Delton 830B User manual

1
830B
DMM OPERATOR’S MANUAL
1. Overview
This multimeter is characterized at slim size, portable, stable performance .
Using 3½ digits LCD monitor with character 13MM high, they offer clear
readings. With overall circuitry design centering on large-scale IC A/D
converters in conjunction and over-load protection circuit, the meters give
excellent performance and exquisite making as a handy utility instrument.
The meters can be used to measure DC & AC voltage, DC current,
resistance, positive diode voltage fall, hFE parameters for transistor and
Continuity.
2. Safety Information
2-1 The meters are designed according to IEC-1010 concerning electronic
measuring instruments with an over-voltage category (CAT Ⅲ) and
pollution 2.
2-2 Follow all safety and operating instructions to ensure that the meter
is used safely and is kept in good operating condition.
2-3 safety symbols:
important safety information, refer to the operating manual.
Dangerous voltage may be presence.
Double insulation (protection Class II)
3. Special Cautions for Operation
3-1 The meters can be safe only according to standard procedures when
used in conjunctions with the supplied test leads. To replace
damaged test leads with only the same model or same electric
specifications.
3-2 To avid risk of electric shock, do not use the meters before the cover
is in place.
3-3 The range switch should be right position for the testing.
3-4 To avoid electric shock and damaging the instruments, the input
signals are forbidden to exceed the specified limits.
3-5 When measuring TV set or switched power, attention should be paid
to the possible pulses that may bring destruction to the circuit.
3-6 Range switch position is forbidden to be changed at random during
measurement.
3-7 Take caution against shock in the course ot measuring voltage
higher than DC 60V & AC 30V.
3-8 Protection fuse should be replaced only with same type and same
specification.
4. GENERAL SPECIFICATIONS
4-1 Max Voltage between input terminal and Earth Ground: CAT II 600V
4-2 Over-range Indication: display “1” for the significant digit.
4-3 Automatic display of negative polarity “_”
4-4 Low Battery Indication: „ ‟ displayed
4-5 Max LCD display: 1999 (31/2 digits)
4-6 Fuse protection: F-200mA/250V (Ø 5x20MM)
4-7 Power Supply: 9V battery, 6F22 or NEDA 1604
4-8 Operating Temp.: 0℃to 40℃(relative humidity <85%)
4-9 Storage Temp.:-10℃to 50℃((relative humidity <85%)
4-10 Guaranteed precision Temp.: 23±5 ℃
(relative humidity <85%)
4-11 Dimension: 69x126x24
4-12 Weight: approx. 120g (including battery)
5. Testing Specifications
Accuracy is specified for a period of year after calibration and at 18℃to
28℃(64℉to 82℉) with relative humidity to 75%.
5-1 DC Voltage
range
resolution
accuracy
200mV
0.1mV
±(0.8% of rdg +10 digits )
2000mV
1mV
±(0.8% of rdg + 10digits)
20V
10mV
±(0.8% of rdg +10 digits)
200V
100mV
±(0.8% of rdg + 10 digits)
1000V
1V
±(1.0% of rdg +15 digits)
-- Input Impendence: 1MΩ
-- Overload protection: 250V for 200mV range, effective DC or AC 750V for
other ranges
5-2 AC Voltage
range
resolution
accuracy
200V
100mV
±(1.2% of rdg + 20 digits)
750V
1V
±(2.0% of rdg + 20 digits)
Frequency Range: 40 to 400Hz
40 to 100Hz for range 750V
-- Response: average, calibrated in rms of sine wave
5-3 DC Current
range
Resolution
accuracy
200uA
0.1μA
±(1.0% of rdg + 15 digits)
2000uA
1μA
20mA
10μA
200mA
100μA
±(1.5% of rdg + 20 digits)
10A
10mA
±(3.0% of rdg + 20 digits)
-- Overload protection: F 250mA/250V fuse
Note: 10A range: not fused. 10A up to 10 seconds
5- 4 Resistance
range
Resolution
accuracy
200Ω
0.1Ω
±(1.5% of rdg +25 digits)
2000Ω
1Ω
±(0.8% of rdg + 20digits)
20KΩ
10Ω
±(0.8% of rdg + 20 digits)
200KΩ
100Ω
±(0.8% of rdg +20 digits)
2000KΩ
1KΩ
±(1.8% of rdg + 20 digits)
-- over-load protection: 250V effective value
5-5 Transistor hFE Test
range
Test Range
Test Current / voltage
NPN & PNP
0-1000
Ib=10uA / Vce=3V
5-6 Diode Test
range
resolution
Function
1mV
Display: read approximate
forward voltage of diode
-- over-load Protection: 250V effective value
-- forward DC current: approximate 1mA
-- Reversed DC voltage: approximate 3.0V
6. OPERATING INSTRUCTIONS
6-1 Attention before operation
6-1-1 Check 7V battery. If the battery voltage is less than 7V, display will
show “ ”, the battery should be replaced at this time to ensure
measuring precision.
6-1-2 Pay attention to the “ ” besides the input jack which shows that
the input voltage or current should be within the specified value.
