Dell Latitude 3000 Series User manual

Dell™ Latitude™ 3000 Series
Technical Guidebook
Model 3450 & 3550
December 2014
Specific features/models/configs/options discussed in this document may not be available WW

Table of Contents
Product
View and Technical Specifications 3–
11
Weight and Dimensions 4-
5
Technical Specifications 6-
11
Marketing Configurations
12-
17
Operating System
13
Processors 14-
15
Memory
16
Primary Storage and Intel Rapid Start
Technology
17
Connectivity Options
18
Detailed Technical Overview
and
Configuration Specifications
19-
52
Storage 20-
23
Memory
24
Ports and Connectors
25
Web Cam Specifications
26
Wireless Communications (WLAN) 27-
34
Wired Communications
35
Security
36
Integrated Graphics Controller
37
Discrete Graphics Controller
38
Display 39-
44
Battery Specifications
45
Power Adapters 46-
47
Keyboard
48
Keyboard Hot Key Definition
49
Touchpad Specifications
50
Environmental Specifications
51
MIL-STD 810G Testing
52

Dell Latitude 3000
Series
Product Views and
Technical
Specifications
3
Specific features/models/configs/options discussed in this document may not be available WW

Latitude 14 3000 Weight, Dimensions, All Views
4
Starting weight:
1.9 kg (4.2 lbs) with 3-cell
Dimensions:
Width: 342.0 mm
Depth: 245.9 mm
Height:
touch 23.0 mm
non-touch 22.2 mm
1.Microphones
2.Camera-status light
3.Camera
4.Power button
5.VGA connector
6.Network connector
7.HDMI connector
8.USB 3.0 connectors (2)
9.Headset connector
10.Touchpad
11.Finger print reader (optional)
12.Speakers
13.Power-status light
14.Battery-status light
15.Memory-card reader
16.USB 2.0 connector
17.Power connector
18.Security-cable slot
19.Service-tag label

Latitude 15 3000 Weight, Dimensions, All Views
5
Starting weight:
2.2 kg (4.9 lbs) with 3-cell
Dimensions:
Width: 380.4 mm
Depth: 258.95 mm
Height:
touch 23.2 mm
non-touch 22.3 mm
1.Microphones
2.Camera-status light
3.Camera
4.Power button
5.VGA connector
6.Network connector
7.HDMI connector
8.USB 3.0 connectors (2)
9.Headset connector
10.Touchpad
11.Finger print reader (optional)
12.Speakers
13.Power-status light
14.Battery-status light
15.Memory-card reader
16.USB 2.0 connector
17.Power connector
18.Security-cable slot
19.Service-tag label

