Delmhorst Instrument Co TechCheck PLUS User manual

TechCheck PLUS
MOISTURE METER
Owner’s Manual
Version 2.02
For TechCheck Meters starting with Serial #13560
Delmhorst Instrument Co.
Rev 5 September 2014
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 2 of 35
TABLE OF CONTENTS
PAGE
GENERAL DESCRIPTION & FEATURES 3
OPERATING INSTRUCTIONS 4
INSTALLING THE BATTERY 4
TO POWER THE METER ON 5
TO TAKE WOOD READINGS 5-6
TO TAKE DRYWALL READINGS 6
TO TAKE SCAN READINGS 6-7
TO SET THE ALARM IN WOOD, DRYWALL, SCAN MODE 7
MAIN MENU OPTIONS 8
TAKING A READING –PRACTICAL APPLICATIONS 9
TESTING WOOD 9
PAINT FAILURE AND MOISTURE 9
EIFS 9-10
TESTING CONCRETE 10-11
TESTING INSULATION 11
TESTING DRYWALL 11
CARE OF YOUR METER 13
SERVICE FOR YOUR METER 14
WARRANTY 15
SPECIES CORRECTION TABLE 17-18
TEMPERATURE CORRECTION TABLE 19
OWNER’S MANUAL IN SPANISH
(MANUAL DEL PROPIETARIO EN ESPANOL) 20
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 3 of 35
GENERAL DESCRIPTION & FEATURES
Thank you for your purchase of Delmhorst Instrument Co’s newly designed TechCheck Plus
handheld moisture meter. The TechCheck Plus offers the latest in features and functionality and
is intuitive and easy to operate. We recommend that you read the following pages in detail to
take full advantage of all that the TechCheck Plus has to offer.
Outstanding Features:
Pin mode
oWood scale –6%-60% (Douglas Fir)
oDrywall scale –0.1% - 6%
Scan Mode
oReference scale –0-300
Other Features:
oSpanish Language option
oBuilt in back-light
oAlarm lets you know when your pre-selected moisture level is reached
o“Hold”readings on-screen
oAuto shutoff timer
oRugged construction
oSturdy plastic carrying case
o9-V Battery included
o1 year warranty
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 4 of 35
OPERATING INSTRUCTIONS
-User Guide-
This guide provides step-by-step instructions on powering up, using and powering down the
meter.
NAVIGATION:
The meter uses an on-screen, menu-driven approach to navigate through the meter features,
allowing for an intuitive understanding of keypad functions. Each screen presents the user with a
number of selectable options. One of the options is always selected and the user can move
(navigate) the selection to any other available option. The keypad is aimed at providing
navigational control, and not at accessing specific features. There are four directional keys
aligned intuitively around a middle (fifth) key (see Figure 1): Above (UP), below (DOWN), to the
right (RIGHT) and to the left (LEFT). The middle key is used to SELECT the option highlighted on
the screen. For purposes of this owner’s manual, the five keys will be referred to as
and SELECT.
INSTALLING THE BATTERY:
The battery compartment is located on the underside of the case, at the bottom of the handle.
1. Open the battery compartment by sliding the lid back while pressing on the release indent.
2. Ensure correct polarity, and push the battery in flush with the bottom board until the
connectors snap together on both sides. Use only Duracell or Energizer alkaline 9V.
3.
4. Replace the battery compartment lid.
LOW BATTERY:
The meter features a battery status monitor, designed to warn the user as well as protect
measurement accuracy from impending battery failure conditions. The battery warning is
triggered by either continuous or temporary low voltage conditions. Visible (a battery icon on the
top right side of the display) and audible (buzzer warble) indicators accompany a battery warning.
Once a permanent low battery condition is detected, all measurement functions are disabled. The
battery should be replaced immediately. If the battery reaches critical levels, the meter will refuse
to stay on at power-up. This gradual warning system is intended to provide the user advanced
battery status notice and give ample time for replacement before operational limitations occur.
NOTE: Current meter settings are not lost during battery replacement or low battery conditions.
