Avaya Call Management System
Dell PowerEdge™ R720 and R620
Computer Hardware Installation,
Maintenance, and Troubleshooting
October 2015

© 2014-2015 Avaya Inc. All Rights Reserved.
Notice
While reasonable efforts have been made to ensure that the information in this
document is complete and accurate at the time of printing, Avaya assumes no
liability for any errors. Avaya reserves the right to make changes and
corrections to the information in this document without the obligation to notify
any person or organization of such changes.
Documentation disclaimer
“Documentation” means information published by Avaya in varying mediums
which may include product information, operating instructions and performance
specifications that Avaya generally makes available to users of its products.
Documentation does not include marketing materials. Avaya shall not be
responsible for any modifications, additions, or deletions to the original
published version of documentation unless such modifications, additions, or
deletions were performed by Avaya. End User agrees to indemnify and hold
harmless Avaya, Avaya's agents, servants and employees against all claims,
lawsuits, demands and judgments arising out of, or in connection with,
subsequent modifications, additions or deletions to this documentation, to the
extent made by End User.
Link disclaimer
Avaya is not responsible for the contents or reliability of any linked websites
referenced within this site or documentation provided by Avaya. Avaya is not
responsible for the accuracy of any information, statement or content provided
on these sites and does not necessarily endorse the products, services, or
information described or offered within them. Avaya does not guarantee that
these links will work all the time and has no control over the availability of the
linked pages.
Warranty
Avaya provides a limited warranty on its hardware and Software (“Product(s)”).
Refer to your sales agreement to establish the terms of the limited warranty. In
addition, Avaya’s standard warranty language, as well as information regarding
support for this Product while under warranty is available to Avaya customers
and other parties through the Avaya Support website:
http://www.avaya.com/support
Please note that if you acquired the Product(s) from an authorized Avaya
reseller outside of the United States and Canada, the warranty is provided to
you by said Avaya reseller and not by Avaya. “Software” means computer
programs in object code, provided by Avaya or an Avaya Channel Partner,
whether as stand-alone products or pre-installed on hardware products, and
any upgrades, updates, bug fixes, or modified versions thereto.
Licenses
THE SOFTWARE LICENSE TERMS AVAILABLE ON THE AVAYA WEBSITE,
http://support.avaya.com/LicenseInfo/ ARE APPLICABLE TO ANYONE WHO
DOWNLOADS, USES AND/OR INSTALLS AVAYA SOFTWARE,
PURCHASED FROM AVAYA INC., ANY AVAYA AFFILIATE, OR AN
AUTHORIZED AVAYA RESELLER (AS APPLICABLE) UNDER A
COMMERCIAL AGREEMENT WITH AVAYA OR AN AUTHORIZED AVAYA
RESELLER. UNLESS OTHERWISE AGREED TO BY AVAYA IN WRITING,
AVAYA DOES NOT EXTEND THIS LICENSE IF THE SOFTWARE WAS
OBTAINED FROM ANYONE OTHER THAN AVAYA, AN AVAYA AFFILIATE
OR AN AVAYA AUTHORIZED RESELLER; AVAYA RESERVES THE RIGHT
TO TAKE LEGAL ACTION AGAINST YOU AND ANYONE ELSE USING OR
SELLING THE SOFTWARE WITHOUT A LICENSE. BY INSTALLING,
DOWNLOADING OR USING THE SOFTWARE, OR AUTHORIZING OTHERS
TO DO SO, YOU, ON BEHALF OF YOURSELF AND THE ENTITY FOR
WHOM YOU ARE INSTALLING, DOWNLOADING OR USING THE
SOFTWARE (HEREINAFTER REFERRED TO INTERCHANGEABLY AS
“YOU” AND “END USER”), AGREE TO THESE TERMS AND CONDITIONS
AND CREATE A BINDING CONTRACT BETWEEN YOU AND AVAYA INC. OR
THE APPLICABLE AVAYA AFFILIATE (“AVAYA”).
Avaya grants you a license within the scope of the license types described
below, with the exception of Heritage Nortel Software, for which the scope of
the license is detailed below. Where the order documentation does not
expressly identify a license type, the applicable license will be a Designated
System License. The applicable number of licenses and units of capacity for
which the license is granted will be one (1), unless a different number of
licenses or units of capacityis specified in the documentation or other materials
available to you. “Designated Processor” means a single stand-alone
computing device. “Server” means a Designated Processor that hosts a
software application to be accessed by multiple users.
License type(s)
Designated System(s) License (DS). End User may install and use each
copy of the Software only on a number of Designated Processors up to the
number indicated in the order. Avaya may require the Designated Processor(s)
to be identified in the order by type, serial number, feature key, location or other
specific designation, or to be provided by End User to Avaya through electronic
means established by Avaya specifically for this purpose.
Concurrent User License (CU). End User may install and use the Software on
