GDDR5
Table 9. Integrated graphics specifications
Integrated graphics
Controller External display support Memory size Processor
Intel UHD Graphics 630 Two DisplayPort 1.4 Shared system memory 10th Generation Intel
Core i3/i5/i7/i9
16 Specifications of Precision 3440 Small Form Factor

Communications
Ethernet
Table 10. Ethernet specifications
Description Values
Model number Intel i219-LM
Transfer rate 10/100/1000 Mbps
Wireless module
Table 11. Wireless module specifications
Description Values
Model number Qualcomm QCA61x4a (DW1820) Intel AX201
Transfer rate Up to 867 Mbps Up to 2400 Mbps
Frequency bands supported 2.4 GHz/5 GHz 2.4 GHz/5 GHz
Wireless standards • WiFi 802.11a/b/g
• Wi-Fi 4 (WiFi 802.11n)
• Wi-Fi 5 (WiFi 802.11ac)
• Wi-Fi 802.11a/b/g
• Wi-Fi 4 (Wi-Fi 802.11n)
• Wi-Fi 5 (Wi-Fi 802.11ac)
• Wi-Fi 6 (Wi-Fi 802.11ax)
Encryption • 64-bit/128-bit WEP
• AES-CCMP
• TKIP
• 64-bit/128-bit WEP
• AES-CCMP
• TKIP
Bluetooth Bluetooth 5.0 Bluetooth 5.1
Ports and connectors
Table 12. Ports and connectors
Description Values
External:
Network 1 RJ-45
USB • One USB 2.0 Type-A port (front)
• One USB 2.0 Type-A with PowerShare (front)
• One USB 3.2 Gen 2 Type-A (front)
• One USB 3.2 Gen 2 Type-C port with PowerDelivery (front)
• Two USB 2.0 ports with Power On (rear)
• One USB 2.0 header for Comon Access Card (CAC)
• Three USB 3.2 Gen 1 Type-A ports (rear)
• One USB 3.2 Gen 2 Type-A ports (rear)
Audio • One Universal Audio Jack (front)
• One Line -in/out retasking (rear)
Specifications of Precision 3440 Small Form Factor 17

Table 12. Ports and connectors (continued)
Description Values
Video • Two DisplayPort 1.4 port (rear)
• One HDMI 2.0 port (rear, optional)
• One VGA port (rear, optional)
• One Type-C w/DP-Alt mode (rear optional)
Memory card reader One SD-card 4.0 slot
Power port AC-in
Security • One Wedge-shaped lock
• One Padlock Loop
• One Lockable Port Cover
• One Intrusion switch
Antenna Two SMA connectors (optional)
Internal:
SATA One SATA slots for 2.5-inch Hard-disk drive
M.2 • One half-height Gen3 PCIe x16 slot (discrete graphics)
• One half-height Gen3 PCIe x4 slot
• Three SATA 3.0 for Hard-disk drive/Solid-state drive
• One M.2 2230 slot for WiFi/Bluetooth card
• One M.2 2230/2280 slot for solid-state drive
• One M.2 2230 slot for PCIe solid-state drive
NOTE: To learn more about the features of different
types of M.2 cards, see the knowledge base article
SLN301626.
Power supply
Table 13. Power supply
Feature Specifications
Input voltage 100–240 VAC, 50–60 Hz
Wattage • 200 W 100V-240V Full range
• 260 W 100V-240V Full range
Security
Table 14. Security
Feature Description
Trusted Platform Module (TPM) 2.0 Integrated on the system board
Firmware TPM Optional
Windows Hello Support Optional via security input device
18 Specifications of Precision 3440 Small Form Factor

Table 14. Security (continued)
Feature Description
Cable cover Optional
Chassis intrusion switch Standard
Dell Smartcard Keyboard Optional
Chassis lock slot and loop support Standard
Security Software
Table 15. Security Software
Features Description
Dell Endpoint Security Suite Enterprise Optional
Dell Data Guardian Optional
Dell Encryption (Enterprise or Personal) Optional
Dell Threat Defense Optional
RSA SecurID Access Optional
RSA NetWitness Endpoint Optional
MozyPro or MozyEnterprise Optional
VMware Airwatch/WorkspaceONE Optional
Absolute Data & Device Security Optional
CAC/PIV Module
Table 16. CAC/PIV Module
Features Tower/Small Form Factor/Micro
Connector Type ISO 7816 compliant contact smart card NFC forum 2.0
PCB
Dimensions (W x L x T) 74.5 mm x 45.7 mm
Layer 6
Controller Details
Controller bus architecture (example PCIe 1.0a x1) USB 2.0
Data transfer mode (example Bus-Master DMA) USB 2.0
Power consumption (full operation per data rate
connection speed)
288.08 mA x 3.3 V
Specifications of Precision 3440 Small Form Factor 19

Table 16. CAC/PIV Module (continued)
Features Tower/Small Form Factor/Micro
Power consumption (standby operation) 8.9 mA x 3.3 V
Standard compliance (example 802.1P) NFC Forum 2.0, ISO7816
Hardware Certifications (example FCC, B, GS mark…) FIPS201, FIPS140-2
Boot ROM Support Integrated inside Lynx SoC
Processor/Chipset
NFC Broadcom Cortex-M3 BC58102
Card reader driver NXP TDA8034HN/C2
USB 2.0 Hub GENESYS GL850G-OHY50
PROM WINBOND W25Q32JVSSIQ 32M/bit
Power IC RICHTEK RT5796AHGJ5
Power LDO (NFC VBAT) GMT G9141T11U
Environmental
Operating System Driver Support Dell ControlVault2 Driver
Manageability (examples WOL, PXE) No, this is not a LAN controller chipset.
Management Capabilities Alerting (example ASF 2.0) No, this is not a LAN controller chipset.
Add-in Slots
Card reader connector 1 (10 PIN)
USB 2.0 header 1 (5 PIN)
NFC header 1 (6 PIN)
Out of Band Systems Management Intel Standard
Manageability
Intel Standard Manageability (ISM) must be configured in our factory at the time of purchase, as it is NOT field upgradable. ISM offers
out-of-band management and DASH compliance https://registry.dmtf.org/registry/results/field_initiative_name%3A%22DASH
%201.0%22. ISM offers a limited set of out-of-band features like remote power on/off, Serial-over-LAN redirect, Wake-on-LAN, etc. ISM
leverages the same capabilities that were available with Intel’s Active Management Technology (AMT) version 5.0.
To learn more about Intel ISM, visit Intel’s website at: https://software.intel.com/en-us/blogs/2009/03/27/what-is-standard-
manageability
Computer environment
Airborne contaminant level: G1 as defined by ISA-S71.04-1985
20 Specifications of Precision 3440 Small Form Factor
