OptiPlex 740
Reviewer’s Guide
Contact:
Name:
Phone:
Fax:
E-Mail:
Visit: www.dell.com/optiplex

• Positioning Section 3, 4
– Dell™ OptiPlex™ Brand positioning 3
– OptiPlex 740 Product positioning 4
• New Product Messages 5 – 12
– Power Efficiency 5, 6
– Smart Security 7, 8
– Remote Control 9, 10
– Direct Deploy 11, 12
• Product Specifications 13 - 16
TABLE OF CONTENTS

Dell OptiPlex™ Desktops
Enabling Business Momentum
Technology and Partnership that deliver More Function, Less Friction
Business doesn’t stand still. Neither does technology. However, many different
business and technology challenges can create unnecessary friction for your
organization — slowing you down and even preventing you from reaching your
strategic goals.
Dell OptiPlex desktops are designed to eliminate much of the complexity and
hassles that can get in your way. At the same time, OptiPlex delivers the
performance and usability you need to move your business forward, faster and
more efficiently
Dell OptiPlex™ desktops help:
•Simplify operations by removing bottlenecks so IT can focus on higher-value
activities
•Improve productivity by helping end users get more done in less time
• Deliver Cost-effective solutions through lower lifecycle costs and a hassle-
free direct relationship
Delivering more function, less friction —at every stage of the product
lifecycle
• Planning - Helping you make informed IT decisions
• Acquisition - Streamlining procurement, assuring image stability
• Deployment - Simplifying image management and customization
• Active life - Delivering:
– Outstanding reliability and ease-of-management
– Rock-solid security with flexible options
– Advanced end-user productivity features
• Disposal/refresh - Providing asset recovery and recycling programs,
environmental leadership
Overview – Brand Positioning
*See page 47 for important information

The New OptiPlex 740:
A Solid New Platform for Business-Class Computing
• The new OptiPlex™ 740 is for IT customers who are looking
for choice in a business PC designed to scale to their
operational needs incorporating the latest relevant
technologies that help deliver lower lifecycle costs and a
better ownership experience.
• The new OptiPlex is designed to simplify operations, improve
productivity and deliver cost effective solutions.
• System Naming
– Dell OptiPlexTM
•Dell
• OptiPlex
• 740
• OptiPlex 740: Business Mainstream
• OptiPlex 740 Positioning
– The OptiPlex 740 is a scalable mainstream solution designed for
those customers who value relevant technologies that help
reduce ownership cost. The OptiPlex 740 is configurable with a
wide range of options including systems management support,
AMD X2 processor performance, unique security features,
graphics support and much more. It is designed to deliver
ownership cost savings from the time the order is placed with
solutions such as Dell Advanced Configuration Services (ACS) to
systems management (with ASF 2.0) and unique chassis
designs (BTX and DirectDetect™).
Overview – Product Positioning

OptiPlex 740 - Power Efficiency
Through intuitive design and performance-driven technology, Dell OptiPlex
desktops deliver outstanding capabilities in the most efficient design possible.
In addition, we pack every system with business-relevant features built on
direct feedback from customers just like you. The result? Higher productivity
and greater effectiveness, across the board.
Superior Power Efficiency and Performance
The latest dual-core technology improves performance while consuming less power than
previous-generation processor technology (single- or dual-core). With next-generation
OptiPlex systems, you’ll continue to enjoy enhanced multitasking with the power to run
multiple and multi-threaded applications — all with industry-leading power efficiency.
• Up to 70% energy savings vs. previous generation OptiPlex platforms
• Up to 11% performance increase with dual core processors vs. single core
Dell Energy Saver — Going above and beyond
OptiPlex desktops take power management to the next level with power settings that exceed
government regulations. That means your system will consume even less power than the
government allows — helping conserve the earth’s resources as well as your bottom line.
• Get ENERGY STAR® compliance out of the factory, meeting all regulatory
requirements
• Maximize power management — The BIOS is pre-set to go into sleep state at 15
minutes of inactivity (vs. ENERGY STAR specs of 30 minutes)
• Energy Efficient Power Factor Correcting (PFC) Power Supplies - High efficiency
power supplies designed to reduce wasted power in the PC and power grid. These
power supplies use power more efficiently and require less line current. This saves
energy costs and reduces the likelihood of power draws which may trip an electrical
breaker. (When compared to some "consumer" PC power supplies, line current may
be reduced 12% or more)
• Optimize system-level power consumption through intelligent CPU technologies —
AMD Cool’n’Quiet™ Technology balances power usage with application demands on
the processor
* See important information on page 17

