Dell EMC PowerEdge T640 D24XR Manual

Dell EMC PowerEdge T640
Installation and Service Manual
Regulatory Model: E47S Series
Regulatory Type: E47S001
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dell PowerEdge
T640 D24XR o cerca il tuo prodotto tra le migliori offerte di Server

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2017 -2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.
2018 - 08
Rev. A02

Contents
1 Dell EMC PowerEdge T640 overview............................................................................................................. 8
Supported congurations..................................................................................................................................................9
Front view of the system.................................................................................................................................................10
Status LED indicators.................................................................................................................................................12
iDRAC Direct LED indicator codes............................................................................................................................13
iDRAC Quick Sync 2 indicator codes....................................................................................................................... 14
System health and system ID indicator codes........................................................................................................ 15
Drive indicator codes..................................................................................................................................................16
Back view of the system..................................................................................................................................................17
NIC indicator codes.................................................................................................................................................... 18
Power supply unit indicator codes............................................................................................................................19
Locating the Service Tag of your system...................................................................................................................... 21
System information label.................................................................................................................................................22
PowerEdge T640 – system information label........................................................................................................ 22
2 Technical specications............................................................................................................................... 27
Chassis dimensions..........................................................................................................................................................28
Chassis weight................................................................................................................................................................. 28
Processor specications................................................................................................................................................. 28
Supported operating systems........................................................................................................................................ 29
Cooling fan specications............................................................................................................................................... 29
PSU specications...........................................................................................................................................................29
System battery specications........................................................................................................................................ 30
Expansion bus specications..........................................................................................................................................30
Memory specications..................................................................................................................................................... 31
Storage controller specications.....................................................................................................................................31
Drive specications...........................................................................................................................................................31
Hard drives...................................................................................................................................................................31
Optical drive................................................................................................................................................................32
Ports and connectors specications............................................................................................................................. 32
USB ports....................................................................................................................................................................32
NIC ports.....................................................................................................................................................................32
VGA ports................................................................................................................................................................... 32
Serial connector......................................................................................................................................................... 33
Internal Dual SD Module with vFlash card..............................................................................................................33
Video specications.........................................................................................................................................................33
Environmental specications.......................................................................................................................................... 33
Standard operating temperature..............................................................................................................................35
Expanded operating temperature............................................................................................................................ 35
Particulate and gaseous contamination specications..........................................................................................36
3 Initial system setup and conguration.......................................................................................................... 37
Contents 3

Setting up your system....................................................................................................................................................37
iDRAC conguration.........................................................................................................................................................37
Options to set up iDRAC IP address........................................................................................................................ 37
Log in to iDRAC..........................................................................................................................................................38
Options to install the operating system.........................................................................................................................38
Methods to download rmware and drivers...........................................................................................................38
Downloading drivers and rmware.......................................................................................................................... 39
4 Pre-operating system management applications..........................................................................................40
Options to manage the pre-operating system applications........................................................................................40
System Setup...................................................................................................................................................................40
Viewing System Setup.............................................................................................................................................. 40
System Setup details..................................................................................................................................................41
System BIOS............................................................................................................................................................... 41
iDRAC Settings utility................................................................................................................................................ 62
Device Settings.......................................................................................................................................................... 62
Dell Lifecycle Controller...................................................................................................................................................62
Embedded system management............................................................................................................................. 62
Boot Manager...................................................................................................................................................................62
Viewing Boot Manager..............................................................................................................................................62
Boot Manager main menu........................................................................................................................................ 63
One-shot BIOS boot menu.......................................................................................................................................63
System Utilities...........................................................................................................................................................63
PXE boot...........................................................................................................................................................................63
5 Installing and removing system components................................................................................................ 64
Safety instructions...........................................................................................................................................................64
Before working inside your system................................................................................................................................64
After working inside your system...................................................................................................................................64
Optional front bezel......................................................................................................................................................... 64
Removing the front bezel......................................................................................................................................... 65
Installing the front bezel............................................................................................................................................65
System feet...................................................................................................................................................................... 66
Removing the system feet........................................................................................................................................66
Installing the system feet.......................................................................................................................................... 67
Caster wheels – optional................................................................................................................................................ 68
Removing caster wheels...........................................................................................................................................68
Installing caster wheels............................................................................................................................................. 69
Drives.................................................................................................................................................................................70
Removing a drive blank............................................................................................................................................. 70
Installing a drive blank.................................................................................................................................................71
Removing a drive carrier........................................................................................................................................... 72
Installing a drive carrier..............................................................................................................................................73
Removing the drive from the drive carrier..............................................................................................................74
Installing a drive into the drive carrier......................................................................................................................75
Removing a 3.5 inch drive adapter from a 3.5 inch drive carrier..........................................................................76
4Contents