6
Dell Latitude 14 3000 Series Technical Specifications
Feature
Technical Specification (4th Generation
Intel®Sept 2014 - April 2015)
Technical Specification (5th Generation
Intel®January 2015 - April 2016)
Series/Model Number
Latitude 14 3000 Series (3450)
Latitude 14 3000 Series (3450)
Processor
Options
4th Generation Intel® Core i3/i5 Processors
5th Generation Intel® Celeron, Core™ up to i7 processors
Operating System
Microsoft® Windows® 7 Professional 32/64 bit
Microsoft® Windows® 7 Professional 32/64 bit
Microsoft® Windows® 7 Professional 32/64
-bit (available through downgrade
rights from Windows® 8.1 Pro 64
-bit)
Microsoft® Windows® 7 Professional 32/64
-bit (available through
downgrade rights from Windows® 8.1 Pro 64
-bit)
Microsoft® Windows® 8.1 64
-bit
Microsoft® Windows® 8.1 64
-bit
Microsoft® Windows® 8.1 Pro 64
-bit
Microsoft® Windows® 8.1 Pro 64
-bit
Microsoft® Windows® 8.1 Single Language 64
-bit
Microsoft® Windows® 8.1 Single Language 64
-bit
UBUNTU Linux 14.04 LTS (64
-bit)
UBUNTU Linux 14.04 LTS (64
-bit)
Memory
2,4 Options
DDR3L SDRAM 1600MHz; 2 slots supporting up to 4GB
1
DDR3L SDRAM 1600MHz; 2 slots supporting up to 16GB
1
Chipset
Integrated with the Processor (Lynx Point LP)
Integrated with the processor (Wildcat Point
-LP)
Graphics
Intel® Integrated HD Graphics 4400 (Core x
- 4th Gen)
Nvidia® GeForce® 830M
Intel® Integrated HD Graphics (Celeron)
Intel® Integrated HD Graphics 5500 (Core x
- 5th Gen)
Nvidia® GeForce® 830M
Display
14.0” HD (1366 x 768) Anti Glare (16:9) WLED
14.0” HD (1366 x 768) Anti Glare (16:9) WLED
14.0” FHD (1920 x 1080) Anti Glare (16:9) WLED
14.0” HD Touch with Corning® Gorilla® Glass NBT (1366 x 768) (16:9) WLED
Storage
4Options
500GB 7200RPM Hard Disk Drive
500GB 7200RPM Hard Disk Drive
500GB 5400 RPM Hybrid Drive (8GB Cache)
500GB 5400 RPM Hybrid Drive (8GB Cache)
1TB 5400RPM Hard Disk Drive
1TB 5400RPM Hybrid Drive (8GB Cache)
Security
1
DDP|Security
Tools
DDP|Protected
Workspace (1 year)
Optional DDP|E Encryption Software
Optional Computrace
8
DDP|Security
Tools
DDP|Protected
Workspace (1 year)
Optional DDP|E Encryption Software
Optional Computrace
8
Docking Options
USB Docking Only
USB Docking Only
Optical Drive Options
External Options Only
External Options Only
Multimedia
High Quality Speakers
High Quality Speakers
Universal Headphone Jack
Universal Headphone Jack
Integrated digital array microphone
Integrated digital array microphone
Integrated 1.0mp HD video webcam
Integrated 1.0mp HD video webcam

7
Dell Latitude 14 3000 Series Technical Specifications
Feature
Technical Specification (4th Generation Intel®Sept 2014
- April 2015)
Technical Specification (5th Generation Intel®January 2015
- April 2016)
Series/Model Number
Latitude 14 3000 Series (3450)
Latitude 14 3000 Series (3450)
Battery Options
4 cell 58
Whr Li-Ion (Prismatic cell) with ExpressCharge™
3 cell 43
Whr Li-Ion (Prismatic cell) with ExpressCharge™
4 cell 58
Whr Li-Ion (Prismatic cell) with ExpressCharge™
Power Options
65 Watt or 90 Watt E4 AC Adapter
65 Watt or 90 Watt E4 AC Adapter
Connectivity options
1
10/100/1000 Gigabit Ethernet
10/100/1000 Gigabit Ethernet
Wireless LAN Options:
Wireless LAN Options:
Intel 7265 2x2 dual band 802.11 AGN with BT Combo Card
Intel 7265 2x2 dual band 802.11 AGN with BT Combo Card
No Mobile Broadband Options
Dell Wireless 1707 1x1 single band 802.11n + BT 4.0
No Mobile Broadband Options
Ports, Slots & Chassis
Memory card reader
Memory card reader
2 USB 3.0, 1 USB 2.0, HDMI, VGA
2 USB 3.0, 1 USB 2.0, HDMI, VGA
Network connector (RJ
-45)
Network connector (RJ
-45)
Optional Fingerprint Reader
Optional Fingerprint Reader
Lock slot
Lock slot
Dimensions & Weight
7
Width: 13.46” / 342.0mm
Width: 13.46” / 342.0mm
Height: .87“ / 22.2mm (non
-Touch); .9” / 23.0mm (Touch)
Height: .87“ / 22.2mm (non
-Touch); .9” / 23.0mm (Touch)
Depth: 9.68” / 245.9mm (non
-Touch); 9.69" / 246.1mm (Touch)
Depth: 9.68” / 245.9mm (non
-Touch); 9.69" / 246.1mm (Touch)
Starting weight: 4.2lbs / 1.9kg (with 3
-cell battery)
Starting weight: 4.2lbs / 1.9kg (with 3
-cell battery)
Regulatory and Environmental Compliance
Regulatory Model: P51G
Regulatory Model: P51G
Regulatory Type: P51G001
Regulatory Type: P51G001
ENERGY STAR 6.0 (includes Windows and Ubuntu OS)
ENERGY STAR 6.0 (includes Windows and Ubuntu OS)
EPEAT Registered. For specific country participation and rating,
please visit www.epeat.net
EPEAT Registered. For specific country participation and rating,
please visit www.epeat.net
Input
Single Pointing non
-backlit keyboard
Single Pointing non
-backlit keyboard
Optional Single Pointing backlit keyboard
Optional Single Pointing backlit keyboard
Clickpad Touchpad
Clickpad Touchpad
Peripheral Ecosystem
1
Dell Monitor Stand with Port Replicator, Dell 22” or 24” Monitor, Dell Wireless
Keyboard & Mouse, Dell Professional Topload Carrying Case
Dell Monitor Stand with Port Replicator, Dell 22” or 24” Monitor, Dell
Wireless Keyboard & Mouse, Dell Professional Topload Carrying Case
Warranty and Service
Limited Hardware Warranty
3; Standard 1-year On Site Service after Remote
Diagnosis
5(3-3-3); Optional 3-year Dell ProSupport™ for IT6; 4 year and 5 year
service and support options
6
Limited Hardware Warranty
3; Standard 1-
year On Site Service after Remote
Diagnosis
5(3-3-3); Optional 3-year Dell ProSupport™ for IT6; 4 year and 5
year service and support options
6

