^1 HARDWARE REFERENCE MANUAL
^2 PMAC2 PCI
^3 PMAC 2 PCI Bus Expansion Card
^4 4XX-603486-xHxx
^5 May 26, 2004
Single Source Machine Control Power // Flexibility // Ease of Use
21314 Lassen Street Chatsworth, CA 91311 // Tel. [phone] Fax. [phone] // www.deltatau.com
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Copyright Information
© 2003 Delta Tau Data Systems, Inc. All rights reserved.
This document is furnished for the customers of Delta Tau Data Systems, Inc. Other uses are
unauthorized without written permission of Delta Tau Data Systems, Inc. Information contained
in this manual may be updated from time-to-time due to product improvements, etc., and may not
conform in every respect to former issues.
To report errors or inconsistencies, call or email:
Delta Tau Data Systems, Inc. Technical Support
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: http://www.deltatau.com
Operating Conditions
All Delta Tau Data Systems, Inc. motion controller products, accessories, and amplifiers contain
static sensitive components that can be damaged by incorrect handling. When installing or
handling Delta Tau Data Systems, Inc. products, avoid contact with highly insulated materials.
Only qualified personnel should be allowed to handle this equipment.
In the case of industrial applications, we expect our products to be protected from hazardous or
conductive materials and/or environments that could cause harm to the controller by damaging
components or causing electrical shorts. When our products are used in an industrial
environment, install them into an industrial electrical cabinet or industrial PC to protect them
from excessive or corrosive moisture, abnormal ambient temperatures, and conductive materials.
If Delta Tau Data Systems, Inc. products are exposed to hazardous or conductive materials and/or
environments, we cannot guarantee their operation.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
Table Of Contents i
Table of Contents
INTRODUCTION.......................................................................................................................................................1
Board Configuration..................................................................................................................................................1
Base Version.........................................................................................................................................................1
Option 1: Additional Four Channels Axis Interface Circuitry.............................................................................1
Option 2: Dual-Ported RAM................................................................................................................................1
Option 5xF: CPU Speed Options.........................................................................................................................2
Option 6: Extended Servo Algorithm...................................................................................................................2
Option 7: Plate Mounting....................................................................................................................................2
Option 8: High-Accuracy Clock Crystal..............................................................................................................2
Option 10: Firmware Version Specification........................................................................................................2
Option 12: Analog-to-Digital Converters............................................................................................................2
Option 16: Battery-Backed Parameter Memory..................................................................................................2
HARDWARE SETUP.................................................................................................................................................3
Piggyback CPU Board Jumper Configuration...........................................................................................................3
Watchdog Timer Jumper.......................................................................................................................................3
Dual-ported RAM Source Jumper.........................................................................................................................3
Power-Up State Jumpers ......................................................................................................................................3
Firmware Load Jumper ........................................................................................................................................3
Flash Memory Bank Select Jumpers.....................................................................................................................3
Base Board Jumper Configuration ............................................................................................................................3
Servo and Phase Clock Direction Control............................................................................................................3
CPU Frequency Control Jumpers.........................................................................................................................4
Re-Initialization Jumper .......................................................................................................................................4
Encoder Sample Clock Source Jumpers ...............................................................................................................4
Serial Port Selection Jumper................................................................................................................................4
Output Disable State Jumpers ..............................................................................................................................4
Resistor Pack Configuration......................................................................................................................................5
Termination Resistors...........................................................................................................................................5
Pull-Up/Pull-Down Resistors ...............................................................................................................................5
Connections...............................................................................................................................................................6
Mounting...............................................................................................................................................................6
Power Supply Connection.....................................................................................................................................6
Machine Port Connections ...................................................................................................................................6
Display Port..........................................................................................................................................................6
Multiplexer Port....................................................................................................................................................7
I/O Port.................................................................................................................................................................7
Serial Ports...........................................................................................................................................................7
A/D-Converter Port ..............................................................................................................................................7
Handwheel Port....................................................................................................................................................7
COMMUNICATIONS SETUP ..................................................................................................................................9
FLEX CPU BOARD JUMPER DESCRIPTIONS..................................................................................................11
E1: Watchdog Disable Jumper...............................................................................................................................11
E2: Dual-Ported RAM Port Select .........................................................................................................................11
