Endress+Hauser Proline Fieldcheck User manual

BA067D/06/en/04.04
50100085
Valid as of software version
V 1.02.XX
Operating Instructions
Proline Fieldcheck
Flow simulator
E
+
-

Proline Fieldcheck Table of contents
Endress+Hauser 3
Table of contents
1 Safety instructions . . . . . . . . . . . . . . . . 4
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Notes on operating Fieldcheck in an environment with
strong electromagnetic interference . . . . . . . . . . . . . 4
1.3.1 Radiated RF noise (EN 61326-1) . . . . . . . . . 4
1.4 Notes on safety conventions and icons . . . . . . . . . . . 5
2 Identification . . . . . . . . . . . . . . . . . . . . 6
2.1 Device designation . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1.1 Fieldcheck nameplate . . . . . . . . . . . . . . . . . 6
2.1.2 Simubox nameplate . . . . . . . . . . . . . . . . . . . 6
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 CE mark, Declaration of conformity . . . . . . . . . . . . . 7
2.4 Registered trademarks . . . . . . . . . . . . . . . . . . . . . . . 7
3 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 Connecting to Promag 10 . . . . . . . . . . . . . . . . . . . . 9
3.3 Connecting to Promag 50/53 compact version . . . 10
3.4 Connecting to Promag 50/53 remote version . . . . 11
3.5 Connecting to Promass 40/80/83 compact version 12
3.6 Connecting to Promass 80/83 remote version . . . . 13
3.7 Connecting to Prowirl 72 . . . . . . . . . . . . . . . . . . . 14
3.7.1 Prowirl 72 wiring diagram . . . . . . . . . . . . . 15
3.8 Assignment of Fieldcheck connections . . . . . . . . . . 16
3.9 Post-connection check . . . . . . . . . . . . . . . . . . . . . . 16
4 Operation . . . . . . . . . . . . . . . . . . . . . . 17
4.1 Display and operating elements . . . . . . . . . . . . . . . 17
4.1.1 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.1.2 Display icons . . . . . . . . . . . . . . . . . . . . . . . 19
4.2 Brief operating instructions on the function matrix . 20
4.2.1 General notes . . . . . . . . . . . . . . . . . . . . . . 20
4.3 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.3.1 FieldTool™ operating program . . . . . . . . . 21
5 Commissioning. . . . . . . . . . . . . . . . . . 22
5.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.2 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.2.1 Charging the battery . . . . . . . . . . . . . . . . . 22
6 Maintenance. . . . . . . . . . . . . . . . . . . . 23
7 Accessories. . . . . . . . . . . . . . . . . . . . . 24
7.1 Software history . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 Technical data . . . . . . . . . . . . . . . . . . 25
8.1 Technical data at a glance . . . . . . . . . . . . . . . . . . . 25
8.1.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
8.1.2 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
8.1.3 Power supply . . . . . . . . . . . . . . . . . . . . . . . 25
8.1.4 Performance characteristics . . . . . . . . . . . . 25
8.1.5 Operating conditions (Environment) . . . . . . 25
8.1.6 Mechanical construction . . . . . . . . . . . . . . 26
8.1.7 Display and user interface . . . . . . . . . . . . . 26
8.1.9 Accessories . . . . . . . . . . . . . . . . . . . . . . . . 26
8.1.10 Documentation . . . . . . . . . . . . . . . . . . . . . 26
9 Description of device functions -
General section . . . . . . . . . . . . . . . . . . 27
9.1 Notes on the description of device functions . . . . . . 27
9.1.1 Using the table of contents to locate a function
description . . . . . . . . . . . . . . . . . . . . . . . . . 27
