Open Manage Network Manager – Release Notes
Package Release Numbering: 4.4
The following is the format for release/version numbers:
<ProductID>.<Major Version>.<Minor Release>.<Maintenance
Release>.<Build #>
When contacting Customer Support, please refer to the complete release number
for components, which is in the Help > About Box. The versions mentioned below
refer to component versions rather than the package.
Note
You can upgrade to this release only from OMNM 4.3. Upgrades from other versions of OMNM are
not supported. Also: If you upgrade, you must re-register any additional licenses you have pur-
chased by opening the Settings > Permissions > Register Licenses menu, and locating the license
upgrades you have installed previously. (3446)
This OpenManage Network Manager release adds support for new PowerConnect
devices as well as several significant firmware updates. Many known bug fixes are
also included.
Caution
Do not install this software when a command or oware shell is open. Close the shell first.
Also: Even though the installer allows it, do not select an IPv6 address during installation. It is not
supported.
Some notes below refer to OpenManage Network Manager as OMNM. Use the
numbers at the ends of notes below for reference when you contact tech support.
Significant New Features in This Release
The following sections are application notes. See also Supported Functionality and
Equipment on page 14 for equipment-related notes. This is a 32-bit application,
however it has been tested for Windows only on both 32- and 64-bit operating
system versions. Linux works even on their 64-bit versions, as long as the 32-bit
libraries are installed. Windows 2003 Server 64-bit on Dell 64-bit hardware is the
reference test platform for Windows.
General
• OpenManage Network Manager now comes with a license to manage up to
10 Dell devices, and up to 50 unknown, other devices. OpenManage Network
Manager supports only more limited (SNMP-only) management for unknown
devices, but you may be able to upgrade to complete management with
optional add-ons.
• Supported devices now include the following:5524, 5548, 5524P, 5548P,
7024, 7024P, 7024F, 7048, 7048P, 7048R, 7048R-RA, M8428-K, M8024-K, J-
SRX100S, J-SRX100SU, W-620, W-650, W-651, W-3200, W-3400, W-3600, B-

Open Manage Network Manager – Release Notes
2
MLXe4, B-MLXe8, B-MLXe16, B-FCOE1024, B-FCX624, B-FCX624S, B-
FCX648, B-FCX648S, B-TI24X.
• Support for PowerConnect B-Series: B-RX4, B-RX8, B-RX16, B-8000/8000e,
and B-DCX4S. See PowerConnect B-Series on page 16 for more about these.
Note
Key Metric monitoring is not supported by some RX devices. If you save a Key Metric monitor with-
out monitor-able attributes, it will disable that monitor for other devices too. Workaround: action >
Reload default monitors. (12556)
• Support for PowerConnect J Series EX8208, EX8216, EX4200-24T, EX4200-
48T, EX4200-24F, SRX100B, SRX100H, SRX210B, SRX210H, SRX210-P,
SRX240B, SRX240H, SRX240-P, SRX100S, SRX100SU. See PowerConnect J-Series
on page 17 for more about those.
• Supported systems also include 3800, 3850, 3900, 200E, 2014, 2016, 2040,
2024, 4100, 4900, 5000, 76000, 12000, 24000, 48000, DCX 8000e, 8000, Big-
Iron RX4, RX8. (See Help > About for the details of supported firmware.)
• While not officially supported in OpenManage Network Manager 4.4, there
have been a few requests to install it onto Windows 2008 R2 and some have
claimed that it works fine with R2. OpenManage Network Manager 4.4 how-
ever is only officially supported on the R1 version of Windows 2008 Server.
To install and use without such official support, you must override a setting
during installation. To ignore the OS version, add the following line to the
setup.ini file in the installation root directory before install:
ignore.os=true
• OpenManage Network Manager includes several new ACLI group operations
in this version. You must install Perl to take advantage of all of these opera-
tions’ capabilities.
• Upgrading: You can upgrade to this version of OpenManage Network Man-
ager from the previous one. So you can upgrade from 4.3 to 4.4. Upgrade
from 4.1 to 4.2, then to 4.3 if you have a previous version.
Configuration File Management
• Summary backup e-mail from Group Operations’ backup “single” e-mail now
publishes its results in the following groups (and in the following order):
- changes
- new files
- no changes
- error
If a group has no members, it does not appear in the e-mail. Devices in a
group appear listed in order of device name sorted alphabetically. (11477)
• E-mails from file backup group operations now provide lines below and
above any comparison. This “CONTEXT” e-mail format is now the default.
You can return to the previous default format by changing properties in
\owareapps\lib\nr.properties . Look for the email.type property.
(11464)