OptiPlex 740 - Power Efficiency (cont)
Efficient, Reliable BTX Design
All OptiPlex models are built on the thermal-efficient BTX
form factor and packed with additional features that help
ensure quality and thermal reliability.
• Enjoy better reliability and quieter, cooler operations:
– Dell BTX chassis, power supply and motherboards are
uniquely designed to manage heat throughout the system
– HyperCool™ thermal-management technology uses variable
speed fans for additional cooling, while using less power and
generating less noise
– New Ambient Thermal Sensor — Measures the incoming
ambient air temperature to appropriately control internal
cooling and helps improve thermal reliability
– More thermally robust components — Going beyond
industry standards by defining more stringent temperature
specifications for capacitors and hard drive casings to
improve thermal reliability
• Ensure a seamless user experience — Hardened power
supplies offer brown-out circuitry and line-surge protection
to help minimize stress on power supply and provide black-
out protection
Continued design improvements
• Thanks to our “closed-loop” cycle of improvements, the
next generation of OptiPlex platforms will deliver even
further quality and reliability enhancements. In addition to
the thermal-efficiency features mentioned above, we’ve
added vibration-dampening features to the hard-disk drive,
which help offset unbalanced media for better acoustics
and reliability.

OptiPlex 740 - Smart Security
Every organization has different security needs. That’s why Dell offers
comprehensive yet flexible security options — so you can choose the hardware
and software building blocks you need to keep your vital systems and data
protected. And even though we customize to meet your unique requirements,
all of our offerings are built on industry standards, to help ensure you get safe,
proven and easily integrated technology.
Physical Defenses
• Chassis loop lock support (with cable locks available)
• Chassis intrusion & configuration alerting
• Asset tagging & recovery services
• CompuTrace® PC theft recovery
Identity & Data Security
• Wave EMBASSY® Trust Suite
• Log-on authentication
• Cutting-edge PC, user, system and data authentication safeguards based on
Trusted Platform Module (TPM) 1.2
• BIOS passwords
• Biometric fingerprint and Smart card readers
• Hard-disk-drive encryption software
• Altiris® Local Recovery™ backup and recovery
• “Keep Your Hard Drive” services
PC Threat Defense
• PC firewall software
• Anti-virus software
• Anti-spyware software
• Anti-spam software
Multilayered Network Security
• Firewalls/VPN
• Streamlined patch management
• Thorough data backup & recovery

OptiPlex 740 - Smart Security (cont)
Wave EMBASSY® Trust Suite
Wave Systems’ EMBASSY Trust Suite (ETS) is a set of trusted client
applications that delivers advanced security functionality, including:
• Superior VPN log-on security rooted to the TPM
• Advanced standards-based password protection and automation with
Private Information Manager and Trusted Platform Module (TPM) chip
hardware
• Enhanced data protection via Document Manager’s file and folder
encryption
• Login security with multi-factor authentication via the Wave EMBASSY
Security Center
• Including: Fingerprint Biometrics, Smart Cards, TPM and PKI
• Secure email and wireless authentication through TPM authentication
• Built-in private key infrastructure (PKI) support
• Available key recovery and migration capabilities
• Available VPN security package for enabling log-in security
ETS is easy to use, thanks to automated features, wizards and Microsoft®
integration. And because the solution includes digital certificates, it can be
used right out of the box. ETS is also fully compatible with the Enterprise
Version, enabling seamless integration for enterprise-wide security.