multiple Designated Processors or one or more servers, so long as only the
licensed number of Units are accessing and using the Software at any given
time. A “Unit” means the unit on which Avaya, at its sole discretion, bases the
pricing of its licenses and can be, without limitation, an agent, port or user, an
e-mail or voice mail account in the name of a person or corporate function
(e.g., webmaster or helpdesk), or a directory entry in the administrative
database utilized by the Software that permits one user to interface with the
Software. Units may be linked to a specific, identified Server.
Named User License (NU). You may: (i) install and use the Software on a
single Designated Processor or Server per authorized Named User (defined
below); or (ii) install and use the Software on a Server so long as only
authorized Named Users access and use the Software. “Named User”, means
a user or device that has been expressly authorized by Avaya to access and
use the Software. At Avaya’s sole discretion, a “Named User” may be, without
limitation, designated by name, corporate function (e.g., webmaster or
helpdesk), an e-mail or voice mail account in the name of a person or corporate
function, or a directory entry in the administrative database utilized by the
Software that permits one user to interface with the Software.
Shrinkwrap License (SR). You may install and use the Software in
accordance with the terms and conditions of the applicable license
agreements, such as “shrinkwrap” or “clickthrough” license accompanying or
applicable to the Software (“Shrinkwrap License”).
Heritage Nortel Software
“Heritage Nortel Software” means the software that was acquired by Avaya as
part of its purchase of the Nortel Enterprise Solutions Business in December
2009. The Heritage Nortel Software currently available for license from Avaya
is the software contained within the list of Heritage Nortel Products located at
http://support.avaya.com/LicenseInfo/ under the link “Heritage Nortel
Products”. For Heritage Nortel Software, Avaya grants Customer a license to
use Heritage Nortel Software provided hereunder solely to the extent of the
authorized activation or authorized usage level, solely for the purpose specified
in the Documentation, and solely as embedded in, for execution on, or (in the
event the applicable Documentation permits installation on non-Avaya
equipment) for communication with Avaya equipment. Charges for Heritage
Nortel Software may be based on extent of activation or use authorized as
specified in an order or invoice.
Copyright
Except where expressly stated otherwise, no use should be made of materials
on this site, the Documentation, Software, or hardware provided by Avaya. All
content on this site, the documentation and the Product provided by Avaya
including the selection, arrangement and design of the content is owned either
by Avaya or its licensors and is protected by copyright and other intellectual
property laws including the sui generis rights relating to the protection of
databases. You may not modify, copy, reproduce, republish, upload, post,
transmit or distribute in any way any content, in whole or in part, including any
code and software unless expressly authorized by Avaya. Unauthorized
reproduction, transmission, dissemination, storage, and or use without the
express written consent of Avaya can be a criminal, as well as a civil offense
under the applicable law.
Third-party components
Certain software programs or portions thereof included in the Software may
contain software (including open source software) distributed under third party
agreements (“Third Party Components”), which may contain terms that expand
or limit rights to use certain portions of the Software (“Third Party Terms”).
Information regarding distributed Linux OS source code (for those product that
have distributed Linux OS source code) and identifying the copyright holders of
the Third Party Components and the Third Party Terms that apply is available
in the Documentation or on Avaya’s website at:
http://support.avaya.com/ThirdPartyLicense/
You agree to the Third Party Terms for any such Third Party Components.
Preventing Toll Fraud
“Toll fraud” is the unauthorized use of your telecommunications system by an
unauthorized party (for example, a person who is not a corporate employee,
agent, subcontractor, or is not working on your company's behalf). Be aware
that there can be a risk of Toll Fraud associated with your system and that, if
Toll Fraud occurs, it can result in substantial additional charges for your
telecommunications services.
Avaya Toll Fraud intervention
If you suspect that you are being victimized by Toll Fraud and you need
technical assistance or support, call Technical Service Center Toll Fraud
Intervention Hotline at+1-800-643-2353 for the United States and Canada. For
additional support telephone numbers, see the Avaya Support website:
http://www.avaya.com/support. Suspected security vulnerabilities with Avaya
products should be reported to Avaya by sending mail to:
[e-mail].