Installing a 3.5 inch drive adapter into the 3.5 inch drive carrier.......................................................................... 77
Removing a 2.5 inch drive from a 3.5 inch drive adapter......................................................................................78
Installing a 2.5 inch drive into a 3.5 inch drive adapter..........................................................................................79
Power supply units...........................................................................................................................................................80
PSU specications.....................................................................................................................................................80
Hot spare feature........................................................................................................................................................81
Removing a power supply unit blank........................................................................................................................81
Installing a power supply unit blank..........................................................................................................................82
Removing a AC power supply unit...........................................................................................................................82
Installing a AC power supply unit............................................................................................................................. 83
Removing a DC power supply unit...........................................................................................................................84
Installing DC power supply unit................................................................................................................................ 85
Wiring instructions for a DC power supply unit..................................................................................................... 85
System cover....................................................................................................................................................................86
Removing the system cover.....................................................................................................................................86
Installing the system cover........................................................................................................................................87
Inside the system............................................................................................................................................................. 88
Air shroud..........................................................................................................................................................................89
Removing the optional GPU air shrouds.................................................................................................................89
Installing the optional GPU air shrouds................................................................................................................... 90
Removing the air shroud............................................................................................................................................91
Installing the air shroud............................................................................................................................................. 92
Cooling fans......................................................................................................................................................................93
Cooling fan specications......................................................................................................................................... 93
Cooling fan matrix......................................................................................................................................................94
Removing a middle or rear cooling fan....................................................................................................................94
Installing a middle or rear cooling fan...................................................................................................................... 95
Removing the right external fan.............................................................................................................................. 96
Installing the right external fan................................................................................................................................. 97
Cooling fan (middle fan) assembly.................................................................................................................................98
Removing the middle cooling fan assembly ...........................................................................................................98
Installing the middle cooling fan assembly.............................................................................................................. 98
Flex bays........................................................................................................................................................................... 99
Removing a NVMe drive bay or ex bay.................................................................................................................99
Installing a NVMe drive bay or ex bay................................................................................................................. 100
Optical drives and tape drives....................................................................................................................................... 101
Optical drives and tape drives specications.........................................................................................................101
Removing the optical or tape drive blank..............................................................................................................102
Installing the optical or tape drive blank................................................................................................................ 102
Removing the optical drive cage or tape drive.....................................................................................................103
Installing the optical drive cage or tape drive....................................................................................................... 104
Removing the slim optical drive..............................................................................................................................105
Installing the slim optical drive................................................................................................................................ 106
NVDIMM-N battery........................................................................................................................................................107
Removing the NVDIMM-N battery........................................................................................................................ 107
Contents 5