3
Open Manage Network Manager – Release Notes
• OpenManage Network Manager can automate sending e-mail if a configura-
tion file changes. If the e-mail attachment describing config changes is
empty, now the e-mail sent says “No changes” in the subject. (8934)
• To produce e-mails that do not count a shift in a config file line’s position as a
change, modify the following property in
\owareapps\netrestore\lib\nr.properties (or, better, override it in
owareapps\installprops\lib\installed.properties
):
#============================================
# NetConfig Move Omit Property:
# Terms specified will be used to let NetConfig
# know what movement changes in config files should be
# included in configuration changes emails.
#
# Note: This property is only used if
# identical(!) lines move in config files.
#
# Example:
# Old Changes:
# line 259: ntp server 10.20.0.1
# New Changes:
# line 273: ntp server 10.20.0.1
#
# In the above case the line moved from line 259 to 273.
# This change will show up in the email sent to the specified
# end user.
# To omit this change from the email, include 'ntp server' in
# the property below.
# Best practice is to place this property in
# ...\owareapps\installprops\lib\installed.properties
#============================================
#append.com.dorado.redcell.netrestore.backup.move.omit=,## Last
Event/Alarm Management
• Added Entity Description as a viewable field in the alarm manager. (6054)
• The filter manager inside the event processing rules editor now allows you to
filter by either entity or by entity name. (2199)
• You can now view affected services and customers for selected alarms by
right-clicking them. (4678)
• Added Alarm Suppression which can be initiated either manually or by a
schedule.
• Added Alarm Propagation

Open Manage Network Manager – Release Notes
4
• Syslog message correlation to avoid duplicates is more sophisticated. Added
Causes and Impacts to alarm reference tree for service-related alarms. These let
you see the sources and repercussions of a service alarm.
• The attribute, Service Effecting, now appears in event definitions. A new filter,
Service Effecting, is available for alarm manager or the user can include this
attribute in their own filters. Note: Alarms with severity less than minor are
not considered service effecting no matter what the event definition says.
Known Issues
• Link discovery is not supported for the Wireless devices that do not support
LLDP. (PV-15101)
• The “Print available enabled ports” or “Print available disabled ports” action
works only when the list of ports includes the Administrative State and Oper-
ational State columns. This option also only prints ports already visible in
the current Ports manager view. (12800)
• If you collect performance data, the more you collect, and the slower the
machine you use to run OpenManage Network Manager, the longer a dash-
board with that data takes to appear. (12939)
General
• Lists in properties: If you list properties, or even a single item in a property,
you must prepend a comma. For example:
append.com.dorado.redcell.netrestore.backup.change.omit=,ntp clock-
period
(11404)
• Count of Managed Items—If the number of items that appear in a manager
differs from the count reported, or from the maximum rows set, you may not
have permission to see all such listed items. OpenManage Network Manager
calculates maximum rows on all available items, but only displays those for
which the user has access permissions. (11103)
• Web v. Java Client—Web clients are more limited than Java clients. For
example: The “are you sure you want to do this?” confirming dialog boxes
that appear on Java clients do not appear on the web. For a complete list of
features supported on Java v. web clients, consult the User Guide. (8087)
• Installation—Windows 2008 Terminal Server is not supported. The installer
becomes non-responsive with Data Execution Prevention enabled. This
option is disabled by default on Windows Server 2008, but is enabled on a
Windows Server 2008 machine running Terminal Server.(2310)
• Linux Installation—When installing to Redhat 6+, you must install the
“compatibility libraries” from Redhat’s package manager before OpenManage
Network Manager can successfully install. (PV-12964)
• Discovery—The final discovery panel, whether appearing for a Discovery
profile or at the end of the advanced wizard presents asynchronous informa-
tion. If you click Finish before the process is done, the discovery process still
continues. While that is occuring you may not see elements being discovered
in their resync schedule until the discovery job is actually complete. Execut-
ing scheduled resync while discovery is still ongoing may also result in excep-
tions. (1581)

5
Open Manage Network Manager – Release Notes
• On rare occasions, the job viewer displaying discovery progress may display
overlapping or jumbled information. Workaround: Open this discovery
screen in Audit Trails. (PV-8639)
• SSH with
stricthostkey checking = yes is not supported (5350)
• Virus Warnings—Two files installed with this product—
bash.exe and
md5sum.exe —may trigger warnings with some anti-virus software. If you get
a virus detection warning for these files during installation, take no action.
• Java Errors—Some Java errors may appear when logging into OpenManage
Network Manager’s client. These are typically benign, and have no effect on
the software’s operation. (1539)
• Uninstalling—The uninstaller deletes
uninstall.exe if you press the cancel
button. After canceling uninstallation, several directories and files remain on
disk that require manual deletion to completely uninstall. (606)
• Limitation of Context-Sensitive Help—When you call a help screen, con-
text-sensitive help typically appears for the entire screen, not equipment-spe-
cific panels—although some exceptions to this rule do exist. Workaround:
Search the index for the context-appropriate helpscreen. (214)
• Group Operations—When you delete an equipment group that is the target
for group operations, the group operation does not work correctly. (591)
• The internal FTP/TFTP file server is not supported on Linux. Nevertheless, the
Test button remains active, and will cause an error if used in that context.
(1326)
• User Account Control—This Application requires User Account Control be
disabled in Vista or any other operating systems with this capability (like
Windows Server 2008). (2311) Alternatively, you can run application server as
service. Another option is to run as administrator on startappserver. In Vista,
right click the startappserver icon and select run as administrator. (8779)
• Views—In some managers, altering the default view means all users will see
that alteration. Workaround: If you want a view that is uniquely your own,
create a new one. (2714)
• Telnet sessions—Telnet sessions are synchronous. You cannot interrupt a
command in progress with another command you send, unless you have
enabled something that periodically prompts for additional commands (for
example enabling line continuation prompts).
• For cut-through or Direct Access to login to a device, it must be configured
with a login userid and/or password. Without this configuration Direct Access
produces a login prompt but not enable-level access (PV-14372).
• If something from the old installation is running during an upgrade installa-
tion, it interferes with completing the new installation. Workaround: Reboot
to terminate stray processes and re-do the installation. (PV-14975)
• The oraclepostinstall script does not run licenseimporter. Workaround: Run
licenseimporter manually after running oraclepostinstall.
• If you look at a port with an FC link, the parent is not visible. Link Discovery
uses only the interface name to create the name of a FC link. Workaround:
You can expand tree view to get addtional data. (12634)
• Mediation server in an HA configuration does not drop notifications. This
results in delievery of very old notifications when a switchover from standby