E4 – E6: Power-Up/Reset Load Source .................................................................................................................11
E7: Firmware Reload Enable..................................................................................................................................11
E10A, B, C: Flash Memory Bank Select................................................................................................................12
PMAC2 PCI BASE BOARD JUMPER DESCRIPTIONS....................................................................................13
E2: CPU Frequency Select......................................................................................................................................13
E3: Normal/Re-Initializing Power-Up/Reset...........................................................................................................13
E4: CPU Frequency Select......................................................................................................................................13
E5 – E6: (Reserved for Future Use) ........................................................................................................................14
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
ii Table of Contents
E13 - E14: Encoder Sample Clock Direction Control............................................................................................14
E17 - E18: Serial Port Type Selection....................................................................................................................14
E111-118: Command Output Disable State ...........................................................................................................15
MATING CONNECTORS.......................................................................................................................................17
CPU Board Connectors...........................................................................................................................................17
J2 (JEXP)/Expansion..........................................................................................................................................17
Baseboard Connectors.............................................................................................................................................17
J1 (JANA)/Analog (Option 12) ...........................................................................................................................17
J2 (JTHW)/Multiplexer Port...............................................................................................................................17
J3 (JIO)/Digital I/O ............................................................................................................................................17
J5 (JRS232)/RS-232 Serial Communications......................................................................................................17
J5A (JRS422)/RS-422 Serial Communications...................................................................................................17
J6 (JDISP)/Display.............................................................................................................................................17
J7 (JHW)/Auxiliary Channel...............................................................................................................................17
J8 (JEQU)/Position Compare.............................................................................................................................18
J9 (JMACH1)/Machine Port 1............................................................................................................................18
J10 (JMACH2)/Machine Port 2..........................................................................................................................18
J11 (JMACH3)/Machine Port 3..........................................................................................................................18
J12 (JMACH4)/Machine Port 4..........................................................................................................................18
PMAC2 PCI BASE BOARD CONNECTOR PINOUTS.......................................................................................19
J1 (JANA) Analog Input Port Connector................................................................................................................19
J2 (JTHW) Multiplexer Port Connector..................................................................................................................20
J3 (JI/O) General Input/Output Connector..............................................................................................................21
J5 (JRS232) Serial Port Connector..........................................................................................................................22
J5A (RS422) Serial Port Connector ........................................................................................................................22
J6 (JDISP) Display Connector ................................................................................................................................23
J7 (JHW) Handwheel Encoder Connector...............................................................................................................23
J8 (JEQU) Position Compare Output Connector.....................................................................................................24
J9 (JMACH1) Connector Description.....................................................................................................................24
J9 JMACH1 Connector.......................................................................................................................................25
J9 JMACH1 Connector.......................................................................................................................................27
J10 (JMACH2) Connector Description...................................................................................................................27
J11 (JMACH3) Connector Description...................................................................................................................30
J11 JMACH3 Connector.....................................................................................................................................31
J12 (JMACH4) Connector Description...................................................................................................................33
J12 JMACH4 Connector.....................................................................................................................................34
J12 JMACH4 Connector.....................................................................................................................................35
J12 JMACH4 Connector.....................................................................................................................................36
TB1 (2/4-Pin Terminal Block) ................................................................................................................................36
TB2 (3-Pin Terminal Block) ...................................................................................................................................37
BASE BOARD JUMPERS LAYOUT......................................................................................................................39
SCHEMATICS..........................................................................................................................................................41
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
Introduction 1
INTRODUCTION
The PMAC2 PCI (part number 400-603367-10x) is a member of the PMAC family of boards optimized
for interface to sinewave or direct-PWM servo drives and to pulse-and-direction stepper drives. Its
software is capable of eight axes of control. It can have up to eight channels of on-board axis interface
circuitry. It can also support up to eight channels of off-board axis interface circuitry through its
expansion port, connected to Acc-24P or Acc-24P2 ISA-format boards. Acc-24 boards in PCI format are
not yet available.
The PMAC2 PCI is a full-sized PCI-bus expansion card, with a small piggyback board containing the
CPU board. This piggyback board occupies part of the next slot, but ½-sized boards are permitted in this
next slot. While the PMAC2 PCI is capable of PCI bus communications, with or without the optional on-
board dual-ported RAM, it does not need to be inserted into a PCI expansion slot. Communications can
be done through the standard RS-232/RS-422 serial port. Standalone operation is possible.