9.1.2 Using the graphic of the function matrix to
locate a function description . . . . . . . . . . . 27
9.2 Function matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9.3 Block USER INTERFACE . . . . . . . . . . . . . . . . . . . . 29
9.3.1 Group CONTROL . . . . . . . . . . . . . . . . . . . 29
9.4 Block BASIC FUNCTIONS . . . . . . . . . . . . . . . . . . . 31
9.4.1 Group SENSOR PARAMETER . . . . . . . . . . 32
9.4.2 Group OUTPUTS . . . . . . . . . . . . . . . . . . . . 33
9.4.3 Group PROCESS PARAMETER . . . . . . . . . 34
9.4.4 Group READ IN PARAMETERS . . . . . . . . . 35
9.5 Block SUPERVISION . . . . . . . . . . . . . . . . . . . . . . . 36
9.5.1 Group RESULTS . . . . . . . . . . . . . . . . . . . . 36
9.5.2 Group VERSION INFO . . . . . . . . . . . . . . . 38
10 Description of device functions -
Fieldcheck and electromagnetic
measuring devices . . . . . . . . . . . . . . . . 39
10.1 Block FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . 39
10.1.1 Group SIMULATION . . . . . . . . . . . . . . . . . 40
10.1.2 Group VERIFICATION . . . . . . . . . . . . . . . 44
11 Description of device functions -
Fieldcheck and Coriolis measuring
systems . . . . . . . . . . . . . . . . . . . . . . . . 49
11.1 Block FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . 49
11.1.1 Group SIMULATION . . . . . . . . . . . . . . . . . 50
11.1.2 Group VERIFICATION . . . . . . . . . . . . . . . 53
12 Description of device functions -
Fieldcheck and vortex measuring
systems . . . . . . . . . . . . . . . . . . . . . . . . 59
12.1 Block FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . 59
12.1.1 Group SIMULATION . . . . . . . . . . . . . . . . . 60
12.1.2 Group VERIFICATION . . . . . . . . . . . . . . . 63
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Safety instructions Proline Fieldcheck
4Endress+Hauser
1 Safety instructions
1.1 Designated use
The Fieldcheck flow simulation system may only be used for the simulation of sensor signals with a
flowmeter of the Proline equipment generation from Endress+Hauser. The device is normally
installed by service technicians who are familiar with the function and operating method of the
equipment. The manufacturer accepts no liability for damages resulting from incorrect use.
#Warning!
Fieldcheck may not be used in hazardous areas without corresponding safety measures.
1.2 Operational safety
• The manufacturer reserves the right to modify technical data without prior notice. Please contact
your E+H distributor for information on modifications or updates of these Operating Instructions.
• The measuring system complies with the general safety requirements in accordance with EN
61010, the EMC requirements of EN 61326/A1 and NAMUR Recommendation NE 21.
1.3 Notes on operating Fieldcheck in an environment with
strong electromagnetic interference
1.3.1 Radiated RF noise (EN 61326-1)
To operate Fieldcheck with a Proline flowmeter in the simulation and verification mode, the
electronics and connection compartments must first be opened. In this mode, the radiated RF noise
will not exceed the industrial limits (EN 61326-1).
In a heavily disturbed (EMC) environment, you must expect that the operation of both Fieldcheck
and the flowmeter may be temporarily affected. We recommend that - when using Fieldcheck - you
take care to ensure effective ESD protection for the affected measuring point and the operator.
If necessary, the measuring equipment can be reset:
• Via the local controls
• By interrupting the voltage supply
• By restarting Fieldcheck.

