DeLonghi MAGNIFICA S ECAM22.110.B S11 User manual

ECAM20.11X - 21.11X - 22.11X
BEAN TO CUP ESPRESSO
AND CAPPUCCINO
MACHINE
Instruction for use

2
PUSH
A
A1
A2
A3
A5
A6
A4
A7
A8
A19
A18
A14
A13
A15 A17
A16
A10
A9
A11
A12

3
B2
B3
B4
B7
B8
B9
B5
B6
B
C
B1
C2 C4C1 C3

4
CONTENTS
1. FUNDAMENTAL SAFETY WARNINGS.............5
2. SAFETY WARNINGS ....................................6
2.1 Symbols used in these instructions ...............6
2.2 Designated use..............................................6
2.3 Instruction for Use.........................................6
3. INTRODUCTION..........................................6
3.1 Letters in brackets.........................................6
3.2 Troubleshooting and repairs..........................7
4. DESCRIPTION.............................................7
4.1 Description of the appliance .........................7
4.2 Description of the control panel....................7
4.3 Description of the accessories........................7
4.4 Description of lights ......................................7
5. BEFORE USE...............................................7
5.1 Checking the appliance.................................7
5.2 Installing the appliance.................................8
5.3 Connecting the appliance..............................8
5.4 Setting up the appliance...............................8
6. TURNING THE APPLIANCE ON......................9
7. TURNING THE APPLIANCE OFF ....................9
8. AUTOOFF.................................................. 9
9. ENERGY SAVING.........................................9
10. WATER SOFTENER FILTER CERTAIN MODELS ONLY
................................................................................. 10
10.1 Installing the lter ......................................10
10.2 Removal and replacement of the water
softener lter ..............................................10
11. MAKING COFFEE....................................... 10
11.1 Selecting the coee taste............................10
11.2 Selecting the quantity of coee in the cup..11
11.3 Adjusting the coee mill.............................11
11.4 Setting the temperature .............................11
11.5 Tips for a hotter coee.................................11
11.6 Making coee using coee beans ...............12
11.7 Making coee using pre-ground coee.......12
12. MAKING CAPPUCCINO ............................. 13
12.1 Cleaning the cappuccino maker after use....13
13. HOT WATER ............................................. 13
14. CLEANING................................................ 14
14.1 Cleaning the machine .................................14
14.2 Cleaning the machine’s internal circuit........14
14.3 Cleaning the coee grounds container........14
14.4 Cleaning the drip tray and condensate tray.14
14.5 Cleaning the inside of the coee machine...15
14.6 Cleaning the water tank..............................15
14.7 Cleaning the coee spouts ..........................15
14.8 Cleaning the pre-ground coee funnel .......15
14.9 Cleaning the infuser....................................15
15. DESCALING.............................................. 16
16. SETTING WATER HARDNESS...................... 17
16.1 Measuring water hardness..........................17
16.2 Setting water hardness ...............................17
17. TECHNICAL DATA...................................... 17
18. DISPOSAL................................................ 17
19. EXPLANATION OF LIGHTS.......................... 18
20. TROUBLESHOOTING ................................. 20

5
1. FUNDAMENTAL SAFETY WARNINGS
• The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Designated use: this appliance is designed and made to prepare coee and milk
based beverages and hot water. Any other use is considered improper and thus dan-
gerous. The manufacturer is not liable for damage deriving from improper use of the
appliance.
• The surface of the heating element remains hot after use and the outside of the appli-
ance may retain the heat for several minutes depending on use.
• To clean, follow the instructions in the section“14. Cleaning”.
• Cleaning and user maintenance shall not be made by children without supervision.
• Never clean by immersing the appliance in water.
• CAUTION: To prevent damage to the appliance do not use alkaline cleaning agents
when cleaning, use a soft cloth and a mild detergent
• This is a household appliance only. It is not intended to be used in: sta kitchen areas in
shops, oces and other working environments; farm houses; by clients in hotels, mo-
tels and other residential type environments; bed and breakfast type environments.
• If the plug or cord is damaged, it must be replaced by Customer Services only to avoid
all risk.
• Appliances with removable cord: avoid splashes of water on the power cord connector
or socket at the back of the appliance.
• WARNING: Models with glass surfaces: do not use the appliance if the surface is
cracked.
FOR EUROPEAN MARKETS ONLY:
• This appliance can be used by children aged from 8 years and above if they have been
given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. User cleaning and maintenance shall not be made
by children unless they are above 8 years old and supervised. Keep the appliance and
power cord away from children under 8 years of age.
• Appliances can be used by persons with reduced physical, sensory or mental capabil-
ities or lack of experience and knowledge if they are supervised or have been given

