DeLonghi DSBSDX16 Service manual

DSBSDX16
installation / instructions manual
εγχειρίδιο εγκατάστασης / οδηγιών
Ψυγείο-καταψύκτης
αμερικανικού τύπου με
διανομέα νερού
American Style
Fridge Freezer with
Water Dispenser GB
GR
DSBSDX16_IB_2L_RC_171011_grace.indb 1 11/10/17 2:19 pm

DSBSDX16_IB_2L_RC_171011_grace.indb 2 11/10/17 2:19 pm

GB
Contents
safety warnings .................................................................................................................. 5
unpacking............................................................................................................................ 9
installation......................................................................................................................... 10
location .......................................................................................................................... 10
levelling the unit............................................................................................................. 10
free space requirements................................................................................................ 10
installling the water tank .................................................................................................11
cleaning before use ........................................................................................................11
before using your unit.....................................................................................................11
product overview.............................................................................................................. 12
main unit........................................................................................................................ 12
operation ........................................................................................................................... 13
temperature setting ....................................................................................................... 13
super cool mode............................................................................................................ 13
super freeze mode ........................................................................................................ 13
holiday mode ................................................................................................................. 13
eco mode....................................................................................................................... 14
smart mode ................................................................................................................... 14
door alarm ..................................................................................................................... 14
child lock........................................................................................................................ 14
twistable ice tray............................................................................................................ 14
lling the water tank....................................................................................................... 15
receiving water from the water dispenser...................................................................... 15
noises inside the unit!.................................................................................................... 16
tips for keeping food in the unit ..................................................................................... 16
preparations for freezing ............................................................................................... 16
defrosting frozen food.................................................................................................... 17
cleaning the interior and the exterior of the unit........................................................... 17
cleaning the water tank and water dispenser ................................................................ 17
maintenance...................................................................................................................... 18
changing the internal LED light ..................................................................................... 18
care when handling / moving your unit.......................................................................... 18
servicing ........................................................................................................................ 18
switching off for long periods of time ............................................................................. 18
condensation ................................................................................................................. 18
disposal............................................................................................................................. 18
specications.................................................................................................................... 19
product che..................................................................................................................... 19
DSBSDX16_IB_2L_RC_171011_grace.indb 3 11/10/17 2:19 pm

Περιεχομενα
προειδοποιήσεις ασφαλείας............................................................................................. 7
αφαίρεση συσκευασίας ................................................................................................... 20
εγκατάσταση ..................................................................................................................... 21
τοποθεσία ...................................................................................................................... 21
ισοστάθμιση της μονάδας.............................................................................................. 21
απαιτήσεις ύπαρξης ελεύθερου χώρου ......................................................................... 21
εγκατάσταση της δεξαμενής νερού................................................................................ 22
αλλαγή πριν από τη χρήση............................................................................................ 22
προτού χρησιμοποιήσετε τη μονάδα σας ...................................................................... 22
επισκόπηση προϊόντος ................................................................................................... 23
κύρια μονάδα................................................................................................................. 23
λειτουργία.......................................................................................................................... 24
ρύθμιση θερμοκρασίας.................................................................................................. 24
λειτουργίας υψηλής ψύξης ............................................................................................ 24
λειτουργίας υπερψύξης ................................................................................................. 24
λειτουργία διακοπών...................................................................................................... 24
οικολογική λειτουργία..................................................................................................... 25
έξυπνη λειτουργία.......................................................................................................... 25
ηχητική ειδοποίηση πόρτας .......................................................................................... 25
κλείδωμα για παιδιά....................................................................................................... 25
περιστρεφόμενος δίσκος για παγάκια ........................................................................... 26
πλήρωση της δεξαμενής νερού ..................................................................................... 26
τροφοδότηση με νερό από το διανομέα νερού .............................................................. 26
θόρυβοι στο εσωτερικό της μονάδας!............................................................................ 27
συμβουλές για τη συντήρηση τροφίμων στη μονάδα .................................................... 27
προετοιμασίες για κατάψυξη ......................................................................................... 27
απόψυξη κατεψυγμένων τροφίμων ............................................................................... 28
καθαρισμός του εσωτερικού και του εξωτερικού της μονάδας .................................... 29
καθαρισμός της δεξαμενής και του διανομέα νερού ...................................................... 29
συντήρηση ........................................................................................................................ 30
αντικατάσταση της εσωτερικής λυχνίας LED ................................................................. 30
φροντίδα κατά το χειρισμό / μετακίνηση της μονάδας σας ............................................ 30
εργασίες σέρβις ............................................................................................................. 30
απενεργοποίηση για μακρά χρονικά διαστήματα .......................................................... 30
συμπύκνωση ................................................................................................................. 30
απόρριψη .......................................................................................................................... 30
προδιαγραφές .................................................................................................................. 31
δελτίο τεχνικών δεδομένων προϊόντος ......................................................................... 31
GR
DSBSDX16_IB_2L_RC_171011_grace.indb 4 11/10/17 2:19 pm

