DELTA Temp BREEZER MACH 4 User manual

QUICK GUIDE
BREEZER MACH 4 - ADIABATIC COOLER
Delta-Temp Belgium
Lange Ambachtstraat 13, 9860 Oosterzele
T: [phone]
E : [email protected]
www.delta-temp.be
Delta-Temp Germany
Carl-Still-Straße 19, 45659 Recklinghausen
T: [phone]
E : [email protected]
www.delta-temp.de
1. Mounting the fan head:
• Lock each of the rear wheels by pressing down
on the brakes.
• Open the lid latch by rst pulling forward the
lower portion of the latch.
• Remove tank lid by rst lifting up on the
transport handle and then pulling forward.
2. Adding water to the water tank:
• Do not ll the water tank above the max ll
level, as shown. If water tank is lled past this
level, water may leak out of the water tank and
cause a hazard around the Breezer.
• The water valve can be adjusted for optimal
performance according to your climate.
• Lift the fan head straight up and align it with
the fan head support pole. Once the fan head is
seated on the support pole, rotate the fan head
horizontally until you feel it engage with the
support pole.
• Once installed, the atomizer (metal disk) will
be facing the water tank, air will be blown over
the water tank when the Breezer is turned on.
3. Routing power and water lines and replace
tank lid:
• Route the fan head power cord, atomizer
drain hose, and water inlet hose through
the openings in the back of the water tank as
shown above.
• Slide the lid tab into the corresponding water
tank notch in the back of the water tank.
• Lower the front of the tank lid onto the water
tank and re-lock lid latch.
I. SETUP
>>

Delta-Temp Belgium
Lange Ambachtstraat 13, 9860 Oosterzele
T: [phone]
E : [email protected]
www.delta-temp.be
Delta-Temp Germany
Carl-Still-Straße 19, 45659 Recklinghausen
T: [phone]
E : [email protected]
www.delta-temp.de
II. OPERATION
1. Turning on your unit:
1a. Press the power button and hold for one second.
The LED light for the power button will be lit and the
fan blades will begin to slowly rotate to indicate the unit is
powered on.
1b. Press the fan speed button to increase the fan speed.
Adjust the fan speed by pressing the or buttons.
1c. Press the oscillation button once to activate the
oscillation feature.
1d. Press the atomizer button once to activate the misting
feature.
2. Adjusting the misting level:
1a. Press the power button and hold for one second if unit is not
already on.
1b. Set fan speed to desired level.
1c. Locate the water valve. The water valve is located inside the
reservoir tank towards the rear of the tank.
1d. Start with the water valve closed, at the 6 o’clock position as
shown.
1e. Start the atomizer by pressing the atomizer button once.
2a. Open the water valve slightly and check the distance of the mist.
There will be a short delay before misting begins.
2b. If there is a strong mist at 6 feet away, then the moisture setting is
too high for conditions. To reduce misting, rotate the water valve
lever back towards the 6 o’clock position.
Optimal moisture settings can also be adjusted according to personal prefe-
rence.
Atomizer (misting)
on / o
Fan Speed
up / down
Power
on / o
Head Rotation
on / o
MAX FILL LINE
MAX FILL LINE