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 5 of 35
TO POWER THE METER ON:
To turn the meter on, press and hold the SELECT button for approx. 2 seconds.
The first screen will temporarily display the meter name and the software revision level.
Refer to this revision level whenever you call Customer Service.
The next screen is the MAIN MENU. Use the  keys to select the desired
function/mode and then press SELECT to activate the function.
METER USE
TO TAKE WOOD READINGS:
1. From the Main Menu, use the key to highlight WOOD. Then, use the SELECT key
to enter the WOOD screen.
2. The meter will display the WOOD screen, as shown below:
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 6 of 35
3. Push the contact pins into material to be tested. Any Delmhorst electrode may also be
used in WOOD mode by simply attaching it to the connector next to the contact pins.
4. The unit will read %MC on a wood scale between 6% and 60%. At elevated wood
temperatures, a reading above 30 percent is valid if the temperature-corrected reading
falls below 30 percent. Otherwise, these high readings provide relative comparisons,
indicating that the material is taking on or losing moisture.
5. To hold a reading on-screen, press the HOLD (SELECT) KEY. Press the HOLD
(SELECT) KEY again to return to measuring mode.
6. Use the key to highlight EXIT. Then, use the SELECT key to return to the MAIN
MENU when finished.
NOTE:The TechCheck Plus is calibrated to give %MC readings on Douglas Fir. If you are
taking readings on other species of wood, refer to the species correction chart.
TO TAKE DRYWALL READINGS:
1. From the Main Menu, use the key to highlight DRYWALL. Then, use the SELECT
key to enter the pin mode.
2. The meter will display the DRYWALL screen, as shown below:
3. Push the contact pins into material to be tested. Any Delmhorst electrode may also be
used in DRYWALL mode by simply attaching it to the connector next to the contact pins.
4. The unit will read %MC on a drywall scale between 0.1% and 6%.
5. To hold a reading on-screen, press the HOLD (SELECT) KEY. Press the HOLD
(SELECT) KEY again to return to measuring mode.
6. Use the key to highlight EXIT. Then, use the SELECT key to return to the MAIN
MENU when finished.
TO TAKE SCAN READINGS:
1. From the Main Menu, use the key to highlight SCAN. Then, use the SELECT
key to enter the SCAN mode.
2. The meter will display the SCAN screen, as shown below:
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 7 of 35
3. You may begin taking readings by firmly pressing the back of the meter onto the
material to be tested. This will display a relative reading that ranges between 0 and 300.
4. To hold a reading on-screen, press the HOLD (SELECT) KEY. Press the HOLD
(SELECT) KEY again to return to measuring mode.
NOTE:The SCAN mode will give relative readings only, not %MC. The numbers displayed
represent the relative dryness or wetness of the material on a scale of 0 to 300. In
order to accurately interpret your readings, first establish a baseline reading by taking
a reading in an area you know to be unaffected or dry, then take a reading in the
affected or wet area and compare the two readings.
TO SET THE ALARM FOR WOOD, DRYWALL, OR SCAN MODE:
1. If you wish to set the alarm, to beep after a pre-selected value is reached for WOOD,
DRYWALL, or SCAN use the  keys from the MAIN MENU screen to highlight the
ALARM. Press the SELECT key to enter the alarm sub menu.
2. The default status of all alarms is “OFF.” Press the HOLD (SELECT) key on the
desired alarm to turn it on.
3. After the alarm is turned on, use the key to increase the alarm value, and the key to
decrease alarm value.
4. After you have selected the alarm value, use the key to highlight EXIT. Press the
center HOLD (SELECT) key to return to MAIN MENU.
5. The chosen alarm value will be displayed on the WOOD, DRYWALL, or SCAN mode
screen and an audible alarm will sound if that value is reached.
Note: Default alarm settings are: WOOD - 15% DRYWALL –1%, SCAN - 300.
