DeLonghi DFC60W16 Service manual

DFC60W16 / DFC60X16
installation / instructions manual
εγχειρίδιο εγκατάστασης / οδηγιών
Ψυγείο-καταψύκτης
τεχνολογίας αποτροπής
σχηματισμού πάγου
(Frost Free) 60cm
60cm Frost Free
Fridge Freezer GB
GR
DFC60W_X16_IB_2L_160407_grace.indb 1 7/4/16 6:19 pm

GB
Contents
safety warnings .................................................................................................................. 4
unpacking............................................................................................................................ 8
installation........................................................................................................................... 9
location ............................................................................................................................ 9
levelling the unit............................................................................................................... 9
free space requirements.................................................................................................. 9
installling the door handle................................................................................................ 9
reversing the door swing ............................................................................................... 10
cleaning before use ....................................................................................................... 13
before using your unit.................................................................................................... 13
product overview.............................................................................................................. 14
main unit........................................................................................................................ 14
operation ........................................................................................................................... 15
switching on your unit.................................................................................................... 15
super freeze mode ........................................................................................................ 15
holiday mode ................................................................................................................. 15
noises inside the unit!.................................................................................................... 16
tips for keeping food in the unit ..................................................................................... 16
preparations for freezing ............................................................................................... 16
defrosting frozen food.................................................................................................... 17
cleaning the interior and the exterior of the unit........................................................... 17
maintenance...................................................................................................................... 18
changing the internal LED light ..................................................................................... 18
care when handling / moving your unit.......................................................................... 18
servicing ........................................................................................................................ 18
switching off for long periods of time ............................................................................. 18
condensation ................................................................................................................. 18
disposal............................................................................................................................. 18
specications.................................................................................................................... 19
DFC60W_X16_IB_2L_160407_grace.indb 2 7/4/16 6:19 pm

Περιεχομενα
προειδοποιήσεις ασφαλείας............................................................................................. 6
αφαίρεση συσκευασίας ................................................................................................... 20
εγκατάσταση ..................................................................................................................... 21
τοποθεσία ...................................................................................................................... 21
ισοστάθμιση της μονάδας.............................................................................................. 21
απαιτήσεις ύπαρξης ελεύθερου χώρου ......................................................................... 21
τοποθέτηση της χειρολαβής της πόρτας........................................................................ 21
αλλαγή φοράς πόρτας ................................................................................................... 22
αλλαγή πριν από τη χρήση............................................................................................ 25
προτού χρησιμοποιήσετε τη μονάδα σας ...................................................................... 25
επισκόπηση προϊόντος ................................................................................................... 26
κύρια μονάδα................................................................................................................. 26
λειτουργία.......................................................................................................................... 27
ενεργοποίηση της μονάδας σας .................................................................................... 27
κατάσταση λειτουργίας υπερ-ψύξης .............................................................................. 27
λειτουργία διακοπών...................................................................................................... 27
θόρυβοι στο εσωτερικό της μονάδας!............................................................................ 28
συμβουλές για τη συντήρηση τροφίμων στη μονάδα .................................................... 28
προετοιμασίες για κατάψυξη ......................................................................................... 28
απόψυξη κατεψυγμένων τροφίμων ............................................................................... 29
καθαρισμός του εσωτερικού και του εξωτερικού της μονάδας .................................... 29
συντήρηση ........................................................................................................................ 30
αντικατάσταση της εσωτερικής λυχνίας LED ................................................................. 30
φροντίδα κατά το χειρισμό / μετακίνηση της μονάδας σας ............................................ 30
εργασίες σέρβις ............................................................................................................. 30
απενεργοποίηση για μακρά χρονικά διαστήματα .......................................................... 30
συμπύκνωση ................................................................................................................. 30
απόρριψη .......................................................................................................................... 30
προδιαγραφές .................................................................................................................. 31
GR
DFC60W_X16_IB_2L_160407_grace.indb 3 7/4/16 6:19 pm

