Denon AVR-X5200W User manual

MODEL JP E3 E2 EK EA E1 E1C E1K
AVR-X5200W
P P P
INTEGRATED NETWORK AV RECEIVER
Ver. 2
• Please use this service manual with referring to the operating instructions without fail.
• Some illustrations using in this service manual are slightly different from the actual set.
• For purposes of improvement, specications and design are subject to change without notice.
Please refer to the
MODIFICATION NOTICE.
e
SERVICE MANUAL
e
D&M Holdings Inc.

ABOUT THIS MANUAL.............................................................3
What you can do with this manual ............................................3
Using Adobe Reader (Windows version) ..................................4
SAFETY PRECAUTIONS..........................................................6
NOTE FOR SCHEMATIC DIAGRAM.........................................7
NOTE FOR PARTS LIST...........................................................7
TECHNICAL SPECIFICATIONS................................................9
DIMENSION...............................................................................9
Precautions During Service...................................................10
Initializing This Unit .................................................................10
Service Jigs.............................................................................10
DISASSEMBLY........................................................................11
1. FRONT PANEL ASSY ........................................................13
2. RADIATOR ASSY...............................................................14
3. SMPS ASSY.......................................................................15
4. POWER TRANS ................................................................16
5. BACK PANEL ASSY...........................................................17
SPECIAL MODE......................................................................18
Special Mode Conguration Buttons.......................................18
1. Version Display Mode ........................................................19
2. PANEL / REMOTE LOCK Selection Mode.........................23
3. Selection Modes for Service-related Operations................24
DIAGNOSTIC PATH DIAGRAM.........................................31
4. Remote ID Setup Mode......................................................74
5. Protection Pass Mode........................................................75
6. CX870 / CY920 Reboot Mode............................................75
7. CX870 / CY920 Initialization Mode ....................................76
JIG FOR SERVICING ..............................................................77
Procedure after Replacing the Microprocessor, etc. ..........79
Firmware Update Procedure..................................................79
1. Updating by USB................................................................79
2. Updating by DPMS.............................................................88
ADJUSTMENT.........................................................................95
SURROUND MODES AND PARAMETERS............................96
TROUBLE SHOOTING............................................................99
1. POWER..............................................................................99
2. Analog video ....................................................................100
3. HDMI/DVI .........................................................................102
4. AUDIO..............................................................................104
5. Network/Bluetooth/USB ...................................................107
6. SMPS...............................................................................112
Audio Check PASS ..............................................................114
CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK...........115
LEVEL DIAGRAM..................................................................116
GND DIAGRAM .....................................................................124
POWER DIAGRAM................................................................125
CPU DIAGRAM......................................................................126
PRINTED WIRING BOARDS.................................................127
SCHEMATIC DIAGRAMS (1/35 ) ..........................................133
SCH01_DIGITAL CONNECT ................................................133
SCH02_DIR ADC ZONEDAC ...............................................134
SCH03_AUDIO PLD .............................................................135
SCH04_DSP1 .......................................................................136
SCH05_DSP2 .......................................................................137
SCH06_DSP3 .......................................................................138
SCH07_DSP4 .......................................................................139
SCH08_MAIN CPU ...............................................................140
SCH09_SUB CPU.................................................................141
SCH10_DECODER...............................................................142
SCH11_HDMI SW1...............................................................143
SCH12_HDMI SW2...............................................................144
SCH13_IP SCALER..............................................................145
SCH14_IP SCALER DDR .....................................................146
SCH15_VIDEO PLD .............................................................147
SCH16_HDMI RX TX............................................................148
SCH17_HDMI SUPPLY.........................................................149
SCH18_NETWORK ..............................................................150
SCH19_AUDIO VIDEO CONNECT ......................................151
SCH20_AUDIO VOLUME .....................................................152
SCH21_PREOUT..................................................................153
SCH22_VIDEO SELECTOR .................................................154
SCH23_CONNECT...............................................................155
SCH24_ZONEDAC ADC.......................................................156
SCH25_MAIN DAC ...............................................................157
SCH26_FRONT HDMI USB..................................................158
SCH27_SPEAKER................................................................159
SCH28_REG.........................................................................160
SCH29_FRONT ....................................................................161
SCH30_SMPS ......................................................................162
SCH31_AMP CONNECT ......................................................163
SCH32_232C PHONO..........................................................164
SCH33_POWER AMP...........................................................165
SCH34_CX870 CONNECT (CX870 Only) ............................166
SCH35_BT MODULE (CX870 Only).....................................167
EXPLODED VIEW .................................................................168
PACKING VIEW.....................................................................169
SEMICONDUCTORS.............................................................170
1. IC's...................................................................................170
2. FL DISPLAY .....................................................................192
CONTENTS
2