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 8 of 35
MAIN MENU OPTIONS:
ENGLISH / ESPANOL:
This option will toggle the displayed language. Pressing SELECT key on this
option when displayed as ESPANOL will change all displayed meter text to the
Spanish language. Pressing the SELECT key on this option when displayed as
ENGLISH will change all displayed meter text to the English language.
DEFAULTS:
This will delete all defined parameters and readings stored in the meter. The
meter will be now set to the factory parameters: English, Wood Alarm 15% and
OFF, DRYWALL Alarm 1% and OFF, SCAN Alarm 300 and OFF.
OFF:
This menu option will power down the meter.
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 9 of 35
TAKING A READING –PRACTICAL APPLICATIONS
The following application notes are intended for use with the meter in PIN
MODE except where otherwise indicated.
TESTING WOOD:
The integral contact pins (5/16in penetration) on top of the meter are best for wood up to 1-
1/2inches (6/4) or drywall. Use the 26-ES electrode on hard materials, wood over 2 inches thick,
or for any application where using the insulated pins are needed for best accuracy. The 22-E
with 1/2in non-insulated pins is also an excellent option for wood or drywall. Mount the electrode
directly to the external connector at the top of the meter.
To take a wood reading, align the contact pins parallel to the grain and push them to their
full penetration into the wood, if possible. Insulated pins read only at the tip and can be
driven to the desired depth.
Press the SELECT button and read the moisture content on the meter scale. The meter
displays the %MC for two seconds.
Apply species and temperature corrections if necessary for best accuracy. Refer to charts
at the back of the manual.
PAINT FAILURE AND MOISTURE
Moisture is by far the most frequent cause of paint failure. The key to preventing paint failure is to
insure that moisture is not absorbed through the wood to the back of the paint film. So, in order to
insure quality paint jobs, wood must remain dry after the application of paint.
Outdoor wood can be safely painted without danger of peeling if the %MC is 15% or less. In drier
climates, the maximum reading should be 10% to 11%. Indoor wood should be between 7% and
8% prior to painting.
The following conditions may cause high moisture content in wood:
Leaky gutters and down spouts
Leaky pipes or condensation on cold water lines in attic or hollow walls
Faulty flashing around windows, doors and where porch and dormer roofs meet sidings
End-grain wood that is not sealed with paint at all joints around windows, corners, and butt
joints
Porch columns that do not have good drainage and ventilation where they rest on porch
floors
Siding or any other wood that is in contact with the ground may absorb moisture
Siding and shingles without sufficient lap so that water is forced up through cracks by wind
pressure
Ice dams
Condensation of vapor within hollow walls
EIFS (Exterior Insulation & Finish Systems)
Moisture intrusion problems in EIFS (also known as synthetic stucco) stem from leaking window
frames, improper use of or lack of sealant, and faulty installation of flashing.
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 10 of 35
If you suspect a problem take a visual inspection. Look for gaps around windows, doors, air
conditioning units, light fixtures, hose bibs, dryer vents and other areas of potential penetration.
Also look for visible signs of water damage. If you feel a problem exists, use the 21-E electrode.
This electrode uses the 608 - (4") insulated pins or 608/001 (7”) insulated pins.
Procedure:
Drill two 1/4" holes about ¾” apart at an upward 45° angle.
Push the 21-E Electrode into the holes through the polystyrene and into the substrate and
read the moisture content on the meter scale. When used on materials other than wood, the
meter’s PIN mode will give relative readings only, not %MC. The numbers displayed
represent the relative dryness or wetness of the material on a scale of 6 to 60. In order to
accurately interpret your readings, first establish a baseline reading by taking a reading in an
area you know to be unaffected, then take a reading in the affected area and compare the
two readings.
TESTING CONCRETE SLABS FOR FLOORING APPLICATIONS
Moisture meters are an effective tool to check comparative moisture conditions in concrete slabs.
They can tell you where there may be excess moisture and help determine if you need to conduct
further testing, and identify specific areas on which that testing should be performed. Meters do
not provide quantitative results as a basis for acceptance of a slab for installation of moisture-
sensitive flooring systems. ASTM Test Method F2170 (RH using in-situ probes), F1869 (calcium
chloride), and F2420 (RH on surface using insulated hood) provide quantitative information for
determining if moisture levels are within specific limits.