6-1-3 The range switch should be positioned to desired range for
measurement before operation.
6-2 Measuring DC Voltage
6-2-1 Connect the black test lead to COM jack and the red to VΩmA jack.
6-2-2 Set the rotary switch at the desired DCVrange position.
6-2-3 Connect test leads across the source or load under

2
measurement.
6-2-4 You can get reading from LCD. The polarity of the red lead
connection will be indicated along with the voltage value.
NOTE:
1. When the value scale to be measured is unknown beforehand, set the
range selector at the highest position.
2. When only the figure‟1‟ or „-1‟ is displayed, it indicates over-range
situation and the higher range has to be selected.
3. “ ” means you can‟t input the voltage more than 1000V, it‟s
possible to show higher voltage, but it may destroy the inner circuit or
pose a shock.
4. Be cautious against shock when measuring high Voltage.
6-3 Measuring AC Voltage
6-3-1 Connect the black test lead to COM jack and the red to VΩmA jack.
6-3-2 Set the rotary switch at the desired ACVrange position.
6-3-3 Connect test leads across the source or load under
measurement.
6-3-4 You can get reading from LCD.
NOTE:
1. When the value scale to be measured is unknown beforehand, set the
range selector at the highest position.
2. When only the figure‟1‟ or „-1‟ is displayed, it indicates over-range
situation and the higher range has to be selected.
3. “ ” means you can‟t input the voltage more than 750V, it‟s possible
to show higher voltage, but it may destroy the inner circuit or pose a
shock.
4. Be cautious against shock when measuring high Voltage.
6-4 Measuring DC Current
6-4-1 Connect the black test lead to COM jack and the red to the VΩmA
jack for a maximum 200mA current , for a maximum 10A current,
move the red lead to the 10A jack.
6-4-2 Set the rotary switch at the desired DCArange position.
6-4-3 Connect test leads in series with the load under measurement.
6-4-4 You can get reading from LCD. The polarity of the red lead
connection will be indicated along with the current value.
NOTE:
1. When the value scale to be measured is unknown beforehand, set
the range selector at the highest position.
2. When only the figure‟1‟ or „-1‟ is displayed, it indicates over-range
situation and the higher range has to be selected.
3. “ ” means the socket mA‟s maximum current is 200mA and 10A‟s
maximum current is 10A, over current will destroy the fuse. Since
10A is not fused, the measuring time should be less than 1 second to
prevent precision from affecting by circuit heating.
6-5 Measuring Resistance
6-5-1 Connect the black test lead to COM jack and the red to VΩmA jack.
6-5-2 Set the rotary switch at the desired Ωrange position.
6-5-3 Connect test leads across the resistance under measurement.
6-5-4 You can get reading from LCD.
NOTE:
1. When only the figure‟1‟ or „-1‟ is displayed, it indicates over-range
situation and the higher range has to be selected.
2. For measuring resistance above 1MΩ, the mete may take a few
seconds to get stable reading.
3. When the input is not connected, i.e. at open circuit, the figure „1‟ will
be displayed for the over-range condition.
4. When checking in-circuit resistance, be sure the circuit under test
has all power removed and that all capacitors have been discharged
fully.
5. the value scale to be measured is unknown beforehand, set the
range selector at the highest position.
6-6 Transistor Testing
6-6-1 Set the rotary switch at ‟hFE‟ position.
6-6-2 Determine whether the transistor under testing is NPN or PNP and
locate the emitter, base and collector leads. Insert the leads into
proper holes of hFE socket on the front panel.
6-6-3 Read the approximate hFE value at the testing condition of base
current Ib10uA and Vce 3V.
6-7 Diode Testing
6-7-1 Connect the black test lead to COM jack and the red to VΩmA jack.
(the polarity of red lead is „+‟)
6-7-2 Set the rotary switch at the F range position.
6-7-3 Connect the red lead to the anode and the black lead to
the cathode of the diode under testing.
6-7-4 You can get a reading from LCD.
NOTE:
1. The meter will show approximate forward voltage drop of the diode.
2. If the lead connections is reversed, only „1‟ will be displayed.
7. Maintenance
7-1 Before attempting to remove the battery door or open the case, be
sure that test leads have been disconnected from measurement circuit
top avoid electric shock hazard.
7-2 To avoid electrical shock, remove test leads from measurement circuits
before replacing the fuse. For protection against fire, replace fuses only
with specified ratings: F-250mA/250V fuse.
7-3 Your must replace the test leads if the lead is exposed, and should
adopt the leads with the same specifications as origin.
7-4 Use only moist fabric or small amount of detergent but not chemical
solution for cleaning.
7-5 do not use the meter before the back cover is properly closed and
screw secured. Upon any abnormality, stop operation immediately
and send the meter for maintenance.
7-6 Please take out the battery when not using for a long time.
8. Accessories
[1] Test Leads: electric rating 1000V 10A
[2] Fuse: F-250mA/250V
[3] Operator‟s Manual
Above picture and content just for your reference. Please be subject
to the actual products if anything different or updated. Please pardon
for not informing in advance.