4
GB
safety warnings
For your continued safety and to reduce the risk of injury or electric
shock, please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them
for future reference.
• Retain the manual. If you pass the unit onto a third party, make
sure to include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
– farm houses and by clients in hotels, motels and other residential
type environment;
– bed and breakfast type environment;
– staff kitchen areas in shops, offices and other working
environment;
– catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection
from the mains supply.
• If the mains cable is damaged, it must be replaced by the
manufacturer, its service agent or a qualified technician in order to
avoid a hazard.
• Choose a location for your unit away from heat sources such as
radiators or fires as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children should be supervised to ensure that they do not play with
the unit.
• If your unit is fitted with a lock to prevent children being trapped
inside, keep the key out of reach and not in the vicinity of the unit.
DFC60W_X16_IB_2L_160407_grace.indb 4 7/4/16 6:19 pm

5
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN
AUTHORISED SERVICE PERSONNEL TO CARRY OUT
SERVICING OF REPAIRS WHICH INVOLVE THE REMOVAL
OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT
ATTEMPT REPAIRS YOURSELF.
WARNING
• Keep ventilation openings in the unit enclosure or in the built-
in structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a
very environmental-friendly gas but is also combustible. Take
care when transporting or moving the unit to ensure that the
refrigeration circuit is not damaged. In the event of damage
avoid naked flames or ignition sources and ventilate the room
in which the unit is placed for a few minutes.)
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• Do not store bottles or glass containers in the freezer
compartment. Contents can expand when frozen (fizzy
drinks) which may break the bottle and damage your freezer
compartment. (If applicable)
DFC60W_X16_IB_2L_160407_grace.indb 5 7/4/16 6:19 pm

6
GR
προειδοποιησεις ασφαλειας
Για τη συνεχή ασφάλειά σας και τη μείωση του κινδύνου πρόκλησης
τραυματισμού ή ηλεκτροπληξίας, ακολουθήστε όλες τις προφυλάξεις
ασφαλείας που αναφέρονται παρακάτω.
• Διαβάστε όλες τις οδηγίες προσεκτικά πριν τη χρήση της μονάδας
και κρατήστε τις για λόγους μελλοντικής αναφοράς.
• Κρατήστε το εγχειρίδιο. Εάν μεταβιβάσετε τη μονάδα σε τρίτους,
βεβαιωθείτε ότι το εγχειρίδιο συμπεριλαμβάνεται.
• Αυτή η συσκευή προορίζεται για εσωτερική χρήση σε οικιακό
περιβάλλον και παρόμοιες χρήσεις όπως:
– σε φάρμες και από πελάτες σε ξενοδοχεία, πανδοχεία και άλλα
περιβάλλοντα οικιστικού τύπου,
– σε περιβάλλοντα τύπου bed & breakfast (με πρωινό),
– σε καταστήματα, γραφεία ή άλλα περιβάλλοντα εργασίας με
χώρους με εξοπλισμό κουζίνας,
– για χρήσεις σε υπηρεσίες ομαδικής εστίασης και παρόμοιες
υπηρεσίες πλην της λιανικής.
• Βεβαιωθείτε ότι το βύσμα είναι εύκολα προσβάσιμο για
αποσύνδεση από την τροφοδοσία κύριου δικτύου.
• Εάν το καλώδιο τροφοδοσίας από το κύριο δίκτυο καταστραφεί,
πρέπει να αντικατασταθεί από τον κατασκευαστή, τον πράκτορα
σέρβις ή τον εξειδικευμένο τεχνικό για την αποφυγή πρόκλησης
κινδύνων.
• Επιλέξτε για τη μονάδα σας μια θέση μακριά από πηγές
θερμότητας όπως θερμαντικά σώματα ή φλόγες καθώς το ψυκτικό
και η φλυκταινογόνος ουσία είναι εύφλεκτες.
• Η μετακίνηση της μονάδας γίνεται από τουλάχιστον 2 άτομα.
• Αυτή η συσκευή μπορεί να χρησιμοποιηθεί από παιδιά ηλικίας
από 8 ετών και άνω και από άτομα με μειωμένες σωματικές,
αισθητήριες ή διανοητικές ικανότητες ή έλλειψη εμπειρίας και
γνώσης, εφόσον επιβλέπονται ή τους έχουν δοθεί οδηγίες σχετικά
με τη χρήση της συσκευής με ασφαλή τρόπο και κατανοούν τις
κινδύνους που εμπλέκονται. Τα παιδιά δεν πρέπει να παίζουν με
τη συσκευή. Ο καθαρισμός και η συντήρηση από το χρήστη δεν θα
πρέπει να γίνεται από παιδιά χωρίς επιτήρηση.
DFC60W_X16_IB_2L_160407_grace.indb 6 7/4/16 6:19 pm