6
instruction concerning use of the appliance in a safe way and if they understand the
hazards involved.
• Children shall not play with the appliance.
• Always unplug the appliance when left unattended and before assembly, taking apart
or cleaning.
Surfaces marked with this symbol become hot during use (the symbol is present in
certain models only).
2. SAFETY WARNINGS
2.1 Symbols used in these instructions
Important warnings are identied by these symbols. It is vital to
follow these warnings.
Danger!
Failure to observe the warning may result in life threatening
injury by electric shock.
Important!
Failure to observe the warning could result in injury or damage
to the appliance.
Danger of burns!
Failure to observe the warning could result in scalds or burns.
Please note:
This symbol identies important advice or information for the
user.
Danger!
This is an electrical appliance and may cause electric shock.
You should therefore follow these safety warnings:
• Never touch the appliance with damp hands or feet.
• Never touch the plug with damp hands.
• Make sure the socket used is freely accessible at all times,
enabling the appliance to be unplugged when necessary.
• Unplug directly from the plug only. Never pull the cord as
you could damage it.
• To disconnect the appliance completely you must unplug it
from the mains socket.
• If the appliance is faulty, do not attempt to repair.
Turn it o, unplug from the mains socket and contact Cus-
tomer Services.
• Before cleaning the appliance, turn it o, unplug from the
mains socket and allow to cool.
Important:
Keep all packaging (plastic bags, polystyrene foam) away from
children.
Danger of burns!
This appliance produces hot water and steam may form while
it is in operation.
Avoid contact with splashes of water or hot steam.
When the appliance is in operation, the cup shelf could become
very hot.
2.2 Designated use
This appliance is designed and made to prepare coee and heat
drinks.
Any other use is considered improper and thus dangerous. The
manufacturer is not liable for damage deriving from improper
use of the appliance.
2.3 Instruction for Use
Read this Instruction for Use carefully before using the appli-
ance. Failure to follow this Instruction for Use may result in
burns or damage to the appliance.
The manufacturer is not liable for damage deriving from failure
to respect this Instruction for Use.
Please note:
Keep this Instruction for Use. If the appliance is passed to other
persons, they must also be provided with this Instruction for
Use.
3. INTRODUCTION
Thank you for choosing this bean to cup espresso and cappuc-
cino machine.
We hope you enjoy using your new appliance. Take a few min-
utes to read this Instruction for Use. This will avoid all risks and
damage to the appliance.
3.1 Letters in brackets
The letters in brackets refer to the legend in the description of
the appliance on page 2-3.

7
3.2 Troubleshooting and repairs
In the event of problems, rst try and resolve them by reading
the information given in the“20. Explanation of lights”and“19.
Troubleshooting”sections.
If this does not resolve the problem or you require further in-
formation, you should consult Customer Services by calling the
number given on the annexed“Customer Service”sheet.
If your country is not among those listed on the sheet, call the
number given in the guarantee. If repairs are required, contact
De’Longhi Customer Services only. The addresses are given in
the guarantee certicate provided with the machine.
4. DESCRIPTION
4.1 Description of the appliance
(page 3 - A )
A1. Control panel
A2. Grinding adjustment dial
A3. Cup shelf
A4. Beans container lid
A5. Pre-ground coee funnel lid
A6. Pre-ground coee funnel
A7. Beans container
A8. Main switch
A9. Water tank
A10. Infuser door
A11. Infuser
A12. Coee spouts (adjustable height)
A13. Coee grounds container
A14. Condensate tray
A15. Cup tray
A16. Drip tray water level indicator
A17. Drip tray
A18. Cappuccino maker
A19. Steam/hot water dial
4.2 Description of the control panel
(page 2 - B )
B1. Lights
B2. button: turns the appliance on and o
B3. button: to make 1 cup of short espresso coee.
B4. button: to make 2 cups of short espresso coee.
B5. button: to rinse or descale the appliance
B6. Selection dial: turn to select coee quantity or to use pre-
ground coee
B7. button: to deliver steam to make hot milk-based
coees
B8. button: to make 1 cup of long espresso coee
B9. button: to make 2 cups of long espresso coee.
4.3 Description of the accessories
(page 2 - C )
C1. “Total Hardness Test”indicator paper
C2. Measure
C3. Descaler bottle
C4. Water softener lter
4.4 Description of lights
Light ashing: the machine is heating up.
The appliance is delivering one or two cups of
short coee.
The appliance is delivering one or two cups of
long coee.
Light on steadily: the“steam”function has been
selected;
Light ashing: you must turn the steam dial.
An alarm is displayed on the control panel (see
the section“19. Explanation of lights”).
Light on steadily: the coee grounds container
must be inserted;
Light ashing: the grounds container is full and
must be emptied.
Light on steadily: the water tank is missing;
Light ashing: there is not enough water in the
tank.
Light ashing: the appliance must be descaled
(see the section“15. Descaling”).
Light on steadily: the appliance is performing a
descaling cycle.
ECO “Energy Saving”mode is active.
5. BEFORE USE
5.1 Checking the appliance
After removing the packaging, make sure the product is com-
plete and undamaged and that all accessories are present. Do