Installing the NVDIMM-N battery.......................................................................................................................... 108
System memory..............................................................................................................................................................109
System memory population.....................................................................................................................................109
General memory module installation guidelines......................................................................................................111
NVDIMM-N memory module installation guidelines .............................................................................................111
Mode-specic guidelines..........................................................................................................................................112
Removing a memory module................................................................................................................................... 113
Installing a memory module......................................................................................................................................114
Processors and heat sinks..............................................................................................................................................115
Removing a processor and heat sink module........................................................................................................ 115
Removing the processor from the processor and heat sink module.................................................................. 116
Installing the processor into a processor and heat sink module.......................................................................... 118
Installing a processor and heat sink module...........................................................................................................121
Expansion card holder....................................................................................................................................................122
Removing the expansion card holder.....................................................................................................................122
Installing the expansion card holder....................................................................................................................... 123
GPU card holder (optional)........................................................................................................................................... 124
GPU card restriction.................................................................................................................................................124
GPU card installation guidelines..............................................................................................................................124
Removing the optional GPU card holder............................................................................................................... 124
Installing the optional GPU card holder................................................................................................................. 125
Expansion cards..............................................................................................................................................................126
Expansion card installation guidelines.................................................................................................................... 126
Expansion card slot priority..................................................................................................................................... 127
Removing a expansion card.....................................................................................................................................129
Installing an expansion card.....................................................................................................................................130
M.2 SSD module..............................................................................................................................................................131
Removing the M.2 SSD module.............................................................................................................................. 131
Installing the M.2 SSD module................................................................................................................................132
Optional IDSDM or vFlash module............................................................................................................................... 133
Removing the MicroSD card...................................................................................................................................133
Installing the MicroSD card..................................................................................................................................... 134
Removing the optional IDSDM or vFlash module.................................................................................................134
Installing optional IDSDM or vFlash module..........................................................................................................135
Backplane........................................................................................................................................................................ 136
Backplane connectors..............................................................................................................................................136
Removing a backplane.............................................................................................................................................138
Installing a backplane............................................................................................................................................... 139
Backplane cabling............................................................................................................................................................141
Integrated storage controller card................................................................................................................................145
Removing the integrated storage controller card.................................................................................................145
Installing the integrated storage controller card................................................................................................... 146
System battery............................................................................................................................................................... 146
Replacing the system battery................................................................................................................................. 147
Optional internal USB memory key...............................................................................................................................148
6Contents

Replacing the optional internal USB memory key.................................................................................................148
Control panel assembly..................................................................................................................................................148
Removing the control panel assembly................................................................................................................... 148
Installing the control panel assembly..................................................................................................................... 150
Trusted Platform Module................................................................................................................................................151
Upgrading the Trusted Platform Module................................................................................................................151
Initializing TPM for BitLocker users........................................................................................................................152
Initializing the TPM 1.2 for TXT users.................................................................................................................... 152
System board..................................................................................................................................................................153
Removing the system board................................................................................................................................... 153
Installing the system board......................................................................................................................................155
Power interposer boards................................................................................................................................................157
Main and GPU power interposer boards connectors...........................................................................................157
Removing the GPU power interposer board.........................................................................................................158
Installing the GPU power interposer board........................................................................................................... 159
Removing the main power interposer board.........................................................................................................159
Installing the main power interposer board........................................................................................................... 160
Converting the system from tower mode to rack mode............................................................................................161
Converting the system from tower mode to rack mode .....................................................................................161
6 Using system diagnostics........................................................................................................................... 163
Dell Embedded System Diagnostics.............................................................................................................................163
Running the Embedded System Diagnostics from Boot Manager.....................................................................163
Running the Embedded System Diagnostics from the Dell Lifecycle Controller..............................................163
System diagnostic controls..................................................................................................................................... 164
7 Getting help............................................................................................................................................... 165
Recycling or End-of-Life service information..............................................................................................................165
Contacting Dell EMC..................................................................................................................................................... 165
Documentation feedback.............................................................................................................................................. 165
Accessing system information by using QRL..............................................................................................................166
Quick Resource Locator for PowerEdge T640.....................................................................................................166
Contents 7

Dell EMC PowerEdge T640 overview
The Dell EMC PowerEdge T640 is a dual-socket, 5U rackable tower server that supports up to:
• Two Intel Xeon Scalable processors
• 24 DIMM slots (support for DDR4 RDIMM, LR-DIMM) or 12 NVDIMM-N (one DIMM per channel) are supported
• Nine PCIe Gen 3 expansion cards, including a dedicated PERC slot
• Four GPUs
• Two hot swappable power supply units
• Drive congurations:
– 8 x 3.5-inch or 8 x 2.5 inch (in 3.5 inch carrier) SAS/SATA/SSD drives
– 18 x 3.5-inch SAS/SATA/SSD drives
– 16 x 2.5-inch SAS/SATA/SSD drives
– 16 x 2.5-inch SAS/SATA/SSD drives with 8 x NVME drives
– 32 x 2.5-inch SAS/SATA/SSD drives
Topics:
• Supported congurations
• Front view of the system
• Back view of the system
• Locating the Service Tag of your system
• System information label
1
8 Dell EMC PowerEdge T640 overview