OptiPlex 740 - Remote Control
Dell OptiPlex™ desktops help simplify operations with new remote-management
capabilities. Using the latest advanced tools, you’ll gain convenient control over and
greater visibility into your computing environment. As a result, IT can be much more
efficient and effective, with more bandwidth to focus on higher-value activities.
New Dell Client Manager Standard (DCM)
Our new cutting-edge software tool for centralized hardware management is available for
download at no charge for Dell OptiPlex customers. Dell Client Manager Standard empowers your
IT department to deploy, manage and troubleshoot Dell client systems across your entire
organization — from a single console — whether the operating system on the target PC is present
or not.
Using DCM’s integrated, enterprise-ready management console, IT can:
• Remotely identify, inventory and add computers to the pool of managed resources
• Remotely configure or update the BIOS of multiple computers simultaneously (with or
without an agent)
• Monitor the subsystems of important computers
• Assess need and readiness for a hardware refresh or OS migration
• Automatically send hardware trouble-ticket incident reports to help-desk personnel
• Remotely push the client agent to systems as needed, rather than having the manage
the agent within an image
Secure Remote Power Control
With Alert Standard Format (ASF) 2.0, this added feature enables IT to remotely power up,
power down and recycle systems in order to streamline provisioning, improve software
patching and enhance security and reliability. The result? Even more efficient and effective
IT, with far fewer desk-side visits.
Dell Client Manager Standard is a direct result of customer experience with our OpenManage™
client-management solutions. Driven by your feedback, DCM 2.0 integrates all the different
OpenManage components into one powerful tool, a single download and just one enhanced user
interface.
DCM Standard integrates the following OpenManage components into one console:
• Dell Client Configuration Utility (DCCU)
• OpenManage Client Instrumentation (OMCI)
• IT Assistant (ITA)
• OpenManage Client Connector (OMCC)

OptiPlex 740 - Remote Control (cont)
Extend your remote-management capabilities with DCM Plus and Altiris®
Client Management Suite
Dell Client Manager is available in three levels to fit different needs. Each one builds on the
previous solution with additional capabilities, yet uses the same familiar interface, the same
database and the same management agent. Through this stair-step approach, you can
secure the right functionality for your current needs and add more when you’re ready. With
Dell and Altiris, it’s easier than ever to gain the benefits of centralized, automated client
management for your organization.
• DCM Standard = Centralized hardware management
• DCM Plus = DCM Standard + fundamental software deployment/distribution, PC
migration and inventory capabilities
• Altiris Client Management Suite = DCM Plus + Alitiris’ most advanced software
management tools
Dell Client Manager (DCM) Plus
This fee-based upgrade adds fundamental software-management capabilities on top of
DCM Standard functionality. With DCM Plus, IT can:
• Migrate users to a new computer or operating system
• Remotely image a new computer or re-image an existing computer
• Remotely distribute and install software
• Create software packages for remote distribution
• Scan computers for detailed operating system and application inventory
information
• Take control of a computer on a LAN
Altiris Client Management Suite (CMS)
As a fee-based upgrade to DCM Plus, Altiris CMS delivers highly automated, policy-driven
hardware and software management. In addition to DCM Plus capabilities, Altiris CMS
empowers IT to:
• Ensure all computers are compliant with published security patches
• Track the distribution usage of software licenses
• Establish and enforce software-application usage policies

OptiPlex 740 - Direct Deploy
Image management and customization are simple, thanks to Dell Direct Deploy
Services. Through our unique stepping-stone approach, you can choose the
level of customization that best suits your needs — helping to ensure flexibility,
making the most of your budget and scaling to meet your deployment needs as
your business grows.
New! Advanced Configuration Services
Designed to simplify system customization and help speed up deployment by reducing
repetitive IT tasks, Advanced Configuration Services (ACS) costs a fraction of what it would
take to configure your systems internally or use an external vendor.
• Modify and customize standard OS image and configurations of systems quickly
and easily — during the purchase process.
• Select just the configurations you need, which are included in your systems’
Hardware Limited Warranty1
• No minimum order quantities, so you can use ACS for just one or up to 100
systems
Level 1 Level 2 Level 3 Level 4
New Advanced
Configuration
Services
Imaging Services Custom Factory
Integration Managed Deployment Services
Web-based service
lets you configure
BIOS settings, OS
components, hard
drive partitions and
more during the
ordering process
Integrated suite to
help you develop,
validate, maintain
and deploy standard
corporate images on
any new Dell client
system
Service that
integrates hardware,
images, applications
and peripherals with
your systems as
they're being built
Comprehensive and
customizable
deployment services
along with a single
point of contact.