It is important to test both the surface and mid-section of the slab, especially if the slab is on or
below grade. This will help determine if there is continuous moisture migration toward the
surface. If this condition exists, the moisture movement may be so slow that once it reaches the
surface, moisture evaporates and causes a “dry” reading when a surface test is made.
However, if a sub-surface test is made, the meter may read “wet” indicating the presence of
moisture. When the slab is covered and the upward movement of moisture continues, moisture
will move into a hygroscopic (wood) floor, or build-up pressure under a non-breathing synthetic
floor, causing delamination.
Taking a surface reading:
USING PIN MODE –WOOD scale
Drive two hardened-steel masonry nails about 3/4" apart into the finish coat of
concrete floor. Drive them about 1/8" deep so they make firm contact with the concrete
and do not move when touched.
Touch the nails with the contact pins. If the meter reads less than “28”, the surface is
dry. However, sub-surface tests should be made to verify if the slab is dry throughout.

USING SCAN MODE
First establish a benchmark by takingreadings in areas that you know are dry, or
acceptable.
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 11 of 35
Take readings on areas that are wet. These “dry to wet” readings can be used as
reference points against which subsequent readings are compared. Understanding the
meter’s behavior on a particular material, along with these comparative readings, your
experience, and visual clues will all help determine the overall condition. All readings
should be evaluated in the light of factors such as type of paint, type of construction, and
climatic conditions.
Subsurface test:
Drill two 1/4" holes, 3/4" apart and 1/2" to 2" deep.
Drive the masonry nails into the bottom of the holes and make the tests as described
above. Nails must not touch sides of drilled holes.
If the meter still indicates a “dry” condition, the floor is ready for covering. Tests should
be made at several points, especially when the slab is thick (4” or more) and air
circulation is poor. Make tests only in newly drilled holes.
Even readings in the “wet” range can indicate relatively low moisture content in Concrete.
For example, readings in the “28 - 35” range indicate approximately 2% to 4% moisture
content.
When evaluating a slab for readiness, always consider its age, thickness, whether the
slab is on grade or suspended, whether a vapor barrier is present and the drainage
condition of the ground.
TESTING INSULATION:
Set the meter to the Wood scale. Remember that when used on materials other than wood,
the meter’s PIN mode will give relative readings only. Establish a baseline reading by taking a
reading in an area you know to be unaffected, then take a reading in the affected area and
compare the two readings.
To take a reading, attach a 21-E electrode with 4” insulated contact pins to the meter. Push
the contact pins through the drywall into the insulation behind it.
Press the SELECT button and read the relative moisture level on the meter scale. The
meter displays the “relative” moisture level for two seconds.
TESTING DRYWALL
USING PIN MODE
Set the meter scale to Drywall
To take a reading, push the contact pins into the drywall to their full penetration, if possible.
Press the SELECT button and read the moisture content on the meter scale. The meter
displays the %MC for two seconds.
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 12 of 35
Note:
Readings between 0.1% and 0.5% indicate a sufficiently dry moisture level. Readings between
0.5% and 1% indicate a borderline situation. Readings greater than 1% indicate material that is
too wet for painting or wallpaper. A reading above 1% also indicates enough moisture present to
allow mold growth to occur but only if other factors are also present such as a high RH level and
food source.
USING SCAN MODE
You can also take a reference reading on drywall using the meter’s SCAN mode. To take a
reading, firmly press the back of the meter onto the material to be tested while in SCAN mode.
This will display a relative reading that ranges between 0 and 300. Remember to establish a
baseline reading by taking a reading in an area you know to be unaffected, then take a reading in
the affected area and compare the two readings.