Board Configuration
Base Version
The base version of the PMAC2 PCI provides a 1-1/2-slot board with:
• 40MHz DSP563xx CPU (Option 5AF, 80MHz 56002 equivalent)
• 128k x 24 0-wait-state flash-backed SRAM
• 512k x 8 flash memory for user backup & firmware
• Latest released firmware version
• RS-232/RS422 serial interface, PCI bus interface
• Four channels axis interface circuitry, each including:
• Three output command signal sets, configurable as either:
 Two serial data streams to external DACs, 1 pulse-and-direction
 Three PWM top-and-bottom pairs
• 3-channel differential/single-ended encoder input
• Nine input flags, two output flags
• Interface to two external serial ADCs, 8 to 18 bits
• Two channels supplemental interface circuitry, each including:
• 2-channel differential/single-ended encoder input
• One output command signal set, configurable as
pulse-&-direction or PWM top-and-bottom pair
• Display, MACRO, muxed I/O, direct I/O interface ports
• PID/notch/feedforward servo algorithms
• 1-year warranty from date of shipment
• One manual per set of one to four PMACs shipped
(Cables, mounting plates, mating connectors not included)
Option 1: Additional Four Channels Axis Interface Circuitry
• Option 1 provides an additional four channels of on-board axis interface circuitry, identical to the
standard first four channels. The key components on the board are the DSPGATE1 IC at U7 and
connectors J11 and J12.
Option 2: Dual-Ported RAM
Dual-ported RAM provides a very high-speed communications path for bus communications with the
host computer through a bank of shared memory. DPRAM is advised if more than 100 data items per
second are to be passed between the controller and the host computer in either direction.
• Option 2 provides an 8k x 16 bank of dual-ported RAM. The key component on the board is U28.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
2 Introduction
Option 5xF: CPU Speed Options
• Option 5CF: 80MHz DSP563xxx CPU (160MHz 56002 equivalent)
• Option 5EF: 160MHz DSP563xxx CPU (320MHz 56002 equivalent)
• Option 5AF: 40MHz DSP563xx CPU (80MHz 56002 equivalent) Default configuration provided
automatically if no CPU option ordered.
Option 6: Extended Servo Algorithm
The standard PID servo algorithm with feedforward and notch filter is suitable for most applications.
Systems with difficult dynamics, especially with significant flexibility, may require a more powerful
servo algorithm, such as the Extended Servo Algorithm (ESA).
Option 7: Plate Mounting
• Option 7 provides a mounting plate connected to the PMAC2 PCI with standoffs. It is used to install
the PMAC2 PCI in standalone applications.
Option 8: High-Accuracy Clock Crystal
The PMAC2 PCI has a clock crystal (component Y1) of nominal frequency 19.6608MHz (~20MHz).
The standard crystal’s accuracy specification is +/-100 ppm.
• Option 8A provides a nominal 19.6608MHz crystal with a +/-15 ppm accuracy specification.
Option 10: Firmware Version Specification
Normally the Turbo PMAC2 PCI is provided with the newest released firmware version. A label on the
U10 flash memory IC on the CPU board shows the firmware version loaded at the factory.
• Option 10 provides for a user-specified firmware version.
Option 12: Analog-to-Digital Converters
• Option 12 permits the installation of 8 or 16 channels of on-board multiplexed analog-to-digital
converters. 1 or 2 of these converters are read every phase interrupt. The analog inputs are not
optically isolated, and each can have a 0 – 5V input range, or a +/-2.5V input range, individually
selectable.
• Option 12 provides an 8-channel 12-bit A/D converter. The key components on the board are U28
and connector J1.
• Option 12A provides an additional 8-channel 12-bit A/D converter. The key component on the board
is U29.
Option 16: Battery-Backed Parameter Memory
The contents of the standard memory are not retained through a power-down or reset unless they have
been saved to flash memory first. Option 16 provides supplemental battery-backed RAM for real-time
parameter storage that is ideal for holding machine state parameters in case of an unexpected power-
down. The battery is located at component BT1.