7
ΠΡΟΕΙΔΟΠΟΙΗΣΗ
ΕΙΝΑΙ ΕΠΙΚΙΝΔΥΝΟ ΓΙΑ ΟΠΟΙΟΝΔΗΠΟΤΕ ΕΚΤΟΣ ΑΠΟ ΤΟ
ΕΞΕΙΔΙΚΕΥΜΕΝΟ ΠΡΟΣΩΠΙΚΟ ΣΕΡΒΙΣ ΝΑ
ΠΡΑΓΜΑΤΟΠΟΙΕΙ ΕΡΓΑΣΙΕΣ ΣΕΡΒΙΣ Ή ΕΠΙΣΚΕΥΕΣ ΠΟΥ
ΠΕΡΙΛΑΜΒΑΝΟΥΝ ΤΗΝ ΑΦΑΙΡΕΣΗ ΤΩΝ ΚΑΛΥΜΜΑΤΩΝ.
ΠΡΟΣ ΑΠΟΦΥΓΗ ΤΟΥ ΚΙΝΔΥΝΟΥ ΠΡΟΚΛΗΣΗΣ
ΗΛΕΚΤΡΟΠΛΗΞΙΑΣ ΜΗΝ ΕΠΙΧΕΙΡΕΙΤΕ ΝΑ ΚΑΝΕΤΕ
ΕΠΙΣΚΕΥΕΣ ΜΟΝΟΙ ΣΑΣ.
ΠΡΟΕΙΔΟΠΟΙΗΣΗ
• Διατηρήστε τις σχισμές εξαερισμού στο περίβλημα της
μονάδας ή στην ενσωματωμένη μονάδα απαλλαγμένες από
εμπόδια.
• Μη χρησιμοποιείτε μηχανικές συσκευές ή άλλα μέσα για
να επισπεύσετε την διαδικασία απόψυξης, εκτός από τις
προτεινόμενες από τον κατασκευαστή.
• Μη χρησιμοποιείτε ηλεκτρικές συσκευές στο εσωτερικό των
θαλάμων φύλαξης τροφίμων της μονάδας, εκτός αν είναι του
προτεινόμενου από τον κατασκευαστή τύπου.
• Μην προκαλείτε βλάβη στο κύκλωμα ψυκτικού (Το ψυκτικό
είναι ένα πολύ φιλικό προς το περιβάλλον αέριο, που όμως
είναι εύφλεκτο. Να είστε προσεκτικοί κατά τη μεταφορά
ή μετακίνηση της συσκευής για να διασφαλιστεί ότι στο
κύκλωμα ψυκτικού δεν έχει προκληθεί βλάβη. Σε περίπτωση
βλάβης αποφεύγετε τις γυμνές φλόγες ή πηγές ανάφλεξης και
εξαερίστε το χώρο στον οποίο έχει τοποθετηθεί η μονάδα για
λίγα λεπτά.)
• Τα παιδιά πρέπει να επιβλέπονται για να διασφαλιστεί ότι δεν
παίζουν με τη μονάδα.
• Εάν η μονάδα σας διαθέτει κλειδαριά για να αποφευχθεί το
ενδεχόμενο να παγιδευτούν παιδιά στο εσωτερικό τους, φυλάξτε το
κλειδί σε περιβάλλον που δεν έχουν πρόσβαση και όχι κοντά στη
μονάδα.
• Μην αποθηκεύετε εκρηκτικές ουσίες όπως δοχεία αερολυμάτων με
εύφλεκτο προωθητικό μέσο σε αυτή τη συσκευή.
• Μην αποθηκεύετε φιάλες ή γυάλινους περιέκτες στο θάλαμο
κατάψυξης. Τα περιεχόμενα μπορούν να διασταλούν όταν
καταψύχονται (αναψυκτικά), προκαλώντας θραύση της φιάλης και
βλάβη στο θάλαμο κατάψυξης. (εάν διατίθεται)
DFC60W_X16_IB_2L_160407_grace.indb 7 7/4/16 6:19 pm