Jump to the target of a schematic
diagram connector
Click the Ref. No. of the target connector in the red
box around a schematic diagram connector.
•The screen jumps to the target connector.
•Pagemagnicationstaysthesameasbeforethe
jump.
CP401
CP106
v
ABOUT THIS MANUAL
Read the following information before using the service manual.
What you can do with this manual
Search for a Ref. No. (phrase)
(Ctrl+Shift+F)
You can use the search function in Acrobat Reader to
search for a Ref. No. in schematic diagrams, printed
wiring circuit diagrams, block diagrams, and parts
lists.
1.Press Ctrl+Shift+Fonthekeyboard.
• The Search window appears.
2.EntertheRef.No.youwanttosearchforinthe
Search window, and then click the Search button.
•A list of search results appears.
3.Click an item on the list.
• The screen jumps to the page for that item, and the
searchphraseisdisplayed.
Ctrl
Shift
F
3

Using Adobe Reader (Windows version)
• Properties
Click this button and check that the printer is set to a
suitable paper size.
• Page to print
Select the following checkbox.
"More Options" : "Current View"
• Page Sizing & Handling
Select the following checkbox.
"Size" / "Size Options" : "Fit"
Add notes to this data (Sign)
TheSignfunctionletsyouaddnotestothedatain
this manual.
Savetheleonceyouhavenishedaddingnotes.
[Example using Adobe Reader X]
On the "View" menu, click "Sign".
• The Sign pane appears.
[Example using Adobe Reader 9]
On the "Document" menu, click "Sign".
Magnify schematic / printed circuit
board diagrams - 1
(Ctrl+Space, mouse operation)
Press Ctrl+Spaceonthekeyboardanddragthe
mousetoselecttheareayouwanttoview.
• Theselectedareaismagnied.
• Whenyouwanttomovetheareashown,hold
down Space and drag the mouse.
• Whenyouwanttoshowafullpageview,press
Ctrl+0onthekeyboard.
Ctrl Space
0
Print a magnied part of the manual
ThePropertiesdialogboxandfunctionswillvarydependingonyourprinter.
1. Dragthemousetomagnifythepartyouwanttoprint.
2. On the "File" menu, click "Print".
3. CongurethefollowingsettingsinthePrintdialogbox.
4. Click the Print button to start printing.
4

Magnify schematic / printed circuit
board diagrams - 2
(Pan & Zoom function)
ThePan&Zoomfunctionletsyouseewhichpartof
amagnieddiagramisbeingshowninaseparate
window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Pan & Zoom".
• The Pan & Zoom window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Pan & Zoom Window".
Magnify schematic / printed circuit
board diagrams - 3
(Loupe Tool function)
TheLoupeToolfunctionletsyoumagnifyaspecic
part of a diagram in a separate window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Loupe Tool".
• The Loupe Tool window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Loupe Tool Window".
5