5
GB
safety warnings
For your continued safety and to reduce the risk of injury or electric
shock, please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them
for future reference.
• Retain the manual. If you pass the unit onto a third party, make
sure to include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
– farm houses and by clients in hotels, motels and other residential
type environment;
– bed and breakfast type environment;
– staff kitchen areas in shops, offices and other working
environment;
– catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection
from the mains supply.
• If the mains cable is damaged, it must be replaced by the
manufacturer, its service agent or a qualified technician in order to
avoid a hazard.
• Choose a location for your unit away from heat sources such as
radiators or fires as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children should be supervised to ensure that they do not play with
the unit.
• If your unit is fitted with a lock to prevent children being trapped
inside, keep the key out of reach and not in the vicinity of the unit.
DSBSDX16_IB_2L_RC_171011_grace.indb 5 11/10/17 2:19 pm

6
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN
AUTHORISED SERVICE PERSONNEL TO CARRY OUT
SERVICING OF REPAIRS WHICH INVOLVE THE REMOVAL
OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT
ATTEMPT REPAIRS YOURSELF.
WARNING
• Keep ventilation openings in the unit enclosure or in the built-
in structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a
very environmental-friendly gas but is also combustible. Take
care when transporting or moving the unit to ensure that the
refrigeration circuit is not damaged. In the event of damage
avoid naked flames or ignition sources and ventilate the room
in which the unit is placed for a few minutes.)
• When positioning the appliance, ensure the supply cord is not
trapped or damaged.
• Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• Do not store bottles or glass containers in the freezer
compartment. Contents can expand when frozen (fizzy
drinks) which may break the bottle and damage your freezer
compartment. (If applicable)
DSBSDX16_IB_2L_RC_171011_grace.indb 6 11/10/17 2:19 pm

7
GR
προειδοποιησεις ασφαλειας
Για τη συνεχή ασφάλειά σας και τη μείωση του κινδύνου πρόκλησης
τραυματισμού ή ηλεκτροπληξίας, ακολουθήστε όλες τις προφυλάξεις
ασφαλείας που αναφέρονται παρακάτω.
• Διαβάστε όλες τις οδηγίες προσεκτικά πριν τη χρήση της μονάδας
και κρατήστε τις για λόγους μελλοντικής αναφοράς.
• Κρατήστε το εγχειρίδιο. Εάν μεταβιβάσετε τη μονάδα σε τρίτους,
βεβαιωθείτε ότι το εγχειρίδιο συμπεριλαμβάνεται.
• Αυτή η συσκευή προορίζεται για εσωτερική χρήση σε οικιακό
περιβάλλον και παρόμοιες χρήσεις όπως:
– σε φάρμες και από πελάτες σε ξενοδοχεία, πανδοχεία και άλλα
περιβάλλοντα οικιστικού τύπου,
– σε περιβάλλοντα τύπου bed & breakfast (με πρωινό),
– σε καταστήματα, γραφεία ή άλλα περιβάλλοντα εργασίας με
χώρους με εξοπλισμό κουζίνας,
– για χρήσεις σε υπηρεσίες ομαδικής εστίασης και παρόμοιες
υπηρεσίες πλην της λιανικής.
• Βεβαιωθείτε ότι το βύσμα είναι εύκολα προσβάσιμο για
αποσύνδεση από την τροφοδοσία κύριου δικτύου.
• Εάν το καλώδιο τροφοδοσίας από το κύριο δίκτυο καταστραφεί,
πρέπει να αντικατασταθεί από τον κατασκευαστή, τον πράκτορα
σέρβις ή τον εξειδικευμένο τεχνικό για την αποφυγή πρόκλησης
κινδύνων.
• Επιλέξτε για τη μονάδα σας μια θέση μακριά από πηγές
θερμότητας όπως θερμαντικά σώματα ή φλόγες καθώς το ψυκτικό
και η φλυκταινογόνος ουσία είναι εύφλεκτες.
• Η μετακίνηση της μονάδας γίνεται από τουλάχιστον 2 άτομα.
• Αυτή η συσκευή μπορεί να χρησιμοποιηθεί από παιδιά ηλικίας
από 8 ετών και άνω και από άτομα με μειωμένες σωματικές,
αισθητήριες ή διανοητικές ικανότητες ή έλλειψη εμπειρίας και
γνώσης, εφόσον επιβλέπονται ή τους έχουν δοθεί οδηγίες σχετικά
με τη χρήση της συσκευής με ασφαλή τρόπο και κατανοούν τις
κινδύνους που εμπλέκονται. Τα παιδιά δεν πρέπει να παίζουν με
τη συσκευή. Ο καθαρισμός και η συντήρηση από το χρήστη δεν θα
πρέπει να γίνεται από παιδιά χωρίς επιτήρηση.
• Τα παιδιά πρέπει να επιβλέπονται για να διασφαλιστεί ότι δεν
παίζουν με τη μονάδα.
• Εάν η μονάδα σας διαθέτει κλειδαριά για να αποφευχθεί το
DSBSDX16_IB_2L_RC_171011_grace.indb 7 11/10/17 2:19 pm