Trademarks
The trademarks, logos and service marks (“Marks”) displayed in this site, the
Documentation and Product(s) provided by Avaya are the registered or
unregistered Marks of Avaya, its affiliates, or other third parties. Users are not
permitted to use such Marks without prior written consent from Avaya or such
third party which may own the Mark. Nothing contained in this site, the
Documentation and Product(s) should be construed as granting, by implication,
estoppel, or otherwise, any license or right in and to the Marks without the
express written permission of Avaya or the applicable third party.
Avaya is a registered trademark of Avaya Inc.
All non-Avaya trademarks are the property of their respective owners, and
“Linux” is a registered trademark of Linus Torvalds.
All other trademarks are the property of their respective owners.
Downloading documents
For the most current versions of documentation, see the Avaya Support
website:
http://www.avaya.com/support
Contact Avaya Support
See the Avaya Support website: http://support.avaya.com for product notices
and articles, or to report a problem with your Avaya product.
For a list of support telephone numbers and contact addresses, go to the
Avaya Support website: http://support.avaya.com, scroll to the bottom of the
page, and select Contact Avaya Support.

Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015 5
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Purpose. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Intended audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Document changes since last issue . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Related resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Avaya Mentor videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Documentation websites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 2: Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Preparing for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Safety precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
System precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Unpacking and inventorying the equipment. . . . . . . . . . . . . . . . . . . . . . . . 14
Parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Determining the computer model. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Dell PowerEdge™ R720 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Dell PowerEdge™ R620 MID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Dell PowerEdge™ R620 LOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Computer layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Mounting the Server Using the Rack Mount Kit . . . . . . . . . . . . . . . . . . . . . . 27
Setting up power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Peripheral connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Avaya approved backup devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Support for KVM and headless CMS systems. . . . . . . . . . . . . . . . . . . . . . . 31
Connecting the keyboard and mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connecting the monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connecting to external interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connecting the switch link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connecting to the customer network . . . . . . . . . . . . . . . . . . . . . . . . . 33
Connecting the Customer Supplied SAS Tape Drive . . . . . . . . . . . . . . . . . 33
Turning on the system and verifying POST . . . . . . . . . . . . . . . . . . . . . . . . 33
Turning the system over for provisioning . . . . . . . . . . . . . . . . . . . . . . . . . 33
Chapter 3: Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Contents