• Option 16 provides a 16k x 24 bank of battery-backed parameter RAM in components U6, U9, and
U15 on the CPU board.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
Hardware Setup 3
HARDWARE SETUP
Piggyback CPU Board Jumper Configuration
Watchdog Timer Jumper
Jumper E1 on the Turbo CPU board must be OFF for the watchdog timer to operate. This is an important
safety feature, so it is vital that this jumper be OFF in normal operation. E1 should be put ON only to
debug problems with the watchdog timer circuit.
Dual-ported RAM Source Jumper
Jumper E2 must connect pins 1 and 2 to access dual-ported RAM from the baseboard. To use Option 2
DPRAM on the baseboard, jumper E2 must be in this setting.
Jumper E2 must connect pins 2 and 3 to access dual-ported RAM through the JEXP expansion port. To
use DPRAM on an external accessory board, jumper E2 must be in this setting.
Power-Up State Jumpers
Jumper E4 on the Turbo CPU board must be OFF, jumper E5 must be ON, and jumper E6 must be ON, in
order for the CPU to copy the firmware from flash memory into active RAM on power-up/reset. This is
necessary for normal operation of the card. (Other settings are for factory use only.)
Firmware Load Jumper
If jumper E7 on the CPU board is ON during power-up/reset, the board comes up in bootstrap mode,
which permits the loading of new firmware into the flash-memory IC on the board. When the PMAC
Executive program tries to establish communications with a board in this mode, it will detect
automatically that the board is in bootstrap mode and ask what file to download as the new firmware.
Jumper E7 must be OFF during power-up/reset for the board to come up in normal operational mode.
Flash Memory Bank Select Jumpers
The flash-memory IC in location U10 on the Flex CPU board has the capacity for eight separate banks of
firmware, only one of which can be used at any given time. The eight combinations of settings for
jumpers E10A, E10B, and E10C select which bank of the flash memory is used. In the factory production
process, firmware is loaded only into Bank 0, which is selected by having all of these jumpers OFF.
Base Board Jumper Configuration
Servo and Phase Clock Direction Control
Jumper E1 should be off if the board is using its own internally generated phase and servo clock signals.
In this case, these signals are output on spare pins on the J5A RS-422 serial-port connector, where they
can be used by other PMAC controllers set up to take external phase and servo clock signals.
Jumper E1 should be on if the board is using externally generated phase and servo clock signals brought
in on the J5A RS-422 serial port connector. In this case, another PMAC controller generates the clock
signals and output is on its serial port connector. Commonly, serial communications are also shared over
a multi-drop RS-422 cable, with software addressing of the cards matching the I0 serial card number for
each controller. Alternately, the phase and servo clock signals can come from clock signals involved in
the process.
If E1 is on for external phase and clock signals, and these clock signals are not brought in on the serial
port connector, the watchdog timer will trip immediately and shut down the board.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
4 Hardware Setup
In order to change the state of the card between use of internal clock and use of external clock, the card
must be re-initialized (either powered up with jumper E3 on, or given the $$$*** command) with
jumper E1 in the new state. Before the card is reset again, a SAVE command must be issued to store the
new internal settings.
CPU Frequency Control Jumpers
If variable I46 is set to the default value of zero, jumpers E2 and E4 on the base PMAC2 PCI board
control the frequency at which the CPU will operate (or attempt to operate). Generally this will be the
highest frequency at which the CPU is rated to operate.
• If jumpers E2 and E4 are both OFF, the CPU will operate at a 40MHz frequency.
• If E2 is ON and E4 is OFF, the CPU will operate at a 60MHz frequency.
• If E2 is OFF and E4 is ON, the CPU will operate at an 80MHz frequency.
• If I46 is set to a value greater than zero, E2 and E4 are not used. The CPU frequency is set to 10MHz
(I46+1)
Re-Initialization Jumper
If E3 is off during power-up/reset, the controller will load its last saved set-up parameters from flash
memory into active memory. This is the setting for normal operation.
If E3 is on during power-up/reset, the controller will load its factory-default set-up parameters from
firmware into active memory. Generally, this is done only if communications cannot be established with
the card when it comes up in normal operational mode.
Encoder Sample Clock Source Jumpers
Jumpers E13 and E14 control the source of the SCLK encoder-sampling clock for each servo IC. The
default setting no jumper installed means that the SCLK signal comes from the servo IC and is output on
the JMACH connectors. This setting is suitable for all but a few very special applications.