SAFETY PRECAUTIONS
The following items should be checked for continued protection of the customer and the service technician.
leakage current check
Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the set is defective.
Be sure to test for leakage current with the AC plug in both polarities, in addition, when the set's power is in each state
(on,offandstandbymode),ifapplicable.
CAUTION Please heed the following cautions and instructions during servicing and
inspection.
◎Heed the cautions!
Cautions which are delicate in particular for servicing
are labeled on the cabinets, the parts and the chassis,
etc. Be sure to heed these cautions and the cautions
described in the handling instructions.
◎Cautions concerning electric shock!
(1) AnACvoltageisimpressedonthisset,soifyou
touch internal metal parts when the set is energized,
youmaygetanelectricshock.Avoidgettingan
electricshock,byusinganisolatingtransformer
and wearing gloves when servicing while the set is
energized,orbyunpluggingthepowercordwhen
replacing parts, for example.
(2) Therearehighvoltagepartsinside.Handlewith
extra care when the set is energized.
◎Caution concerning disassembly and
assembly!
Through great care is taken when parts were
manufacturedfromsheetmetal,theremaybeburrson
theedgesofparts.Theburrscouldcauseinjuryifngers
are moved across them in some rare cases. Wear gloves
toprotectyourhands.
◎Use only designated parts!
Theset'spartshavespecicsafetyproperties(re
resistance,voltageresistance,etc.).Besuretouseparts
which have the same properties for replacement. The
burrs have the same properties. In particular, for the
importantsafetypartsthatareindicatedbythezmark
on schematic diagrams and parts lists, be sure to use
the designated parts.
◎Be sure to mount parts and arrange the wires
as they were originally placed!
Forsafetyseasons,somepartsusetapes,tubesorother
insulatingmaterials,andsomepartsaremountedaway
from the surface of printed circuit boards. Care is also
takenwiththepositionsofthewiresbyarrangingthem
andusingclampstokeepthemawayfromheatingand
highvoltageparts,sobesuretoseteverythingbackas
itwasoriginallyplaced.
◎Make a safety check after servicing!
Check that all screws, parts and wires removed or
disconnected when servicing have been put back in their
original positions, check that no serviced parts have
deteriorate the area around. Then make an insulation
check on the external metal connectors and between
the blades of the power plug, and otherwise check that
safetyisensured.
(Insulationcheckprocedure)
Unplug the power cord from the power outlet, disconnect
the antenna, plugs, etc., and on the power. Using a 500V
insulation resistance tester, check that the insulation
resistancevaluebetweentheinplugandtheexternally
exposedmetalparts(antennaterminal,headphones
terminal,inputterminal,etc.)is1MΩorgreater.Ifitis
less, the set must be inspected and repaired.
Manyoftheelectricandthestructuralpartsusedinthe
sethavespecialsafetyproperties.Inmostcasesthese
propertiesaredifculttodistinguishbysight,andtheuse
ofreplacementpartswithhigherratings(ratedpower
andwithstandvoltage)doesnotnecessarilyguarantee
thatsafetyperformancewillbepreserved.Partswith
safetypropertiesareindicatedasshownbelowonthe
wiring diagrams and the parts list in this service manual.
Be sure to replace them with the parts which have the
designated part number.
(1) Schematicdiagrams.......Indicatedbythez mark.
(2) Partslists.......Indicatedbythezmark.
The use of parts other than the
designated parts could cause electric
shocks,resorotherdangerous
situations.
CAUTION Concerning important
safety parts
6