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 13 of 35
CARE OF YOUR METER
Store your meter in a clean, dry place. The protective carrying case provided is an ideal
storage place when the meter is not in use. If the meter has been left in a hot or cold
environment overnight or for an extended period, the calibration of the pinless mode may be
adversely affected. Under these conditions, allow the meter to acclimate to the temperature
conditions in which it will be used for minimum 1-2 hours, or as long as possible.
Change contact pins as needed. Keep pin retainers hand tightened.
Clean the meter and contact pins with any biodegradable cleaner. Use the cleaner sparingly
and on external parts only. Keep cleaner out of the external connector.
Remove the battery if the meter will not to be used for one month or longer.
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 14 of 35
WARRANTY
Delmhorst Instrument Co., referred to hereafter as Delmhorst, guarantees the TechCheck Plus
meter for one year from date of purchase and any optional electrodes against defects in material
or workmanship for 90 days. If, within the warranty period of the Model TechCheck Plus, you find
any defect in material or workmanship, return the meter following the instructions in the “Service
for Your Meter” section. This warranty does not cover abuse, alteration, misuse, damage during
shipment, improper service, unauthorized or unreasonable use of the meter or electrodes. This
warranty does not cover batteries, pin assemblies, or pins. If the meter or any optional electrodes
have been tampered with, the warranty shall be void. At our option, we may replace or repair the
meter.
Delmhorst shall not be liable for incidental or consequential damages for the breach of any
express or implied warranty with respect to this product or its calibration. With proper care and
maintenance the meter should stay in calibration; follow the instructions in the “Care of Your
Meter” section.
UNDER NO CIRCUMSTANCES SHALL DELMHORST BE LIABLE FOR ANY INCIDENTAL,
INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES OF ANY TYPE WHATSOEVER,
INCLUDING, BUT NOT LIMITED TO, LOST PROFITS OR DOWNTIME ARISING OUT OF OR
RELATED IN ANY RESPECT TO ITS METERS OR ELECTRODES AND NO OTHER
WARRANTY, WRITTEN, ORAL OR IMPLIED APPLIES. DELMHORST SHALL IN NO EVENT
BE LIABLE FOR ANY BREACH OF WARRANTY OR DEFECT IN THIS PRODUCT THAT
EXCEEDS THE AMOUNT OF PURCHASE OF THIS PRODUCT.
The express warranty set forth above constitutes the entire warranty with respect to Delmhorst
meters and electrodes and no other warranty, written, oral, or implied applies. This warranty is
personal to the customer purchasing the product and is not transferable.
For over 65 years Delmhorst has been the leading manufacturer of high quality moisture meters
and thermo-hygrometers. We also offer a wide range of meters for a variety of applications
including woodworking/lumber, agriculture, construction, paper, restoration, IAQ and flooring.
510INS-0029 REV 09/14
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 15 of 35
SPECIES CORRECTION TABLE
METER READINGS WITH NON-INSULATED PINS
SPECIES
7
8
9
10
12
14
16
18
20
22
24
ALDER
8
9
10
11
13
15
17.5
19.5
21.5
24
27
APITONG
8
9
10
11
13
15
17
20
22
24
27
ASPEN
7
8
9
10
11.5
13
15
16.5
18
20
21
ASH, WHITE
6.5
7.5
8
9
11
13
14.5
16
18
19.5
21
BASSWOOD
7
8
8
9
10.5
13
15
17
19
20.5
22
BIRCH
8
9
10
11
13
15
17
19
21.5
23.5
25.5
CEDAR, EAST. RED
8
9.5
10.5
12
14
17
19
21
23
25
26
CEDAR, INCENSE
7
8
9.5
10.5
12.5
15
17
19
21
23
25
CHERRY
8
9
10
11
13.5
15.5
18
20
22
24
26
COTTONWOOD
6
7.5
8.5
9.5
12
14
15
17
19.5
21
23
CYPRESS
7
8
9
10
12
14
16
18
19.5
21.5
23.5
ELM, AMERICAN
7
7.5
8
8.5
10
11.5
13
15
16
18
19
FIR, DOUGLAS
7
8
9
10
12
14
16
18
20
22
24
FIR,RED
7
8
9
10
12.5
15
17
19
21
23
25
FIR, WHITE
8
9
9.5
10.5
12.5
15
17
19
21
23
25
GUM, BLACK
7.5
9
10
11
13
15
16
18
19
20.5
22
GUM, RED
7
8
9
10
12.5
14.5
16.5
19
20.5
22.5
24
HEMLOCK, WESTERN
7
8
9
10.5
13
15
17
19
20.5
22
23.5
HACKBERRY
7
8.5
9
9.5
12
13
15
17
18.5
20
22
HICKORY
8
8.5
9
10
11
12.5
14
15.5
17
19
20.5
KERUING
8
9
10
11
13
15
17
20
22
24
27
LARCH
7.5
9
10
11
13
15
17
19
21
23
25.5
MAGNOLIA
7.5
9
10
11.5
14
16
17.5
19
21
22.5
24.5
MAHOGANY, AFRICAN
8
9.5
10.5
12
15
17
19.5
22
24
26
28
(ALSO KHAYA)
MAHOGANY, HOND.
