Denon AVR-S670H User manual

Quick
Start
Guide
AVR-S670H
INTEGRATED NETWORK AV RECEIVER
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 11. AVR-S670HE2_QSG_ENG_00A_230522.indd 1 2023/06/06 10:29:552023/06/06 10:29:55

1
Thank you for choosing a Denon AVR.
Use the Setup Assistant function to help configure the settings for this unit when you first set it up.
Follow the guidance displayed on the TV screen connected to this unit to configure the settings.
This manual describes the procedure up until starting the Setup Assistant.
Please do not return this unit to the store – call for assistance.
If you need help… :
If you need additional help in solving problems, contact Denon customer service in your area.
www.denon.com
Welcome
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 11. AVR-S670HE2_QSG_ENG_00A_230522.indd 1 2023/06/06 10:29:552023/06/06 10:29:55

2
EN
DE
FR
IT
ES
NL
SV
RU
PL
Before you begin
• When connecting this unit to a device that is compatible with the Deep Color, 4K, ARC and eARC functions, use a “High Speed HDMI cable
with Ethernet” that displays the HDMI logo.
• When connecting this unit to a device that is compatible with 8K and 4K 120Hz video, use a certified “Ultra High Speed HDMI cable”. If you
use a different HDMI cable, the video may not display or other problems may occur.
Required for setup
TV Speaker cables
HDMI® cable Subwoofer cable
Speakers
Optional
LAN cable
Wi-Fi® router
or
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 21. AVR-S670HE2_QSG_ENG_00A_230522.indd 2 2023/06/06 10:29:562023/06/06 10:29:56

3
What’s in the box
Quick Start Guide AVR Sound calibration
microphone
Safety instructions Power cord Sound calibration
microphone stand
Cautions on using
batteries FM indoor antenna Remote control (RC-1258)
Notes on radio AM loop antenna 2× R03/AAA batteries
Cable labels
• The included sound calibration microphone stand is convenient for performing speaker calibration. Using your own tripod or the supplied
Sound calibration microphone stand enables settings to be automatically configured to the optimum listening environment, providing
exceptionally high performance.
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 31. AVR-S670HE2_QSG_ENG_00A_230522.indd 3 2023/06/06 10:29:562023/06/06 10:29:56

4
EN
DE
FR
IT
ES
NL
SV
RU
PL
Attach the included cable labels
The supplied cable labels include labels for the speaker and HDMI cables.
Attach a cable label to each cable that matches the speakers and HDMI devices being connected, as shown below.
This makes it easy to identify and properly connect the cables between your components.
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 41. AVR-S670HE2_QSG_ENG_00A_230522.indd 4 2023/06/06 10:29:562023/06/06 10:29:56

5
Rotate the antenna upwards for the best possible
reception.
Setup
Optional
If you are connecting the AVR to a wired network, connect an
Ethernet cable (not included) between the AVR and your router.
Do not connect the Ethernet cable if you are connecting the
AVR to a wireless network.
Router
LAN port
• The antennas are required for both Bluetooth and Wi-Fi
functions.
Rotate the antennas
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 51. AVR-S670HE2_QSG_ENG_00A_230522.indd 5 2023/06/06 10:29:572023/06/06 10:29:57

6
EN
DE
FR
IT
ES
NL
SV
RU
PL
Place the AVR near your TV and connect the power cord.
TV
AVR
Power cord
Connect the power cord
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 61. AVR-S670HE2_QSG_ENG_00A_230522.indd 6 2023/06/06 10:29:572023/06/06 10:29:57

7
HDMI IN
(ARC/eARC)
HDMI OUT
TV
(ARC/eARC)
HDMI cable
AVR (Rear panel)
Connect the AVR to your TV
Using a high quality HDMI cable*, connect one end to the HDMI
port labeled “eARC” or “ARC” on your TV. Connect the other
end to the HDMI OUT TV port on your AVR.
What is ARC and eARC?
Audio Return Channel or “ARC” sends audio back to the AVR
using the same HDMI cable that sends video from your AVR
to your TV. This allows your AVR to process the sound from
your TV’s built-in tuner and apps. TVs with an Enhanced Audio
Return Channel or “eARC” port provide additional support for
high bitrate multichannel audio (Dolby TrueHD and DTS-HD).
Please refer to your TV owner’s manual for details about eARC
support for your particular model.
* For 4K TVs, we recommend using an HDMI cable labeled
“High Speed” and “with Ethernet” .
* For 8K TVs, we recommend using an HDMI cable labeled
“Ultra High Speed”.
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 71. AVR-S670HE2_QSG_ENG_00A_230522.indd 7 2023/06/06 10:29:572023/06/06 10:29:57