OptiPlex 740 - Direct Deploy (cont)
Having standardized images that are built for your specific departments, field offices, or
regions, can significantly simplify and accelerate system deployment. Dell Imaging
Services can help by providing the expertise to develop, test, maintain and deploy your
custom images. It is possible to utilize solutions such as one-touch factory integration, which
helps minimize errors, and reduce PC deployment times.
• Dell imaging experts use Microsoft® Sysprep, to script and provide cross-platform
imaging for all of your Dell client systems.
• Industry changes, such as driver updates, can be automatically added to images.
• Using Dell’s X-image technology, we are able to build a single image which can be
run on any Dell computer in your environment. You may even choose to modify
this image, to be utilized on computers from other manufacturers.
Designed for companies and organizations ordering larger quantities of systems, Dell
Custom Factory Integration (CFI) enables you to build systems that meet your exact
operational and organizational needs. A CFI representative will guide you through the
process of having custom hardware, software and peripheral integrated into your new
systems as they are being built.
• Your systems arrive customized and ready to use, thereby speeding up
deployment
• Factory integration helps reduce installation errors and improve consistency
• Add custom asset tags and include documentation, parts, media, computer locks,
and other components in system box
Our managed deployment services utilize Dell factory integration and deployment
services to simplify the purchase and deployment of your end-user systems. These services
are designed to lower your total cost-of-ownership by improving efficiencies and helping
your users start using their new systems as quickly as possible.
• Simplify system refreshes, in a single or multiple locations
• Deployment and managed client services include custom delivery, asset tracking
and tagging, installation, asset management, service desk, and field service for
moving, adding, changing or repairing systems
• Offers application packaging services, including inventory, packaging, remediation,
and distribution
• Residual value on used system that are resold are returned to you; obsolete
computer equipment is responsibly recycled

740 Specifications
OptiPlex 740 – Technical Specifications
* See important information on page 17

740 Specifications
* See important information on page 17
OptiPlex 740 – Technical Specifications

740 Specifications
OptiPlex 740 – Technical Specifications
* See important information on page 17

740 Specifications
OptiPlex 740 – Technical Specifications
* See important information on page 17

Benchmarks
Based on 3DMark05 and Sysmark 2004 SE Office Productivity benchmark tests performed
by Dell Labs in August 2006 on OptiPlex 740 with AMD® Athlon 64 X2 CPU, DDR2 1GB
(dual channel) memory, 80GB 7200 SATA HDD, NVIDIA integrated graphics and XP Pro
SP2 OS, compared with the OptiPlex GX620 with Intel Pentium D 830 CPU, 80GB 7200
SATA HDD, Intel 945G integrated graphics, and XP Pro SP2 OS. Actual performance and
power consumption will vary based on configuration, usage and manufacturing variability.
Dell Limited Warranty
For a copy of our guarantees or limited warranties, please write Dell USA L.P., Attn:
Warranties, One Dell Way, Round Rock, TX 78682. For more information, visit
www.dell.com/warranty.
Shared Memory
Between 64 MB and 512 MB of system memory may be allocated to support integrated
graphics, depending on system memory size and other factors.
Dual-Channel Memory
Dual-channel memory requires t2 each of the same capacity memory DIMMS.
Memory Key
For writeable storage devices, MB means 1 million bytes; total accessible capacity varies
depending on operating environment.
Desktops configured with 4GB of memory or more
The total amount of available memory will be less that than 4 GB. The amount less depends
on the actual system configuration. To fully utilize 4GB or more of memory requires a 64-bit
enabled processor and 64-bit Operating System.
Hard Drive Size
For hard drives, GB means 1 billion bytes; actual capacity varies with preloaded material and
operating system and will be less.
DVD+/-RW Drives
Discs burned with this drive may not be compatible with some existing drives and players;
using DVD+R media provides maximum compatibility.
DVD-ROM
DVD-ROM drives may have write-capable hardware that has been disabled via firmware
modifications.
On Site Service
Service may be provided by third-party. Technician will be dispatched if necessary following
phone-based troubleshooting. Subject to parts availability, geographical restrictions and
terms of service contract. Service timing dependent upon time of day call placed to Dell. U.S.
only.
Important Information