8
Dell Latitude 14 3000 Series Technical Specifications
Feature
Technical Specification (4th Generation Intel®Sept 2014
- April 2015)
Technical Specification (5th Generation Intel®January 2015
- April 2016)
Series/Model Number
Latitude 14 3000 Series (3450)
Latitude 14 3000 Series (3450)
1 Offering may vary by country and by configuration
2
A 64-bit operating system is required to support 4GB or more of system memory
3 Limited Hardware Warranty: For copy of Limited Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Ro
ck, TX 78682 or see www.dell.com/warranty
4 GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environ
ment and will be less.
5Onsite Service after Remote Diagnosis: Remote Diagnosis is determination by online/phone technician of cause of issue; may in
volve customer access to inside of system and multiple or extended
sessions. If issue is covered by Limited Hardware Warranty (www.dell.com/warranty) and not resolved remotely, technician and/
or part will be dispatched, usually within 1 business day following
completion of Remote Diagnosis. Availability varies. Other conditions apply.
6 Dell Services: Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescri
ptions.
7 Weights vary depending on configuration and manufacturing variability.
8COMPUTRACE Not a Dell offer. Certain conditions apply. For full details, see terms and conditions at www.absolute.com/en/abou
t/legal/agreements.

9
Dell Latitude 15 3000 Series Technical Specifications
Feature
Technical Specification (4th Generation Intel®Sept 2014
- April 2015)
Technical Specification (5th Generation Intel®January 2015
- April 2016)
Series/Model Number
Latitude 15 3000 Series (3550)
Latitude 15 3000 Series (3550)
Processor
Options
4th Generation Intel® Core i3/i5 Processors
5th Generation Intel® Celeron, Core™ up to i7 processors
Operating System
Microsoft® Windows® 7 Professional 32/64 bit
Microsoft® Windows® 7 Professional 32/64 bit
Microsoft® Windows® 7 Professional 32/64
-bit (available through
downgrade rights from Windows® 8.1 Pro 64
-bit)
Microsoft® Windows® 7 Professional 32/64
-bit (available through downgrade rights
from Windows® 8.1 Pro 64
-bit)
Microsoft® Windows® 8.1 64
-bit
Microsoft® Windows® 8.1 64
-bit
Microsoft® Windows® 8.1 Pro 64
-bit
Microsoft® Windows® 8.1 Pro 64
-bit
Microsoft® Windows® 8.1 Single Language 64
-bit
Microsoft® Windows® 8.1 Single Language 64
-bit
UBUNTU Linux 14.04 LTS (64
-bit)
UBUNTU Linux 14.04 LTS (64
-bit)
Memory
2,4 Options
DDR3L SDRAM 1600MHz; 2 slots supporting up to 4GB
1
DDR3L SDRAM 1600MHz; 2 slots supporting up to 16GB
1
Chipset
Integrated with the Processor (Lynx Point LP)
Integrated with the processor (Wildcat Point
-LP)
Graphics
Intel® Integrated HD Graphics 4400 (Core x
- 4th Gen)
Intel® Integrated HD Graphics (Celeron)
Intel® Integrated HD Graphics 4400 (Core x
- 4th Gen)
Intel® Integrated HD Graphics 5500 (Core x
- 5th Gen)
Nvidia® GeForce® 830M
Display
15.6” HD (1366 x 768) Anti Glare (16:9) WLED
15.6” HD (1366 x 768) Anti Glare (16:9) WLED
15.6” FHD (1920 x 1080) Anti Glare (16:9) WLED
15.6” HD Touch with Corning® Gorilla® Glass NBT (1366 x 768) (16:9) WLED
Storage
4Options
500GB 7200RPM Hard Disk Drive
500GB 7200RPM Hard Disk Drive
500GB Solid State Hybrid Drive (8GB Cache)
1TB 5400RPM Hard Disk Drive
1TB Solid State Hybrid Drive (8GB Cache)
Security
1
DDP|Security
Tools
DDP|Protected
Workspace (1 year)