8
EN
DE
FR
IT
ES
NL
SV
RU
PL
TV remote control
Turn on the TV Select the appropriate HDMI
input on your TV
HDMI
or
INPUT
TV/
VIDEO
TV remote control
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 81. AVR-S670HE2_QSG_ENG_00A_230522.indd 8 2023/06/06 10:29:572023/06/06 10:29:57

9
Install batteries in the AVR
remote control
• Batteries can be taken out in reversed order.
Press Xon the remote control.
Turn on the AVR
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 91. AVR-S670HE2_QSG_ENG_00A_230522.indd 9 2023/06/06 10:29:572023/06/06 10:29:57

10
EN
DE
FR
IT
ES
NL
SV
RU
PL
Verify that you can see this screen on your TV.
Please select a language...
AV Receiver Setup Assistant
[1/7]
Français
Deutsch
Italiano
Español
English
If this screen is not displayed, please go back and retry the
steps again in the recommended sequence.
Follow the on-screen Setup
Assistant
The TV is now connected to the AVR.
The Setup Assistant will walk you through connecting and
configuring your speakers and components to your Denon
AVR. Use the remote control and follow the instructions on
the TV screen to complete the AVR settings using the Setup
Assistant.
Verify the connection
Setup Assistant Complete!
Setup is now complete.
Your AVR is now properly configured to provide you
with the best possible sound and video experience.
Enjoy!
Done
• In case the unit was already setup back in time the Setup
Assistant won't start automatically and you only see the
Denon logo on screen. In such case you can access the Setup
Assistant by pressing SETUP on the remote control and
selecting Setup Assistant from the menu.
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 101. AVR-S670HE2_QSG_ENG_00A_230522.indd 10 2023/06/06 10:29:582023/06/06 10:29:58

11
Firmware update
If you see this screen after completing Setup Assistant, select Update Now to make sure your new AVR is up to date with the latest
firmware and features.
The following features are available for your AVR.
Estimated time to install: min
Update Later Update Now
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 111. AVR-S670HE2_QSG_ENG_00A_230522.indd 11 2023/06/06 10:29:582023/06/06 10:29:58

12
EN
DE
FR
IT
ES
NL
SV
RU
PL
Download the mobile apps
Download both the “HEOS” app and the “Denon AVR Remote”
app for the full home entertainment experience. The HEOS app
is required to access online music through your AVR.
HEOS app
The HEOS app allows you to explore, browse, and play music
from many online streaming services or from your own music
library.
Denon AVR Remote
Control your new AVR with the latest Denon AVR Remote app.
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 121. AVR-S670HE2_QSG_ENG_00A_230522.indd 12 2023/06/06 10:29:582023/06/06 10:29:58

13
Online manual
Owner’s manual
Refer to the online manual for other functions, information and
operation procedure details.
manuals.denon.com/AVRS670H/EU/EN/
For more information, visit www.denon.com
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 131. AVR-S670HE2_QSG_ENG_00A_230522.indd 13 2023/06/06 10:29:582023/06/06 10:29:58

14
EN
DE
FR
IT
ES
NL
SV
RU
PL
Trademark information
The Bluetooth® word mark and logos are registered trademarks owned
by the Bluetooth SIG, Inc. and any use of such marks by D&M Holdings
Inc. is under license. Other trademarks and trade names are those of their
respective owners.
Manufactured under license from Dolby Laboratories. Dolby, Dolby
Audio, Pro Logic, Dolby Vision, and the double-D symbol are trademarks
of Dolby Laboratories.
For DTS patents, see http://patents.dts.com. Manufactured under license
from DTS, Inc. or DTS Licensing Limited. DTS, DTS-HD, and the DTS-HD
logo are registered trademarks or trademarks of DTS, Inc. in the United
States and other countries. © 2021 DTS, Inc. ALL RIGHTS RESERVED.
The Wi-Fi CERTIFIED logo is a registered trademark of the Wi-Fi Alliance.
Wi-Fi Certification provides assurance that the device has passed the
interoperability test conducted by the Wi-Fi Alliance, a group that certifies
interoperability among wireless LAN devices.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade
dress and the HDMI Logos are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc.
App Store® is registered in the U.S. and other countries.
Google Play and the Google Play logo are trademarks of Google LLC.
1. AVR-S670HE2_QSG_ENG_00A_230522.indd 141. AVR-S670HE2_QSG_ENG_00A_230522.indd 14 2023/06/06 10:29:582023/06/06 10:29:58

www.denon.com
Printed in Vietnam 5411 12044 00AS
© 2023 DEI Sales, Inc. All Rights Reserved.
