Derksen PHOS 45 move User manual
(Note: This makes the corresponding connec�on ter-
minal accessible if you want to connect your own sup-
ply cable instead of using the already installed mains
plug. Cf. 4.2. Connec�ng your own power supply)
▶
▶
▶
▶
(Make sure to only hold the gobo by the sides when in-
ser�ng it into the holder.)
A. Mirror side: The coated side of the gobo. The mirror
side faces the light source.
B. Dark side: The dark side of the coa�ng can be seen
through the glass. The dark side faces the lens.
▶
▶
(Note: With the eect module circular mo�on mirror, the
mirror can be �lted by 10°. The greater the inclina�on, the
larger the radius of movement for the projec�on)
(Note: There is a mechanical stop to limit the projec-
tor head’s rota�on and prevent damage to the cable.
Do not �lt or rotate the projector head without pre-
viously loosening the countersunk screw.)