8
not use the appliance if it is visibly damaged. Contact De’Longhi
Customer Services.
5.2 Installing the appliance
Important!
When you install the appliance, you should respect the follow-
ing safety warnings:
• The appliance could be damaged if the water it contains
freezes.
Do not install the appliance in a room where the tempera-
ture could drop below freezing point.
• The appliance gives o heat. After positioning the appli-
ance on the worktop, leave a space of at least 3 cm be-
tween the surfaces of the appliance and the side and rear
walls and at least 15 cm above the coee machine.
• Water penetrating the coee machine could cause
damage.
Do not place the appliance near taps or sinks.
• Arrange the cord in such a way that it cannot be damaged
by sharp edges or contact with hot surfaces (e.g. electric
hot plates).
5.3 Connecting the appliance
Important!
Check that the mains power supply voltage corresponds to that
indicated on the rating plate on the bottom of the appliance.
Connect the appliance to an eciently earthed and correctly
installed socket with a minimum current rating of 10A only.
If the power socket does not match the plug on the appliance,
have the socket replaced with a suitable type by a qualied
professional.
5.4 Setting up the appliance
Please note:
• Coee has been used to factory test the appliance and it is
therefore completely normal for there to be traces of cof-
fee in the mill. The machine is, however, guaranteed to be
new.
• You should customise water hardness as soon as possible
following the instructions in the section:“16. Setting water
hardness”.
Proceed as described:
1. Remove the water tank (A9), ll to the MAX line with fresh
water (g. 1A) then put back in the appliance (g. 1B).
2. Place a container with a minimum capacity of 100 ml
under the cappuccino maker (A18) (g. 2).
1A
1B 2
3. Plug the appliance into the mains socket and place the
main switch (A8) on the back of the appliance in the Iposi-
tion (g. 3).
3 4
4. The light ashes on the control panel (B7, g. 4).
5. Turn the steam dial (A19) to the Iposition (g. 5). Water is
delivered from the cappuccino maker, then the appliance
goes o.
5
6. Turn the steam dial to the 0position.
The coee machine is now ready for normal use.
Please note:
• The rst time you use the coee maker, you need to make
4/5 cups of coee or 4/5 cappuccinos before it starts to give
satisfactory results.
• To enjoy your coee even more and improve the perfor-
mance of your appliance, we recommend installing a water

9
softener lter (C4) as described in the section “10. WATER
SOFTENER FILTER”. If your model is not provided with a l-
ter, you can request one from De’Longhi Customer Services.
6. TURNING THE APPLIANCE ON
Please note:
• Before turning the appliance on, make sure the main
switch (A8) on the back of the appliance is in the Iposition
(g. 3).
• Each time the appliance is turned on, it performs an auto-
matic preheat and rinse cycle which cannot be interrupt-
ed. The appliance is ready for use only once this cycle is
complete.
Danger of burns!
During rinsing, a little hot water comes out of the coee spouts
(A12) and is collected in the drip tray underneath. Avoid contact
with splashes of water.
• To turn the appliance on, press the button (B2, g.
6). The light ashes while the appliance is heating up
and performing an automatic rinse cycle. By circulating hot
water, the appliance heats both the boiler and the internal
circuits.
6
The appliance is at temperature when the light goes o and
the coee lights come on.
7. TURNING THE APPLIANCE OFF
Whenever the coee machine is turned o after being used to
make coee, it performs an automatic rinse cycle.
Danger of burns!
During rinsing, a little hot water ows from the coee spouts
(A12).
Avoid contact with splashes of water.
To turn the appliance o, press the button (B2, g. 6).The
appliance performs a rinse cycle then goes o.
Please note:
If the appliance is not used for an extended period, place the
main switch (A8) in the 0position (g. 3).
Important!
To avoid damaging the appliance, do not place the main switch
(g. 3) in the 0position until you have turned the appliance o
with the button.
8. AUTOOFF
The time can be changed so that the appliance switches o after
being idle for 15 or 30 minutes, or after 1, 2 or 3 hours.
To change the Auto-o setting, proceed as follows:
1. With the appliance o and the main switch (A8) in the Ipo-
sition (g. 3), press the button (B9) and hold it down
until the lights on the control panel come on.
2. Press the button (B3, on the left of the dial B6) until
the lights corresponding to the delay before the appliance
goes o automatically come on:
15 minutes ECO
30 minutes ECO
1 hour ECO
2 hours ECO
3 hours ECO
3. Press the button (B8, on the right of the dial) to
conrm the selection. The lights go o.
9. ENERGY SAVING
Use this function to enable or disable energy saving. When en-
abled, the function reduces energy consumption in compliance
with European regulations.
Energy saving mode is active when the green ECO light is on
(g. 7).
7
1. With the appliance o and the main switch (A8) in the I
position (g. 3), press the button (B7) and hold it
down until the ECO light (g. 7) come on.
2. To disable the mode, press the button (on the left of
the dial). The ECO light ashes.
3. To re-enable the mode, press the button (on the left of
the dial) again. The ECO light comes on steadily.

