Depco 200 Series User manual

200 Series
1-800-767-1062  www.depcoinc.com
211: Drafting Table LH Instructions
Step 1:
Remove all parts from the box. La the Back Panel
on the floor. Note: You ma want to la some
scrap pieces of wood under the Back panel to keep
from scratching it on the floor.
Attach the Left Leg to the Back Panel using the
assembl fittings.
Step 2:
Attach the Middle Leg to the Back Panel using the
assembl Fittings
Hardware List:
Qty. Item
1 Power Strip with four screws
2 Grommets
1 1¼ Screw
Ke s
Step :
Attach the Right Leg to the Back Panel using the
assembl fittings
Step 4:
Attach Bottom Shelf to the Middle and Left Legs
using the assembl fittings
Turn cam lock 1/2 turn in
the clockwise direction
Thank ou for purchasing our DEPCO Technolog
Lab Furniture! If ou need further assistance, please
call 1-800-767-1062.

200 Series
1-800-767-1062  www.depcoinc.com
211: Drafting Table LH Instructions
Step 5:
Attach the Toe Kick to the Middle Leg, Le t Leg and
the Bottom Shel using the assembly ittings.
Step 6:
Attach the Stile to the Middle and Le t Legs using
the assembly ittings.
Step 7:
Stand the Dra ting Table in the upright position.
Place the Top on the assembly and attach using the
assembly ittings
Step 8:
Insert the Drawer into the Dra ting Table
Step 9:
Insert the Keyboard tray into the Dra ting Table.
Note: It may be hard to push the tray in or the
irst time this is because it needs to set the slide
into the bearings.
Step 10:
Attach the door to the Le t Side.
Place the ront o the hinge over the hinge plate
irst then push on the back o the hinge until it
snaps into place.

We give experiences.
PO Box 176 | 3305 Airport Dr. | Pittsburg, KS 66762 | 1-800-767-1062 | F x: 316-231-0019 | s [email protected]
200 Series
1-800-767-1062  www.depcoinc.com
211: Drafting Table LH Instructions
Step 11:
Pl ce the 3/16 pins in the Monitor Pl tform into
the holes in the upper left corner of the Top. Insert
1 1/4 screw from the bottom through the hole in
the top into the Monitor Pl tform to hold it securely
in pl ce. Do Not Over Tighten.
Step 12:
Insert Grommets into the holes in the Middle Leg
nd the B ck P nel
Att ch the Remote Power Strip to the left side of the
Middle Leg using the 4 screws supplied in the
H rdw re P ck.