Proline Fieldcheck Safety instructions
Endress+Hauser 5
1.4 Notes on safety conventions and icons
The devices are designed to meet state-of-the-art safety requirements, have been tested, and left the
factory in a condition in which they are safe to operate. The devices comply with the applicable
standards and regulations in accordance with EN 61010 “Protection Measures for Electrical
Equipment for Measurement, Control, Regulation and Laboratory Procedures”. They can, however,
be a source of danger if used incorrectly or for other than the designated use.
Consequently, always pay particular attention to the safety instructions indicated in these Operating
Instructions by the following icons:
#Warning!
“Warning” indicates an action or procedure which, if not performed correctly, can result in injury
or a safety hazard. Comply strictly with the instructions and proceed with care.
"Caution!
“Caution” indicates an action or procedure which, if not performed correctly, can result in incorrect
operation or destruction of the device. Comply strictly with the instructions.
!Note!
“Note” indicates an action or procedure which, if not performed correctly, can have an indirect
effect on operation or trigger an unexpected response on the part of the device.

Identification Proline Fieldcheck
6Endress+Hauser
2 Identification
2.1 Device designation
The Fieldcheck flow simulation system consists of the following components:
• The Fieldcheck flow simulator itself
• The Simubox for correct connection to the respective measuring device
2.1.1 Fieldcheck nameplate
F06-DXC10xxx-18-00-xx-xx-000
Fig. 1: Nameplate specifications for the Fieldcheck flow simulator (example)
1 Order code/serial number
2 Permitted ambient temperature range
2.1.2 Simubox nameplate
F06-DXC10xxx-18-00-xx-xx-001
Fig. 2: Nameplate specifications for the Simubox (example)
1 Order code
2 Serial number
FIELD CHECK
ENDRESS+HAUSER
Order Code:
Ser.No.:
50098801
12345678901
0°C(+32°F)<Tamb<+60°C(+140°F)
1
2
4
SIMUBOX - MID
ENDRESS+HAUSER
Order Code: 50097102
1
2
Ser.No.: 12345678901

Proline Fieldcheck Identification
Endress+Hauser 7
2.2 Scope of delivery
The equipment supplied with Fieldcheck comprises the following components:
• The Fieldcheck flow simulator with battery pack
• A connecting cable for the service interface
• A connecting cable for the Simubox
• Two connecting cables for current and frequency output
• An "RS 232" connecting cable for connecting the Fieldcheck to a computer (9-pin COM interface)
• A line adapter
• A softcase
• Operating Instructions
The Simuboxes for the respective flow measuring systems are available via separate order numbers.
2.3 CE mark, Declaration of conformity
The devices are designed to meet state-of-the-art safety requirements, have been tested, and left the
factory in a condition in which they are safe to operate. The devices comply with the applicable
standards and regulations in accordance with EN 61010 “Protection Measures for Electrical
Equipment for Measurement, Control, Regulation and Laboratory Procedures”.
The measuring system described in these Operating Instructions thus complies with the statutory
requirements of the EC Directives. Endress+Hauser confirms successful testing of the device by
affixing the CE mark.
2.4 Registered trademarks
FieldTool™, Fieldcheck™
Registration-pending or registered trademarks of Endress+Hauser Flowtec AG, Reinach,
Switzerland

Wiring Proline Fieldcheck
8Endress+Hauser
3 Wiring
#Warning!
When connecting Ex-certified devices, see the notes and diagrams in the Ex-specific supplement to
these Operating Instructions of the relevant measuring device. Fieldcheck may not be used in
hazardous areas. Please do not hesitate to contact your E+H representative if you have any
questions.
3.1 Overview
Fieldcheck is connected to the following transmitter connections:
• Via the Simubox to the transmitter amplifier
• To the transmitter service plug
• To the current or frequency output.
For correct synchronisation with the measuring device we recommend that you abide by the
following procedure.
1. Start the device to be tested.
2. First connect the cables to the flowmeter (→Page 9 to Page 14).
3. Next, connect the cables to the front of Fieldcheck (→Page 16).
!Note!
Fieldcheck does not need an external power supply during operation. Power is provided by internal
storage batteries. Make sure that the storage batteries are fully charged before beginning a
simulation.

Proline Fieldcheck Wiring
Endress+Hauser 9
3.2 Connecting to Promag 10
"Caution!
Connect the ground terminals on the cables to the uninsulated housing components or to the
ground terminals in the cover of the connection compartment.
1. Remove cover of the electronics compartment (c).
2. Remove the local display (d) from the connection compartment cover.
3. Press the side latches (e) and fold down the connection compartment cover.
4. Pull the sensor signal cable plug out of the amplifier socket (f).
5. Insert Simubox cable plug into the amplifier socket (f).
6. Connect Fieldcheck to current and pulse output (g) of the transmitter.
!Note!
The configuration of the outputs is dependent on the product type and the product version of
the tested transmitter. To find out which terminal pairs are assigned to the outputs, see the
“Wiring” chapter of the flowmeter Operating Instructions.
7. Connect FieldCheck to the service plug (h).
F06-DXC10xxx-04-00-xx-xx-007
Fig. 3: Connecting Fieldcheck to Promag 5X (compact version)
a Fieldcheck flow simulator
b Simubox
c Electronics compartment cover
d Local display
e Latches
f Amplifier socket
g Terminals for current/pulse output
h Service plug-in jack
1
2
f
h
g
Esc
a
b
d
c
e