Open Manage Network Manager – Release Notes
6
to active occurs. Workaround: Request a patch from your sales representa-
tive. (12178)
• In clustered deployments the heartbeat polices does not redeploy correctly
after upgrading. Workaround: Disable and reenable the heartbeat policy.
(12433)
• During application server startup the following error is benign. You can safely
ignore it: “soap service manager: unable to read 'deployedservices.ds': assum-
ing fresh start” (6705)
• You can create a bad filter that conceals the Layout menu in a manager if you
add an empty “Match all of the Following” term, followed by another “Match
all of the Following” term with a single criterion. Workaround: This is not an
issue if you remove the empty (second) "Match All of the Following." (12125)
• You can add an Alarm Suppression column to Resource Manager, but its func-
tionality is not applicable to OpenManage Network Manager (3208)
• Importing a license when the server is running may not take effect for up to
15 minutes. There is no user interface indication that the license update does
not take effect immediately. (11574)
• When you filter the display of schedules by end date, those ending after “n”
occurances appear in the result set. Regardless of whether you filter for a spe-
cific date or never-endings schedules, any schedule that ends after “n” occur-
ances appears. (11425)
• The software limits filters to 48924 months back, 16308 quarters back, 4022
years back. Filters produce no results if you have inputs exceeding these num-
bers (11061).
• When tasks appear in the Inspect panel during discovery (not from a menu,
or from Discovery Profiles) you may see duplicate task entries because the
Group ID is set. The Group ID of the task matches the name of the Profile
associated with it. You can safely ignore these duplicates. (7819)
• Some audits may show a “working” icon (gears) even though the task is com-
plete. (8756)
• Some hot keys (for example [Alt]+s) do not work in the revised Discovery wiz-
ard. Workaround: Use the mouse rather than hot keys. (8313, 8314)
• A benign warning sometimes appears when OpenManage Network Manager
clients shut down. (8686)
• The IP address filter selecting ranges is limited to 254 IP addresses.
Workaround: If you need to do, for example, group operations on more
devices than this limit, make several groups rather than a single group. (8597)
• The Next Execution date in scheduled Discovery profiles may display an erro-
neous date. (8307)
• On Windows 2008 Server, the Print or Export dialogs can disappear behind
the OpenManage Network Manager user interface. Workaround: Use
[Alt]+[Tab] to make the dialog box visible. (8245)
• If the properties screen in topology disappears after you have opened it, use
[Alt]+[Tab] to retrieve it, and make whatever changes you like, or close it.
(7311)
• Filters in Port Manager may retrieve ports whose name does not agree with
the filter if those whose name agrees are connected. (7073)