Contents
Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015 6
Turning the computer off and on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Using an ESD wrist strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Maintaining disk drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Required references . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Replacing a disk drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Maintaining tape drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Cleaning the customer supplied tape drive . . . . . . . . . . . . . . . . . . . . . . 39
Connecting to external interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Connecting the switch link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Connecting to the customer network . . . . . . . . . . . . . . . . . . . . . . . . . 40
Connecting the tape drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Connecting an optional SAS tape drive . . . . . . . . . . . . . . . . . . . . . . 40
Turning on the system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Adding memory and replacing the CPU . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Chapter 4: Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
System messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Recovery procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Loss of power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015 7
Chapter 1: Introduction
Purpose
The document describes how to install, maintain, and troubleshoot Dell PowerEdge™ R720 and
R620.
Note:
Note: Dell PowerEdge™ R720 and R620 are compatible with Avaya Call Management
System (CMS) R17 for new installations and CMS R18 for upgrades.
Intended audience
This document is intended for implementation engineers, support personnel, and system
administrators who will install and maintain call center applications, such as CMS.
Document changes since last issue
The following change has been made to this document since the last issue:
●Identified that the Dell R720 and R620 are supported for upgrades to CMS R18.
Related resources
Documentation
See the following documents.

Chapter 1: Introduction
8Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015
Avaya Mentor videos
Avaya Mentor is an Avaya-run channel on YouTube that includes technical content on how to
install, configure, and troubleshoot Avaya products.
Go to http://www.youtube.com/AvayaMentor and perform one of the following actions:
●Enter a key word in the Search Channel to search for a specific product or topic.
●Scroll down Playlists, and click the name of a topic to see the available list of videos
posted on the site.
Documentation websites
All CMS documentation can be found at http://www.support.avaya.com. New issues of CMS
documentation will be placed on this website when available.
Use the following websites to view related support documentation:
●Information about Avaya products and service
http://www.avaya.com
●Dell hardware documentation
http://www.dell.com
Table 1: Related documents
Title Use this document
to: Audience
Implementing
Avaya Call
Management
System Software
Installation,
Maintenance, and
Troubleshooting for
Linux
Install, maintain, and
troubleshoot CMS
on the Linux
operating system.
Implementation
engineers and
system
administrators

Support
Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015 9
Support
Visit the Avaya website at http://www.support.avaya.com for the most up-to-date
documentation, product notices, and knowledge articles. You can also search for release notes,
downloads, and resolutions to issues. Use the online service request system to create a service
request. Chat with live agents to get answers to questions, or request an agent to connect you
to a support team if an issue requires additional expertise.

Chapter 1: Introduction
10 Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015

Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015 11
Chapter 2: Installation
This section describes how to install the computer and related peripheral equipment. Use the
following table to check off each required procedure after completion.
Procedure Completed
Preparing for installation on page 12
Unpacking and inventorying the equipment on page 14
Mounting the Server Using the Rack Mount Kit on page 27
Setting up power on page 27
Peripheral connectivity on page 29
Parts list on page 30
Avaya approved backup devices on page 31
Support for KVM and headless CMS systems on page 31
Connecting the keyboard and mouse on page 32
Connecting the monitor on page 32
Connecting to external interfaces on page 32
Turning on the system and verifying POSTon page 33
Turning the system over for provisioning on page 33

Chapter 2: Installation
12 Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015
Preparing for installation
This section contains the following information that will help you prepare for the computer
installation:
●Safety precautions on page 12
●System precautions on page 13
Safety precautions
For your protection, observe the following safety precautions when setting up your equipment:
●Follow all cautions, warnings, and instructions that are marked on the equipment.
●Never push objects of any kind through openings in the equipment. They could touch
dangerous voltage points or short out components. This could result in fire or electric
shock.
●Refer servicing of equipment to qualified personnel.
●To protect both yourself and the equipment, observe the following precautions.
Precaution Item Problem
Wear a conductive wrist strap or foot
strap when handling printed circuit
boards.
Wrist or
foot strap Electro-Static Discharge
(ESD)
Reinstall all cabinet cover panels after
you perform any service work on the
system.
Cover
panels System damage and
overheating
Make sure that you have installed a
filler panel on all empty board slots. Board slot filler
panels
System
damage and
overheating