Wiring Proline Fieldcheck
10 Endress+Hauser
3.3 Connecting to Promag 50/53 compact version
"Caution!
Connect the ground terminals on the cables to the uninsulated housing components or to the
ground terminals in the cover of the connection compartment.
1. Remove cover of the electronics compartment (e).
2. Pull local display (f) down.
3. Pull the sensor signal cable plug out of the amplifier socket (g).
4. Insert Simubox cable plug into the amplifier socket (g).
5. Remove the cover of the connection compartment (h) from the transmitter housing.
6. Connect Fieldcheck to the current and frequency outputs of the transmitter (terminal pairs
22/23, 24/25 or 26/27).
!Note!
The configuration of the outputs is dependent on the product type and the product version of
the tested transmitter. To find out which terminal pairs are assigned to the outputs, see the
“Wiring” chapter of the flowmeter Operating Instructions.
7. Connect Fieldcheck to the service plug (i).
F06-DXC10xxx-04-00-xx-xx-000
Fig. 4: Connecting Fieldcheck to Promag 5X (compact version)
a Fieldcheck flow simulator
bSimubox
c Stainless steel transmitter
d Aluminium transmitter
e Electronics compartment cover
f Local display
g Amplifier socket
h Connection compartment cover
I Service plug
27
25
23
21
2
1
26
24
22
20
L1 (L+)
N (L-)
E
- +
h
c
e
d
h
e
g
f
b
a
i

Proline Fieldcheck Wiring
Endress+Hauser 11
3.4 Connecting to Promag 50/53 remote version
"Caution!
Connect the ground terminals on the cables to the uninsulated housing components or to the
ground terminals in the cover of the connection compartment.
1. Remove the cover of the connection compartment (d).
2. Completely remove the terminal block (e, terminal nos. 4-8, 36+37) from the base.
"Caution!
If the terminal block is not removed, a correct simulation/verification is not guaranteed.
3. Insert Simubox cable plug into the amplifier socket (g).
4. Connect Fieldcheck to the current and frequency outputs of the transmitter (terminal pairs
22/23, 24/25 or 26/27).
!Note!
The configuration of the outputs is dependent on the product type and the product version of
the tested transmitter. To find out which terminal pairs are assigned to the outputs, see the
“Wiring” chapter of the flowmeter Operating Instructions.
5. Connect Fieldcheck to the service plug (f).
F06-DXC10xxx-04-00-xx-xx-001
Fig. 5: Connecting Fieldcheck to Promag 5X (remote version)
a Fieldcheck flow simulator
b Simubox
c Transmitter wall-mount housing
d Connection compartment cover
e Terminal block
f Service plug
g Amplifier socket
1222 23
20 21 24 25 26 27
41
42
6578437 36
c
d
eg
f
b
a

Wiring Proline Fieldcheck
12 Endress+Hauser
3.5 Connecting to Promass 40/80/83 compact version
"Caution!
Connect the ground terminals on the cables to the uninsulated housing components or to the
ground terminals in the cover of the connection compartment.
1. Remove cover of the electronics compartment (e).
2. Remove local display.
3. Disconnect the excitation current cable from the excitation current socket (f).
#Warning!
The excitation current cable must be disconnected as otherwise the measuring tube could
vibrate in the resonance frequency and become damaged!
4. Pull the sensor signal cable plug out of the amplifier socket (g).
5. Insert Simubox cable plug into the amplifier socket (g).
6. Remove the cover of the connection compartment (h) from the transmitter housing.
7. Connect Fieldcheck to the current and frequency outputs of the transmitter (terminal pairs
22/23, 24/25 or 26/27).
!Note!
The configuration of the outputs is dependent on the product type and the product version of
the tested transmitter. To find out which terminal pairs are assigned to the outputs, see the
“Wiring” chapter of the flowmeter Operating Instructions.
8. Connect Fieldcheck to the service plug (i).
F06-DXC10xxx-04-00-xx-xx-004
Fig. 6: Connecting Fieldcheck to Promass 8x (compact version)
a Fieldcheck flow simulator
bSimubox
c Stainless steel transmitter
d Aluminium transmitter
e Electronics compartment cover
f Exciting current socket
g Amplifier socket
h Connection compartment cover
i Service plug
27
25
23
21
2
1
26
24
22
20
L1 (L+)
N (L-)
h
c
e
d
h
e
g
f
b
a
i