Serial Port Selection Jumper
Jumpers E17 and E18 control which serial-port connector is used. If E17 and E18 connect their pins 1
and 2, the 10-pin RS-232 port connector J5 is used. If E17 and E18 connect their pins 2 and 3, the 26-pin
RS-422 port connector J5A is used. The RS-422 port must be used if several cards are to be daisy-
chained together on a single multi-drop cable.
Output Disable State Jumpers
Jumpers E111 through E118 control the hardware state of the digital command output signals for each
channel when the amplifier enable signal for that channel is in the disable state (false). Jumper E11n(n=
1 to 8) controls the output signals for channel non the board.
If E11n is off (default), the command output signals for channel nare still active when the amplifier
enable signal is in the disable state. The Turbo PMAC software should be commanding a net zero
command to be output on these signals and the amplifier enable signal should be used by the amplifier so
that no command output will cause action if it is receiving a disable signal. The off setting should be used
when DAC output format is selected for the channel.
If E11nis on, the command output signals for channel nare tri-stated when the amplifier-enable signal is
in the disable state. This setting is used only with direct-PWM power-block amplifiers that do not use
amplifier enable to gate the PWM signals, and in which the zero-command format of 50% top on-time,
and 50% bottom on-time cannot be tolerated in the disable state.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
Hardware Setup 5
Resistor Pack Configuration
Termination Resistors
The PMAC2 PCI provides sockets for termination resistors on differential input pairs coming into the
board. As shipped, there are no resistor packs in these sockets. If these signals are brought long distances
into the PMAC2 PCI board and ringing at signal transitions is a problem, SIP resistor packs may be
mounted in these sockets to reduce or eliminate the ringing.
All termination resistor packs have independent resistors (no common connection) with each resistor
using two adjacent pins. The following table shows which packs are used to terminate each input device:
Input Pack Pack Size Input Pack Pack Size
Encoder 1 RP46 6-pin ADC 1 & 2 RP60 8-pin
Encoder 2 RP50 6-pin ADC 3 & 4 RP61 8-pin
Encoder 3 RP47 6-pin ADC 5 & 6 RP121 8-pin
Encoder 4 RP51 6-pin ADC 7 & 8 RP122 8-pin
Encoder 5 RP107 6-pin Fault 1 & 2 RP63 6-pin
Encoder 6 RP111 6-pin Fault 3 & 4 RP64 6-pin
Encoder 7 RP108 6-pin Fault 5 & 6 RP124 6-pin
Encoder 8 RP112 6-pin Fault 7 & 8 RP125 6-pin
SCLK12&34 RP52 6-pin SCLK56&78 RP113 6-pin
Pull-Up/Pull-Down Resistors
The differential input signal pairs to the PMAC2 PCI have user-configurable pull-up/pull-down resistor
networks to permit the acceptance of either single-ended or differential signals in one setting, or the
detection of lost differential signals in another setting.
The ‘+’ inputs of each differential pair each have a hard-wired 1 kohm pull-up resistor to +5V. This
cannot be changed.
The ‘-’ inputs of each differential pair each have a hard-wired 2.2 kohm resistor to +5V; each has another
2.2 kohm resistor as part of a socketed resistor pack that can be configured as a pull-up resistor to +5V, or
a pull-down resistor to GND.
If this socketed resistor is configured as a pull-down resistor (the default configuration), the combination
of pull-up and pull-down resistors on this line acts as a voltage divider, holding the line at +2.5V in the
absence of an external signal. This configuration is required for single-ended inputs using the ‘+’ lines
alone; it is desirable for unconnected inputs to prevent the pick-up of spurious noise. It is permissible for
differential line-driver inputs.
If this socketed resistor is configured as a pull-up resistor (by reversing the SIP pack in the socket), the
two parallel 2.2 kohm resistors act as a single 1.1 kohm pull-up resistor, holding the line at +5V in the
absence of an external signal. This configuration is required if encoder-loss detection is desired; or if
complementary open-collector drivers are used. It is permissible for differential line-driver inputs even
without encoder loss detection.