7
Open Manage Network Manager – Release Notes
• Some types of reports run only against the OpenManage Network Manager
database, and do not require the selection of equipment. In these cases, the
Add button in Select equipment groups appears disabled. (6387)
• If you make an inventory report with Adaptive CLI as the Inventory Type, the
Add button is grayed out under Select the Equipment Groups for this Report.
Some inventory types do not allow for the selection of equipment because
they run against the entire database. (6387)
• Web client has difficulty connecting to Linux SUSE application server.
Workaround: The following steps configure X Windows on SUSE, to allow
for subsequent xvfb sessions to successfully start.
1. in YaST Go to System.
2. Go to
/etc/sysconfig Editor .
3. Select Desktop.
4. Select Display manager.
5. Select DISPLAYMANAGER_XSERVER_TCP_PORT_6000_OPEN and set
this value to Yes .
6. Reboot (full reboot so that X windows is completely shutdown and
restarted
OpenManage Network Manager should now start normally.
• After you select both equipment and links in topology, the action > Key Met-
rics menu item appears, but as long as links are selected, you cannot initiate
key metric monitoring. (4592)
• You cannot select links in topology or link manager and suppress alarms on
them. (4589)
• If a cursor hovers over the small update column within a table in a selector,
and you right mouse click, it selects the row, but the Select button at the bot-
tom of the screen is not enabled. Workaround: Left- (or right-) click else-
where in the row, the the Select button works. (4468)
• Newly created filters do not appear until you close and reopen a manager.
(4443)
• When you make a copy of any OpenManage Network Manager user group,
you only copy a set of the current permissions. If an upgrade introduces new
permissions, the copy is not updated; only OpenManage Network Manager
seeded groups get updated. Workaround: Open the copied group and check
all the necessary boxes to set new permissions. (4358)
• The Max items displayed count of maximum displayed rows in managers may
not accurately reflect the actual number of rows available for display after
you filter the display. For example, if you have 79 audit trail filters, and set
Max items displayed to 100 in the filter manager, you may not see all available
filters. Workaround: Increase the Max items displayed and the filtered rows
appear.
• Exceptions appear in application server and client shells and logs when you
click on Go while no value is in a manager’s filter. (2909)
• IPv6—Even though the installer allows it, do not select an IPv6 address dur-
ing installation. It is not supported. (2835)

Open Manage Network Manager – Release Notes
8
• Do Not Install Downgrades—While this application supports an upgrade
from a previous version, it does not support installing an older version over a
newer one. (2398)
• In addition to any licensing limitations, the IP Address filtering in discovery
currently does not support an IP Range of more than 1000 IP addresses. The
filter limits the query to starting the starting IP address in the range and 999
more addresses. (1995)
• You may be unable to edit a Task after making Schema (attribute) changes.
Workaround: Create a new Task to replace the one you are editing, and make
the attribute changes to it. (2202)
• When you set No. of failed cycles to two or larger in the Heartbeat function,
the Device Down alarm does not appear, even if the device does not respond.
(2208)
• Link discovery does not find OSPF links. (2200)
• Occasionally, when you invoke a help screen, a benign error appears in the
client shell (
EOFException: no more data available ). You can safely
ignore this. (1897)
• Currently in this application manages Device Authentication Configurations
separately from User Groups. When you copy a user group like Administra-
tors, the User Group manager does not coordinate Device Authentication
Configurations that refer to the Administrators group.
• For a new User Group to have access to existing devices you must manually
add them to the approved groups list in the Authentication Configuration.
(1493)
• Cannot start application server manually. Workaround: Install with applica-
tion server installed as a process (so it starts with Process monitor) or go to
\Dell\OpenManage\Network Manager\oware\bin\owcommonfunctions ,
and modify the section starting
GetServerVMHeapSize to set
MaxPermSize=128m
(1831)
• The Discovery Wizard sticks at Select Devices to be discovered panel if a device is
marked licensed -> No and you check the box indicating the device is to be
saved. Workaround: Unselect the check box. (Note: this may only happen
when Other is licensed and the actual device's license is not enabled.) (1536)
• If you do not shut down clients before restarting application servers, warn-
ings like the following appear in the application server log/shell:
2009-01-08 10:58:35,425 WARN
[org.jboss.ha.framework.interfaces.HAPartition.APP-T1000Partition]
javax.naming.NameNotFoundException: ServerStatus not bound
(1237)
For Windows XP, you must install service pack 3, and installing .NET v. 3 is
strongly recommended, particularly if you are monitoring the performance of
Windows equipment.
• Upgrade / Data Migration Fails—If an upgrade installation fails with the mes-
sage with the
app_setup.log error Connecting to database...>>>>>
ERROR: OWSessionIDRDBMS : Failed to make database connection
, the
problem is that the database is not running on the host being upgraded. To
cure this problem, manually start the database, and then re-try the upgrade

9
Open Manage Network Manager – Release Notes
installation. The following are the startup commands for the embedded data-
base:
Linux (executed as the root user):
/etc/init.d/owaredb start
You should see the following response in the shell where you execute this
command:
Starting MySQL[ OK ]
Windows:
net start mysql
You should see the following response in the shell where you execute this
command:
The MySQL service was started successfully.
• Red Hat Password Malfunction— If you launch a new form, password fields
in Red Hat Linux may not work. Workaround: Before typing into a password
field, type/change something in a normal text field. Then return to the pass-
word field and it should let you enter characters. This is a third party issue
already known to Redhat on 1.6: (878)
• Topology—You can tile printing topology views over several pages; however,
if you make that number of pages very large—for example, 100,000—generat-
ing the print job or preview will adversely impact performance. If this occurs,
OpenManage Network Manager may freeze. (750)
• Printing Topologies—If you change the page orientation to landscape then
print, label text appears backwards and upsidedown on Japanese Windows
XP Pro. Workaround: Print in portrait not landscape orientation. (749)
• Linux Headless Servers—For headless Linux systems, you must change the
DISPLAY variable. Use
DISPLAY=<ip address>:623:0 rather than
DISPLAY=<ip address>:0.0 .
• Ethernet link discovery does not discover links to servers. (456)
• In some managers, the max row count limits any query to return the proper
number of items, but changing it may return an inaccurate number of rows.
(44454)
•
Too many open file errors appear in logs. Workaround: On Redhat Linux
installations, modify
/etc/security/limits.conf on the application
server/mediation server installations. Add the following to the file to lift the
file limits:
username hard nofile 90000
username soft nofile 90000
Replace username with the name of the user under which the application
server was installed. (44236)
• Uninstalling on Windows XP, Service Pack 3 may produce a benign error:
owprocmon.exe has encountered a problem and needs to close.
(43481)
• You can delete a filter already in use for a manager. If you do this, then the
next time you open that manager, it opens with its default filter. (43008)
• If the ifindex value changes on the ports/interfaces while the application is
discovering them, discovery does not work. (41801)

