Dell C5519Q User manual

1
1
Service Manual
Dell C5519Q
Content Index
1. General Safety Instructions....................................................................................... 2
1.1 SAFETY: General Safety ......................................................................................... 2
1.2 SAFETY: General Power Safety............................................................................... 4
2. Exploded view diagram with list of items ................................................................ 5
3. Wiring connectivity diagram..................................................................................... 7
4. How to connect and disconnect power cable/ connectivity cable........................... 8
5. Mechanical Instruction............................................................................................ 10
5.1 Disassembly Procedures: .................................................................................... 12
5.2 Assembly Procedures:......................................................................................... 16
6. Trouble shooting instructions................................................................................ 18
Model No.: C5519Q
Regulatory model: C5519Qc

2
2
1. General Safety Instructions
Use the following safety guidelines to help ensure your own personal safety and to help protect your
equipment and working environment from potential damage.
NOTE: In this section, equipment refers to monitors.
IMPORTANT NOTICE FOR USE IN HEALTHCARE ENVIRONMENTS:
Dell products are not medical devices and are not listed under UL or IEC 60601 (or equivalent). As a
result, they must not be used within 6 feet of a patient or in a manner that directly or indirectly
contacts a patient
1.1 SAFETY: General Safety
WARNING: To prevent the spread of fire, keep candles or other open flames away from this product at all
times.
When setting up the equipment for use:
Place the equipment on a hard, level surface. Leave 10.2 cm (4 in) minimum of clearance on all
vented sides of the computer to permit the airflow required for proper ventilation.
Restricting airflow can damage the computer or cause a fire.
Do not stack equipment or place equipment so close together that it is subject to recalculated or
preheated air.
NOTE: Review the weight limits referenced in your computer documentation before placing a
monitor or other devices on top of your computer.
Ensure that nothing rests on your equipment's cables and that the cables are not located where they
can be stepped on or tripped over.
Ensure that all cables are connected to the appropriate connectors. Some connectors have a similar
appearance and may be easily confused (for example, do not plug a telephone cable into the network
connector).
Do not place your equipment in a closed-in wall unit or on a bed, sofa, or rug.
Keep your device away from radiators and heat sources.
Keep your equipment away from extremely hot or cold temperatures to ensure that it is used within
the specified operating range.
Do not push any objects into the air vents or openings of your equipment. Doing so can cause fire
or electric shock by shorting out interior components.
Avoid placing loose papers underneath your device. Do not place your device in a closed-in wall unit,
or on a soft, fabric surface such as a bed, sofa, carpet, or a rug.
When operating your equipment:
Do not use your equipment in a wet environment, for example, near a bath tub, sink, or swimming

3
3
pool or in a wet basement.
Do not use AC powered equipment during an electrical storm. Battery powered devices may be used
if all cables have been disconnected.
Do not spill food or liquids on your equipment.
Before you clean your equipment, disconnect it from the electrical outlet. Clean your device with a
soft cloth dampened with water. Do not use liquids or aerosol cleaners, which may contain flammable
substances.
Clean the monitor display with a soft, clean cloth and water. Apply the water to the cloth, then
stroke the cloth across the display in one direction, moving from the top of the display to the bottom.
Remove moisture from the display quickly and keep the display dry.
Long-term exposure to moisture can damage the display. Do not use a commercial window cleaner
to clean your display.
If your equipment does not operate normally - in particular, if there are any unusual sounds or
smells coming from it - unplug it immediately and contact an authorized dealer or service center.
Protecting Against Electrostatic Discharge
Electrostatic discharge (ESD) events can harm electronic components inside your equipment. Under
certain conditions, ESD may build up on your body or an object, such as a peripheral, and then discharge
into another object, such as your computer. To prevent ESD damage, you should discharge static
electricity from your body before you interact with any of your equipment’s internal electronic
components, such as a memory module. You can protect against ESD by touching a metal grounded
object (such as an unpainted metal surface on your computer’s I/O panel) before you interact with
anything electronic. When connecting a peripheral (including handheld digital assistants) to your
equipment, you should always ground both yourself and the peripheral before connecting it. In addition,
as you work inside the equipment, periodically discharge any static charge your body may have
accumulated.
You can also take the following steps to prevent damage from electrostatic discharge:
When unpacking a static-sensitive component from its shipping carton, do not remove the
component from the antistatic packing material until you are ready to install the component.
Just before un wrapping the antistatic package, be sure to discharge static electricity from your
body.
When transporting a sensitive component, first place it in an antistatic container or packaging.
Handle all electrostatic sensitive components in a static-safe area. If possible, use antistatic floor
pads and work bench pads.

