Delta Leland 978-DST User manual

1 1/6 " Dia.
(27 mm)
KITCHEN FAUCETS
■Leland®Collection
■Single Handle Widespread
■2 or 3 Hole Sink Applications
■ Optional Soap Dispenser
■DIAMOND™ Seal Technology
■ Integrated Supply Tubes
■2-Function Pull-Down
■MagnaTite™ Docking System
Submitted Model No.:_______________________________________________
Specific Features: __________________________________________________
STANDARD SPECIFICATIONS:
• Single handle, 2-function pull-down kitchen faucets
for exposed mounting on two and three hole sinks.
• 14 1/4" (362 mm) high, 9 3/16" (233 mm) long,
spout swings 360˚.
• Control shall return to neutral position when
faucet is turned off.
• Red/blue graphics on handle button to indicate
hot/cold temperature.
•Integral double check valves in sprayer assembly.
•Disposable hose lead to aid installation.
•Recommended hole size 1 3/8" (35mm) on 4"
(102mm) centers.
• 3/8" O.D. straight, staggered pex supply tubes -
36 3/4" (934 mm) and 37 3/4" (959 mm) long.
•Touch-Clean®2 function (stream spray) sprayhead.
•Magnetic docking system secures sprayer to spout.
0
1
2
3
4
5
0102030405060708090
Pressure (PSI)
Flow (U.S. Gallons Per Minute)
6
069 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flow (Liters Per Minute)
978-DST 978-SD-DST
55 E. 111th Street, Indianapolis, Indiana 46280
395 Matheson Blvd. E., Mississauga, ON L4Z 2H2
© 2008 Masco Corporation of Indiana
14 1/4"
(362 mm)
9 3/16"
(233 mm)
7 3/16"
(182 mm)
5 13/16"
(147 mm)
16 1/2"
(419 mm)
7 1/8"
(181 mm)
2 3/8 "
(60 mm)
2 1/8"
(53 mm)
37 3/4"
(959 mm)
36 3/4"
(933 mm)
10 3/8"
(263 mm)
2 13/16"
(71 mm)
3 5/8"
(92 mm) 2"
(51 mm)
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-K-978-DST Rev. A
2 1/2"
(64 mm)
Max. Deck
Thickness
®
®
UPC
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
WARRANTy
• Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from defects
in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
4"
(102 mm)
Min.
1 3/8"
(35 mm)
Hole
Size
2 1/8 "
(53 mm)