Optional DDP|E Encryption Software
Optional Computrace
8
DDP|Security
Tools
DDP|Protected
Workspace (1 year)
Optional DDP|E Encryption Software
Optional Computrace
8
Docking Options
USB Docking Only
USB Docking Only
Optical Drive Options
External Options Only
External Options Only
Multimedia
High Quality Speakers
High Quality Speakers
Universal Headphone Jack
Universal Headphone Jack
Integrated digital array microphone
Integrated digital array microphone
Integrated 1.0mp HD video webcam
Integrated 1.0mp HD video webcam

10
Dell Latitude 15 3000 Series Technical Specifications
Feature
Technical Specification (4th Generation Intel®Sept 2014
- April 2015)
Technical Specification (5th Generation Intel®January 2015
- April 2016)
Series/Model Number
Latitude 15 3000 Series (3550)
Latitude 15 3000 Series (3550)
Battery Options
4 cell 58 Whr
Li-Ion (Prismatic cell) with ExpressCharge™
3 cell 43 Whr Li
-Ion (Prismatic cell) with ExpressCharge™
4 cell 58 Whr
Li-Ion (Prismatic cell) with ExpressCharge™
Power Options
65 Watt E4 AC Adapter
65 Watt or 90 Watt E4 AC Adapter
Connectivity options
1
10/100/1000 Gigabit Ethernet
10/100/1000 Gigabit Ethernet
Wireless LAN Options:
Wireless LAN Options:
Intel 7265 2x2 dual band 802.11 AGN with BT Combo Card
Intel 7265 2x2 dual band 802.11 AGN with BT Combo Card
No Mobile Broadband Options
Dell Wireless 1707 1x1 single band 802.11n + BT 4.0
No Mobile Broadband Options
Ports, Slots & Chassis
Memory card reader
Memory card reader
2 USB 3.0, 1 USB 2.0, HDMI, VGA
2 USB 3.0, 1 USB 2.0, HDMI, VGA
Network connector (RJ
-45)
Network connector (RJ
-45)
Optional Fingerprint Reader
Optional Fingerprint Reader
Lock slot
Lock slot
Dimensions & Weight
7
Width: 14.98” / 380.4mm
Width: 14.98” / 380.4mm
Height: .88“ / 22.3mm (non
-Touch); .91” / 23.2mm (Touch)
Height: .88“ / 22.3mm (non
-Touch); .91” / 23.2mm (Touch)
Depth: 10.19” / 258.95mm (non
-Touch); 10.2" / 259.2mm (Touch)
Depth: 10.19” / 258.95mm (non
-Touch); 10.2" / 259.2mm (Touch)
Starting weight: 4.9lbs / 2.2kg (with 3
-cell battery)
Starting weight: 4.9lbs / 2.2kg (with 3
-cell battery)
Regulatory and Environmental Compliance
Regulatory Model:
P38F
Regulatory Model:
P38F
Regulatory Type:
P38F001
Regulatory Type:
P38F001
ENERGY STAR 6.0 (includes Windows and Ubuntu OS)
ENERGY STAR 6.0 (includes Windows and Ubuntu OS)
EPEAT Registered. For specific country participation and rating,
please visit www.epeat.net
EPEAT Registered. For specific country participation and rating,
please visit www.epeat.net
Input
Single Pointing non
-backlit keyboard
Single Pointing non
-backlit keyboard
Optional Single Pointing backlit keyboard
Optional Single Pointing backlit keyboard
Clickpad Touchpad
Clickpad Touchpad
Peripheral Ecosystem
1
Dell Monitor Stand with Port Replicator, Dell 22” or 24” Monitor, Dell Wireless
Keyboard & Mouse, Dell Professional Topload Carrying Case
Dell Monitor Stand with Port Replicator, Dell 22” or 24” Monitor, Dell Wireless
Keyboard & Mouse, Dell Professional Topload Carrying Case
Warranty and Service
Limited Hardware Warranty
3; Standard 1-year On Site Service after Remote
Diagnosis
5(3-3-3); Optional 3-year Dell ProSupport™ for IT6; 4 year and 5 year
service and support options
6
Limited Hardware Warranty
3; Standard 1-year On Site Service after Remote
Diagnosis
5(3-3-3); Optional 3-year Dell ProSupport™ for IT6
; 4 year and 5 year service
and support options
6

