Dell S5000 Series Operating and installation instructions

Dell S5000 Series Servers for SAP HANA
Description Guide
Regulatory Model: M3S2G8, M3UX16
September 2022
Rev. A01

Copyright
©2022 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc.
or its subsidiaries. Other trademarks may be trademarks of their respective owners.

WARNING: Please read carefully the safety instructions in the
Multilingual Safety Notices Guide before you
perform the procedures described in this document.
Intended audience
This document is intended for use by administrators and operators.
Related documents
For the most recent product information, documentation, firmware updates, software fixes, and service offers, see the Dell
Technologies Support Site.
Preface
Preface 3

Contents i
Table of Contents
Regulatory Declarations and Disclaimers p‐1...........................................
Safety Compliance Statement p‐1.....................................................
European Union (EU) Certification p‐1.................................................
UL/CSA Certification p‐1...............................................................
International Certification (Standard memory servers only) p‐1........................
Electromagnetic Compatibility Statement p‐1.........................................
EU Certification p‐1...................................................................
Federal Communications Commission (FCC) Certification (USA) p‐1....................
IECS-03 Certification (CANADA) p‐2...................................................
VCCI Certification (Japan) p‐2.........................................................
Waste Management p‐2...............................................................
REACH p‐2............................................................................
ROHS p‐2.............................................................................
WEEE p‐2.............................................................................
Safety Notices p‐3........................................................................
Chapter 1. Related Publications 1-1................................................
Chapter 2. Dell S5000 Series Servers Overview 2-1................................
2.1. Overview 2-1..............................................................
2.2. Dell S5000 Series Servers 2-2.............................................
2.2.1. S5408 Server 2-2.................................................
2.2.2. S5416 Server 2-3.................................................
2.3. Module 2-6................................................................
2.3.1. Module Overview 2-6..............................................
2.3.2. Main Box Overview 2-7............................................
2.3.3. Filler Bezel 2-7....................................................
Chapter 3. Rear Component Slots 3-1...............................................
3.1. S5408 Server 3-1.........................................................
3.2. Power Supply Units (PSUs) 3-2.............................................
Chapter 4. Compute Unit Components 4-1..........................................
4.1. Components 4-1..........................................................
4.2. CPU Purley Board (CPB) Motherboard 4-2..................................
4.3. Processor Assembly (CPU) 4-3.............................................
4.4. Memory Modules 4-4......................................................
4.5. PCIe Slots 4-6.............................................................
4.6. Front Disk Blades (FDB) 4-8...............................................
4.6.1. FDB Numbering 4-8...............................................
4.6.2. FDB Description 4-9...............................................
4.6.3. FDB Disks 4-9.....................................................
4.6.4. FDB Fan Boxes 4-12................................................

ii Description Guide
Chapter 5. UBox Components 5-1...................................................
5.1. Components 5-1..........................................................
5.2. Numbering 5-3............................................................
5.2.1. UNB Module Numbering 5-3.......................................
5.2.2. UNB Memory Module Numbering 5-4..............................
5.2.3. SCI Module Numbering 5-5........................................
5.2.4. CLKB Module Numbering 5-6......................................
5.2.5. UNB Fan Module Numbering 5-6...................................
5.2.6. UBox PSU Numbering 5-7.........................................
Chapter 6. LEDs, Buttons and Ports 6-1.............................................
6.1. Front LEDs and Buttons 6-1...............................................
6.1.1. Compute Unit LEDs 6-1...........................................
6.1.2. HITDP Unit LEDs 6-2..............................................
6.1.3. UBox LEDs 6-3....................................................
6.1.4. Buttons 6-6.......................................................
6.2. Rear LEDs and Buttons 6-7................................................
6.2.1. LEDs 6-7..........................................................
6.2.2. Buttons 6-11.......................................................
6.3. Ports 6-12..................................................................
Appendix A. Technical Description A-1...............................................
A.1. General Technical Specifications A-1.......................................
A.2. Dimensions and Weights A-1...............................................
A.3. Module Technical Specifications A-2........................................
A.4. UBox Technical Specifications A-2..........................................
A.5. Server Technical Description A-3...........................................
Acronyms a‐1..........................................................................