If Pin 1 of the resistor pack (marked by a dot on the pack) matches Pin 1 of the socket (marked by a wide
white line on the front side of the board and a square solder pin on the back side of the board), then the
pack is configured as a bank of pull-down resistors. If the pack is reversed in the socket, it is configured
as a bank of pull-up resistors.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
6 Hardware Setup
The following table lists the pull-up/pull-down resistor pack for each input device:
Device Resistor Pack Device Resistor Pack
Encoder 1 RP43 ADC/Fault1&2 RP58
Encoder 2 RP48 ADC/Fault3&4 RP59
Encoder 3 RP44 ADC/Fault5&6 RP119
Encoder 4 RP49 ADC/Fault7&8 RP120
Encoder 5 RP104 SCLK12&34 RP62
Encoder 6 RP109 SCLK56&78 RP123
Encoder 7 RP105
Encoder 8 RP110
Connections
Mounting
The PMAC2 PCI can be mounted in one of two ways: in the PCI bus, or using standoffs.
• PCI bus: To mount in the PCI bus, simply insert the P1 card-edge connector into the PCI socket. If
there is a standard PC-style housing, a bracket at the end of the PMAC2 PCI board can be used to
screw into the housing to hold the board down firmly.
• Standoffs: At each of the four corners of the PMAC2 PCI board, there are mounting holes that can be
used to mount the board on standoffs.
Power Supply Connection
The standard PMAC2 PCI requires only 5V power: 3A in a 4-channel configuration, 4A in an 8-channel
configuration (with Option 1). If the Option 12 A/D converters are installed, a –12V supply is also
required. In this case, a +12V supply also can be passed through the card and out to the analog devices
feeding the A/D converters.
The power can be provided in several ways:
• Bus connector: If the PMAC2 PCI is mounted in an electrically active PCI bus slot, it automatically
draws its 5V and +/-12V power from the bus.
• Terminal block: The TB1 2/4-point terminal block can be used to bring in 5V power, especially in
standalone applications. Point 1 is GND; Point 2 is +5V. Points 3 and 4 are needed only if the
Option-12 A/D converters are ordered.
• JMACH connectors: Up to 2A may be brought in through each 100-pin JMACH connector from an
Acc-8 board or its equivalent, provided the cable is 500mm (20 inches) or less in length.
Machine Port Connections
The PMAC2 PCI has a 100-pin high-density header for each pair of servo interface channels. Through
this connector pass all of the digital signals to and from the amplifier, encoder, and flags for the two
channels. Typically, this header is connected with a matching Delta Tau Acc-8 family 2-channel
breakout board or equivalent through a provided 100-pin flat cable.
The machine port connectors are:
• J9 (JMACH1) Board Channels 1 and 2
• J10 (JMACH2) Board Channels 3 and 4
• J11 (JMACH3) Board Channels 5 and 6 (Option 1 required)
• J12 (JMACH4) Board Channels 7 and 8 (Option 1 required)
Display Port
The J6 (JDISP) display port provides a 14-pin IDC header for connection to the Acc-12 family of
displays. Flat cables are provided with each of these displays for direct connection between the display
and this port.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
Hardware Setup 7
Multiplexer Port
The J2 (JTHW) multiplexer port provides eight TTL-compatible 5V CMOS inputs and eight TTL-
compatible 5V CMOS outputs on a 26-pin IDC header. These can be used directly as general-purpose
digital I/O, or with PMAC2’s special M-variable support (TWB, TWD, TWR, and TWS formats), they
can be used to support hundreds, or even thousands of multiplexed I/O points on accessory boards.
Delta Tau provides the following accessory boards that can be connected to the multiplexer port. Each
comes with a flat cable for direct connection to the port.
• Acc-8D Option 7 Resolver-to-Digital Converter Board
• Acc-18 Thumbwheel Board
• Acc-34 family of Digital I/O Boards
• Acc-35A and B Extender Boards
I/O Port
The J3 (JIO) I/O port provides 32 TTL-compatible 5V CMOS I/O points on a 40-pin IDC header.
Direction is selectable by byte. These are used as general-purpose digital I/O points. Acc-21A provides a
convenient connections adapter from this port to OPTO-22 style boards.
Serial Ports
The PMAC2 PCI has two serial-port connectors. Only one of these can be used in an application. J5 is a
10-pin IDC header for RS-232 communications. It can be connected to a standard DB9 RS-232
connector on a host computer or terminal via a flat cable such as the Acc-3L. A commercially available
DB9-to-DB25 adapter can be added to this flat cable if the host computer or terminal has a DB25 serial
connector. Jumpers E17 and E18 on the PMAC2 PCI must connect pins 1 and 2 to use this port.