11
Dell Latitude 15 3000 Series Technical Specifications
Feature
Technical Specification (4th Generation Intel®Sept 2014
- April 2015)
Technical Specification (5th Generation Intel®January 2015
- April 2016)
1 Offering may vary by country and by configuration
2
A 64-bit operating system is required to support 4GB or more of system memory
3 Limited Hardware Warranty: For copy of Limited Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Ro
ck, TX 78682 or see www.dell.com/warranty
4 GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environ
ment and will be less.
5Onsite Service after Remote Diagnosis: Remote Diagnosis is determination by online/phone technician of cause of issue; may in
volve customer access to inside of system and multiple or extended
sessions. If issue is covered by Limited Hardware Warranty (www.dell.com/warranty) and not resolved remotely, technician and/
or part will be dispatched, usually within 1 business day following
completion of Remote Diagnosis. Availability varies. Other conditions apply.
6 Dell Services: Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescri
ptions.
7 Weights vary depending on configuration and manufacturing variability.
8COMPUTRACE Not a Dell offer. Certain conditions apply. For full details, see terms and conditions at www.absolute.com/en/abou
t/legal/agreements.

Marketing System
Configurations
12
Specific features/models/configs/options discussed in this document may not be available WW

Dell Latitude 3000 Series–Operating Systems
Windows 8.1
•
Microsoft® Windows 8.1 Pro 64 bit
•
Microsoft® Windows 8.1 64 bit
•
Microsoft® Windows 8.1 Single Language 64 bit
Windows 7
•
Microsoft® Windows 7 Professional 32/64 bit
Windows Downgrade
•
Microsoft® Windows® 7 Professional 32/64-
bit (available through downgrade rights from
Windows® 8.1 Pro 64-bit)
Other
•
Ubuntu 14.04 LTS (64 bit)
OS Media
Support
•
100% Drop in the box provided for Windows 8.1 on Downgrade
•
Optional RDVD or USB upsell (select one)
13

Intel®processor Technology
Haswell Architecture
Latitude 3000 Series is built with Intel 4th Generation Core processor Technology
•4th generation Dual Core Processor
•Intel® Integrated HD Graphics 4400
•Intel® Wireless Display 5.X Application included in Intel WLAN options
Processors Support List UMA Graphics GSP
Intel® Core i3-4005U (Dual Core, 1.7GHz, 3M cache, 15W) Intel® HD Graphics 4400 No
Intel® Core i3-4030U (Dual Core, 1.9GHz, 3M cache, 15W) Intel® HD Graphics 4400 No
Intel® Core i5-4210U (Dual Core, 1.7 GHz, 3M cache, 15W) Intel® HD Graphics 4400 No
14