7
8
9
10.5
12.5
14.5
16
18
19.5
21.5
22.5
MAHOGANY, PHIL.
6
7
7.5
8
9.5
11
13
14
15.5
17
18
MAPLE, HARD/SOFT
8
9
9.5
10
12
14
16
18
20
22.5
25
MERANTI, DARK RED
8.5
9.5
10.5
11.5
12.5
16
18
20.5
22.5
24.5
26.5
OAK, RED
7
8
9
10
12
14
16
18
20
22
24
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 16 of 35
OAK, WHITE
7
8
8.5
9.5
11.5
13.5
15
17
18.5
20
22
PECAN
6.5
8
9.5
11
12.5
14
16
17.5
19
22
24
PINE, LONGLEAF
8
8.5
10
11
13
15.5
17.5
19.5
21
23
25
PINE, PONDEROSA
7.5
8.5
10
11
13.5
15.5
17.5
19.5
21
23
25.5
PINE, SHORTLEAF
7.5
9
10
11
13
15.5
17.5
19.5
21.5
23.5
25
PINE, SO. YELLOW*
8
9.5
10.5
12
14.5
16.5
19
21
23
25
28
PINE, SUGAR
7
8
9
10
12
15
17
19
21
23
25
PINE, WHITE
7
8
9
10
13
15
17
19
21
23
25.5
METER READINGS WITH NON-INSULATED PINS
SPECIES
7
8
9
10
12
14
16
18
20
22
24
POPLAR, YELLOW
8
8.5
10
11
13
15.5
17.5
19.5
22
24
26
RAMIN
7
8
9
10
11
13
15
16
18
20
21
SPECIES
7
8
9
10
12
14
16
18
20
22
24
RADIATA PINE
10
11
11
12
14
16
18
20
23
25
27
REDWOOD
7
8
9
10
12
13.5
15
17
19
22
24
SPRUCE, SITKA
7
8
9
10
12.5
14.5
17
19
21
23.5
26
SPF**
9
10
11.5
13
15.5
18
20.5
23
25
28
30
SPF/COFI
8
9
10
11
13
15
17
19
21
23
25
TEAK
7
8
8.5
9
11
12
14
15
17
18.5
20
VIROLA
6.5
7
8
9
11
12.5
14
16
18
18.5
20.5
WALNUT, BLACK
7.5
8.5
9.5
10.5
12.5
14.5
16
18
20
22
23.5
The species correction values shown in this chart have been rounded for easy reference.
*Meter readings taken with 26-E 2-pin electrode. Do not apply 2-pin correction.