J5A is 26-pin IDC header for RS-422 communications. It can be connected to a standard DB25 RS-422
connector on a host computer or terminal via a flat cable such as the Acc-3D. Jumpers E17 and E18 on
the PMAC2 PCI must connect pins 2 and 3 to use this port.
A/D-Converter Port
If the Option 12 A/D converters are ordered, the J1 (JANA) analog-input port is provided on the PMAC2
on a 20-pin IDC header. Option 12 provides eight analog inputs at 0 – 5V, or +/-2.5V levels. Option 12A
provides eight additional analog inputs at these levels. The +12V and –12V supplies can either be
brought in on this connector, or brought out on it for the external analog circuitry, if they have been
brought in through TB1 or P1.
Handwheel Port
The J7 (JHW) handwheel port provides two limited supplemental channels, each with a 2-channel
encoder input, and a pulse-and-direction or PWM top-and-bottom pair output. All inputs and outputs are
digital 5V differential line-driver pairs.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
8 Hardware Setup
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
Communications Setup 9
COMMUNICATIONS SETUP
Delta Tau provides communication tools that take advantage of the PCI bus Plug and Play feature of 32-
bits Windows® based computers. Starting with MOTIONEXE.EXE version 10.32.00, which is included
in PEWIN32 version 2.32 and newer, a PMAC2 PCI board plugged in a PCI bus slot will be recognized
by the operating system when the computer is booted up. The available PCI address, dual-ported RAM
address and Interrupt lines are set automatically by the operating system and can be checked (but not
modified) in the MOTIONEXE.EXE application.
Open MOTIONEXE
and press Setup for the
PCI device desired
The PMAC2 PCI board may have the optional on-board dual-ported RAM circuitry, which is ordered
through Option-2. If the dual-ported RAM circuitry is not on-board, manually disable its automatically
assigned use through the setup page of MOTIONEXE:
MOTIONEXE
version number
Disable Interrupts
and Dual-ported
RAM if not used
The MOTIONEXE application will look first for PMAC PCI boards on the PCI bus and will assign
device numbers sequentially from Device0 to each PMAC PCI until all the PMAC PCI boards found have
a device number assigned. Then, manually add other devices for either ISA bus or Serial port
communications.
After each PMAC has a device number assigned to it, communications through the PCI bus are identical
to the ISA bus. Any application written for the ISA bus using the Delta Tau provided 32-bits
communication libraries provided will not require any further change and the process is transparent.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
10 Communications Setup
Note:
For example, if a Device0 for serial RS-232 communications was defined before a
PMAC PCI board was installed in the computer, its setup information will be
overwritten by the MOTIONEXE application when the PMAC2 PCI board is
found. Therefore, it is very important to take note of the all the devices and their
parameters defined in MOTIONEXE before installing a new PMAC board in the
computer.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
Flex CPU Board Jumper Descriptions 11
FLEX CPU BOARD JUMPER DESCRIPTIONS
E1: Watchdog Disable Jumper
E Point and
Physical Layout Description Default
E1
Jump pin 1 to 2 to disable Watchdog timer (for test purposes
only).
Remove jumper to enable Watchdog timer.
No jumper
installed
E2: Dual-Ported RAM Port Select
E Point and
Physical Layout Description Default
E2
Jump pin 1 to 2 to access DPRAM from baseboard.
Jump pin 2 to 3 to access DPRAM through JEXP expansion
port.
Pins 1 and 2
jumpered
E4 – E6: Power-Up/Reset Load Source
E Point and
Physical Layout Description Default
E6
E4
Remove jumper E4;
Jump E5 pin 1 to 2;
Jump E6 pin 2 to 3;
to read flash IC on power-up/reset
Other combinations are for factory use only; the board will
not operate in any other configuration.
No E4 jumper
installed;
E5 and E6 jump
pin 1 to 2
E7: Firmware Reload Enable
E Point and
Physical Layout Description Default
E7
Jump pin 1 to 2 to reload firmware through serial or bus port
Remove jumper for normal operation. No jumper
installed
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
12 Flex CPU Board Jumper Descriptions
E10A, B, C: Flash Memory Bank Select
E Point and
Physical Layout Description Default
E10A
E10C
Remove all three jumpers to select flash memory bank with
factory-installed firmware.