Supported congurations
Figure 1. Supported congurations of the PowerEdge T640
Dell EMC PowerEdge T640 overview 9

Front view of the system
The front view displays the features available on the front of the system.
Figure 2. Front view of the 18 x 3.5-inch drive tower system
1Power button 2 Information tag
3 iDRAC Quick Sync 2 wireless indicator (optional) 4 Status LED indicators
5 System health and system ID indicator 6 USB port (USB 2.0-compliant)
7 USB port (USB 3.0-compliant) 8 iDRAC Direct (Micro-AB USB) port
9 Optical drive (optional) 10 Drive slots
10 Dell EMC PowerEdge T640 overview

Figure 3. Front view of the 32 x 2.5-inch drive tower system
1Power button 2 Information tag
3 iDRAC Quick Sync 2 wireless indicator (optional) 4 Status LED indicators
5 System health and system ID indicator 6 USB port (USB 2.0-compliant)
7 USB port (USB 3.0-compliant) 8 iDRAC Direct (Micro-AB USB) port
9 Optical drive (optional) 10 Drive slots
Dell EMC PowerEdge T640 overview 11

Figure 4. Front view of the 8 x 3.5-inch drive rack system
1Power button 2 Information tag
3 iDRAC Quick Sync 2 wireless indicator (optional) 4 Status LED indicators
5 System health and system ID indicator 6 USB port (USB 2.0-compliant)
7 VGA port 8 USB port (USB 3.0-compliant)
9 iDRAC Direct (Micro-AB USB) port 10 Optical drive (optional)
11 Drive slots 12 Rack ear latch (2)
13 Drive blank
For more information on the ports, see the Technical specications section.
Status LED indicators
NOTE: The indicators display solid amber if any error occurs.
Figure 5. Status LED indicators
Table 1. Status LED indicators and descriptions
Icon Description Condition Corrective action
PCIe indicator The indicator turns
solid amber if a PCIe
Restart the system. Update any required drivers for the PCIe card. Reinstall
the card.
If the problem persists, see Getting help.
12 Dell EMC PowerEdge T640 overview

Icon Description Condition Corrective action
card experiences an
error. NOTE: For more information about the supported PCIe cards, see
Expansion card installation guidelines.
Memory
indicator
The indicator turns
solid amber if a
memory error
occurs.
Check the System Event Log or system messages for the location of the
failed memory. Reseat the memory module.
If the problem persists, see Getting help.
Electrical
indicator
The indicator turns
solid amber if the
system experiences
an electrical error
(for example,
voltage out of
range, or a failed
power supply unit
(PSU) or voltage
regulator).
Check the System Event Log or system messages for the specic issue. If it
is due to a problem with the PSU, check the LED on the PSU. Reseat the
PSU.
If the problem persists, see Getting help.
Temperature
indicator
The indicator turns
solid amber if the
system experiences
a thermal error (for
example, the
ambient
temperature is out
of range or there is
a fan failure).
Ensure that none of the following conditions exist:
• A cooling fan has been removed or has failed.
• System cover, air shroud, memory module blank, or back ller bracket is
removed.
• Ambient temperature is too high.
• External airow is obstructed.
If the problem persists, see Getting help.
Drive indicator The indicator turns
solid amber if there
is a drive error.
• Check the System Event Log to determine if the drive has an error.
• Run the appropriate Online Diagnostics test. Restart the system and run
embedded diagnostics (ePSA).
• If the drives are congured in a RAID array, restart the system, and
enter the host adapter conguration utility program.
iDRAC Direct LED indicator codes
The iDRAC Direct LED indicator lights up to indicate that the port is connected and is being used as a part of the iDRAC subsystem.
You can congure iDRAC Direct by using a USB to micro USB (type AB) cable, which you can connect to your laptop or tablet. The
following table describes iDRAC Direct activity when the iDRAC Direct port is active:
Dell EMC PowerEdge T640 overview 13