p‐1Regulatory Declarations and Disclaimers
Regulatory Declarations and Disclaimers
Safety Compliance Statement
This product is in compliance with the following directives:
European Union (EU) Certification
Low voltage directive 2014/35/EU: standard EN 60950-1
UL/CSA Certification
UL 60950 (USA)
CSA 60950 (Canada)
International Certification (Standard memory servers only)
Standard IEC 60950-1
Electromagnetic Compatibility Statement
This product is in compliance with the protection requirements of the following
directives:
EU Certification
EMC directive 2014/30/EU : standards EN 55024, EN 55032, EN61000-3-2,
EN 61000-3-3
Federal Communications Commission (FCC) Certification
(USA)
FCC Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
Properly shielded and grounded cables and connectors must be used in order to
meet FCC emission limits. Neither the provider nor the manufacturer are
responsible for any radio or television interference caused by using other than
recommended cables and connectors or by unauthorized changes or
modifications to this equipment. Unauthorized changes or modifications could
void the user's authority to operate the equipment.

p‐2 Description Guide
Pursuant to Part 15.21 of the FCC Rules, any changes or modifications to this
equipment not expressly approved by the manufacturer may cause harmful
interference and void the FCC authorization to operate this equipment. An FCC
regulatory label is affixed to the equipment.
IECS-03 Certification (CANADA)
Canadian Compliance Statement (Industry Canada)
This Class A digital apparatus meets all requirements of the Canadian
Interference Causing Equipment Regulations.
This product is in conformity with the protection requirements of the ICES-003
standard.
VCCI Certification (Japan)
This equipment complies with the VCCI V-3/ 2008-4 requirements.
This is a Class A product based on the standard of the Voluntary Control Council
for Interference by Information Technology Equipment (VCCI). If this
equipment is used in a domestic environment, radio disturbance may arise.
When such trouble occurs, the user may be required to take corrective actions.
A VCCI regulatory label is affixed to the equipment.
Waste Management
This product has been built to comply with the following directives:
REACH
Regulation (EC) N°1907/2006 of the European Parliament and the 18/12/2006
REACH Council
ROHS
2011/65/EU
WEEE
2012/19/EU

p‐3Safety Notices
Safety Notices
Important Read the safety notices before undertaking any procedures
described in the documentation.
All safety notices used in the documentation are listed in the Multilingual Safety
Notices Guide and are classified by severity:
D0xx DANGER
D0xx
A Danger notice indicates the presence of a hazard that has the
potential of causing death or serious personal injury.
C0xx CAUTION
C0xx
A Caution notice indicates the presence of a hazard that has the
potential of causing moderate or minor personal injury.
W0xx WARNING
W0xx
A Warning notice indicates an action that could cause damage to a
program, device, system, or data.
Each safety notices is prefixed with a unique identification number. This can be
used to locate the corresponding translated version in the Multilingual Safety
Notices Guide.

Chapter 1. Related Publications 1-1
Chapter 1. Related Publications
This list is not exhaustive. Useful documentation is supplied in the Resource
and Documentation ISO file delivered with the system. You are strongly advised
to refer carefully to this documentation before proceeding to configure, use,
maintain, or update your system.
Read Me First
•Resource and Documentation ISO file
contains the tools and documentation required to configure, operate and
maintain the system.
•Dell S5000 Series Servers for SAP HANA Site Preparation Guide
explains how to prepare a Data Processing Center, in compliance with the
standards in force. This guide is intended for use by all personnel and trade
representatives involved in the site preparation process.
•Dell S5000 Series Servers for SAP HANAMultilingual Safety Notices Guide
lists, in different languages, the notices referenced in the documentation
procedures.
•Dell S5000 Series Servers for SAP HANA Description Guide
gives a general overview of the server. This guide is intended for use by
administrators and operators.
•Dell S5000 Series Servers for SAP HANA Rack Cabinet Prerequisites
gives the prerequisites to install a Dell S5000 Series server in a rack cabinet.
Installation
•Dell S5000 Series Servers for SAP HANA R@ck'n Roll 1200 Installation and
Service Guide
explains how to install and service the cabinets. This guide is intended for
use by qualified personnel.
•Dell S5000 Series Servers for SAP HANA R@ck'nRoll Cabinet Unpacking &
Depalletizing Sheet
explains how to unpack and depalletize the Rack'n Roll 1200 cabinet.
•Dell S5000 Series Servers for SAP HANA Installation Guide
explains how to install the server for the first time. This guide is intended for
use by qualified personnel in charge of installing servers.
Operation
•Dell S5000 Series Servers for SAP HANA SHC Reference Guide
explains how to use the Server Hardware Console (SHC) to manage the
server. This guide is intended for use by server administrators, operators and
qualified personnel.
•Dell S5000 Series Servers for SAP HANA Getting Started Guide
gives an overview of server features and provides tips and instructions to get
started with the server.
•Dell S5000 Series Servers for SAP HANA Configuration Guide
explains how to configure and manage servers.