8
GB
unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Fridge Freezer.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this installation/instruction
manual in order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this installation/
instruction manual for future reference.
The Main Unit
Salad Bin Cover Shelf
Upper Left
Hinge Cover
Wine Rack
Fridge Glass Shelf x 3
Salad Bin Small Freezer Drawer x 2 Large Freezer Drawer
Upper Fridge Door Shelf
x 2
Egg Tray
Bottle Stopper
Instruction Manual Ice Tray
Lower Fridge Door Shelf
Instruction
Manual
Door Handle x 2
Door Handle Screw
x 4
Door Handle Screw
Cap x 4
Upper Right
Corner Cover
Upper Door Stop
Block (left side)
Screw for
Stop Block
Freezer Glass Shelf x 2
DFC60W_X16_IB_2L_160407_grace.indb 8 7/4/16 6:19 pm

GB
location
When selecting a position for your unit you should make sure the floor is flat and firm, and the
room is well ventilated with an average room temperature of between 10°C and 43°C. Avoid
locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight
as it may increase the electrical consumption. Extreme cold ambient temperatures may also
cause the unit not to perform properly. This unit is not designed for use in a garage or outdoor
installation. Do not drape the unit with any covering.
Max. 160°
Y mm
X mm
levelling the unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
free space requirements
When installing the unit, ensure that 25 mm of free
space is left at both sides, 50 mm at the rear of
the unit and 25 mm at the top of the unit. The door
can be opened to the right or the left, depending on
which best suits the location.
Please ensure there is more than twice the width
and depth distance space of the unit to fully open
the door to a maximum angle of 160°.
installing the door handle
Remove the screw hole plugs. Place the door handle in place and screw tightly. Cover the screw
holes with the door handle screw caps.
9
installation
DFC60W_X16_IB_2L_160407_grace.indb 9 7/4/16 6:19 pm

GB
• Ensure the unit is unplugged and empty.
• To take the door off it is necessary to tilt the unit backwards. You should rest the unit on
something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe that
you are qualified to do so.
reversing the door swing
tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
1. Remove all fridge door shelves from the
upper door. Remove the upper cover,
upper corner cover and upper door corner
block.
2. Remove the upper hinge cover, screws
and upper hinge. Lift the upper door and
place it on a padded surface to prevent
from being scratched.
3. Remove the stopper from the bottom of
the upper door and move it to the opposite
side. Screw tightly. Remove also the upper
door stop block. For the opposite side, use
another stop block and screw tightly.
Upper corner cover has left and right
side. There is the letter “L” and “R”
at the back to identify which side it
belongs to. The upper corner cover
packed as an accessory is for the right
side.
Upper door stop block has left and
right side. The upper door stop block
packed as an accessory is for the left
side.
Upper hinge cover has left and right
side. The upper hinge cover packed as
an accessory is for the left side.
10
installation
DFC60W_X16_IB_2L_160407_grace.indb 10 7/4/16 6:19 pm

GB
4. Remove the middle hinge. Lift the lower
door and place it on a padded surface to
prevent from being scratched.
5. Remove the stopper and lower door stop
block from the bottom of the lower door
and move them to the opposite side. Screw
tightly.
6. Lay down the unit. Remove both levelling
feet, levelling feet fix board and bottom
hinge.
7. Swap the position of the levelling feet fix
board with the bottom hinge. On the bottom
hinge, move the position of the bottom
hinge pin to the other hole. Tighten the pin
securely.
11
installation
DFC60W_X16_IB_2L_160407_grace.indb 11 7/4/16 6:19 pm

