Dell OptiPlex 7010 User manual

Inspired Design
The OptiPlex 7010 is designed to seamlessly integrate into
the oce environment. Choose from four dierent chassis
that are all optimized to maximize desk space: mini-tower,
desktop, small form-factor, and ultra small form-factor. In
addition, two All-in-One stand solutions enable deployment
as a single device with up to 24” displays.
With a robust metal chassis that has undergone intense
Highly Accelerated Life testing, the OptiPlex 7010 is
designed for ultimate durability and reliability. Color-coded
highlight tool-less accessible system components and grip
points make the system easy to service and deploy.
Dell OptiPlex desktops are engineered to respect our planet
and oer services that help minimize energy consumption
and recycle. Dell provides recyclable packaging, and
OptiPlex systems have a minimum of 10% post-consumer
recycled plastic enclosure and oer highly ecient power
supply options.
Smart Productivity
Unleash workforce productivity with performance features
that fit specific needs. Users can power through their day
with the latest Intel® Core™ i processors, high-speed
memory options, and Intel HD graphics.
Users can connect and communicate with colleagues around
the world with wireless connectivity options, front microphone
and headset mini-jacks for voice-over-IP, and Microsoft Unified
Communications support for optimal video conferencing.
Maximize productivity with intuitive design features that
adapt to unique work styles, including support for up to
three digital native monitors and up to four front USB ports.
Business-Class Control
Manage your OptiPlex 7010 easily with the latest Intel®
vPro systems management iAMT 8.x, which helps deliver
seamless out-of-band management with Dell KACE1
appliances or a leading client management solution.
Driver and image commonality across form factors further
simplifies management.
Confidently safeguard data with Dell Data Protection
software, Trusted Platform Module (TPM)2, encrypted
hard drive options, and optional biometric authentication
peripherals. Physical lock slot and lockable port cover and
desk mount further help protect your system.
Dell OptiPlex long lifecycles, managed transitions, and
ImageWatch™ advance look at software and hardware
changes help ensure long-term stability so you can
confidently plan for the future.
Finally, rely on Dell Services to configure, deploy, manage,
and support your OptiPlex desktops for their entire lifecycle,
including reselling or recycling when they reach end of life.
Integrated Solutions
Dell oers tailored solutions for cost eective security,
management, and end-user productivity.
Dell Data Protection | Encryption1oers a single solution
for flexible data encryption across your network and
removable media. One-touch preset compliance policy
templates enable fast deployment, and the solution
delivers the highest level of Federal Information Processing
Standards 140-2 certification commercially available with
the optional Hardware Encryption Accelerator.
Dell Desktop Virtualization Solutions provide a datacenter
infrastructure to improve data security, streamline
management, and speed time to value with purpose-built
hardware, software and services for client virtualization.
Dell’s services and flexible delivery models help define and
implement the right solution for your needs.
Dell systems management solutions help you centralize
management, automate processes, and reduce support costs.
Each client system comes with a complete set of utilities
to enable industry-leading consoles, like Microsoft System
Center tools, to better deploy, configure, manage, and update
those devices. Dell also oers KACE1appliances to help
seamlessly manage endpoints or Dell Services to help define
and implement the right client management solution for your
unique needs.
Dell Cloud Solutions help you ooad select IT workloads and
adopt an on-demand, pay-as-you-go model that scales with
your organization. Automate manual or resource intensive
tasks such as email management and crisis management and
alerting.
Dell OptiPlex 7010
The Dell™OptiPlex™7010 business client desktop delivers right-sized performance, security and
manageability features to match your productivity needs.

Discover professional class desktops at Dell.com/OptiPlex
1. Oering may vary by region.
2. TPM: TPM is not available in all regions.
3. Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescriptions.
4. System Memory and Graphics: Significant system memory may be used to support graphics, depending on system memory size and other factors.
5. 4GB or Greater System Memory Capability: A 64-bit operating system is required to support 4GB or more of system memory.
6. Hard Drive: GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
7. PSU: This form factor utilizes a more ecient Active Power Factor Correction (APFC) power supply. Dell recommends only Universal Power Supplies (UPS) based on Sine Wave output
for APFC PSUs, not an approximation of a Sine Wave, Square Wave, or quasi-Square Wave (see UPS technical specifications). If you have questions please contact the manufacturer to
confirm the output type.