Preparing for installation
Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015 13
System precautions
!WARNING:
!
WARNING: DO NOT make mechanical or electrical modifications to the computer. Dell
Computer Corp. is not responsible for regulatory compliance of modified
computers.
Ensure that the voltage and frequency of the power outlet used matches the electrical rating
labels on the equipment.
Wear antistatic wrist straps when handling any magnetic storage devices and printed circuit
boards.
Each power supply uses nominal input voltages of 100-240 V AC at 50-60 Hz. The computer
should be powered by an Uninterruptible Power Supply (UPS) or a non-switched,
dedicated, 20-amp circuit. Dell products are designed to work with single-phase power systems
having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug Dell
products into another type of power source. Contact your facilities manager or qualified
electrician if you are unsure what type of power is supplied to your building.
A UPS provides a temporary electrical supply to a computer for several minutes, depending on
the number of components connected to the UPS. For a CMS computer, a 1.5KVA minimum is
required for each power supply. See your UPS documentation to determine the projected
amount of backup battery time for your model. If the system is without power for longer than the
backup time, the system may shut down improperly, and the customer could lose data.
Each of the following items requires a separate power cord:
●Computer
●External peripherals
●Monitor
Keep in mind the following:
●The room must have sufficient air conditioning capacity to support the cooling needs of the
entire system.
●The air conditioning system must have controls that prevent excessive temperature.

Chapter 2: Installation
14 Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015
Unpacking and inventorying the equipment
!WARNING:
!
WARNING: Never move the computer when the power is on. Excessive movement can cause
catastrophic disk drive failure. Always power the system off before moving the
computer.
!WARNING:
!
WARNING: Always wear an electrostatic discharge (ESD) strap when handling internal
components.
CAUTION:
!
CAUTION: Always have up-to-date system backups before turning off and moving the
computer.
Inspect all shipping cartons for evidence of physical damage. If a shipping carton is damaged,
request that the carrier representative be present before the carton is opened.
Unpack the computer and associated peripheral equipment. Compare the contents of the carton
to the shipping inventory list to verify that all equipment was delivered.
In the United States, Contact your Avaya Sales team if any parts are defective on arrival or are
missing.
Outside of the United States, contact your Avaya representative or distributor if any parts are
missing or defective.
This section includes the following topics:
●Parts list on page 15
●Determining the computer model on page 15
●Computer layout on page 17

Unpacking and inventorying the equipment
Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015 15
Parts list
Verify that you have the following components before you begin installation:
●Computer and power cord
●Monitor, VGA cable, and monitor AC power cord
●USB keyboard and cable
●USB mouse and cable
●RedHat and CMS software
●Optional Backup device. See Avaya approved backup devices on page 31 for more
information.
Determining the computer model
CMS R17.0 supports the Dell PowerEdge™ R720 MID, R620 MID and LOW computer models.
See Dell PowerEdge™ R720 on page 15, Dell PowerEdge™ R620 MID on page 16, and Dell
PowerEdge™ R620 LOW on page 16 for more information.
Dell PowerEdge™ R720
November 2013 model (used for new CMS R17 installations and upgrades to CMS
R18)
●Two Intel® Xeon® E5-2620 2.00GHz 6-Core processors
●64 GB RAM
●Twelve internal 300 GB SAS disks
●Internal DVD-RW disc drive
●Two hot-swappable 750 W AC power supplies
●RAID 10 system only
●One RAID controller card
●Can be used as a desktop unit or can be configured for rack mounting
●SAS HBA with external ports to support optional tape drive
●Optional backup device

Chapter 2: Installation
16 Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015
Dell PowerEdge™ R620 MID
May 2013 size model (used for new CMS R17 installations and upgrades to CMS
R18)
●One Intel® Xeon® E5-2620 2.00GHz 6-Core processor
●16 GB RAM
●Four internal 300 GB SAS disks
●Internal DVD-RW disc drive
●Two hot-swappable 495 W AC power supplies
●RAID 10 system only
●One RAID controller card
●Can be used as a desktop unit or can be configured for rack mounting
●SAS HBA w/external ports to support optional tape drive
●Optional backup device
Dell PowerEdge™ R620 LOW
May 2013 LOW-size model (used for new CMS R17 installations and upgrades to
CMS R18)
●One Intel® Xeon® E5-2620 2.00GHz 6-Core processor
●8 GB RAM
●One internal 300 GB SAS disk
●Internal DVD-RW disc drive
●One 495 W AC power supply
●No RAID or mirroring used
●Can be used as a desktop unit or can be configured for rack mounting
●SAS HBA w/external ports to support optional tape drive
●Optional backup device