NOTE FOR SCHEMATIC DIAGRAM
WARNING:
Partsindicatedbythezmarkhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythemanufacturer.
CAUTION:
Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassisresistancecheck.
If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the
set is defective.
WARNING:
DONOTreturnthesettothecustomerunlesstheproblemisidentiedandremedied.
NOTICE:
ALLRESISTANCEVALUESINOHM.k=1,000OHM/M=1,000,000OHM
ALLCAPACITANCEVALUESAREEXPRESSEDINMICROFARAD,UNLESSOTHERWISEINDICATED.PINDICATESMICRO-MICRO
FARAD.EACHVOLTAGEANDCURRENTAREMEASUREDATNOSIGNALINPUTCONDITION.CIRCUITANDPARTSARESUBJECT
TOCHANGEWITHOUTPRIORNOTICE.
NOTE FOR PARTS LIST
1.Partsindicatedby"nsp" on this table cannot be supplied.
2.Whenorderingapart,makeacleardistinctionbetween"1"and"I"(i)toavoidmis-supplying.
3.Apartorderedwithoutspecifyingitspartnumbercannotbesupplied.
4.Partindicatedby" ★" mark is not illustrated in the exploded view.
WARNING:Partsindicatedbythezmarkhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythemanufacturer.
INSTRUCTIONS FOR HANDLING SEMI-CONDUCTORS AND OPTICAL UNIT
Electrostaticbreakdownofthesemi-conductorsoropticalpickupmayoccurduetoapotentialdifferencecausedby
electrostatic charge during unpacking or repair work.
1. GroundforHumanBody
Besuretowearagroundingband(1MΩ)thatisproperlygroundedtoremoveanystaticelectricitythatmaybe
chargedonthebody.
2. GroundforWorkbench
Besuretoplaceaconductivesheetorcopperplatewithpropergrounding(1MΩ)ontheworkbenchorothersurface,
wherethesemi-conductorsaretobeplaced.Becausethestaticelectricitychargeonclothingwillnotescapethrough
thebodygroundingband,becarefultoavoidcontactingsemi-conductorswithyourclothing
<Incorrect>
CBA
Grounding Band
Conductive Sheet or
Copper Plate
1MΩ
1MΩ
<Correct>
CBA
7

