ViewSonic PRO8500 User manual

The ViewSonic®Pro8500 is an advanced high brightness DLP®installation
projector which includes BrilliantColor™technology to produce more
vibrant colors. The Pro8500 delivers 5000 lumens with a 1024x768 XGA
native resolution, allowing it to shine in virtually any lighting situation.
The Pro8500 provides maximum mounting flexibility with a wide 1.5X
optical zoom adjustment and a multitude of connectivity options including
Network Display, USB, and WiFi. The filter-less design and long lamp life
provide for easy maintenance and low total cost of ownership.
Brilliant and 3D-ready.
Pro8500
NETWORKABLE HIGH
BRIGHTNESS PROJECTOR
120HZ AND 3D-READY
SHINE BRIGHT, ANYWHERE
Network control through RJ-45>
Schedule, manage and monitor the projector remotely
and receive e-mail alerts of projector lamp status.
Bright in virtually any setting with 5,000 lumens>
Ultra-bright 5,000 lumen output makes this the perfect choice
for large boardrooms, conference halls and auditoriums
BrilliantColor>™technology
Latest BrilliantColor technology delivers stunning all-digital
clarity with life-like color, sharp graphics and outstanding video.
The sophisticated 6-segment color wheel enhances the yellow
color performance that is key to accurate and vivid color
reproduction.
Closed captioning>
Integrated closed captioning decoder for the hearing impaired.
Give Greener presentations and save>
Use the Eco mode to achieve lower power consumption,
reduce overall noise and extend lamp life.
Stay connected>
Supports multiple video timing formats from
SD (NTSC, PAL & SECAM) to HD 1080p.

Optional Accessories
> Replacement Lamp RLC-059
> Universal Ceiling Mount Kit WMK-005
> Wireless G Presentation Gateway WPG-360
> Extended Express Exchange®PRJ-EE-08-03
Sales: [phone] . [email protected] . ViewSonic.com
*Running eco-mode exclusively can extend lamp life. See ViewSonic.com for full Express Exchange details. Specifications and availability subject to change
without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks
stated herein are the property of their respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved [15134-00B-07/10] Pro8500-1
Projection
Distance
4:3 Aspect
M
1.5
1.8
2
3
5
10
DISPLAY Type 0.7" Digital Micromirror Device (DLP™)
Resolution XGA 1024x768 (Native)
Lens 1.5× Manual optical zoom / Manual optical focus
Keystone Vertical digital keystone correction: +/– 40 degrees
Size 30"–300" / 0.76m–7.6m
Throw Distance 1.2m–10m / 3.9ft–32.8ft
Throw Ratio 1.45 – 2.18:1
Lamp 280 watt
Lamp Life (Normal / Eco-mode) 4000 / 5000* hours
Brightness 5000 Lumens
Contrast Ratio 2000:1 (typ), 3000:1 (dynamic)
Aspect Ratio 4:3 (native) and 16:9
Color Gamut 90% NTSC 1931 CIE
INPUT SIGNAL Computer and Video NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N,
60), SECAM (B, D, G, K, K1, L), SD 480i and 576i (24fps,
25fps and 30fps), ED 480p and 576p (24fps, 25fps and
30fps), HD 720p, 1080i and 1080p (24fps, 25pfs and 30fps)
Frequency Fh: 31–100KHz, Fv: 48–120Hz
COMPATIBILITY PC VGA to UXGA
Mac®Up to UXGA (scaled)
CONNECTOR RGB Input 15-pin mini D-sub (x2)
RGB Output 15-pin mini D-sub
Digital Input HDMI 1.3
Component RCA (x3)
Composite Input RCA jack
S-video Input 4-pin mini-DIN
Audio Input 3.5mm mini jack
Audio Output 3.5mm mini jack
Control RS-232 (8 Pin Mini-Din)
Network RJ-45
AUDIO Speaker 10W (x2)
POWER Voltage 90~240VAC (Auto Switching), 50/60Hz (universal)
Consumption 350W (typ) / <1W (stand-by mode)
CONTROLS Basic Power, keystone/arrow keys, left/blank, menu/exit,
right/panel key lock, auto, mode/enter, source
OSD Picture: Brightness, Contrast, Color Setting, Keystone,
Aspect Ratio, Image, White Intensity, Gamma, 3D Sync, 3D
Sync invert
Computer Image: Frequency, Tracking, H Position, V Position
Video Image: Saturation, Sharpnes, Tint
Setting: Manual Position, Projection, Signal Type, Lamp
Hour, Lamp Hour Reset, Filter Mode, Filter Hours, Filter
Hours Reset, Power Saving, Auto Source, Eco-mode, High
Altitude, OSD Timeout
Advance: Blank Screen, Password Word, Screen Capture,
Start up Screen, Text Shot, Digital Zoom, DCR, Close
Captions, Brilliant Color,
OPERATING Temperature 32ºF–104ºF (0ºC–40ºC)
CONDITIONS Humidity 10%–80% (non-condensing)
Altitude 0~6,000 ft (1,800m), operational up to 10,000 ft (3048m)
NOISE LEVEL Normal / Eco-mode 32dB / 27dB
DIMENSIONS Physical 13.1 × 4.8 × 10.4 (in) / 332.7× 121.9 × 264.2 (mm)
(W x H x D) Packaging 16.3 × 7.5 × 14.8 (in) / 414 ×190.5 × 375.9 (mm)
WEIGHT Net 8.5 lb (3.86 kg)
Gross 11.8 lb (5.36 kg)
REGULATIONS CB, RoHS, SVHC, WEEE, UL/cUL, FCC-B, ICES-004, TUV-S
(Argentina), NOM, PSB, C-tick, KC, CE, GOST-R, Hygienic,
UKrSEPRO, CCC
PACKAGE CONTENTS ViewSonic projector, power cable, VGA cable, remote
control/laser with batteries, lens cap, Quick Start
Guide, ViewSonic Wizard DVD (with User Guide)
WARRANTY 3-year limited warranty on parts, 1-year limited warranty
on lamp, 1st year Express Exchange®service.
For more product information, visit us on the web at ViewSonic.com
Pro8500
NETWORKABLE HIGH BRIGHTNESS PROJECTOR – 120HZ AND 3D-READY
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
Feet
4.92
5.90
6.56
9.84
16.40
32.80
Wide Tele
Inches
47.8
57.4
63.7
95.8
159.5
319.0
Inches
31.8
38.1
42.4
63.7
106.0
212.1
M
1.22
1.49
1.62
2.44
4.05
8.11
M
0.81
0.97
1.08
1.61
2.69
5.39