Unpacking and inventorying the equipment
Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015 17
Computer layout
Familiarize yourself with the layout of the computer.
Item Indicator, Button, or
Connector Icon Description
1Power-on indicator,
power button The power-on indicator lights when the system power is on. The power button
controls the power supply output to the
system.
Note: On ACPI-compliant operating
systems, turning off the system using the
power button causes the system to perform
a graceful shutdown before power to the
system is turned off.
2NMI button Used to troubleshoot software and device
driver errors when running certain
operating systems. This button can be
pressed using the end of a paper clip.
Use this button only if directed to do so by
qualified support personnel or by the
operating system's documentation.
Dell R720 Front View

Chapter 2: Installation
18 Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015
3System identification
button The identification buttons on the front and back panels can be used to locate a
particular system within a rack. When one
of these buttons is pressed, the LCD panel
on the front and the system status indicator
on the back flashes blue until one of the
buttons is pressed again.
Press to toggle the system ID on and off. If
the system stops responding during POST,
press and hold the system ID button for
more than five seconds to enter BIOS
progress mode.
To reset the iDRAC (if not disabled in F2
iDRAC setup) press and hold the button for
more than 15 seconds.
4USB connector (2) Allows you to insert USB devices to the
system. The ports are USB 2.0-compliant.
5Optical drive (optional) One optional SATA DVD-ROM drive or
DVD+/-RW drive.
NOTE: DVD devices are data only.
6vFlash media card slot Allows you to insert a vFlash media card.
7LCD menu buttons Allows you to navigate the control panel
LCD menu.
8LCD panel Displays system ID, status information, and
system error messages. The LCD lights
blue during normal system operation. The
LCD lights amber when the system needs
attention, and the LCD panel displays an
error code followed by descriptive text.
NOTE: If the system is connected to AC
power and an error is detected, the LCD
lights amber regardless of whether the
system is turned on or off.
9Information tag A slide-out label panel, which allows you to
record system information, such as Service
Tag, NIC, MAC address, and so on as per
your need.
Item Indicator, Button, or
Connector Icon Description

Unpacking and inventorying the equipment
Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015 19
10 Video connector Allows you to connect a VGA display to the
system.
11 Hard drives Up to eight 2.5 inch hot-swappable hard
drives.
Up to four 2.5 hot-swappable hard drives
and up to two 2.5 inch Dell PowerEdge
Express Flash devices (PCIe SSDs).
Item Indicator, Button, or
Connector Icon Description

Chapter 2: Installation
20 Avaya CMS Dell R720 and R620 Computer Hardware Installation October 2015
Item Indicator,Button,or
Connector Icon Description
1System identification
button The identification buttons on the front and back panels can be used to locate a
particular system within a rack. When one
of these buttons is pressed, the LCD panel
on the front and the system status indicator
on the back blink until one of the buttons is
pressed again.
Press to toggle the system ID on and off. If
the system stops responding during POST,
press and hold the system ID button for
more than five seconds to enter BIOS
progress mode.
To reset iDRAC (if not disabled in F2
iDRAC setup) press and hold for more than
15 seconds.
2System identification
connector Allows you to connect the optional system status indicator assembly through the
optional cable management arm.
3iDRAC7 Enterprise
port Dedicated management port.
NOTE: The port is available for use only if
the iDRAC7 Enterprise license is installed
on your system.
4Serial connector Allows you to connect a serial device to the
system.
Dell R720 Rear View