4
4
1.2 SAFETY: General Power Safety
Observe the following guidelines when connecting your equipment to a power source:
Check the voltage rating before you connect the equipment to an electrical outlet to ensure that the
required voltage and frequency match the available power source.
Do not plug the equipment power cables into an electrical outlet if the power cable is damaged
Norway and Sweden: If this product is provided with a 3-prong power cable, connect the power cable
to a grounded electrical outlet only.
If you use an extension power cable, ensure that the total ampere rating of the products plugged in
to the extension power cable does not exceed the ampere rating of the extension cable.
If you must use an extension cable or power strip, ensure the extension cable or power strip is
connected to a wall power outlet and not to another extension cable or power strip. The extension cable
or power strip must be designed for grounded plugs and plugged into a grounded wall outlet.
If you are using a multiple-outlet power strip, use caution when plugging the power cable into the
power strip. Some power strips may allow you to insert a plug incorrectly. Incorrect insertion of the power
plug could result in permanent damage to your equipment, as well as risk of electric shock and/or fire.
Ensure that the ground prong of the power plug is inserted into the mating ground contact of the power
strip.
Be sure to grasp the plug, not the cable, when disconnecting equipment from an electric socket.
If your equipment uses an AC adapter:
Use only the Dell provided AC adapter approved for use with this device. Use of another AC adapter
may cause a fire or explosion.
NOTE: Refer to your system rating label for information on the proper adapter model approved for
use with your device.
Place the AC adapter in a ventilated area, such as a desk top or on the floor, when you use it to run
the computer or to charge the battery. Do not cover the AC adapter with papers or other items that will
reduce cooling; also, do not use the AC adapter inside a carrying case.
The AC adapter may become hot during normal operation of your computer. Use care when
handling the adapter during or immediately after operation.
It is recommended that you lay the adapter on the floor or desk so that the green light is visible.
This will alert you if the adapter should accidentally go off due to external effects. If for any reason the
green light goes off, disconnect the AC power cord from the wall for a period of ten seconds, and then
reconnect the power cord.
Japan Only: Use only the Dell-provided AC power cable with the AC adapter. Use of any other power
cable may damage the device or AC adapter or may present risk of fire or electric shock.

5
5
2. Exploded view diagram with list of items
11
S8
S7
S6
S5
S4
S3
S2
S1
9
10
8
7
6
3
2
4
1
12
13
14
15
16
17
18 19 20 21 22

6
6
No.
Description
Q’ty
Remark
1
LENS
1
For EMEA Only, not
for
other regions
2
KEY
1
3
COVER_KEY
1
4
DECO_BEZEL
1
5
BKT_STAND
1
6
INSULATING SHEET
1
7
BKT_POWER_TOP
1
8
MAINFRAME
1
9
BKT_VESA
2
10
REAR_COVER
1
11
COVER_HINGE
1
12
PANEL
1
13
KEY BOARD
1
14
SPEAKER
2
15
ADAPTER BOARD
1
16
MAIN BOARD
1
17
IR BOARD
1
18
Power Cable
1
See “NOTE"
19
VGA Cable
1
See “NOTE"
20
HDMI Cable
1
See “NOTE"
21
DP Cable
1
See “NOTE"
22
USB 3.0 upstream cable
1
See “NOTE"
NOTE:
For replacement of power cord, connectivity cable and external power supply (if applicable), contact Dell:
1. Go to https://www.dell.com/support.
2. Verify your country or region in the Choose A Country/Region drop-down menu at the bottom-right corner of the page.
3. Click Contact Us next to the country dropdown.
4. Select the appropriate service or support link based on your need.
5. Choose the method of contacting Dell that is convenient for you

7
7
3. Wiring connectivity diagram
FFC 1
Wire 1
FFC 2
Wire 3
Wire 2

8
8
4. How to connect and disconnect power cable/ connectivity cable

9
9

10
10

11
11
5. Mechanical Instruction
NOTE:
This “Disassembly and Assembly Procedures” is for EMEA only, not for other regions. Please note that
Dell will deem warranty void if any disassembly is done on the monitors.
Tools Required
List the type and size of the tools that would typically can be used to disassemble the product to
a point where components and materials requiring selective treatment can be removed.
Tool Description:
− Screwdriver (Phillip-head, Hexagonal head)
− Penknife

12
12
5.1 Disassembly Procedures:
Step
Figure
Remark
S1. Before
disassembl
e
Turn off power,
Unplug external
cables from
product
S2. Remove
the cover
hinge
Use a Philips-head
screwdriver to
remove 4 screws for
remove the cover
hinge.
(No.1~4 screw
size=M4x14;
Torque=12±2kgf.cm)
Use a Philips-head
screwdriver to remove
20 screws for
remove the Rear
Cover.
(No.1~20 screw
size=M3x6;
Torque=4±1kgf.cm)
S3. Remove the
REAR COVER
Use Penknife to
separate the bezel and
rear cove follow the
arrows in sequence,
then you can take out
rear cover.