Table 2. iDRAC Direct LED indicator codes
iDRAC Direct LED
indicator code
Condition
Solid green for two seconds Indicates that the laptop or tablet is connected.
Flashing green (on for two
seconds and o for two
seconds)
Indicates that the laptop or tablet connected is recognized.
Turns o Indicates that the laptop or tablet is unplugged.
iDRAC Quick Sync 2 indicator codes
iDRAC Quick Sync 2 module (optional) is located on the front panel of your system.
Figure 6. iDRAC Quick Sync 2 indicator
Table 3. iDRAC Quick Sync 2 indicators and descriptions
iDRAC Quick Sync 2 indicator
code
Condition Corrective action
O (default state) Indicates that the iDRAC Quick Sync 2
feature is turned o. Press the iDRAC Quick
Sync 2 button to turn on the iDRAC Quick
Sync 2 feature.
If the LED fails to turn on, reseat the cable and check.
If the problem persists, see the Getting help section.
Solid white Indicates that iDRAC Quick Sync 2 is ready
to communicate. Press the iDRAC Quick
Sync 2 button to turn o.
If the LED fails to turn o, restart the system. If the
problem persists, see the Getting help section.
Blinks white rapidly Indicates data transfer activity. If the indicator continues to blink indenitely, see the
Getting help section.
Blinks white slowly Indicates that rmware update is in
progress.
If the indicator continues to blink indenitely, see the
Getting help section.
Blinks white ve times rapidly and
then turns o
Indicates that the iDRAC Quick Sync 2
feature is disabled.
Check if iDRAC Quick Sync 2 feature is congured to
be disabled by iDRAC. If the problem persists, see the
Getting help section. For more information, see
Dell.com/idracmanuals Dell.com/
operatingsystemmanuals.
Solid amber Indicates that the system is in fail-safe
mode.
Restart the system. If the problem persists, see the
Getting help section.
Blinking amber Indicates that the iDRAC Quick Sync 2
hardware is not responding properly.
Restart the system. If the problem persists, see the
Getting help section.
14 Dell EMC PowerEdge T640 overview

System health and system ID indicator codes
The system health and system ID indicator is located on the front panel of your system.
Figure 7. System health and system ID indicators
Table 4. System health and system ID indicator codes
System health and system ID indicator code Condition
Solid blue Indicates that the system is turned on, system is healthy, and system
ID mode is not active. Press the system health and system ID button
to switch to system ID mode.
Blinking blue Indicates that the system ID mode is active. Press the system health
and system ID button to switch to system health mode.
Solid amber Indicates that the system is in fail-safe mode. If the problem persists,
see the Getting help section.
Blinking amber Indicates that the system is experiencing a fault. Check the System
Event Log for specic error messages. For more information about
error messages, see the Event and Error Message Reference Guide
for 14th Generation Dell EMC PowerEdge Servers at Dell.com/qrl.
Dell EMC PowerEdge T640 overview 15

Drive indicator codes
Each drive carrier has an activity LED indicator and a status LED indicator. The indicators provide information about the current status of
the drive. The activity LED indicator indicates whether the drive is currently in use or not. The status LED indicator indicates the power
condition of the drive.
Figure 8. Drive indicators
1Drive activity LED indicator 2 Drive status LED indicator
3 Drive capacity label
NOTE: If the drive is in the Advanced Host Controller Interface (AHCI) mode, the status LED indicator does not turn on.
Table 5. Drive indicator codes
Drive status indicator code Condition
Flashes green twice per second Identifying drive or preparing for removal.
O Drive ready for removal.
NOTE: The drive status indicator remains o until all drives are
initialized after the system is turned on. Drives are not ready
for removal during this time.
Flashes green, amber, and then turns o Predicted drive failure.
Flashes amber four times per second Drive failed.
Flashes green slowly Drive rebuilding.
Solid green Drive online.
Flashes green for three seconds, amber for three seconds, and
then turns o after six seconds
Rebuild stopped.
16 Dell EMC PowerEdge T640 overview

Back view of the system
The back view displays the features available on the back of the system.
Figure 9. Back view of the tower conguration
1PCIe expansion card slots 2 System ID button/indicator
3 VGA port 4 Serial port
5 iDRAC9 dedicated network port 6 USB 2.0 port (2)
7 PCIe expansion card slots 8 NIC port (2)
9 USB 3.0 port (4) 10 Power supply unit (2)
Dell EMC PowerEdge T640 overview 17