Open Manage Network Manager – Release Notes
10
• Devices discovered without a supporting device driver installed support
Direct Access functionally with telnet and SSHv1 (not SSHv2). (43237)
• To see all available content, you may have to resize subpanels when looking
at Audit Trails in a web client. (41045)
• In some screens of the web client, you may have to resize the screen to see all
fields and labels. (42420)
• A
cannot open Internet site... error appears while opening Web client.
Workaround: Such an error appears when you take the focus off the browser
while the browser displays the opened manager page. To avoid the error, do
not move focus. Alternatively, you can update your browser to Internet
Explorer is version 7.0.5730.13 or later. (42279)
• An error message about changing colors may appear when you install on a
machine with Windows Vista AERO Graphics (3D graphics) enabled. This
occurs because the operating system is scaling back to 2D graphics for the
installer. You may also have to resize some installer screens to read the text.
This is a benign error that does not otherwise affect the application’s perfor-
mance once it is installed. (42050)
• In the web client, some forms display a warning to the user about slow
scripts. Click Continue and the script will complete.
Work arounds to extend the script time-outs for the supported browsers:
For Internet Explorer, see http://support.microsoft.com/kb/175500 setting
the decimal value to, for instance, 10000000.
For Firefox, set the URL to
about:config , and set
dom.max_script_run_time to a larger number, like 20. (42096)
• When you shut down the application server using Server Manager, the fol-
lowing error may appear:
Could Not Stop the Oware Service Manager on
Local Computer
.The application server will stop in 30-60 seconds. You must
wait until the Service Manager Stop Service progress bar completes before
attempting to restart the application. Even when the error appears, the appli-
cation server still shuts down. (41862)
• When you delete a device already scheduled for device discovery resync, an
Equipment Not Managed entry replaces it in the scheduler screen. (42133)
• When you manage a device by hostname, even though this application can
collect and manage other information from the device, the listed manage-
ment interface IP address does not update on resync if DHCP or some other
process changes the IP addresses for the device. (42328)
• You may see the following if you use SSL for your web client:
ALERT
SSL certificate due to expire soon (expires on: 2008-08-18 17:57:03,
cert: /C=US/ST=CA/L=Folsom/O=Dorado Software/OU=Development/
CN=tomcat)
Although this self-signed certificate indicates it is expiring, an expired certifi-
cate still functions and does not impose any additional inconvenience on the
web user since the certificate always has issues with hostname and issuing
certificate authority. The original intent was that users would install a valid
certificate and not use this application’s certificate in production.

11
Open Manage Network Manager – Release Notes
Users who have configured the web server to use SSL can run
$OWARE_USER_ROOT/oware/bin/updatetomcatcert to generate a new cert
and update the keystore if the certificate has expired. All recent releases
include a certificate which does not expire for approximately 100 years. (SCR
43257)
• If you want to use the web client with a Linux server, you must use the pro-
cess monitor to start the application server, or otherwise ensure Xvfb is run-
ning prior to starting the appserver. For example, here are commands to start
Xvfb (run as root):
Linux:
/usr/bin/Xvfb :0 -dev vfb screen 0 1152x900x8 &
or
/usr/X11R6/bin/Xvfb :0 -screen 0 1152x900x8 &
(42469)
• This application supports SNMPv3 with privacy using DES privacy encryption
only. (37796, 38959)
• To set the environment correctly for command line functions, after installa-
tion, type oware (or . /etc/.dsienv in Linux—[dot][space]/etc/[dot]dsienv)
before running the specified command. Also: This application can run on any
Linux desktop environment (CDE, KDE, Gnome, and so on) but the installer
will only install shortcuts for CDE. (36442)
• For Linux, you must install no more than a single instance of MySQL—the
one installed with this Element Management System. Before you install,
remove any MySQL if it exists on your Linux machine.
• Some device drivers do not support chassis view for the equipment they man-
age. An error appears when you try to access chassis view: Chassis view for this
device is currently not supported.
• Performance: This application cannot respond faster than the network per-
mits, but the complexity of devices is also important. For example, it can take
time to delete a device that has 4000 interfaces. Such a device can take up to
several minutes to delete, depending on your installation’s hardware.
• This application supports only syslog messaging over UDP, not syslog messag-
ing over TCP at this time (23592)
• When you change the SSH key, subsequent logins can fail if you select the
Regenerate key option and create a new key. This application caches the key
value in a file: <installdir>\oware3rd\cygwin\.ssh\known_host.
You must delete this file since the application looks there for the key. The
application then generates a new file with the new key. This applies to all
device drivers using SSH. (23802)
• A device login banner can not contain the same character(s) that are used
during the device login sequence. For example hashmarks (#) greater than
symbols (>) etc. (24992)
• Clicking on a port or turner refreshes the screen. To display the port edit
screen, you must select a port, and then click Open. (24222)
• This application does not support interface identifier numbers that are very
large. If the query “Fetching children, please wait” freezes it may be on