GB
• Ensure the lower door is aligned
horizontally and vertically, so that the
seals are closed on all sides before
finally tightening the pin.
• Ensure the upper door is aligned
horizontally and vertically, so that the
seals are closed on all sides before
finally tightening the pin.
8. Screw the levelling feet fix board, bottom
hinge and levelling feet tightly on their new
position.
9. Stand the unit. Remove the middle hinge
hole covers and swap their position with the
middle hinge. Reverse the middle hinge.
10. Place the bottom hole of the lower door onto
the bottom hinge pin. Insert the middle hinge
pin into the upper hole of the lower door.
Tighten the pin securely. Screw the middle
hinge tightly. Cover the remaining holes with
the hole covers.
11. Move the magnet cord to the opposite side.
Reverse the upper hinge. Place the bottom
hole of the upper door onto the middle
hinge pin. Insert the upper hinge pin into
the upper hole of the upper door. Tighten
the pin securely. Screw the upper hinge
tightly. Cover the upper hinge with the
upper hinge cover.
12
installation
DFC60W_X16_IB_2L_160407_grace.indb 12 7/4/16 6:19 pm

GB
cleaning before use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water
using a sponge or cloth. Wipe completely dry before replacing the drawers. Clean the exterior of
the unit with a damp cloth.
If you require more information refer to the Cleaning section.
before using your unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time to
settle.
12. Attach the upper corner cover. Put back the
upper cover. Attach the upper door corner
block.
13. Move the door handles to the other side of
the doors accordingly.
13
installation
DFC60W_X16_IB_2L_160407_grace.indb 13 7/4/16 6:19 pm

14
GB
product overview
main unit
Egg Tray Ice Tray Wine Rack Bottle Stopper
Control Panel
Fridge Glass
Shelf
Salad Bin
Salad Bin
Cover Shelf
Fridge Door
Shelf
Freezer Drawer
LED Light
Freezer
Glass Shelf
DFC60W_X16_IB_2L_160407_grace.indb 14 7/4/16 6:19 pm

15
GB
operation
switching on your unit
1. Connect the mains cable to the mains socket. The internal temperature of your unit is controlled
by an electronic control panel.
2. Press repeatedly to set temperature for the fridge compartment (2 to 8°C) and press
repeatedly to set temperature for the freezer compartment (-16 to -24°C).
3. The unit may not operate at the correct temperature if it is in a particularly hot or a particularly
cold room, or if you open the doors often.
4. To ensure that the unit is cool enough to sufficiently chill your food, wait 24 hours before filling it
with food.
5. If you are concerned that your unit is not being kept cold enough and wish to check the
temperature, you will need a special fridge/freezer thermometer. These are available from
most supermarkets and hardware shops. Place the thermometer in either the fridge or freezer
compartment and leave overnight. The correct temperature for the fridge compartment should
be at the recommended 0-8°C. The correct temperature for the freezer compartment should be
-18°C or lower.
super freeze mode
• Press and hold for 3 seconds to activate the super freeze mode. will light up.
Temperature in the freezer compartment will be quickly lowered.
• Toswitcho,pressandhold for 3 seconds, and the freezer temperature will resume to the
previous setting. Otherwise, super freeze mode will also automatically deactivate after 26 hours,
and the freezer temperature will resume to the previous setting. light will extinguish.
holiday mode
• If you will be away for a period of time, you can set the fridge to holiday mode. Press and hold
for 3 seconds to activate the holiday mode. will light up. Temperature in the fridge will
automatically set to 15°C. Do not store any food in the fridge during holiday mode.
• To switch off, press and hold for 3 seconds, and the fridge temperature will resume to the
previous setting. light will extinguish.
DFC60W_X16_IB_2L_160407_grace.indb 15 7/4/16 6:19 pm