13
13
S4. Disconnect
all of the cable
and remove the
speakers
1. Disconnect all of
the pins and
remove the
speakers.
2. Use a Philips-head
screwdriver to
remove 4 screws
for remove the
Speakers
(No.1~4 screw
size=Q4x10;
Torque=8±1kgf.c
m)
Use a Philips-head
screwdriver to
remove 4 screws for
remove the BKT and
Key board (No.1~4
screw size=Q4x10
Torque= 4±1kgf.cm)
S5. Remove the
BKT and the key
board

14
14
Use a Philips-head
screwdriver to remove 8
screws for remove the
Power board.
(No.1~8 screw
size=P3x4;
Torque=4±1kgf.cm)
Use a Philips-head
S6. Remove the
screwdriver to remove 6
Main &Power
screws for remove the
Board
Main board.
(No.1~6 screw
size=D3x6
Torque=6±1kgf.cm )
Use a hex screwdriver to
remove 4 screws for
remove the Main board.
(No.1~4 Hex-screw
Torque=4.5±0.5kgf.cm)
Use finger to
Remove the Mylar
S7. Remove the
Mylar and
remove the
screws to
remove the BKT
stand
Use a Philips-head
screwdriver to remove
4 screws for remove
the BKT stand
(No.1~4 screw
size=M4x8
Torque=6±1kgf.cm
)

15
15
Use a Philips-head
screwdriver to remove 2
S8. Remove
the DECO
bezel
screws for
remove DECO
Bezel
(No.1~2 screw
size=P3x4;
Torque=4±1kgf.cm )
S9. Disconnect
the
FFC cable
Disconnect the pin
S10. Remove the
screw to remove
the AC SOCKET
ASS'Y
Use a Philips-head
screwdriver to remove
3 screws for remove
the BKT stand
(No.1~2 screw
size=M3x6
Torque=4±1kgf.c
m
No.3 screw
size=M4x6
Torque=12±2kgf.cm)
S11. The Deco
bezel and the
IR board
The IR board

16
16
5.2 Assembly Procedures:
Step
Figure
Remark
S1. Assembly the
Deco bezel
and the IR
board
The IR board
Use a Philips-head
screwdriver to tighten
3 screws for the
BKT
stand
(No.1~2 screw
size=M3x6
Torque=4±1kgf.cm
No.3 screw size=M4x6
Torque=12±2kgf.cm)
S2. Tighten the
AC SOCKET
ASS'Y
S3. Connect the
FFC cable
Connect the pin
Use a Philips-head
screwdriver to screw 2
S4. Tighten
the DECO
bezel
screws for tighten
DECO Bezel (No.1~2
screw size=P3x4;
Torque=4±1kgf.cm )

17
17
S5. Paste the
Mylar and
screw the
screws to
tighten the
BKT stand
Use finger to paste the
Mylar
Use a Philips-head
screwdriver to screw 4
screws for tighten the
BKT stand
(No.1~4 screw
size=M4x8
Torque=6±1kgf.cm )
Use a Philips-head
screwdriver to screw 8
screws for tiighten the
Power board.
(No.1~8 screw
size=P3x4;
Torque=4±1kgf.cm)
S6. Remove the
Main &Power
Board
Use a Philips-head
screwdriver to screew 6
screws for tighten the
Main board.
(No.1~6 screw
size=D3x6
Torque=6±1kgf.cm )
Use a hex screwdriver to
screw4 screws for
tighten the Main board.
(No.1~4 Hex-screw
Torque=4.5±0.5kgf.cm)

18
18
S7. Tighten the
BKT and the
key board
Use a Philips-head
screwdriver to screw 4
screws for tighten the
BKT and Key board
(No.1~4 screw
size=Q4x10
Torque= 4±1kgf.cm)
S8. Connect all
of the cable and
assembly the
speakers
1. Connect all of the
pins and assembly
the speakers.
2. Use a Philips-head
screwdriver to screw
4 screws for tighten
the Speakers
(No.1~4 screw
size=Q4x10;
Torque=8±1kgf.cm)
S9. Assembly the
REAR COVER
Use a Philips-head
screwdriver to screw 20
screws for tighten the
Rear Cover.
(No.1~20 screw
size=M3x6;
Torque=4±1kgf.cm)

19
19
6. Trouble shooting instructions

20
20