Open Manage Network Manager – Release Notes
12
account of this limitation. Workaround: Rename the interface with a telnet
session. (32594)
File Management
• You may experience difficulties when using 3CServer as your FTP server.
Workaround: Use 3CDaemon (8525)
• If you cancel changes while creating a new filter within the file server man-
ager, you must exit the filter editor then recreate a new filter before you can
save the filter. (11206)
• A “%1 in event message” error appears if you backup a device without a con-
figured file server.
• In some cases, “NetConfig” appears instead of “File Management” in
messages—for example in Audit Trail queries for type of audited messagess.
Event Management
• OpenManage Network Manager supports multiple IP addresses per resource.
During event processing, filters that include IP address criteria may behave
incorrectly when OpenManage Network Manager evaluates the filter.
Workaround: Best practice is using resource name(s) instead of IP addresses.
(PV-12532)
• The default polling interval is 5 minutes, but if you reduce the polling inter-
val, polling cycles maybe skipped depending on hardware resources, number
of devices being polled and network latency. (11959)
• Events with no corresponding definition appear as alarms of indeterminate
severity. The only way to change behavior of an unknown event in this ver-
sion would be to locate the missing MIB and load it into the system. This cre-
ates the missing event definition(s) needed to specify explicit behaviors.
• Northbound action can now send as proxy. With this option set, there are no
issues with XP’s security patch, Vista or Server 2008. The application attempts
to spoof sourceIP on packet only when the proxy option is not selected.
(1737)
• In Linux, the Event definition manager panel cannot resize when the cursor
changes to a horizontal bi-directional arrow sign. It can only be resized when
the cursor is showing as a arrow sign. (37741)
• Trap listener, Inform listener and all outbound SNMP requests must bind to a
specific interface in a multi-homed environment. This interface is considered
appropriate to use for all network-facing SNMP activity. By default, this is
localhost, interpreted as the application's local IP value (the NIC selected at
installation time). The following text in
installed.properties (in \oware-
apps\installprops\lib) provides a specific IP address to control outbound
SNMP interface binding on the local machine (22258):
#
# specific interface used for all NMS initated
# communications to the network
com.dorado.mediation.outbound.address=localhost

13
Open Manage Network Manager – Release Notes
Include the following text and provide a specific IP address to control
inbound (listener) interface binding on the local machine:
#
# specific interface used for binding mediation
# listeners such as SNMP trap listener
com.dorado.mediation.listener.address=localhost
• Currently event filter supports only single level of grouping. If you create a
new event template, you must click the filter tab on the event template edit
panel before saving the template. (21133)
• Trap Forwarding fails on windows XP service pack 2 with the error The follow-
ing error occurred in sendto:10004 This error occurs because of security changes
in winsock libraries preventing transmission of packets with source address
not matching any of the local interfaces. (24364)
Issues Fixed
General
• Modified calculation of Notifications Batched to include remaining (1) notifi-
cation before OpenManage Network Manager adds it to the queued batch
(12468)
• If you click on the overall “portal” form (the screen that contains all others),
the Edit Property dialog box disappears behind the portal. (8685)
• OpenManage Network Manager MIBs now load without incident. (396)
• If you are upgrading from a previous version, you must close all shells in
which the
oware script is running. (38571)
• In Linux, clicking Go makes columns in some managers squeeze to the left.
Workaround: Use a Windows Client. (38314)
(This is effectively resolved since Solaris 9 support ended with 5.7.6)
• The cursor position onscreen may temporarily conceal field contents in, for
example, the Equipment Editor screen (24224)
• This Application calculates the SNMP v3 EngineID based on the application
server’s local IP address. When multiple addresses exist, the expected Engi-
neID is not predictable. This problem is not limited to a physical network
interface card on the device. (36258)
• If a patch fails during the update’s deployment, the update process stops. To
receive the patches that come sequentially after the failed update, you must
unselect the failed patch in the next update try.
Event / Alarm Management
• Minimizing the Alarm Detail window in the Alarms screen, then closing
Alarms can cause the Detail panel to disappear. (38270)
Review the default DAP and default schedule to ensure that it is aggressive
enough for your deployed system. (38213)