16
GB
noises inside the unit!
You may notice that your unit makes some unusual noises. Most of these are perfectly normal, but
you should be aware of them!
These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has
become more pronounced since the introduction of CFC free gases. This is not a fault and will
not affect the performance of your unit. This is the compressor motor working, as it pumps the
refrigerant around the system.
tips for keeping food in the unit
• Cooked meats/fishes should always be stored on a shelf above raw meats/fishes to avoid
bacterial transfer. Keep raw meats/fishes in a container which is large enough to collect juices
and cover it properly. Place the container on the lowest shelf.
• Leave space around your food, to allow air to circulate inside the compartments. Ensure all parts
of the unit are kept cool.
• To prevent transfer of flavours and drying out, pack or cover the food separately. Fruit and
vegetables do not need to be wrapped.
• Always let pre-cooked food cool down before you put in the unit. This will help to maintain the
internal temperature of the unit.
• To prevent cold air escaping from the unit, try to limit the number of times you open the doors.
We recommend that you only open the doors when you need to put food in or take food out.
• Hang the bottle stopper on any door shelf to hold bottles firmly in place.
preparations for freezing
• Use quality food and handle it as little as possible. Freeze food in small quantities as it freezes
faster, takes less time to defrost and enables you to control the quantity you need better.
• Leave cooked food to cool completely. Chill food before freezing if possible.
• Consider how you will want to cook the food before freezing it.
• Don’t freeze food in metal containers if you may want to microwave it straight from the freezer.
• Use special freezer bags, freezer film, polythene bags, plastic containers, and aluminium foil
(heavy duty grade only). If in doubt, double wrap your food. Don’t use aluminium foil for acidic
foods, e.g. citrus fruits. Don’t use thin cling film, glass, or used food containers without cleaning.
• Exclude as much air from the container as possible. You could buy a special vacuum pump
which sucks excessive air out of the packaging.
• Leave a small amount of air space when freezing liquids to allow expansion.
• You can use the space in the freezer most efficiently if you freeze liquids
(or solids with liquids, e.g. stew) in square blocks. This is known as
“Preforming”. Pour the liquid into a polythene bag which is inside a square
sided container. Freeze it, and then remove it from the container and seal
the bag.
• Label your frozen foods as they will look the same when in frozen state.
Use special freezer tapes, labels and pens with different colours. This
allows you to easily organise and to effectively use the freezer. Write the
contents and date; otherwise the frozen food might exceed the storage time
and this could cause food poisoning. Please refer to your food packaging
for the recommended storage time.
• You may also add the weight and cooking notes, e.g. “defrost first”, “cook from frozen” and keep
a separate log of what is in each drawer. This will save opening the door and searching around
unnecessarily.
DFC60W_X16_IB_2L_160407_grace.indb 16 7/4/16 6:19 pm

17
GB
defrosting frozen food
1. Take the frozen food out from the freezer compartment and uncover the frozen food. Let it
defrost at room temperature. Don’t forget that defrosting in a warm area encourages the growth
of bacteria and low temperature cooking may not destroy dangerous bacteria.
2. Drain off and throw away any liquid lost during defrosting.
3. Always make sure there are no ice-crystals in the food before cooking, particularly with meat.
These crystals indicate that the food has not fully defrosted.
4. Cook food as soon as possible after defrosting.
5. Many microwaves and ovens have a defrost setting. To avoid bacterial build up, only use these if
you intend to cook the food immediately afterwards.
Never re-freeze anything that has been defrosted unless you cook it again, to kill off harmful
bacteria. Never re-freeze defrosted shellfish. Re-seal packs properly after removing items.
This prevents drying or freezer-burn and a build up of frost on any remaining food.
cleaning the interior and the exterior of the unit
• Remove all the shelves and drawers.
• Wipe the inside of the unit with a weak solution of bicarbonate soda and then rinse with warm
water using a sponge or cloth. Wipe completely dry before replacing the shelves, drawers and
salad bin.
• Use a damp cloth to clean the exterior, and then wipe with a standard furniture polish. Make
sure that the doors are closed to avoid the polish getting on the magnetic door seals or inside
the unit.
• The grille of the condenser at the back of the unit and the adjacent components can be
vacuumed using a soft brush attachment.
DFC60W_X16_IB_2L_160407_grace.indb 17 7/4/16 6:19 pm