10
4. Press the button (on the right of the dial) to conrm
the selection. The ECO light goes o.
Please note:
When in energy saving mode, a few seconds may elapse before
the rst coee is delivered as the appliance must heat up again.
10. WATER SOFTENER FILTER CERTAIN MODELS ONLY
Certain models are tted with a water softener lter (C4). If this
is not the case with your model, you are recommended to pur-
chase one from De’Longhi Customer Services.
Important:
• Keep in a cool dry place out of direct sunlight.
• After opening the packaging, use the lter at once.
• Remove the lter before descaling the machine.
To use the lter correctly, follow the instructions below.
10.1 Installing the lter
1. Take the lter (C4) out of its packet and rinse under about
0.5 litre of running water (g. 8).
8
0,5 L
9
2. Turn the date indicator disk until the next two months of
use are displayed (g 9).
Please note:
The lter lasts about two months if the appliance is used nor-
mally. If the coee machine is left unused with the lter in-
stalled, it will last a maximum of three weeks.
3. Extract the tank (A9) from the appliance and ll with water
(g. 1A).
4. Insert the lter in the water tank and immerse it complete-
ly, sloping it to enable the air bubbles to escape (g. 10).
5. Insert the lter into the lter housing and press as far as it will
go (g.11).
10 11
6. Close the tank with the lid (g. 12), then replace the tank
in the machine.
12
7. Place a container with a minimum capacity of 500 ml
under the cappuccino maker (A18).
8. Turn the steam dial (A19) to the Iposition to deliver hot
water.
9. Deliver at least 500 ml of hot water, then turn the hot
water/steam dial back to the 0position.
Please note:
Occasionally one delivery of hot water is not enough to install
the lter and the lights will come on
during installation.
If this happens repeat the installation procedure from point 8.
The lter is now active and you can use the coee machine.
10.2 Removal and replacement of the water
softener lter
After two months (see date indicator disk), or if the appliance
has not been used for 3 weeks, the lter (C4) must be removed
from the tank (A9) and replaced with a new one. Then the in-
stallation procedure above must be repeated.
11. MAKING COFFEE
11.1 Selecting the coee taste
Turn the coee taste selection dial (B9) to set the required taste.
Turning it clockwise increases the quantity of coee beans the

11
appliance will grind and therefore the strength of the coee
obtained.
Turn the dial to MIN for an extra mild coee and to MAX for an
extra strong coee.
Please note:
• The rst time you use the appliance, you will need to make
a number of coees to identify the correct dial position
through trial and error.
• Do not turn the dial too far towards MAX, otherwise the
coee may be delivered too slowly (a drop at a time), par-
ticularly when making two cups of coee at the same time.
11.2 Selecting the quantity of coee in the cup
The appliance is set by default to automatically make the fol-
lowing quantities of coee:
- short coee when the button (B3) is pressed
(≃40ml);
- long coee when the button (B8) is pressed
(≃120ml);
- two short coees when the button (B4) is pressed;
- two long coees when the button (B9) is pressed.
To change the quantity of coee the appliance delivers auto-
matically into the cup, proceed as described below:
- press the button corresponding to the quantity to be mod-
ied and hold it down until the light ashes and the appli-
ance starts delivering coee, then release;
- when the coee in the cup reaches the desired level, press
the same button again to memorise the new amount.
The machine is now reprogrammed with the new quantities.
11.3 Adjusting the coee mill
The coee mill is set by default to prepare coee correctly and
should not require regulating initially.
However, if after making the rst few coees you nd that the
coee is either too weak and not creamy enough or delivery is
too slow (a drop at a time), this can be corrected by adjusting
the grinding adjustment dial (A2) (g. 13).
13
Please note:
The grinding adjustment dial (A2) must only be turned when
the coee mill is in operation.
If the coee is delivered too slowly or
not at all, turn one click clockwise.
For fuller bodied creamier coee, turn
one click anticlockwise (do not turn
more than one click at a time other-
wise the coee could be delivered a
drop at a time).
These adjustments will only be evident after at least 2 cups of
coee have been delivered. If this adjustment does not obtain
the desired result, turn the dial another click.
11.4 Setting the temperature
To modify the temperature of the water used to make the coee,
proceed as follows:
1. With the appliance o and the main switch in the Iposition
(g. 3), press the button (B3) and hold it down until
the lights on the control panel come on;
2. Press the button to select the required temperature:
LOW HIGH
3. Press the button (B8) to conrm the selection. The
lights go o.
11.5 Tips for a hotter coee
For hotter coee, you should:
• before delivering the coee, perform a rinse cycle by press-
ing the button (B5). Hot water is delivered from
the spouts, heating the internal circuits of the appliance
and thus raising the coee temperature;
• warm the cups with hot water (using the hot water
function).