Open Manage Network Manager – Release Notes
14
Supported Functionality and Equipment
The following section contains release notes for functionality and equipment
supported in this product.
• Support added for Windows 7 (Business or better).
• Support of new firmware versions for all existing models.
• Support for Powerconnect 3000, 5000, 6000, 7000 and 8000 series switches.
• Backup and restoration of configuration files, configuration management and
configuration file comparison.
• Equipment Group Management: You can make configuration changes and
deploy firmware to many switches in a single operation.
• Event Management: Available through the capturing, filtering and forward-
ing of events and traps.
• Scheduling: You can schedule network management operations like backup
and configuration changes.
• Performance Management: Capture statistics from PowerConnect switches
and graph these statistics for troubleshooting and network optimization.
• Operating System/Firmware Management: Manage operating systems, or
firmware, in a centralized database that can categorize by PowerConnect
model for easy deployment of these operating systems to the switches.
• Topology: Map and monitor network elements in both a geographical view
and a logical view for easy visual analysis of the network.
• Supports Linux (Redhat v4), Windows 2003, 2008, XP, Vista, and Windows 7.
Also supports Multi-Language modes (independently from the operating sys-
tem’s default language) for German, Spanish, Japanese, T. Chinese and French
language variants.
• Provides discrete operations screens that let you copy running-config to
either startup-config or backup config; additionally, after a configuration
change user is presented with an option to copy running to startup config.
• Alarm screen shows alarms for Dell devices.
• Port Manager displays tells what ports are in use across the network.
Known Issues
• If you use the “backup to flash” option when backing up configuration files,
the filename must have the extension
*.tar.gz. If not, restore fails with a
“failed to decompress” error. (PV-15283)
• 55xx devices echo command lines sent to them, so Adaptive CLI commands
display echoed characters in their Audit Trails. This is not an error and does
not mean the configuration failed. (PV-14796)
• Upgrading from switch to router firmware on an FCX device upgrades an L2
Switch with L3 firmware, so the IP commands/configuration changes and the
L2 configuration are ignored. The device needs to be reconfigured from the
console. (PV-14369)
• M8024-K does not support ethernet link discovery (PV-14853)

15
Open Manage Network Manager – Release Notes
• No support for firmware v4.1.x or greater on the following devices: PC8024,
PCM6220, PCM6348, PCM8024
• PowerConnect 62xx users must be running 3.x.x.x firmware (or later) on
their switch before they can do a standard firmware upgrade. Attempting to
upgrade the firmware while at version 2.x or 1.x fails. To upgrade from these
versions, see the special instructions provided in the Release Notes and
Readme for the firmware itself. (8507)
• OpenManage Network Manager receives all data from the Dell 62xx device,
but if the Last Update day is more than a single digit, then the entire data
table disappears, and OpenManage Network Manager displays a Form Error.
One other symptom: the Last Update, Total Inserts, Total Deletes, Total
Drops, and Total Ageouts do not appear correct, as they are in the CLI.
Workaround: Rebooting switch sets the Last Update back to zero. Once done,
the LLDP Stats works again. (8213)
• Cable Tests on ports in a stack may fail, producing the message
Test has not
been preformed
. Workaround: Make sure the management (master) switch
is set to Unit-1 in the stack. (8129)
• Some discrete configuration (Resource editor) screens do not appear or are
inoperable in Web client. Workaround: Use the Java client. (7110)
• Stacked switches change IP addresses when the master is moved. Moving
master does not function properly in stack configuration. (7002)
• When editing any interface set to disabled mode, and choosing vlan tagging
from the combo box, you will not be able to add a VLAN ID. The field is
grayed out. Workaround: Switch the selection to another item and then back
to the desired one. (6355)
• For PowerConnect 62xx series devices, Editing Managed Equipment does not
display the correct values for Power over Ethernet (PoE) Port Settings parame-
ters. Workaround: Use the PowerConnect 62xx command line interface or
Web Console to view Power over Ethernet (PoE) Port Setting parameters.
(13107)
• You must use the command-line interface to deploy new firmware for the
5324 model (4739)
• LLDP modification through this application may not work on M8024
devices, therefore you must setup LLDP through the telnet CLI. (2583)
• When one of the three banners already configured on a 35xx or 54xx device
is longer than 500 characters, you must modify that banner in OpenManage
Network Manager before you can create a different banner. (2411)
• If directory locks during upgrade, check task manager and close all
ftp.exe
processes.(2455)
• Web client does npt show IPv6 information when older firmware is installed
on the switch. (2967)
• OSPF Areas cannot be deleted for M6220 devices. (44464)
• 35xx models do not support rfc 1042 and IIec, even though these frame types
appear in the screen that includes Vlan protocol group. Currently when you
select these options in Group ops and execute a group operation against a
35xx model device, an error message appears. (6268)