18
GB
maintenance
changing the internal LED light
The internal light is an LED panel that cannot be changed by the user. Please contact a qualified
service agent.
care when handling / moving your unit
Hold the unit around its sides or base when moving it. Under no circumstances should it be lifted by
holding the edges of the top surface.
servicing
The unit should be serviced by an authorised engineer and only genuine spare parts should be
used. Under no circumstances should you attempt to repair the unit yourself. Repairs carried out by
inexperienced persons may cause injury or serious malfunction. Contact a qualified technician.
switching off for long periods of time
When the unit is not in use for a long period of time, disconnect it from the mains supply, empty all
food and clean the appliance, leaving the door ajar to prevent unpleasant smells.
condensation
Condensation may appear on the outside of the unit. This may be due to a change in room
temperature. Wipe off any moisture residue. If the problem continues, please contact a qualified
technician for assistance.
disposal
Old units still have some residual value. An environmentally friendly method of disposal will ensure
that valuable raw materials can be recovered and used again. The refrigerant used in your unit and
insulation materials require special disposal procedures. Ensure that none of the pipes on the back
of the unit are damaged prior to disposal.
Up to date information concerning options of disposing of your old unit and packaging from the new
one can be obtained from your local council office.
When disposing of an old unit break off any old locks or latches and remove the door as a
safeguard.
DFC60W_X16_IB_2L_160407_grace.indb 18 7/4/16 6:19 pm

19
GB
specifications
Model DFC60W16 / DFC60X16
Appliance Category Category 7 (Refrigerator – Freezer)
Overall Dimension (H x W x D) 1850 x 595 x 725 mm
Fresh Food Storage Volume 233 L
Frozen Food Storage Volume 93 L
Defrosting Type Frost free
Climate Class SN, N, ST, T
This appliance is intended to be used at an ambient temperature between 10°C and 43°C.
Storage Temperature Freezer: ≤–18°C
Fridge: 0-8°C, average ≤4°C
Energy Consumption 0.856 kWh / 24 hours
Energy consumption 312 kWh per year, based on standard test results for 24 hours.
Actual energy consumption will depend on how the appliance is used and where it is located.
Airborne Acoustical Noise 42 dB
Energy Grading A+
Temperature Rise 16 hours
Freezing Capacity 12 kg / 24 hours
Rated Voltage 220-240 V~
Rated Current 0.8 A
Features and specifications are subject to change without prior notice.
DFC60W_X16_IB_2L_160407_grace.indb 19 7/4/16 6:19 pm

20
GR
αφαιρεση συσκευασιας
Αφαιρέστε όλα τα αντικείμενα από τη συσκευασία. Κρατήστε τη συσκευασία. Σε περίπτωση
απόρριψης, ακολουθήστε τους κανονισμούς της τοπικής κοινότητας.
Περιλαμβάνονται τα παρακάτω εξαρτήματα:
Σας ευχαριστούμε για την αγορά της νέας συσκευής ψυγείου-
καταψύκτη της.
Αυτές οι οδηγίες λειτουργίας θα σας βοηθήσουν να το χρησιμοποιήσετε κανονικά
και με ασφάλεια.
Συνιστάται να αφιερώσετε λίγο χρόνο στην ανάγνωση αυτού του εγχειριδίου
εγκατάστασης/λειτουργίας προκειμένου να κατανοήσετε πλήρως όλα τα
λειτουργικά χαρακτηριστικά που παρέχονται.
Διαβάστε όλες τις οδηγίες προσεκτικά πριν τη χρήση της μονάδας και κρατήστε
τις για λόγους μελλοντικής αναφοράς.
Η Κύρια
μονάδα
Κάλυμμα-ράφι κάδου
λαχανικών
Κάλυμμα επάνω
αριστερού
μεντεσέ
Ράφι για φιάλες
κρασιού
Γυάλινο ράφι ψυγείου
x 3
Κάδος λαχανικών Μικρό συρτάρι
κατάψυξης x 2
Μεγάλο συρτάρι
κατάψυξης
Επάνω ράφι πόρτας
ψυγείου x 2
Δίσκος αυγών
Σύστημα
συγκράτησης
φιαλών
Εγχειρίδιο χρήσης Δίσκος για
παγάκια
Κάτω ράφι πόρτας
ψυγείου
Instruction
Manual
Χειρολαβή πόρτας
x 2
Βίδα χειρολαβής
πόρτας x 4
Κάλυμμα βίδας
χειρολαβής x 4
Κάλυμμα επάνω
δεξιά γωνίας
Συγκρατητήρας
επάνω πόρτας
(αριστερή
πλευρά)
Βίδα
συγκρατητήρα
Γυάλινο ράφι
κατάψυξης x 2
DFC60W_X16_IB_2L_160407_grace.indb 20 7/4/16 6:19 pm