12
• set a hotter coee temperature (see the section “Setting
the temperature”).
11.6 Making coee using coee beans
Important!
Do not use caramelised or candied coee beans as they could
stick to the coee mill and damage it.
1. Fill the container (A7, g. 14) with coee beans.
14 15
2. Place under the coee spouts (A12):
- 1 cup, if you want to make 1 coee (g. 15);
- 2 cups, if you want 2 coees (g. 16).
16 17
3. Lower the spouts as near as possible to the cup.This makes
a creamier coee (g. 17).
4. Press the button corresponding to the required coee:
5. Preparation begins and the light corresponding to the se-
lected button ashes on the control panel.
Once the coee has been made, the appliance is ready to make
the next drink.
Please note:
• While the machine is making coee, delivery can be in-
terrupted at any moment by pressing one of the coee
buttons.
• At the end of delivery, to increase the quantity of coee
in the cup, just press one of the coee icons (within 3
seconds).
Please note:
For hotter coee, see the section“11.5. Tips for a hotter coee”.
Important!
• If the coee is delivered a drop at a time, too weak and not
creamy enough or too cold, read the tips in the section“20.
Troubleshooting”.
• Lights may be displayed on the control panel during use.
Their meaning is given in the section “19. Explanation of
the lights.
11.7 Making coee using pre-ground coee
Important!
• Never place coee beans in the pre-ground coee funnel
as this could damage the appliance.
• Never add pre-ground coee when the machine is o or it
could spread through the inside of the machine and dirty
it.This could damage the appliance.
• Never use more than 1 level
measure or it could dirty the
inside of the coee machine or
block the funnel.
Please note:
When you use pre-ground coee, you can only make one cup of
coee at a time.
1. Make sure the appliance is on.
2. Turn the coee taste selection dial (B6) anticlockwise as far
as it will go to the position (g. 18).
18 19
3. Make sure the funnel is not blocked, then add one level
measure (C2) of pre-ground coee (g. 19).
4. Place a cup under the coee spouts (A12).
5. Press the corresponding 1 cup coee button ( B3 or
B8).
6. Preparation begins.
1 short coee 1 long coee
2 long coees2 short coees

13
12. MAKING CAPPUCCINO
Danger of burns!
During preparation steam is given o. Take care to avoid scalds.
1. When preparing cappuccino, make the coee in a large
cup;
2. Fill a container (preferably one with a handle to avoid
scalding) with about 100 ml of milk for each cappuccino.
In choosing the size of the container, bear in mind that the
milk doubles or triples in volume;
Please note:
For a richer denser froth, use skimmed or partially skimmed
milk at refrigerator temperature (about 5°C). To avoid milk
with poor froth or large bubbles, always clean the cappuc-
cino maker (A18) as described in the section “Cleaning the
cappuccino maker after use”.
3. Press the button (B7). The light ashes.
4. Immerse the cappuccino maker in the milk container (g.
20).
20
5. After a few seconds, when the light ashes, turn the
steam dial (A19) to the Iposition (g. 5). Steam is deliv-
ered from the cappuccino maker, giving the milk a creamy
frothy appearance and making it more voluminous;
6. For a creamier froth, rotate the container with slow move-
ments in an upward direction. (You should not deliver
steam for more than 3 minutes at a time);
7. When you have obtained the required froth, stop steam
delivery by turning the steam dial back to the 0position.
Danger of burns!
Stop steam delivery before removing the container with
the frothed milk to avoid burns caused by splashes of boil-
ing milk.
8. Add the milk froth to the coee prepared previously. The
cappuccino is ready. Sweeten to taste and, if desired, sprin-
kle the froth with a little cocoa powder.
12.1 Cleaning the cappuccino maker after use
Always clean the cappuccino maker (A18) after use to avoid the
build-up of milk residues and prevent the spouts from clogging.
1. Place a container under the cappuccino maker and deliver
a little water for a few seconds by rotating the steam dial
(A19) to the Iposition (g. 5). Then turn the steam dial to
the 0position to stop the ow of hot water.
2. Wait a few minutes for the cappuccino maker to cool down.
Grip the handle of the cappuccino maker tube rmly in one
hand and with the other rotate the cappuccino maker anti-
clockwise (g. 21), then remove by pulling downwards.
21 22
3. Also remove the steam connection nozzle by pulling it
downwards (g. 22).
4. Make sure the two holes shown by the arrow in g. 23 are
not blocked. If necessary, clean using a toothpick.
23
5. Wash all parts of the cappuccino maker thoroughly with a
sponge and warm water.
6. Reinsert the nozzle, then replace the cappuccino maker
on the nozzle, turning it and pushing it upwards until it is
attached.
13. HOT WATER
Danger of burns!
Never leave the machine unattended while delivering hot water.
The hot water spout becomes hot while water is being delivered
and must be handled by the handle only.