8
ΠΡΟΕΙΔΟΠΟΙΗΣΗ
• Διατηρήστε τις σχισμές εξαερισμού στο περίβλημα της
μονάδας ή στην ενσωματωμένη μονάδα απαλλαγμένες από
εμπόδια.
• Μη χρησιμοποιείτε μηχανικές συσκευές ή άλλα μέσα για
να επισπεύσετε την διαδικασία απόψυξης, εκτός από τις
προτεινόμενες από τον κατασκευαστή.
• Μη χρησιμοποιείτε ηλεκτρικές συσκευές στο εσωτερικό των
θαλάμων φύλαξης τροφίμων της μονάδας, εκτός αν είναι του
προτεινόμενου από τον κατασκευαστή τύπου.
• Μην προκαλείτε βλάβη στο κύκλωμα ψυκτικού (Το ψυκτικό
είναι ένα πολύ φιλικό προς το περιβάλλον αέριο, που όμως
είναι εύφλεκτο. Να είστε προσεκτικοί κατά τη μεταφορά
ή μετακίνηση της συσκευής για να διασφαλιστεί ότι στο
κύκλωμα ψυκτικού δεν έχει προκληθεί βλάβη. Σε περίπτωση
βλάβης αποφεύγετε τις γυμνές φλόγες ή πηγές ανάφλεξης και
εξαερίστε το χώρο στον οποίο έχει τοποθετηθεί η μονάδα για
λίγα λεπτά.)
• Κατά την τοποθέτηση της συσκευής, βεβαιωθείτε ότι το
καλώδιο τροφοδοσίας δεν έχει παγιδευτεί ή υποστεί ζημιά.
• Μην τοποθετείτε πολλά φορητά πολύπριζα ή φορητές
συσκευές τροφοδοσίας στο πίσω μέρος της συσκευής.
ΠΡΟΕΙΔΟΠΟΙΗΣΗ
ΕΙΝΑΙ ΕΠΙΚΙΝΔΥΝΟ ΓΙΑ ΟΠΟΙΟΝΔΗΠΟΤΕ ΕΚΤΟΣ ΑΠΟ ΤΟ
ΕΞΕΙΔΙΚΕΥΜΕΝΟ ΠΡΟΣΩΠΙΚΟ ΣΕΡΒΙΣ ΝΑ
ΠΡΑΓΜΑΤΟΠΟΙΕΙ ΕΡΓΑΣΙΕΣ ΣΕΡΒΙΣ Ή ΕΠΙΣΚΕΥΕΣ ΠΟΥ
ΠΕΡΙΛΑΜΒΑΝΟΥΝ ΤΗΝ ΑΦΑΙΡΕΣΗ ΤΩΝ ΚΑΛΥΜΜΑΤΩΝ.
ΠΡΟΣ ΑΠΟΦΥΓΗ ΤΟΥ ΚΙΝΔΥΝΟΥ ΠΡΟΚΛΗΣΗΣ
ΗΛΕΚΤΡΟΠΛΗΞΙΑΣ ΜΗΝ ΕΠΙΧΕΙΡΕΙΤΕ ΝΑ ΚΑΝΕΤΕ
ΕΠΙΣΚΕΥΕΣ ΜΟΝΟΙ ΣΑΣ.
ενδεχόμενο να παγιδευτούν παιδιά στο εσωτερικό τους, φυλάξτε το
κλειδί σε περιβάλλον που δεν έχουν πρόσβαση και όχι κοντά στη
μονάδα.
• Μην αποθηκεύετε εκρηκτικές ουσίες όπως δοχεία αερολυμάτων με
εύφλεκτο προωθητικό μέσο σε αυτή τη συσκευή.
• Μην αποθηκεύετε φιάλες ή γυάλινους περιέκτες στο θάλαμο
κατάψυξης. Τα περιεχόμενα μπορούν να διασταλούν όταν
καταψύχονται (αναψυκτικά), προκαλώντας θραύση της φιάλης και
βλάβη στο θάλαμο κατάψυξης. (εάν διατίθεται)
DSBSDX16_IB_2L_RC_171011_grace.indb 8 11/10/17 2:19 pm