1-2 Description Guide
•Dell S5000 Series Servers for SAP HANA Remote Hardware Management CLI
Reference Guide
describes the Hardware Management CLI (Command Line Interface) for the
Dell S5000 Series Servers for SAP HANA. This guide is intended for use by
system administrators and operators in charge of managing systems locally
and remotely and of writing server management batch scripts.
•Dell S5000 Series Servers for SAP HANA Remote Hardware Management CLI
Quick Reference Guide
gives a summary of the Hardware Management CLI (Command Line
Interface) for the Dell S5000 Series Servers for SAP HANA.
•Dell S5000 Series Servers for SAP HANA Redfish Reference Guide
explains the implementation of the Redfish API for the Dell S5000 Series
Servers for SAP HANA management. This guide is intended for use by
administrators and operators in charge of managing systems.
Maintenance
•Dell S5000 Series Servers for SAP HANA Customer Service Guide
explains how to replace Customer Replaceable Units (CRU). This guide is
intended for personnel in charge of maintaining the servers on the
customer's site.
•Dell S5000 Series Servers for SAP HANA Customer Troubleshooting Guide
explains how to troubleshoot the server.
•Dell S5000 Series Servers for SAP HANA Messages Reference Guide
describes help messages and associated recovery actions to troubleshoot
servers. This guide is intended for use by server administrators and
operators.

Chapter 2. Dell S5000 Series Servers Overview 2-1
Chapter 2. Dell S5000 Series Servers Overview
2.1. Overview
The Dell S5000 Series Servers for SAP HANA are designed to be modular, easy
to maintain and to increase density and maximize memory capacity.
They exploit the Intel®C627 Chipset, Intel®Xeon®Scalable processors and
the UPI Intel protocol.
Each Dell S5000 Series server module is 2U high and includes two sockets that
can support up to twelve memory modules each. It features five PCIe slots
(either five PCIex8 or two PCIex16 plus one PCIex8).
The Dell S5000 Series offers a S5408 glueless multi-module server via an
intermodule connecting box. The S5408 server can be upgraded to the S5416
server using a UBox, that houses the eXternal Node Controller (XNC).

2-2 Description Guide
2.2. Dell S5000 Series Servers
2.2.1. S5408 Server
The S5408 server is composed of:
•Four modules
•One 4-module connecting box
Rear view
Mark Label
A4-module connecting box
BModule 0
CModule 1
DModule 2
EModule 3
Note If the server is not fully populated with four modules, a filler bezel can
be inserted into the empty space. See section 2.3.3. Filler Bezel for
details.

Chapter 2. Dell S5000 Series Servers Overview 2-3
2.2.2. S5416 Server
2.2.2.1. Overview
The S5416 server is composed of:
•Two S5408 server assemblies (A)
•The 8-module connecting box at the rear (B)
•The UBox at the front (C)
Rear view

2-4 Description Guide
Exploded view
Front view

Chapter 2. Dell S5000 Series Servers Overview 2-5
2.2.2.2. Modules Numbering
Rear view
Mark Description
AModule 0
BModule 1
CModule 2
DModule 3
EModule 4
FModule 5
GModule 6
HModule 7

2-6 Description Guide
2.3. Module
2.3.1. Module Overview
The module consists of the bezel and the main box at the front, the Power
Supply Units (PSUs), the PCIe slots and the Intermodule connecting box at the
rear.
All these components are included in the compute box.
Mark Description
A Bezel
BMain box
CCompute Box
DPower Supply Unit (PSU)
EPCIe slots
FModule connecting box

Chapter 2. Dell S5000 Series Servers Overview 2-7
2.3.2. Main Box Overview
The main box consists of a compute unit (A) and an optional unit (B).
2.3.3. Filler Bezel
If the server is not fully populated with modules, a filler bezel is inserted into
the empty space. It is attached to the front of the server by two captive screws.