14
1. Place a container under the cappuccino maker (A18) (as
close as possible to avoid splashes).
2. Turn the steam dial (A19) to the Iposition. Delivery begins.
3. Stop by turning the steam dial to the 0position.
Please note:
If “Energy Saving” mode is active, you may have to wait a few
seconds before the hot water is delivered.
14. CLEANING
14.1 Cleaning the machine
The following parts of the machine must be cleaned regularly:
- the appliance’s internal circuit;
- coee grounds container (A13);
- drip tray (A17) and condensate tray (A14);
- water tank (A9);
- coee spouts (A12);
- cappuccino maker (A18);
- pre-ground coee funnel (A6);
- infuser (A11), accessible after opening the service door
(A10);
- control panel (A1).
Important!
• Do not use solvents, abrasive detergents or alcohol to clean
the coee machine.With De’Longhi superautomatic coee
machines, you need not use chemical products to clean the
machine.
• None of the components can be washed in a dishwasher.
• Do not use metal objects to remove encrustations or coee
deposits as they could scratch metal or plastic surfaces.
14.2 Cleaning the machine’s internal circuit
If the appliance is not used for more than 3-4 days, before
using it again, we strongly recommend switching it on and
performing:
• 2/3 rinse cycles by pressing the button (B5);
• delivering hot water by turning the hot water/steam dial
(A19) to the Iposition.
Please note:
• After cleaning, it is normal for the grounds container (A13)
to contain water.
14.3 Cleaning the coee grounds container
When the light ashes, the coee grounds container must
be emptied and cleaned. Unless you clean the grounds contain-
er, the light will continue to ash and the appliance cannot be
used to make coee.
To clean (with the machine on):
• Remove the drip tray (A17) (g. 24), empty and clean.
24
• Empty the grounds container (A13) and clean thoroughly
to remove all residues left on the bottom.
• Check the red condensate tray (A14) and empty if
necessary.
Important!
When removing the drip tray, the grounds container must al-
ways be emptied, even if it contains few grounds.
If this is not done, when you make the next coees, the grounds
container may ll up more than expected and clog the machine.
14.4 Cleaning the drip tray and condensate tray
Important!
If the drip tray is not emptied regularly, the water could over-
ow from the edge and seep inside or around the machine.
This could damage the machine, the surface it rests on or the
surrounding area.
The drip tray is tted with a level indicator (A16) (red) show-
ing the level of water it contains (g. 25). Before the indicator
protrudes from the cup tray, the drip tray must be emptied and
cleaned.
25
To remove the drip tray:
1. Remove the drip tray (A17) and the grounds container
(A13) (g. 24);
2. Empty the drip tray and grounds container and wash them;
3. Check the condensate tray (A14) and empty if necessary.

15
4. Replace the drip tray and grounds container.
14.5 Cleaning the inside of the coee machine
Danger of electric shock!
Before cleaning internal parts, the machine must be turned o
(see“7.Turning o”) and unplugged from the mains power sup-
ply. Never immerse the coee machine in water.
1. Check regularly (about once a week) that the inside of the
appliance (accessible after removing the drip tray) is not
dirty. If necessary, remove coee deposits with a sponge.
2. Remove the residues with a vacuum cleaner (g. 26).
26
14.6 Cleaning the water tank
1. Clean the water tank (A9) regularly (about once a month) and
whenever you replace the water softener lter (C4, if provid-
ed) with a damp cloth and a little mild washing up liquid.
2. Remove the lter (if present) and rinse with running water.
3. Replace the lter (if provided), ll the tank with fresh
water and replace the tank.
4. (Models with water softener lter only) Deliver about 100
ml of water.
14.7 Cleaning the coee spouts
1. Clean the coee spouts (A12) with a sponge or cloth (g.
27).
27 28
2. Check the holes in the coee spouts are not blocked. If nec-
essary, remove coee deposits with a toothpick (g. 28).
14.8 Cleaning the pre-ground coee funnel
Check regularly (about once a month ) that the pre-ground
coee funnel (A6) is not blocked. If necessary, remove coee
deposits.
14.9 Cleaning the infuser
The infuser (A11) must be cleaned at least once a month.
Important!
The infuser may not be extracted when the machine is on.
1. Make sure the machine is correctly turned o (see“7.Turn-
ing o”).
2. Remove the water tank (A9).
3. Open the infuser door (A10) (g. 29) on the right side of
the appliance.
29 30
PUSH
PUSH
4. Press the two coloured release buttons inwards and at the
same time pull the infuser outwards (g. 30);
Important!
Clean the infuser without using washing up liquid as it could
be damaged.
5. Soak the infuser in water for about 5 minutes, then rinse
under the tap.
6. Clean coee residues from the support where the infuser
rests.
31
7. After cleaning, replace the infuser by sliding it onto the
internal support (g. 31), then push the PUSH symbol
until it clicks into place.
Infuser support