Personal notes:
8

TECHNICAL SPECIFICATIONS
nAudio section
• Power amplifier
Rated output :
Front：
140W+140W (8Ω, 20Hz - 20kHz with 0.05% T.H.D.)
175W+175W (6Ω, 1kHz with 0.7% T.H.D)
Center :
140W (8Ω, 20Hz - 20kHz with 0.05% T.H.D.)
175W (6Ω, 1 kHz with 0.7 % T.H.D.)
Surround :
140W+140W (8Ω, 20 Hz - 20 kHz with 0.05% T.H.D.)
175W+175W (6Ω, 1 kHz with 0.7 % T.H.D.)
Surround back / Height1 / Front wide / Height2:
140W+140W (8Ω, 20 Hz - 20 kHz with 0.05% T.H.D.)
175W+175W (6Ω, 1 kHz with 0.7 % T.H.D.)
Rated output :
160 W x 2-channel (8 Ω)
250 W x 2-channel (4 Ω)
Output connectors：4 - 16Ω
nAnalog section
Input sensitivity/Input impedance：200 mV/47 kΩ
Frequency response： 10 Hz - 100 kHz — +1, -3 dB(Direct mode)
S/N：102 dB(IHF-A weighted, Direct mode)
Distortion：0.005 % (20 Hz – 20 kHz) (Direct mode)
Rated output：1.2 V
nDigital section
D/A output： Rated output — 2 V (at 0 dB playback)
Total harmonic distortion — 0.008 % (1 kHz, at 0 dB)
S/N ratio — 102 dB
Dynamic range — 100 dB
Digital input：Format — Digital audio interface
nPhono equalizer section
Input sensitivity： 2.5 mV
RIAA deviation： ±1 dB (20 Hz to 20 kHz)
S/N： 74 dB (IHF-A)
Distortion factor： 0.03 % (1 kHz, 3 V)
nVideo section
• Standard video connectors
Input/output level and impedance： 1 Vp-p, 75 Ω
Frequency response：5 Hz – 10 MHz — 0, –3 dB
• Color component video connector
Input/output level and impedance： Y signal — 1 Vp-p, 75 Ω
PB / CB signal — 0.7 Vp-p, 75 Ω
PR / CR signal — 0.7 Vp-p, 75 Ω
Frequency response：5 Hz - 60 MHz — 0, -3 dB
nTuner section
Reception frequency range： F M 87.5 MHz - 107.9 MHz(for E3)
FM 87.5 MHz - 108.0 MHz(for E2, E1C)
AM 530 kHz - 1710 kHz(for E3)
AM 522 kHz - 1611 kHz(for E2, E1C)
Effective sensitivity：FM 1.5μV(14.8dBf)
AM 20 μV
50 dB sensitivity： MONO ― 2.8 μV (20.2 dBf)
S/N ratio (IHF-A)： MONO ― 78 dB
STEREO ― 68 dB
HD ― FM 85dB AM 85dB
Distortion (1 kHz)： MONO ― 0.1 %
SRETEO ― 0.2 %
HD ― FM 0.02% AM 0.02%
nWireless LAN section
Network type
(wireless LAN standard): Conforming to Wi-Fi®z1
Security： WEP 64 bit, WEP 128 bit
WPA/WPA2-PSK (AES)
WPA/WPA2-PSK (TKIP)
Radio frequency： 2.4 GHz
No. of channels： 1 - 11 ch (for E3)
1 - 13 ch (for E2, E1C)
z1 The Wi-Fi® CERTIFIED Logo and the Wi-Fi CERTIFIED On-Product
Logo are registered trademarks of the Wi-Fi Alliance.
nBluetooth section
Communications system： Bluetooth Version 2.1 + EDR
(Enhanced Data Rate)
Transmission power：Maximum 2.5 mW (Class 2)
Maximum communication range：Approx. 32.8 ft/10 m in line of sight
Frequency band：2.4 GHz band
Modulation scheme：FHSS (Frequency-Hopping Spread Spectrum)
Supported proles： A2DP 1.2 (Advanced Audio Distribution Prole)
AVRCP 1.4 (Audio Video Remote Control Prole)
Corresponding codec：SBC, AAC
Transmission range (A2DP)：20 Hz - 20,000 Hz
nGeneral
Power supply： (for E3) : AC 120 V, 60 Hz
(for E2) : AC 230 V, 50 Hz / 60Hz
(for E1C) : AC 220 V, 50 Hz
Power consumption：730W
Power consumption in standby mode：0.1W
Power consumption in CEC standby mode：0.5W
Power consumption in network standby mode：4.5W
For purposes of improvement, specications and design are subject to
change without notice.
DIMENSION
Unit： in. (mm) Weight： 31 lb 1 oz (14.1 kg)
17 1/8 (435)
9 21/64 (237)
2 11/64
(55)
2 3/4
(70)
19/32
(15)
5 63/64 (152) 6 37/64 (167)
9 1/4 (235)
13 11/32 (339) 15 15/32 (393)
55/64
(22)
15/32
(12)
1 17/64
(32)
13 35/64 (344)
2 23/64
(60)
1 51/64 (45.5) 1 51/64 (45.5)
9

PRECAUTIONS DURING SERVICE
Initializing This Unit
Initialize this unit if you have replaced the microcomputer, one of the parts around the microcomputer, or the digital PCB.
1. Press the power button to turn off the power.
2. Hold down buttons "CURSOR d" and "CURSOR f" at the same time and press the power button to turn on the power.
3. Release the buttons after conrming that the display ashes in intervals of approximately 1 second.
＊The unit is initialized.
NOTE：• If the status in step 3 does not occur, start again from step 1.
• Initializing the device restores settings congured by the user to the factory settings. Take note of your settings beforehand
and recongure them after initialization.
Service Jigs
The following jigs (extension cable kit) are used when repairing the PCBs.
Order the jigs from your dealer if necessary.
8U- 110084S : EXTENSION UNIT KIT : 2 Set
(See 77 page)
XCURSOR dCURSOR f
10