Proline Fieldcheck Wiring
Endress+Hauser 13
3.6 Connecting to Promass 80/83 remote version
"Caution!
Connect the ground terminals on the cables to the uninsulated housing components or to the
ground terminals in the cover of the connection compartment.
1. Remove the cover of the connection compartment (d).
2. Remove excitation current cable (h, terminal pair 41/42).
#Warning!
The excitation current cable must be removed as otherwise the measuring tube could vibrate
in the resonance frequency and become damaged!
3. Completely remove the terminal block (e, terminals 4-12) from the base.
"Caution!
If the terminal block is not removed, a correct simulation/verification is not guaranteed.
4. Insert Simubox cable plug into the amplifier socket (g).
5. Connect Fieldcheck to the current and frequency outputs of the transmitter (terminal pairs
22/23, 24/25 or 26/27).
!Note!
The configuration of the outputs is dependent on the product type and the product version of
the tested transmitter. To find out which terminal pairs are assigned to the outputs, see the
“Wiring” chapter of the flowmeter Operating Instructions.
6. Connect Fieldcheck to the service plug (f).
F06-DXC10xxx-04-00-xx-xx-005
Fig. 7: Connecting Fieldcheck to Promass 8X (remote version)
a Fieldcheck flow simulator
b Simubox
c Transmitter wall-mount housing
d Connection compartment cover
e Terminals for sensor signal cable
f Service plug
g Amplifier socket
h Terminals for excitation current cable
12
22 23
20 21 24 25 26 27
41 42
6
578
49101112
c
d
e
g
f
b
a
h

Wiring Proline Fieldcheck
14 Endress+Hauser
3.7 Connecting to Prowirl 72
"Caution!
Connect the ground terminals on the cables to the uninsulated housing components or to the
ground terminals in the cover of the connection compartment.
1. Remove cover of the electronics compartment (c).
2. Remove the local display module (d) from the retainer rails (e).
3. Fit the local display module (d) with its left side onto the right retainer rail (e) (this secures the
local display module).
(Continued on next page)
F06-DXC10xxx-04-00-xx-xx-006
Fig. 8: Connecting Fieldcheck to Prowirl 72
a Fieldcheck
bSimubox
c Electronics compartment cover
d Local display module
e Local display module retainer rails
f Fixing screw for cover of connection compartment
g Connection compartment cover
h Terminals for current output/power supply and pulse output (optional)
i Plastic cover
j Amplifier socket
k Service plug
b
a
e
gf
d
c
g
i
i
j
k
h

Proline Fieldcheck Wiring
Endress+Hauser 15
4. Loosen the fixing screw (f) of the cover of the connection compartment (g) and fold down the
cover.
5. Connect Fieldcheck to the current output/power supply and to the pulse output if available.
The terminals can be disconnected for this.
"Caution!
– The current output can only be tested for accuracy during the verification if it is connected
to the current input of Fieldcheck.
– The pulse output is connected to the frequency input of Fieldcheck.
6. Fold up the plastic cover (i).
7. Disconnect the signal cable plug from the amplifier socket (j).
8. Insert Simubox cable plug into the amplifier socket (j).
9. Connect Fieldcheck to the service plug (k).
3.7.1 Prowirl 72 wiring diagram
F06-72xxxxxx-04-00-00-xx-000
Fig. 9: Assignment of terminals
A = Power supply/current output
B = Pulse/status output
C = Ground terminal (only relevant for remote version)
12 34
A
C
++
--
B

Wiring Proline Fieldcheck
16 Endress+Hauser
3.8 Assignment of Fieldcheck connections
F06-DXC10xxx-04-00-xx-xx-003
Fig. 10: Fieldcheck connection diagram on the front panel
1 Connection to the frequency output of the device
2 Connection to the current output of the device
3 Connection to the internal service interface of the device
4 Connection to the Simubox
5 Connection to the plug power unit
3.9 Post-connection check
• Fieldcheck can only complete the start-up procedure correctly if the simulation box and the
service cable are correctly connected.
• Current and frequency outputs which are incorrectly connected or mixed up result in an incorrect
verification result.
12
345
DCSIMSRV
I
F