16
Please note:
If the infuser is dicult to insert, before insertion, adapt it to the
right size by pressing the two levers shown in g. 32.
32
8. Once inserted, make sure the two coloured buttons have
snapped out (g. 33).
33
PUSH
9. Close the infuser door.
10. Put the water tank back.
15. DESCALING
Descale the appliance when the light (B5) (g. 34) on the
control panel ashes.
34
Important!
• Before use, read the instructions and the labelling on the
descaler pack.
• You should use De’Longhi descaler only. Using unsuitable
descaler and/or performing descaling incorrectly may re-
sult in faults not covered by the manufacturer’s guarantee.
1. Turn the appliance on and wait until it is ready for use.
2. Empty the drip tray (A17) and grounds container (A13) and
put both back in the machine.
3. Empty the water tank (A9) completely and remove the
water softener lter (C4), if present.
4. Pour the descaler (C3) into the tank up to level A (corre-
sponding to a 100 ml pack) marked on the back of the tank,
then add a litre of water up to level B(g. 35) and put the
water tank back in the appliance.
1,8 l
36
B
A
A B
35
. Place a container with a minimum capacity of 1.8 litres
under the cappuccino maker (A18) and coee spouts (A12)
(g. 36).
6. Wait for the coee lights to come on steadily.
7. Press and hold the button (B5) for at least 5 sec-
onds to conrm that you have added
the solution and begin the descaling procedure. The light
in the button comes on steadily to indicate that the desca-
ling programme has begun.
8. The light ashes to indicate the hot water/steam dial
(A19) must be turned to the Iposition.
Important! Danger of burns
Hot water containing acid ows from the cappuccino maker and
coee spouts. Take care to avoid contact with splashes of this
solution.
9. When the dial has been turned to the lposition, the des-
cale programme starts and the descaler liquid comes out of
the cappuccino maker and coee spouts. A series of rinses
and pauses are performed automatically to remove all the
scale residues inside the coee machine.
After about 25 minutes, descaling stops and the and
lights ash on the control panel. Turn the hot water/steam dial
to the 0position.
10. The appliance is now ready for rinsing through with clean
water. Empty the container used to collect the descaler
solution. Extract the water tank, empty, rinse under run-
ning water, ll with fresh water up to the MAX level and
put back in the appliance: the light ashes.
Small lever
Large lever

17
11. Place the container used to collect the descaler solution
empty under the cappuccino maker and coee spouts (g.
36).
12. Turn the hot water/steam dial to the Iposition to begin
rinsing. Hot water is delivered rst from the cappuccino
maker, to continue and end with the coee spouts.
13. When the water tank is completely empty, the and
lights ash on the control panel.Turn the hot water/
steam dial to the 0position.
14. Empty the container used to collect the rinsing water. Re-
move the water tank, replace the water softener lter (if
removed previously), ll the tank up to the MAX level with
cold water and insert in the appliance. The steam
light ashes.
15. Place the container used to collect the rinsing water empty
under the cappuccino maker;
16. Turn the hot water/steam dial to the Iposition. Rinsing
continues from the cappuccino maker only.
17. When it nishes, the steam light ashes on the con-
trol panel.Turn the hot water/steam dial to the 0position.
18. Top up the water tank with fresh water to the MAX level
and put back in the machine.
Descaling is complete.
Please note!
• If the descaling cycle is not completed correctly (e.g. no
electricity) we recommend repeating the cycle.
• After descaling, it is normal for the grounds container
(A13) to contain water.
16. SETTING WATER HARDNESS
Descaling is necessary after a period of operation established
according to the water hardness set.
The machine is set by default for a hardness value of 4. The ma-
chine can also be programmed according to the hardness of the
mains water in the various regions so that the machine needs to
be descaled less often.
16.1 Measuring water hardness
1. Remove the “TOTAL HARDNESS TEST” indicator paper (C1)
from its pack (attached to the English instructions).
2. Immerse the paper completely in a glass of water for one
second.
3. Remove the paper from the water and shake lightly. After
about a minute, 1, 2, 3, or 4 red squares form, depending
on the hardness of the water. Each square corresponds to
one level.
16.2 Setting water hardness
1. Make sure the appliance is o (but connected to the
mains electricity supply and with the main switch in the
I position);
2. Press and hold the button (B5) for at least 5 sec-
onds. The and lights come on together;
3. Press the button (B3, on the left of the dial) to set the
actual water hardness as measured by the indicator paper.
Level Level Level Level
1234
4. Press the button (B8, on the right of the dial) to
conrm the selection.
The machine is now reprogrammed with the new water hard-
ness setting.
17. TECHNICAL DATA
Voltage: 220-240 V~ 50/60 Hz max. 10A
Absorbed power: 1450 W
Pressure: 1.5 MPa (15 bars)
Max. water tank capacity: 1.8 L
Size LxDxH: 240x430x350 mm
Cord length: 1150 mm
Weight: 8.9 kg
Max. beans container capacity: 250 g
This product is compliant with Regulation (EC) No.
1935/2004 on materials and articles intended to come
into contact with food.
18. DISPOSAL
The appliance must not be disposed of with house-
hold waste, but taken to an authorised waste separa-
tion and recycling centre.
Level 1
Level 2
Level 3
Level 4

