Derksen PHOS downlight 25 Operating instructions
▶
The projector must now be connected electrically (see
sec�on 4.2). Subsequent connec�on is possible only if
there is a separate access point.
The arrangement of the cylinder head screws for xing
allows installa�on of the projector assembly in three
dierent posi�ons. Take this into considera�on when
aligning the projector head (see sec�on 5.2).
▶
▶
▶
(Make sure to only hold the gobo by the sides when in-
ser�ng it into the holder.)
A. Mirror side: The coated side of the gobo. The mirror
side faces the light source.
B. Dark side: The dark side of the coa�ng can be seen
through the glass. The dark side faces the lens.
▶
▶
▶