DISASSEMBLY
• Remove each part in the order of the arrows below.
• Reassemble removed parts in the reverse order.
• Read "Precautions During Work" before reassembling removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the
work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FLD PCB
(Ref. No. of EXPLODED VIEW : C1)
HP PCB
(Ref. No. of EXPLODED VIEW : C2)
HDMI USB FRONT PCB
(Ref. No. of EXPLODED VIEW : B2)
Bluetooth PCB
(Ref. No. of EXPLODED VIEW : E1)
TOP COVER
MAIN TRANS
See "DISASSEMBLY"
4. MAIN TRANS
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : 8)
RADIATOR ASSY
See "DISASSEMBLY"
2. RADIATOR ASSY
and "EXPLODED VIEW"
AMP PCB
(Ref. No. of EXPLODED VIEW : D)
R-AMP CONNECT PCB
(Ref. No. of EXPLODED VIEW : D1)
L-AMP CONNECT PCB
(Ref. No. of EXPLODED VIEW : D2)
RADI_PROTDET2 PCB
(Ref. No. of EXPLODED VIEW : D5)
BACK PANEL ASSY
See "DISASSEMBLY"
5. BACK PANEL ASSY
and "EXPLODED VIEW"
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : A)
AUDIO/VIDEO PCB
(Ref. No. of EXPLODED VIEW : B)
DAC PCB
(Ref. No. of EXPLODED VIEW : B1)
CONNECTOR-1 PCB
(Ref. No. of EXPLODED VIEW : B4)
CONNECTOR-2 PCB
(Ref. No. of EXPLODED VIEW : B5)
CONNECTOR-3 PCB
(Ref. No. of EXPLODED VIEW : B6)
CONNECTOR-5 PCB
(Ref. No. of EXPLODED VIEW : B8)
SPEAKER PCB
(Ref. No. of EXPLODED VIEW : C)
HL SPEAKER PCB
(Ref. No. of EXPLODED VIEW : C3)
232C POHNO PCB
(Ref. No. of EXPLODED VIEW : D4)
CX870 CONNECT PCB
(Ref. No. of EXPLODED VIEW : E)
CX870 MODULE
(Ref. No. of EXPLODED VIEW : 59)
SMPS PCB
See "DISASSEMBLY"
3. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
(Ref. No. of EXPLODED VIEW : D3)
11

Explanatory Photos for DISASSEMBLY
• The angles from which the photos are taken are shown by "Photo angle: A, B, C, D".
• See the diagram below about the shooting direction of each photograph.
• Photographs with no shooting direction indicated were taken from the top of the unit.
• The photograph is AVR-X5200WE3 model.
The viewpoint of each photograph
(Shooting direction:X)[View from the top]
Front side
Shooting
direction: D Shooting direction: C
↑Shooting direction: A↑
↓Shooting direction: B↓
12

1. FRONT PANEL ASSY
Proceeding : TOP COVER →FRONT PANEL ASSY
(1) Remove the screws.
(2) Remove the screws. Remove the STYLE PIN, HOLDER, FFC and connector wire.
View from the bottom
N6401
N901
N904
FFC FFC
STYLE PIN
HOLDER
13

2. RADIATOR ASSY
Proceeding : TOP COVER →FRONT PANEL ASSY →RADIATOR ASSY
(1) Remove the STYLE PIN and connector wire. Remove the screws.
(2) Remove the connector wire.
N5812 N5842
N5832 N5831
L-AMP CONNECT R-AMP CONNECT
STYLE PIN
L-AMP CONNECT R-AMP CONNECT
FHR
YELLOW
SBR
GRAY
SR
BROWN
FR
RED
FHL
YELLOW
SBL
GRAY
SL
BROWN
C
BLUE
FL
RED
N5824N5814
STYLE PIN N5842
14