18
19. EXPLANATION OF LIGHTS
LIGHT DISPLAYED POSSIBLE CAUSE REMEDY
The hot water/steam dial must be
turned (A19)
Turn the hot water/steam dial.
FLASHING
Insucient water in the tank (A9). Fill the tank with water and/or insert it correct-
ly, pushing it as far as it will go until it clicks
into place.
The tank (A9) is not correctly in
place.
Insert the tank correctly and press as far as it
will go.
FLASHING
The grounds container (A13) is full. Empty the grounds container and drip tray,
clean and replace. Important: when removing
the drip tray, the grounds container MUST be
emptied, even if it contains few grounds. If this
is not done, when you make the next coees,
the grounds container may ll up more than
expected and clog the machine.
After cleaning, the grounds con-
tainer has not been replaced
(A13).
Remove the drip tray and insert the grounds
container.
FLASHING
The grinding is too ne and the
coee is delivered too slowly or
not at all.
Repeat coee delivery and turn the grinding
adjustment dial (A2, g. 10) one click clock-
wise towards "7" while the coee mill is in
operation. If after making at least 2 coees
delivery is still too slow, repeat the correction
procedure, turning the grinding adjustment
dial another click until delivery is correct (see
"11.3. Adjusting the coee mill). If the prob-
lem persists, turn the steam dial (A19) to the
Iposition and deliver some water from the
cappuccino maker.
If the water softener lter (C4) is
present, an air bubble may have
been released inside the circuit,
obstructing delivery.
Deliver a little water from the cappuccino
maker by turning the steam dial (A19) to the I
position until the ow is regular (g. 5).

19
LIGHT DISPLAYED POSSIBLE CAUSE REMEDY
FLASHING
The "pre-ground coee" function
has been selected without placing
any pre-ground coee in the fun-
nel (A6).
Place pre-ground coee in the funnel or dese-
lect the“pre-ground”function.
FLASHING
The machine must be descaled. The descaling procedure described in the sec-
tion“15. Descaling" needs to be performed.
FLASHING
Too much coee has been used. Select a milder taste or reduce the quantity
of pre-ground coee, then make the coee
again.
FLASHING
The coee beans have run out. Fill beans container.
The pre-ground coee funnel (A6)
is clogged.
Empty the funnel with the help of a brush as
described in the section "14.8. Cleaning the
pre-ground coee funnel".
FLASHING
The infuser has not been replaced
after cleaning (A11).
Insert the infuser as described in the section
“14.9. Cleaning the infuser".
The inside of the appliance is very
dirty.
Clean the inside of the appliance thoroughly,
as described in the section "14. Cleaning". If
the message is still displayed after cleaning,
contact a service centre.

20
20. TROUBLESHOOTING
Below is a list of some of the possible malfunctions.
If the problem cannot be resolved as described, contact Customer Services.
PROBLEM POSSIBLE CAUSE REMEDY
The coee is not hot. The cups were not preheated. Warm the cups by rinsing them with hot water.
Please note: the hot water or rinse function can
be used.
The infuser has cooled down because 2/3
minutes have elapsed since the last coee was
made.
Before making coee, heat up the infuser by
pressing the rinse button.
The coee is weak or not
creamy enough.
The coee is ground too coarsely. Turn the grinding dial one click anticlockwise
while the grinder is in operation (g. 8). Con-
tinue one click at a time until coee delivery is
satisfactory. The eect is only visible after de-
livering 2 coees (see section "11.3Adjusting
the coee mill").
The coee is unsuitable. Use coee beans suitable for espresso
machines.
The coee is delivered too
slowly or a drop at a time.
The coee is ground too nely. Turn the grinding dial one click clockwise
while the grinder is in operation (g. 8). Con-
tinue one click at a time until coee delivery is
satisfactory. The eect is only visible after de-
livering 2 coees (see section "11.3. Adjusting
the coee mill").
Coee does not come out of
one or both of the spouts.
The spouts are blocked. Clean the spouts with a toothpick.
The frothed milk has large
bubbles
The milk is not cold enough or is not
semi-skimmed.
You should ideally use skimmed or semi-
skimmed milk at refrigerator temperature
(about 5°C). If the result is not as you wished,
try changing brand of milk.
The milk is not frothed Cappuccino maker dirty. Clean as described in the section "12.1. Clean-
ing the cappuccino maker after use".
Steam delivery stops A safety device stops steam delivery after 3
minutes.
Wait, and then enable the steam function
again.
The appliance does not come
on
It is not plugged into the mains socket. Plug into the mains socket.
The main switch (A8) is not turned on. Place the main switch in the I position (g. 1).