8 Computrace: Not a Dell oer. Certain conditions apply. For full details, see terms and conditions at www.lojackforlaptops.com.
9. Systems Management Options:
• Intel® vPro Technology - Fully vPro-capable at point of purchase; the vPro systems management option requires vPro processors. Includes support for Intel Advanced
Management Technology (AMT) 8.x.
• Intel® Standard Manageability - Fully enabled at point of purchase, the Intel Standard Management option is a subset of the AMT features. ISM is not upgradeable to vPro
technology post-purchase.
• No Out-of-Band Systems Management - This option entirely removes Intel out of band systems (OOB) management features. The system can still support in band management.
OOB management support through AMT cannot be upgraded post-purchase.
10. Limited Hardware Warranty: For copy of Ltd Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or see www.dell.com/warranty.
11. Next Business Day Onsite Service after Remote Diagnosis: Remote Diagnosis is determination by online/phone technician of cause of issue; may involve customer access to inside
of system and multiple or extended sessions. If issue is covered by Limited Hardware Warranty (www.dell.com/warranty) and not resolved remotely, technician and/or part will be
dispatched, usually within 1 business day following completion of Remote Diagnosis. Availability varies. Other conditions apply.
12. 3rd generation CPUs natively support 3 displays with the integrated CPU graphics. Three simultaneous display output requires one DP port with a maximum resolution of 2500x1600
at 60Hz refresh rate and a DP and VGA port with max resolutions of 1920x1200 at 60Hz refresh rates.
13. Please refer to www.epeat.net for specific country registration rating and participation.
Feature Technical Specication
Processors1, 12 Intel® 3rd generation Core™ i7/i5 Quad Core, i3 Dual Core (Post launch) and Pentium® Dual Core (Post launch);
Intel® 2nd generation Core™ i3 Dual Core, Pentium® Dual Core and Celeron® Dual/Single Core;
Intel vPro™ Technology available on select processors
Chipset Intel® Q77 Express Chipset
Operating System Options1Microsoft® Windows 7® Home Basic (32/ 64 bit) (select countries), Microsoft® Windows 7® Home Premium (32/64 bit),
Microsoft® Windows 7® Professional (32/64 bit), Microsoft® Windows 7® Ultimate (32/64 bit)
Ubuntu® Linux (select countries)
Graphics Options4, 12 Integrated Intel® HD Graphics 2500/4000 (3rd generation Core i3/i5/i7 CPUs); Integrated Intel® HD Graphics 2000/3000 (2nd
generation Core i3 CPUs); Integrated Intel® HD Graphics (Celeron®/Pentium® Dual Core CPU);Optional discrete 1GB AMD
RADEON HD 7570; Optional discrete 1GB AMD RADEON HD 7470
Memory5Up to 4 DIMM slots (2 for USFF); Non-ECC dual-channel 1600MHz DDR3 SDRAM, up to 16GB
Networking Integrated Intel® 82579LM Ethernet LAN 10/100/1000; optional Broadcom® NetXtreme® 10/100/1000 PCIe card; optional Dell
Wireless 1530 PCIe (MT/DT/SFF) WLAN card (802.11n); optional Dell Wireless 1530 half-mini PCIe (USFF) WLAN card (802.11n)
I/O Ports12 4 External USB 3.0 ports (2 front, 2 rear) and 6 External USB 2.0 ports (2 front, 4 rear, except USFF – 4 rear only) and 2 Internal
USB 2.0 (MT/DT only); 1 RJ-45; 1 Serial; 1 VGA; 2 DisplayPort; 2 PS/2 (MT/DT/SFF only); 2 Line-in (stereo/microphone), 2 Line-out
(headphone/speaker), optional Parallel/Serial port support (MT/DT/SFF only), optional 1394a PCI card (MT/DT only)