9
GB
unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Fridge Freezer.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this installation/instruction
manual in order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this installation/
instruction manual for future reference.
WaterDispenser
Freezer Glass Shelf x 3
Fridge Glass Shelf x 3
Twistable Ice Tray with
Ice Box
Main Unit
Freezer Door Shelf x 5
Fridge Door Shelf x 4
Egg Tray
Freezer Drawer x 2
Salad Bin x 2
Wine Rack
Bottle Stopper
Instruction Manual
Instruction
Manual
Salad Bin Cover Shelf x 1
Water Tank
Freezer Drawer Cover
Shelf x 1 Fresh Box Bottom Cover
DSBSDX16_IB_2L_RC_171011_grace.indb 9 11/10/17 2:19 pm

GB
location
When selecting a position for your unit you should make sure the floor is flat and firm, and the
room is well ventilated with an average room temperature of between 10°C and 38°C. Avoid
locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight
as it may increase the electrical consumption. Extreme cold ambient temperatures may also
cause the unit not to perform properly. This unit is not designed for use in a garage or outdoor
installation. Do not drape the unit with any covering.
Y mmY mm
X mmX mm
levelling the unit
1. Adjust the two levelling feet at the front of the unit. If the unit
is not level, the doors and magnetic seal alignments will not
be covered properly.
2. Cover the bottom part by screwing the bottom cover on it
with a hexangular screwdriver until it is secured in place.
free space requirements
When installing the unit, ensure that 25 mm of free
space is left at both sides, 50 mm at the rear of
the unit and 25 mm at the top of the unit. The door
can be opened to the right or the left, depending on
which best suits the location.
Please ensure there is more than twice the width
and depth distance space of the unit to fully open
the door to a maximum angle.
10
installation
DSBSDX16_IB_2L_RC_171011_grace.indb 10 11/10/17 2:19 pm

GB
installing the water tank
• Insert the valve of the water tank into the hole
of the water dispenser and push down the water
tank to attach securely with the water dispenser.
• To remove the water tank, hold firmly on both
sides and bottom of the water tank then push
up.
Be careful not to press on the valve.
Valve
cleaning before use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water
using a sponge or cloth. Wipe completely dry before replacing the drawers. Clean the exterior of
the unit with a damp cloth.
If you require more information refer to the Cleaning section.
before using your unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time to
settle.
11
installation
DSBSDX16_IB_2L_RC_171011_grace.indb 11 11/10/17 2:19 pm

12
GB
product overview
main unit
Fridge Door
Shelf
Water Tank
Twistable Ice
Tray with Ice
Box
Wine Rack
Fridge Glass
Shelf
Freezer Door
Shelf Freezer
Glass Shelf
Salad BinFreezer
Drawer
Egg Tray Bottle Stopper Water Dispenser
(on the door
front)
LED Light
Water Dispenser
(inside the fridge
door)
Salad Bin
Cover Shelf
Freezer Drawer
Cover Shelf
Fresh Box
DSBSDX16_IB_2L_RC_171011_grace.indb 12 11/10/17 2:19 pm