Proline Fieldcheck Operation
Endress+Hauser 17
4Operation
4.1 Display and operating elements
The local display enables you to read all important variables of the simulation and configure the
device using the function matrix.
F06-DXC10xxx-07-xx-xx-xx-000
Fig. 11: Display and operating elements
1 Liquid crystal display
The backlit, liquid crystal display shows measured values, dialog texts, fault messages and information messages.
The HOME position (operating mode) is the name given to the display during normal measuring operation.
2 Optical operating elements for "Touch Control"
3 Plus/minus keys
– Enter numerical values, select parameters
– Select different blocks, groups and function groups within the function matrix
The following functions are activated by pressing the +/- keys (X) simultaneously:
– Exit the function matrix step by step →HOME position
– Press the +/- keys longer than 3 seconds →Direct return to the HOME position
– Cancel data entry
4 Enter key
–HOMEposition→Enter the function matrix
– Save numerical values entered or altered settings
Esc
E
+
-
1
2
34
+7.000
+7.012
dm3/m
dm3/m
MP1 5 %
V
+7.000
+7.012
dm3/m
dm3/m
MP1 5 %
V

Operation Proline Fieldcheck
18 Endress+Hauser
4.1.1 Display
The display area consists of three to four lines; this is where measured values are displayed, and/or
status variables (sequence information of a verification.
F06-DXC10xxx-07-xx-xx-xx-001
Fig. 12: Typical display for normal operating mode (HOME position)
1 Main line: shows simulation values, e.g. volume flow in [dm3/s]
2 Additional line: shows up-to-date measured values of the tested measuring device]
3 Information line: shows the current variables for current and frequency if the corresponding outputs of the device
are connected to Fieldcheck. This is only possible in the SIMULATION operating mode
4 “Information icons” field: icons representing additional information on the measured values are shown in this field.
See figure for a full list of the icons and their meanings.
5 “Measured values” field: the current measured values appear in this field.
6 “Unit of measurement” field: the units of measure and time defined for the flow values appear in this field.
1
45 6
2
3
+7.000
+7.012
dm3/m
dm3/m
I = 17,12 mA F = 783 Hz
V

Proline Fieldcheck Operation
Endress+Hauser 19
4.1.2 Display icons
The icons which appear in the field on the left make it easier to read and recognise error messages
locally.
F06-DXC10xxx-07-xx-xx-xx-002
Fig. 13: Fieldcheck display icons
1 DC power supply
2 Charging status: battery fully charged
3 Charging status: battery 2/3 charged
4 Charging status: battery 1/3 charged (flashing in HOME position)
5 Simulation “continuous"
6 Simulation “step"
7 Simulation “profile"
8 Verification
9Measuredvolumeflow
10 Measured mass flow
1234
5
9
678
V
10
m

Operation Proline Fieldcheck
20 Endress+Hauser
4.2 Brief operating instructions on the function matrix
!Note!
• See the general notes on Page 20.
• Description of functions →Section 9 to Section 12
1. HOME position →F→Enter the function matrix
2. Select a block (e.g. USER INTERFACE)
3. Select a group (e.g. CONTROL)
4. Select a function group (e.g. BASIC CONFIGURATION)
5. Select a function (e.g. LANGUAGE)
Change parameter / enter numerical values:
P→Select or enter release code, parameters, numerical values
F→Save your entries
6. Exit the function matrix:
– Press Esc key (X) longer than 3 seconds →HOME position
– Repeatedly press Esc key (X) →Return step by step to HOME position
F06-x3xxxxxx-19-xx-xx-xx-000
Fig. 14: Selecting functions and configuring parameters (function matrix)
4.2.1 General notes
The function matrix comprises a multiplicity of functions which, for the sake of clarity, are arranged
on a number of menu levels (blocks, groups and function groups).

Proline Fieldcheck Operation
Endress+Hauser 21
Comply with the following instructions when configuring functions:
You select functions as described on Page 20.
!Note!
A detailed description of all the functions as well as a detailed overview of the function matrix are
provided in Sections 9 to 12.
4.3 Communication
Operation via a personal computer using the “FieldTool” operating software.
4.3.1 FieldTool™ operating program
FieldTool™ is a universal service and configuration software package designed for the Proline
measuring devices. The connection is made with a commercial serial cable (9-pole DSUB, 0-
Modem) to the underside of Fieldcheck.
FieldTool™ offers the user the following fields of application:
• Configuring the equipment functions.
• Archiving the verification data.
• Printout of a verification certificate with all measuring results and I/O parameters.
You can find more information on FieldTool™ in the following E+H document:
System Information: SI 031D/06/en “FieldTool™"