Removable Media Options DVD+/-RW; DVD-ROM; Dell 19 in 1 Media Card Reader (MT & DT only)
Hard Drives6 Options 3.5” Hard Drives: up to 1TB 7200 RPM SATA;
2.5” Hard Drives: up to 500GB 7200 RPM SATA; 500GB Hybrid; 320GB 7200 RPM Opal SED, 128GB Solid State Drive;
Supports Dell’s Flexible Computing Solution diskless option
Chassis Minitower (MT) Desktop (DT) Small Form Factor (SFF) Ultra Small
Form Factor (USFF)
Dimensions
(H x W x D)
Inches/(cm)
14.2 x 6.9 x 16.4 /
(36.0 x 17.5 x 41.7) 14.2 x 4.0 x 16.1 / (36.0 x 10.2 x 41.0) 11.4 x 3.7 x 12.3 / (29.0 x 9.3 x 31.2) 9.3 x 2.6 x 9.4 / (23.7 x 6.5 x 24.0)
Min. Weight (lbs/
kg) 20.68 / 9.4 17.38 / 7.9 13.2 /6.0 7.26 / 3.3
Number of Bays 2 internal 3.5”
2 external 5.25” 1 internal 3.5” 1 external 5.25” 1 internal 3.5” 1 external 5.25” (slimline) 1 internal 2.5” 1 external 5.25” (slimline)
Expansion Slots 1 full height PCIe x16
1 full height PCIe x16
(wired x 4)
1 full height PCIe x1
1 full height PCI
1 half height PCIe x16
1 half height PCIe x16
(wired x 4)
1 half height PCIe x1
1 half height PCI
1 half height PCIe x16
1 half height PCIe x16
(wired x 4)
1 miniPCIe connector
Power Supply7
Unit (PSU) Standard 275W PSU Active PFC or optional
275W up to 90% Ecient
PSU (80 PLUS Gold);
ENERGY STAR 5.2
compliant, Active PFC
Standard 250W PSU
Active PFC or optional
250W up to 90% Ecient
PSU (80 PLUS Gold);
ENERGY STAR 5.2
compliant, Active PFC
Standard 240W PSU
Active PFC or optional
240W up to 90% Ecient
PSU (80 PLUS Gold);
ENERGY STAR 5.2
compliant, Active PFC
200W up to 90% Ecient
PSU (80 PLUS Gold);
ENERGY STAR 5.2
compliant, Active PFC
Peripherals Options1Monitors1:
Dell Entry Standard and Widescreen Flat Panel Analog:
Dell E170S, E190S, E1911, E1912H, E2011H, E2210, E2211H, E2311H
Dell Professional Digital Standard and Widescreen Flat Panel:
Dell P170S, P190S, P1911, P2012H, P2210, P2212H, P2312H, P2412H, P2712H
Dell UltraSharp Digital Standard and Widescreen Flat Panel, Adjustable Stand:
Dell 2007FP, U2212HM, U2312HM, U2410, U2412M, U2711, U3011
Keyboards: Dell USB Entry Keyboard, Dell Multimedia Pro Keyboard, Dell Smartcard Keyboard
Mouse: Dell USB Optical Mouse, Dell Laser Mouse
Audio Speakers: Internal Dell Business audio speaker, Dell AX210 2.0 Desktop Speakers; Dell AX510 and AX510PA Sound Bar
Security Options1Trusted Platform Module2 (TPM) 1.2, Dell Data Protection Access, Dell Data Protection Encryption, Chassis lock slot support, Chassis
Intrusion Switch, Setup/BIOS Password, I/O Interface Security, optional Smart Card keyboard, Intel® Trusted Execution Technology,
Intel® Identity Protection Technology, Intel® Anti-Theft Technology, Dell Secure Works, BIOS support for optional Computrace8
Systems Management
Options9
Intel® vPro Technology (iAMT 8.0) ) including Dell unique vPro extensions; Intel® Standard Manageability; No Out of Band Systems
Management
Environmental & Regulatory
Standards
Environmental Standards (eco-labels): ENERGY STAR 5.2, EPEAT Registered13, CECP, WEEE, Japan Energy Law, South Korea
E-standby, South Korea Eco-label (for DT/SFF/USFF only), EU RoHS, China RoHS
Other Environmental Options: Carbon O-set; Asset Resale and Recovery Service
Warranty ans Service Limited Hardware Warranty10; Standard 3-year Next Business Day On Site Service after Remote Diagnosis11 (3-3-3); Optional 3-year
Dell ProSupport™; 4 year and 5 year service and support options3
Configuration Services Factory Image load. BIOS Customization. Hardware Customization, Asset Tagging and Reporting.