Open Manage Network Manager – Release Notes
16
• The Home button returns the user to the Begin Discovery page rather than
the Quickview as documents promise. Workaround: Select Quickview as the
home page manually. (6297)
• Banners are supported only up to 256 characters in length. (2265)
• To set up alarms or events for user login or logout, you must set up the device
syslog server and syslog level. For example, for the 35XX model, you must
issue the following command lines:
logging 192.168.0.117
logging file informational
(6695)
• You must wait more than three minutes to deploy another firmware version
after you successfully deploy the first firmware version. Deploying firmware
can also fail with the default timeout value. You can increase the timeout
value from the Management interface and also in \owareapps\dellpoewr-
connet\dellpc.properties. (6680)
• You must typically increase the timeout for firmware deployment of multi-
stack devices. Stop the Dell OpenManage Network Manager service in Win-
dows., edit the file powerconnect/lib/dellpc.property, and set
PC_NR_TIMEOUT = 10000000. (6681)
• To disable LAG Spanning Tree on a 62xx, you must set the Path Cost to a min-
imum of 1. Leaving path cost at 0 will cause an SNMP error. (6304)
• Dell devices have an SNMP Management Station entry in their web pages
that specifies a destination for SNMP communication. If this does not include
the address of the mediation server (in single host installations this is the
application server), discovery will fail on the SNMP get step. (6689)
PowerConnect B-Series
Firmware / OS Image Update Procedure
Follow these steps to update firmware on the non-RX devices:
1. Download the firmware update (.zip file) from www.brocade.com.
2. Extract that zip file to the download directory of the External FTP file server
OpenManage Network Manager uses.
3. Create an empty file named
release.plist and load into the OpenManage
Network Manager OS Image manager.
4. Deploy that image, selecting the device and
release.plist file loaded in
OpenManage Network Manager. To deploy the image, select the device(s) and
select the
release.plist file in OS Manager.
5. Remove any remaining files before attempting the next Brocade firmware
update.
Note
You cannot deploy these device’s firmware updates using OpenManage Network Manager’s internal
FTP server. (12635)

17
Open Manage Network Manager – Release Notes
Devices with two CPUs may not need to reboot, using failover to transfer the
firmware to both processors. (12638, 12394)
For RX devices, download and deploy firmware updates as you ordinarily would,
registering the OS image in the OS Images manager and deploying them to either
a device or group with the action menu.
Supported Powerconnect B-series systems include the following models: Power-
Connect B-RX4, PowerConnect B-RX8, PowerConnect B-RX16, PowerConnect B-
8000/8000e, and PowerConnect B-DCX4S.
Known Issues
• MLXe does not support ethernet link discovery. (PV-14912)
• Deploying firmware to these devices requires an external file server. (12512)
• Even though restoring a file is successful, a 4xS device does not send an indi-
cation the internal file server can interpret as a successful conclusion to the
restore action. In this case, the timeout emitted by the file server can be
benign. (12584)
• RX devices cannot discover links between the two RX devices or between an
RX and a Dell device.
This occurs because the device does not populate the LLDP-MIB LocPortTable
with unique port IDs. Therefore, link discovery cannot accurately get the port
used for a link and hence the end point is the top level device itself. When a
device has multiple links, only one of the links can be discovered.The rest are
discarded by OpenManage Network Manager as duplicates because the Local
Port ID is supposed to be unique. (12464, 12409)
• OpenManage Network Manager will not telnet connect to some devices if
they use the factory default password. You must set the password to some-
thing other than that default. OpenManage Network Manager does not rec-
ognize the additional prompt asking that default password be changed each
time log in occurs. (12240)
• The Advanced Port Report has no data. Workaround: Resync device and run
the report again (35544)
PowerConnect J-Series
This equipment has a slightly different firmware deployment than standard Pow-
erConnect models.
Firmware / OS Image Update Procedure
Follow these steps to update firmware on the devices:
1. Download the firmware update from www.juniper.net.
2. Include it as an OS image in OpenManage Network Manager.
3. Deploy that image, selecting the device and the file loaded in OpenManage
Network Manager. To deploy the image, select the device(s) and select the file
in OS Manager.
If you have a choice of Image Type in the pick list below the list of supported
models between a “jbundle” or “jinstall” file, select “jinstall.” Not all models

Open Manage Network Manager – Release Notes
18
offer this choice, and “jinstall” may or may not appear in the OS Image file
name, so check this Image Type whenever you deploy firmware.
Note
If you select “snapshot” as part of a file management action, you must have external media, like a
USB drive, plugged into the device, or an error appears.
Features
The J-Series includes the following features:
• Support for JUNOS version 10.4. (PV-13119)
• The Juniper Port Class of Service Scheduler Map now appears for first time
either in new/copy template. (PV-14254)
•
• You can now set router-id on the Routing Options service. This is also popu-
lated on service discovery. (13250)
• Support for JUNOS version 10.3. (12140)
• When executing CLI transaction OpenManage Network Manager now syn-
chronizes on the management IP address so only one session per device can
exist at any one time. (11405)