**SPF correction based on 2-pin 26-E reading with insulated pins. It is based on USDA/Forintek
data and can be used for the following species:
Lodgepole Pine
Alpine Fir
www. .com [e-mail]1.800.561.8187

TEMPERATURE CORRECTION
TABLE
METER READINGS
°C
°F
6
7
10
15
20
25
30
35
40
50
60
-20
0
9
11
15
22
31
38
45
53
-10
20
8
10
14
20
28
34
40
47
55
5
40
7
8
12
18
24
30
36
42
48
15
60
6
7
11
16
21
27
32
38
43
54
30
80
6
7
9
14
19
23
28
33
38
47
55
40
100
5
6
8
12
17
21
25
29
34
42
50
50
120
5
5
7
11
15
19
22
26
30
38
44
60
140
4
5
7
10
14
17
20
23
27
34
40
70
160
4
4
6
9
12
15
18
21
24
30
36
80
180
3
4
5
8
11
13
16
19
22
27
33
95
200
3
4
5
7
10
12
14
17
19
24
28
105
220
2
3
4
6
9
11
13
15
17
21
26
Moisture content values shown shaded are only qualitative, since they are above the fiber
saturation point.
The temperature correction values shown in this chart have been rounded for easy reference. If
you desire a reading closer to your temperature for greater accuracy we have included a
temperature correction slide rule. This will give you correction values for your meter readings in
small gradual increment.
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 18 of 35
TechCheck PLUS
MEDIDOR DE HUMEDAD
Manual del propietario
Versión 2.02
Para medidores TechCheck que comiencen con el Núm. de Serie 13560
Delmhorst Instrument Co.
Rev 5
Septiembre 2014
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 19 of 35
CONTENIDO:
PÁGINA
DESCRIPCIÓN GENERAL Y CARACTERÍSTICAS 20
INSTRUCCIONES DE FUNCIONAMIENTO 21
INSTALACIÓN DE LA BATERÍA 21
PARA ENCENDER EL MEDIDOR DE HUMEDAD 22
PARA TOMAR MEDICIONES DE LA MADERA 22
PARA TOMAR MEDICIONES DEL TABLERO DE YESO 23
PARA TOMAR MEDICIONES CON EL ESCÁNER 24
PARA AJUSTAR LA ALARMA EN EL MODO DE MADERA,
TABLERO DE YESO, ESCÁNER 24
OPCIONES DEL MENÚ PRINCIPAL 25
TOMAR MEDIDAS –APLICACIONES PRÁCTICAS 27
PRUEBA DE LA MADERA 27
FALLO DE LA PINTURA Y HUMEDAD 27
SISTEMA DE AISLAMIENTO TÉRMICO EXTERIOR 28
PRUEBA DEL CONCRETO 28
PRUEBA DEL AISLAMIENTO 29
PRUEBA DEL TABLERO DE YESO 30
CÓMO CUIDAR EL MEDIDOR DE HUMEDAD 31
REPARACIÓN DEL MEDIDOR DE HUMEDAD 31
GARANTÍA 31
TABLA DE CORRECIÓN DE ESPECIES 33-34
www. .com [e-mail]1.800.561.8187

Copyright 2009, Delmhorst Instrument Co.
Page 20 of 35
DESCRIPCIÓN GENERAL Y CARACTERÍSTICAS
Gracias por comprar el nuevo medidor de humedad portátil y recién diseñado TechCheck Plus
de Delmhorst Instrument Co. El TechCheck Plus ofrece lo último en características y
funcionalidad y es intuitivo y de funcionamiento sencillo. Le recomendamos que lea las
siguientes páginas detenidamente para aprovechar plenamente todo lo que el TechCheck Plus
tiene que ofrecer.
Características destacadas:
Modo de patillas
oEscala de madera (Abeto Douglas Fir) de 6%-60%
oEscala de tablero de yeso de 0.1% - 6%
Modo de escáner
oEscala de referencia numérica - 0-300
Características destacadas:
oOpción de idioma español
oLuz posterior incorporada
oLa alarma permite saber cuándo se ha alcanzado el umbral de humedad
preseleccionado
oRetención de las lecturas en la pantalla
oTemporizador de autoapagado
oConstrucción robusta
oEstuche de plástico resistente
oBatería de 9V incluida
oGarantía de 1 año
www. .com [e-mail]1.800.561.8187