13
GB
operation
Connect the mains cable to the mains socket. The internal temperature of your unit is controlled by
an electronic control panel on the door. Before changing any setting, ensure the lock is disabled.
temperature setting
• Fridge temperature setting
1. Temperature range: 2°C to 8°C.
2. Press the Room button to select fridge .
3. Press the Temp. + / Temp. - buttons repeatedly to set the temperature.
• Freezer temperature setting
1. Temperature range: -15°C to -25°C.
2. Press the Room button to select freezer .
3. Press the Temp. + / Temp. - buttons repeatedly to set the temperature.
super cool mode
• Press the Mode button to select the super cool mode .
• The light will be illuminated. Temperature in the fridge is quickly lowered and food in the fridge
can be kept fresh for a longer period.
• Toswitcho,pressthe Room button to select fridge , and the fridge temperature will resume to
the previous setting. Otherwise, super cool mode will also automatically deactivate after 6 hours,
and the fridge temperature will set to 2°C. The light will extinguish.
super freeze mode
• Press the Mode button to select the super freeze mode .
• The light will be illuminated. Temperature in the freezer will be quickly lowered.
• Toswitchoff,pressthe Room button to select freezer , and the freezer temperature will resume
to the previous setting. Otherwise, super freeze mode will also automatically deactivate after 26
hours, and the freezer temperature will set to -24°C. The light will extinguish.
holiday mode
• If you will be away for a period of time, you can set the fridge to holiday mode. Press the Mode
button to select the holiday mode . The light will be illuminated. Temperature in the fridge
will automatically set to 15°C. Do not store any food in the fridge during holiday mode. The
freezer remains on.
• To switch off, press theRoom button to select fridge , and the fridge temperature will resume
to the previous setting. The light will extinguish.
DSBSDX16_IB_2L_RC_171011_grace.indb 13 11/10/17 2:19 pm

14
GB
eco mode
• If you will be away for a period of time, you can set the freezer to eco mode (power-saving
mode). Press the Mode button to select the eco mode . The light will be illuminated.
Temperature in the freezer will automatically set to -15°C to minimise energy consumption.
• To switch off, press the Room button to select freezer , and the freezer temperature will
resume to the previous setting. The light will extinguish.
smart mode
• Press the Mode button to select the smart mode . The temperature of the unit will self-adjust
automatically.
• To switch off, press the Room button to select freezer or fridge .
door alarm
When the fridge or freezer door is left opened for over 1.5 minutes, the alarm indicator will
illuminate and an alarm will sound. The alarm will sound 3 times every 30 seconds and will
automatically stop sounding after sounding 10 times if the alarm is not deactivated manually.
Press the Mode button to deactivate the alarm (until disappears).
child lock
When child lock is activated, pressing all buttons will not work except pressing .
• To activate child lock, press and hold for 5 seconds. The child lock icon will illuminate.
• To deactivate child lock, press and hold for 5 seconds. The child lock icon will extinguish.
twistable ice tray
When ice cubes are formed in the ice tray, twist the knobs on the ice tray clockwise to release the
ice cubes into the ice box. Pull out the ice box to collect the ice cubes. You can then freeze a new
set of ice cubes by filling the empty ice tray with potable water.
DSBSDX16_IB_2L_RC_171011_grace.indb 14 11/10/17 2:19 pm

15
GB
filling the water tank
Turn the small cap anticlockwise then remove it from the water tank.
Fill drinking water into the water tank.
• Do not fill above the level, otherwise, it may overflow.
• Before filling with water, ensure that the water tank is
steady and in a correct position.
• Apart from drinking water, other beverages (such as milk,
juice, carbonated beverage, etc) are not suggested to be
used, especially beverages that include grain must not
be used (may result in blockage and damage).
• Hot water must not be filled into the water tank directly.
• Do not touch other parts of the unit when filling water, it
may lead to leakage.
receiving water from the water dispenser
• You should use the type of container that can fit
under the water dispenser. Place the container
properly underneath and push on the lever for water
to flow.
• Before you dispense the water, make sure the lock
device is at “Unlock” position.
• Ensure to slide to “Lock” position after each
use to prevent children from playing with the
lever.
• When at “Lock” position, do not push on
the lever with force. It will damage the
mechanism.
DSBSDX16_IB_2L_RC_171011_grace.indb 15 11/10/17 2:19 pm