3. SMPS ASSY
Proceeding : TOP COVER →FRONT PANEL ASSY →RADIATOR ASSY →SMPS ASSY
(1) Remove the screws.
(2) Cut the wire clamp, then remove the connector wires.
Shooting
direction: C
↑Shooting direction: A↑
N6502
N6501
CUT
15

4. POWER TRANS
Proceeding : TOP COVER →FRONT PANEL ASSY →RADIATOR ASSY →SMPS ASSY →POWER TRANS
(1) Remove the screws. Remove the HOLDER.
(2) Remove the STYLE PIN and connector wire.
HOLDER
N6201
N6012
N9022
STYLE PIN
STYLE PIN
16

5. BACK PANEL ASSY
Proceeding : TOP COVER →FRONT PANEL ASSY →RADIATOR ASSY →SMPS ASSY →POWER TRANS
→BACK PANEL ASSY
(1) Remove the screws.
Shooting
direction: D Shooting direction: C
↑Shooting direction: A↑
17

SPECIAL MODE
Special Mode Conguration Buttons
b No. 1 - 12, 15 : Hold down buttons "A", "B" and "C" at the same time and press the power button to turn on the power.
b No. 13, 14: Hold down buttons "A" and "B" for at least 3 seconds while the power is on.
b No. 16 ： Press the "A" and "B" buttons simultaneously while inserting the AC plug to turn the power on.
No. Mode Button A Button B Button C Contents
1Version Display Mode
(u-COM / DSP Error Display) SETUP OPTION -
Displays the version of rmware such as the main rmware or DSP,
etc. Errors that have occurred are displayed.
(See 19 page)
2
User Initialization Mode
(Settings for the Installer Setup are not
initialized.)
BACK INFO - Initializes backup data.
(Settings for the Installer Setup are not initialized.)
3
Factory Initialization Mode
(Initialization includes settings for the
Installer Setup.)
CURSOR
d
CURSOR
f-Initializes backup data.
(Initialization includes settings for the Installer Setup.)
4PANEL / REMOTE LOCK Selection Mode STATUS INFO -
Start this unit in the PANEL/REMOTE LOCK selection mode so that
PANEL LOCK and Remote Lock can be selected as ON or OFF.
(See 23 page)
5Check the Video/Audio pass
Mode STATUS ZONE3
SOURCE -
This is a special mode for service conrmation used during repair
work to simplify the conrmation work for the Audio channel/video
channel.
(See 27 page)
6Protection History Display Mode ↑ ↑ - Displays the protection occurrence history.
(See 70 page)
7232C Standby Clear Mode ↑ ↑ - Switches from 232C standby mode to normal standby mode.
(See 71 page)
8Operation Info Mode ↑ ↑ -
Displays the total operating time of the set, number of times
the power was switched on, and number of occurrences of each
protection.
(See 72 page)
9TUNER STEP Mode
(E3 and E2 model only) ↑ ↑ - Enables reception STEP of the ANALOG TUNER to be changed. (See 73 page)
10 Remote ID Setup Mode ↑ ↑ -
If there are multiple DENON AV receivers in the same area, this mode
stops the other AV receivers from being operated concurrently with
this device.
(See 74 page)
11 Installer Setup Mode CURSOR
0BACK -
Access the Remote Maintenance mode via the internet.Installer Setup
is displayed on Setup menu / Network.
b Refer to AVR_RemoteMaintenance_.pdf of SDI.
12 Protection Pass Mode CURSOR
0STATUS ZONE3
SOURCE
Enables the power to be turned on when protection detection is in
the stopped state.
(See 75 page)
13 CX870 / CY920 Reboot Mode DIMMER SETUP -Restarts CX870 / CY920. (See 75 page)
14 CX870 / CY920 Initialization Mode DIMMER CURSOR
1-Enter this mode only after replacing Flash for CX870 / CY920 and
rewriting the rmware. (See 76 page)
15 USB Update Mode STATUS OPTION - Switches this unit to USB Update mode.
(See 79 page)
16 Forced USB All Device Write Mode STATUS OPTION -
Mode used when this unit cannot be recovered.
Forcibly switches this unit to USB update mode.
(See 81 page)
NOTE :
When the volume indicator displays " ", the set has entered a special mode for developers. In this case, RS-232C communication
cannot be used.
To cancel this special mode, press and hold the "CURSOR f"and "STATUS" buttons for 3 seconds and longer. When the volume indica-
tor returns to the normal display, RS-232C communication can be used.
X
ZONE3
SOURCE
d
0 1
STATUS DIMMER
INFO OPTION
SETUPBACK f
18