Use other configuration to select one of the seven other flash
memory banks.
No jumpers
installed
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
Base Board Jumper Descriptions 13
PMAC2 PCI BASE BOARD JUMPER DESCRIPTIONS
E1: Servo and Phase Clock Direction Control
E Point and
Physical Layout Location Description Default
E1
C2 Remove jumper for PMAC2 PCI to use its
internally generated servo and phase clock
signals and to output these signals on the J5A
serial port connector.
Jump pins 1 and 2 for PMAC2 PCI to expect
to receive its servo and phase clock signals on
the J5A serial port connector.
No jumper
installed
Note: If the E1 jumper is ON and the servo and phase clocks are not brought in on the J5A serial port, the
watchdog timer will trip immediately.
E2: CPU Frequency Select
E Point and
Physical layout Location Description Default
E2
C2 Remove jumper for 40MHz operation (E4
OFF also) or for 80MHz operation (E4 ON)
with I46 = 0.
Jump pin 1 to 2 for 60MHz operation (E4
OFF) with I46 = 0.
Not used if I46 > 0.
No jumper
installed
Jumper installed
E3: Normal/Re-Initializing Power-Up/Reset
E Point and
Physical Layout Location Description Default
E3
C2 Jump pin 1 to 2 to re-initialize on power-
up/reset, loading factory default settings.
Remove jumper for normal power-up/reset,
loading user-saved settings.
No jumper
installed
E4: CPU Frequency Select
E Point and
Physical layout Location Description Default
E4
C2 Remove jumper for 40MHz operation (E2
OFF also) or for 60MHz operation (E4 ON)
with I46 = 0.
Jump pin 1 to 2 for 80MHz operation (E2
OFF) with I46 = 0.
Not used if I46 > 0
No jumper
installed (standard
or Option 5B)
Jumper installed
(Option 5C)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
14 Base Board Jumper Descriptions
E5 – E6: (Reserved for Future Use)
E13 - E14: Encoder Sample Clock Direction Control
E Point and
Physical layout Location Description Default
E13
1
2
3
D1 Remove jumper to output SCLK generated in
first ASIC on SCLK_12 and SCLK_34, or to
control direction by software.
Jump pins 1 to 2 to input SCLK signal for
first ASIC on SCLK_34 and output this
signal on SCLK_12.
Jump pins 2 to 3 to input SCLK signal for
first ASIC on SCLK_12 and output this
signal on SCLK_34.
No jumper installed
E14
3 2 1
D2 Remove jumper to output SCLK generated in
second ASIC on SCLK_56 and SCLK_78, or
to control direction by software.
Jump pins 1 to 2 to input SCLK signal for
second ASIC on SCLK_78 and output this
signal on SCLK_56.
Jump pins 2 to 3 to input SCLK signal for
second ASIC on SCLK_56 and output this
signal on SCLK_78.
No jumper installed
Note: E14 is only installed if Option 1 has been ordered.
E17 - E18: Serial Port Type Selection
E Point and
Physical layout Location Description Default
E17
1
2
3
C1 Connect pins 1 and 2 to use the RS-232 port
on the J5 connector.
Connect pins 2 and 3 to use the RS-422 port
on the J5A connector.
Jumper installed in
1-2 position
E18
1
2
3
C1 Connect pins 1 and 2 to use the RS-232 port
on the J5 connector.
Connect pins 2 and 3 to use the RS-422 port
on the J5A connector.
Jumper installed in
1-2 position
Serial Port Choice: Because both RS-232 and RS-422 ports are always provided, jumpers must be set
correctly to use the port of choice. Jumpers E17 and E18 must connect pins 1 and 2 to use the RS-232 port
on the J5 connector; to use the RS-422 port on the J5A connector, they must connect pins 2 and 3.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMAC2 PCI Hardware Reference Manual
Base Board Jumper Descriptions 15
E111-118: Command Output Disable State
E Point and
Physical Layout Location Description Default
E111
E112
E113
E114
E115
E116
E117
E118
C1 Jump pin 1 to 2 of E11nfor digital
servo command output signals of
Channel nto tri-state when amplifier-
enable signal for Channel nis in
disable state.
Remove jumper for digital servo
command output signals of Channel n
to remain active (but typically with
zero command value) when amplifier-
enable signal for Channel nis in
disable state.
No jumper
installed
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