16
GB
noises inside the unit!
You may notice that your unit makes some unusual noises. Most of these are perfectly normal, but
you should be aware of them!
These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has
become more pronounced since the introduction of CFC free gases. This is not a fault and will
not affect the performance of your unit. This is the compressor motor working, as it pumps the
refrigerant around the system.
tips for keeping food in the unit
• Cooked meats/fishes should always be stored on a shelf above raw meats/fishes to avoid
bacterial transfer. Keep raw meats/fishes in a container which is large enough to collect juices
and cover it properly. Place the container on the lowest shelf.
• Leave space around your food, to allow air to circulate inside the compartments. Ensure all parts
of the unit are kept cool.
• To prevent transfer of flavours and drying out, pack or cover the food separately. Fruit and
vegetables do not need to be wrapped.
• Always let pre-cooked food cool down before you put in the unit. This will help to maintain the
internal temperature of the unit.
• To prevent cold air escaping from the unit, try to limit the number of times you open the doors.
We recommend that you only open the doors when you need to put food in or take food out.
• Hang the bottle stopper on any door shelf to hold bottles firmly in place.
preparations for freezing
• Use quality food and handle it as little as possible. Freeze food in small quantities as it freezes
faster, takes less time to defrost and enables you to control the quantity you need better.
• Leave cooked food to cool completely. Chill food before freezing if possible.
• Consider how you will want to cook the food before freezing it.
• Don’t freeze food in metal containers if you may want to microwave it straight from the freezer.
• Use special freezer bags, freezer film, polythene bags, plastic containers, and aluminium foil
(heavy duty grade only). If in doubt, double wrap your food. Don’t use aluminium foil for acidic
foods, e.g. citrus fruits. Don’t use thin cling film, glass, or used food containers without cleaning.
• Exclude as much air from the container as possible. You could buy a special vacuum pump
which sucks excessive air out of the packaging.
• Leave a small amount of air space when freezing liquids to allow expansion.
• You can use the space in the freezer most efficiently if you freeze liquids (or
solids with liquids, e.g. stew) in square blocks. This is known as “Preforming”.
Pour the liquid into a polythene bag which is inside a square sided container.
Freeze it, and then remove it from the container and seal the bag.
• Label your frozen foods as they will look the same when in frozen state. Use
special freezer tapes, labels and pens with different colours. This allows you to
easily organise and to effectively use the freezer. Write the contents and date;
otherwise the frozen food might exceed the storage time and this could cause
food poisoning. Please refer to your food packaging for the recommended
storage time.
• You may also add the weight and cooking notes, e.g. “defrost first”, “cook from frozen” and keep
a separate log of what is in each drawer. This will save opening the door and searching around
unnecessarily.
DSBSDX16_IB_2L_RC_171011_grace.indb 16 11/10/17 2:19 pm

17
GB
defrosting frozen food
1. Take the frozen food out from the freezer compartment and uncover the frozen food. Let it
defrost at room temperature. Don’t forget that defrosting in a warm area encourages the growth
of bacteria and low temperature cooking may not destroy dangerous bacteria.
2. Drain off and throw away any liquid lost during defrosting.
3. Always make sure there are no ice-crystals in the food before cooking, particularly with meat.
These crystals indicate that the food has not fully defrosted.
4. Cook food as soon as possible after defrosting.
5. Many microwaves and ovens have a defrost setting. To avoid bacterial build up, only use these if
you intend to cook the food immediately afterwards.
Never re-freeze anything that has been defrosted unless you cook it again, to kill off harmful
bacteria. Never re-freeze defrosted shellfish. Re-seal packs properly after removing items.
This prevents drying or freezer-burn and a build up of frost on any remaining food.
cleaning the interior and the exterior of the unit
• Remove all the shelves and drawers.
• Wipe the inside of the unit with a weak solution of bicarbonate soda and then rinse with warm
water using a sponge or cloth. Wipe completely dry before replacing the shelves, drawers and
salad bin.
• Use a damp cloth to clean the exterior, and then wipe with a standard furniture polish. Make
sure that the doors are closed to avoid the polish getting on the magnetic door seals or inside
the unit.
• The grille of the condenser at the back of the unit and the adjacent components can be
vacuumed using a soft brush attachment.
cleaning the water tank and water dispenser
• Remove the water tank. Wash the tank, tank cover, flap cover and valve lightly under water.
• After cleaning, dry them thoroughly before installing back in the fridge.
• Wipe the receiving base of the water dispenser with dry towel
regularly to avoid overflowing.
Receiving
base
DSBSDX16_IB_2L_RC_171011_grace.indb 17 11/10/17 2:19 pm