Figure 10. Back view of the rack conguration
1PCIe expansion card slots 2 System ID button/indicator
3 VGA port 4 Serial port
5 iDRAC9 dedicated network port 6 USB 2.0 port (2)
7 PCIe expansion card slots 8 Right external fan (available only with GPGPU conguration)
9 NIC port (2) 10 USB 3.0 port (4)
11 Power supply unit (2) 12 Left external fan (available only with GPGPU conguration)
NIC indicator codes
Each NIC on the back of the system has indicators that provide information about the activity and link status. The activity LED indicator
indicates if data is owing through the NIC, and the link LED indicator indicates the speed of the connected network.
Figure 11. NIC indicator codes
1link LED indicator 2 activity LED indicator
18 Dell EMC PowerEdge T640 overview

Table 6. NIC indicator codes
Status Condition
Link and activity indicators are o The NIC is not connected to the network.
Link indicator is green and activity indicator is blinking green The NIC is connected to a valid network at its maximum port speed and
data is being sent or received.
Link indicator is amber and activity indicator is blinking
green
The NIC is connected to a valid network at less than its maximum port
speed and data is being sent or received.
Link indicator is green and activity indicator is o The NIC is connected to a valid network at its maximum port speed and
data is not being sent or received.
Link indicator is amber and activity indicator is o The NIC is connected to a valid network at less than its maximum port
speed and data is not being sent or received.
Link indicator is blinking green and activity is o NIC identify is enabled through the NIC conguration utility.
NOTE: The LOM (Broadcom 57416) is compatible with 10GBASE-T IEEE 802.3an and 1000 BASE-T IEEE 802.3ab.
Power supply unit indicator codes
AC power supply units (PSUs) have an illuminated translucent handle that serves as an indicator.
The DC PSUs have an LED that serves as an indicator.
The indicator shows whether power is present or if a power fault has occurred.
Figure 12. AC PSU status indicator
1AC PSU status indicator/handle
Table 7. AC PSU status indicator codes
Power indicator codes Condition
Green A valid power source is connected to the PSU and the PSU is operational.
Blinking amber Indicates a problem with the PSU.
Not illuminated Power is not connected to the PSU.
Blinking green When the rmware of the PSU is being updated, the PSU handle blinks green.
CAUTION: Do not disconnect the power cord or unplug the PSU when updating rmware. If
rmware update is interrupted, the PSUs do not function.
Dell EMC PowerEdge T640 overview 19

Power indicator codes Condition
Blinking green and turns o When hot-plugging a PSU, the PSU handle blinks green ve times at a rate of 4 Hz and turns o. This
indicates a PSU mismatch with respect to eciency, feature set, health status, or supported voltage.
CAUTION: If two PSUs are installed, both the PSUs must have the same type of label; for
example, Extended Power Performance (EPP) label. Mixing PSUs from previous generations of
PowerEdge servers is not supported, even if the PSUs have the same power rating. This results
in a PSU mismatch condition or failure to turn the system on.
CAUTION: When correcting a PSU mismatch, replace only the PSU with the blinking indicator.
Swapping the PSU to make a matched pair can result in an error condition and unexpected
system shutdown. To change from a high output conguration to a low output conguration or
vice versa, you must turn o the system.
CAUTION: AC PSUs support both 240 V and 120 V input voltages with the exception of Titanium
PSUs, which support only 240 V. When two identical PSUs receive dierent input voltages, they
can output dierent wattages, and trigger a mismatch.
CAUTION: If two PSUs are used, they must be of the same type and have the same maximum
output power.
CAUTION: Combining AC and DC PSUs is not supported and triggers a mismatch.
Figure 13. DC PSU status indicator
1DC PSU status indicator
Table 8. DC PSU status indicator codes
Power indicator codes Condition
Green A valid power source is connected to the PSU and the PSU is operational.
Blinking amber Indicates a problem with the PSU.
Not illuminated Power is not connected to the PSU.
Blinking green When hot-plugging a PSU, the PSU indicator blinks green. This indicates that there is a PSU mismatch
with respect to eciency, feature set, health status, or supported voltage.
20 Dell EMC PowerEdge T640 overview