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
Hold down buttons "SETUP" and "OPTION" at the same time and press the power button to turn on the power.
Press the "OPTION" button after this to show the information in section 1.3 on the display.
b A version list is also displayed on GUI while the version appears on the display.
1.3. Display Order
Error information(See "1.4. Error display") → q Model destination information, Serial Number
→ w Firmware Package Version → e Main µ-com, Main 1st Boot Loader Version
→ r Sub µ-com, Sub 1st Boot Loader Version → t DSP1/2/3/4 ROM → y Audio, Video PLD → u GUI SFLASH
→ i Ethernet 1st Boot Loader, Hardware ID → o Ethernet 2nd Boot Loader, Rhapsody Flag → Q0 Ethernet IMAGE
→ Q1 Ethernet MAC ADDRESS information → Q2 BT MAC ADDRESS information → Q3 HD Radio(E3 only)
→ Q4 MultEQ Pro APP (Displayed when Audyssey Pro is complete) → Q5 MultEQ Pro ICL (Displayed when Audyssey Pro
is complete)
q Model destination information, Serial Number :
FLD L1 AVR-X5200W E3 *Case of CX870 : Display "*" at the end
FLD L1 AVR-X5200W E2 *Case of CX870 : Display "*" at the end
FLD L1 AVR-X5200W E1C *Case of CX870 : Display "*" at the end
FLD L2 S/N. **********
w Firmware Package Version :
FLD L1 Firm. Package
L2 Ver.:****
e Main µ-com, Main 1st Boot Loader Version :
FLD L1 Main :**.***Case of CX870 : Display "*" at the end
L2 Main FBL :**.**
r Sub µ-com, Sub 1st Boot Loader Version :
FLD L1 Sub :7110****
L2 Sub FBL :**.**
t DSP1/2 ROM :
FLD L1 DSP1 :**.**
L2 DSP2 :**.**
DSP3/4 ROM :
FLD L1 DSP3 :**.**
L2 DSP4 :**.**
y Audio, Video PLD :
FLD L1 Audio PLD:**.**
L2 Video PLD:**.**
19

u GUI SFLASH :
FLD L1 GUI :701Z****
L2
Z
：
Region code(E3/E2=1, E1C=5)
i Ethernet 1st Boot Loader, Hardware ID :
FLD L1 Ethernet FBL
L2 ******-AA
AA:Hardware ID
o Ethernet 2nd Boot Loader, Rhapsody Flag :
FLD L1 Ethernet SBL
L2 *************-BB
Q0 Ethernet IMAGE :
FLD L1 Ethernet IMG
L2 *************
Q1 Ethernet MAC ADDRESS information :
FLD L1 *NET MAC Address
L2 *******-*****
Q2 BT MAC ADDRESS information :
FLD L1 *BT MAC Address
L2 ******-*****S
Q3 HD Radio :
FLD L1 *HD :SSSSSSSS-
L2 RVVVV.BBB
S:Software Congration, R:Release Type, V:Base Version No., B:Build No.
Q4 MultEQ Pro APP :
FLD L1 *MultEQ Pro APP
L2 **.**.**.****
Q5 MultEQ Pro ICL :
FLD L1 *MultEQ Pro ICL
L2 **.**.**.****
20