18
GB
maintenance
changing the internal LED light
The internal light is an LED panel that cannot be changed by the user. Please contact a qualified
service agent.
care when handling / moving your unit
Hold the unit around its sides or base when moving it. Under no circumstances should it be lifted by
holding the edges of the top surface.
servicing
The unit should be serviced by an authorised engineer and only genuine spare parts should be
used. Under no circumstances should you attempt to repair the unit yourself. Repairs carried out by
inexperienced persons may cause injury or serious malfunction. Contact a qualified technician.
switching off for long periods of time
When the unit is not in use for a long period of time, disconnect it from the mains supply, empty all
food and clean the appliance, leaving the door ajar to prevent unpleasant smells.
condensation
Condensation may appear on the outside of the unit. This may be due to a change in room
temperature. Wipe off any moisture residue. If the problem continues, please contact a qualified
technician for assistance.
disposal
Old units still have some residual value. An environmentally friendly method of disposal will ensure
that valuable raw materials can be recovered and used again. The refrigerant used in your unit and
insulation materials require special disposal procedures. Ensure that none of the pipes on the back
of the unit are damaged prior to disposal.
Up to date information concerning options of disposing of your old unit and packaging from the new
one can be obtained from your local council office.
When disposing of an old unit break off any old locks or latches and remove the door as a
safeguard.
DSBSDX16_IB_2L_RC_171011_grace.indb 18 11/10/17 2:19 pm

19
GB
specifications
Rated Voltage 220-240V~, 50 Hz
Rated Current 1.2 A
Rated Power Defrost: 250 W
Dimension (H x W x D) 1766 x 912 x 726 mm
Features and specifications are subject to change without prior notice.
Brand Delonghi
Model DSBSDX16
Household Appliance Category 7
Energy Efficiency Class A+
Energy consumption 433 kWh per year, based on standard test results for 24 hours. Actual energy
consumption will depend on how the appliance is used and where it is located.
Fridge Storage Volume 364 L
Freezer Storage Volume 192 L
Frost Free for the fridge & freezer compartment.
Temperature Rise Time 10 hours
Freezing Capacity 12 kg / 24 hours
Climate Class
SN, N, ST
This appliance is intended to be used at an ambient
temperature between 10°C and 38°C.
Airborne Acoustical Noise 43 dB(A) re 1 pW
product fiche
DSBSDX16_IB_2L_RC_171011_grace.indb 19 11/10/17 2:19 pm

20
GR
αφαιρεση συσκευασιας
Αφαιρέστε όλα τα αντικείμενα από τη συσκευασία. Κρατήστε τη συσκευασία. Σε περίπτωση
απόρριψης, ακολουθήστε τους κανονισμούς της τοπικής κοινότητας.
Περιλαμβάνονται τα παρακάτω εξαρτήματα:
Σας ευχαριστούμε για την αγορά της νέας συσκευής ψυγείου-
καταψύκτη της.
Αυτές οι οδηγίες λειτουργίας θα σας βοηθήσουν να το χρησιμοποιήσετε κανονικά
και με ασφάλεια.
Συνιστάται να αφιερώσετε λίγο χρόνο στην ανάγνωση αυτού του εγχειριδίου
εγκατάστασης/λειτουργίας προκειμένου να κατανοήσετε πλήρως όλα τα
λειτουργικά χαρακτηριστικά που παρέχονται.
Διαβάστε όλες τις οδηγίες προσεκτικά πριν τη χρήση της μονάδας και κρατήστε
τις για λόγους μελλοντικής αναφοράς.
Η Κύρια
μονάδα
Κάλυμμα-ράφι κάδου
λαχανικών x 1
Ράφι για φιάλες
κρασιού
Γυάλινο ράφι ψυγείου
x 3
Κάδος λαχανικών
x 2
Δίσκος αυγών Σύστημα
συγκράτησης φιαλών
Εγχειρίδιο χρήσης
WaterDispenser
Instruction
Manual
Γυάλινο ράφι
κατάψυξης x 3
Δεξαμενή νερού
Περιστρεφόμενος
δίσκος για παγάκια με
παγοθήκη
Ράφι-καπάκι συρταριού
κατάψυξης x 1 Δοχείο φρέσκων
τροφίμων
Κάτω κάλυμμα
Ράφι πόρτας κατάψυξης
x 5
Συρτάρι κατάψυξης x 2
Ράφι πόρτας ψυγείου x 4
DSBSDX16_IB_2L_RC_171011_grace.indb 20 11/10/17 2:19 pm