Intel®processor Technology
Broadwell Architecture (Coming January 2015)
Latitude 3000 Series is built with Intel 5th Generation Core processor Technology
•5th generation Dual Core Processor
•Intel® Integrated HD Graphics 5500
•Intel® Wireless Display 5.X Application included in Intel WLAN options
Processors Support List UMA Graphics GSP
Intel® Celeron 3205U (Dual Core, 1.5GHz, 2M cache, 15W) Intel® HD Graphics No
Intel® Core i3-4005U (Dual Core, 1.7GHz, 3M cache, 15W) Intel® HD Graphics 4400 No
Intel® Core i3-5005U (Dual Core, 2.0GHz, 3M cache, 15W) Intel® HD Graphics 5500 No
Intel® Core i5-5200U (Dual Core, 2.2GHz, 3M cache, 15W) Intel® HD Graphics 5500 No
Intel® Core i5-5300U (Dual Core, 2.3GHz, 3M cache, 15W) Intel® HD Graphics 5500 No
Intel® Core i7-5500U (Dual Core, 2.4GHz, 4M cache, 15W) Intel® HD Graphics 5500 No
15

Memory
•Your computer supports a maximum of 16GB* of memory when you use two 8GB DIMMs; however, 32-bit
operating systems, such as the 32-bit version of Microsoft® Windows® 7, can only use a maximum of 4GB of
address space. Moreover, certain components within the computer require address space in the 4GB range. Any
address space reserved for these components cannot be used by computer memory; therefore, the amount of
memory available to a 32-bit operating system is less than 4GB.
•Greater than 4GB memory requires a 64-bit operating system.
•ONLY MEMORY TYPE SUPPORTED: DDR3-LOW VOLTAGE (“DDR3L”)
•NOT BACKWARD COMPATIBLE WITH DDR3 MEMORY
Memory
3000 Series
DIMM Slots
2
Minimum Memory Configuration
4GB
Maximum
Memory Configuration* 16GB
DIMM
Configurations:
16G 1600MHz DDR3L (2x8G)* X
8G 1600MHz DDR3L (2x4G)* X
4G 1600MHz DDR3L (1x4G) X
*1GB means 1 billion bytes –8GB & 16GB options available beginning January 2015
16

Primary Storage
3000 Series
500GB 7200rpm HDD
X
500GB 5400rpm Hybrid (8GB Cache)
X
1TB 5400rpm HDD*
X
1TB 5400rpm Hybrid
(8GB)* X
Primary Storage
17 *1GB means 1 billion bytes –option available beginning January 2015

Connectivity Options
Connectivity Option
Dell
Latitude
3000 Series
Regions
WLAN
M.2
Dell Wireless™ 1707
1x1 802.11N Single Band Wi-Fi + BT 4.0
Wireless Card*
X All
Intel® Dual Band
Wireless 7265 802.11AGN Wi-Fi + BT 4.0
Wireless Card
X WW
Intel® Dual Band Wireless
-AC 7265 802.11AC Wi-Fi + BT 4.0
Wireless
Card IND X Indonesia Only
Intel® Dual Band
Wireless-AC 7265 802.11AC Wi-Fi + BT 4.0
Wireless Card*
X Brazil Only
18 *option available beginning January 2015

Detailed Engineering
Specifications
19
Specific features/models/configs/options discussed in this document may not be available WW

500GB HDD 7200 RPM
2.5” 500 GB HDD 7200 RPM
Capacity (GB) 500GB
Dimensions inches (W x D x H) Approximately 2.75 x 3.95 x 0.278 inches
Interface type and Maximum speed Up to 6Gb/s (SATA 3.0)
MTBF 550,000 hours
Logical Blocks 976,773,168
Power Source
Power Consumption (reference only) Idle 0.7W, Active 3.25W(running IOmeter utility)
Environmental Operating Conditions (Non
-Condensing):
Temperature Range 5°C to 60°C
Relative Humidity Range 10% to 90% non-condensing
Op Shock (@2ms) 350G
Environmental Non
-Operating Conditions (Non-Condensing):
Temperature Range -40°C to 65°C
Relative Humidity Range 5 to 95%
1For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less.
20
