DERUIZ QUARTZ User manual

www.deruizebike.com
User manual

QUARTZ

Go Further, Born to Ride
with Deruiz Electric Bikes
User Manual

QUARTZ

Using This Manual
This manual contains detailed information about the product and its equipment, as well as
information about the operation, maintenance and other valuable tips for the owner. Please
read it carefully and familiarize yourself with the ebike before use to ensure safe use and
prevent accidents. This manual contains many warnings and cautions regarding safe opera-
tion and the consequences if proper setup, operation and maintenance are not performed.
All information in this manual should be read carefully and if you have any questions, con-
tact DERUIZ immediately.
This manual and any other documents accompanying the ebike should be retained for
future reference, Still all contents of this manual are subject to change without notice.
NOTICE: This manual is not intended to be an extensive reference book about service, maintenance
and / or repairs. Please consult your dealer for service and technical support. You can find more infor-
mation about our products or find a dealer via www.deruizebike.com.

General Information -------------- 1
1.1. Frame Components ----------- 1
1.2. Size & Specification ----------- 2
1.3. PAS & Throttle ----------------- 4
Assembly -------------------------- 5
2.1. What’s in the box -------------- 5
2.2. Assembly Process ------------- 6
Apps & Display -------------------- 14
3.1. App Download ---------------- 14
3.2. Finger-tip Control ------------- 15
3.3. Display Instructions ---------- 16
Battery --------------------------- 22
4.1. Battery Information---------- 22
4.2. Battery Charging------------- 23
4.3. Battery & Charger
Safety Warning -------------- 24
Warranty ------------------------- 26
5.1. Simple fault phenomenon
and elimination -------------- 26
5.2. Covered & Non-Covered----- 28
5.3. Warranty Information ------- 33
CONTENTS
1
2
3
4
5

Allgemeine Informationen --------- 39
1.1. Komponenten des Rahmens --- 39
1.2. Größe & Spezifikation ---------- 40
1.3. PAS & Drosselklappe ----------- 42
Montage ---------------------------- 43
2.1.Was sind im Koer(Lieferungsum
fang) ---------------------------- 43
2.2. Montageprozess --------------- 44
Apps & Display -------------------- 52
3.1. App-Download ---------------- 52
3.2. Fingerspitze Kontrolle --------- 53
3.3. Display - Anweisungen ------- 54
Battrie ----------------------------- 60
4.1. Battrie Information------------- 60
4.2. Battrie Auflanden-------------- 61
4.3. Sicherheitswarnung für Batterie
und Ladegerät---------------- 62
Garantie --------------------------- 64
5.1. Einfache Fehlererscheinung und
beseitigung-------------------- 64
5.2. Gedeckte und nicht gedeckte
Garantie----------------------- 66
5.3. Garantie Information---------- 71
INHALT
1
2
3
4
5

1. General Information
1.1. Frame Components
Display
Supension Fork
Rear Rack
Derailleur
Kickstand
Cranks
Pedal
Saddle
Seat Post
Battery
Handlebar
Front Light
1

1.2. Size & Specification
2
Wheelbase
Top Tube Horizontal
Reach
Head Tube
Chainstays
Stack
Seat Tube
Head Tube Angle
Seat Angle
BB-Height to Hub
Seat Tube
Top Tube Horizontal
Seat Angle
Head Tube Angle
Chainstays
Head Tube
Wheelbase
BB-Height to Hub
Reach
Stack
440mm
590mm
72.4mm
69mm
457mm
170mm
1157.4mm
50mm
421mm
659.8mm

Motor 48V 250W Rear Hub
Battery 48V13.4Ah
Charger 48V2A EU DC2.1
Display LCD with Bluetooth
Controller 48V 15A 6 Tube
Head Light 50LUX LED 6-48V
Rear Light LED 6-48V
Max Riding Weight
Max System Weight
130KG
150KG
Frame ALLOY 6061 XS 45cm
Fork SUNTOUR NEX Air 63mm Lockout
Brake TEKTRO 180 Aries
Derailleur Shimano ALTUS 8-speed
Flywheel 11-32T 8-speed
Sadde Selle Royal
Crank Set 42T 170mm
Rear Rack
Tyre
ALLOY 6061 Max 25KG
SCHWALBE Big Ben 28*2.0"
3

1.3. PAS & Throttle
Due to the powerful support of the motor, you can to reach high speeds faster than when
riding a conventional bicycle. To get used to this, we advise using the e-bike in a familiar
setting without too much trac in the surrounding area when riding it for the first time.
With throttle on demand, you can use the throttle from a complete stop, rather than pedal
first, which can help when riding up steep hills or through an area with lots of stop signs.
However, we generally recommend always pedaling first and then using the throttle wherev-
er possible to ensure stability.
The throttle should provide smooth acceleration when gradually applied. If the throttle,
brake lever, pedal assistance, or lighting is functioning abnormally, intermittently, or not
working, please stop using your ebike immediately.
When switching o pedal assistance the ebike can still be used as a regular bike. However,
be aware that the lights of the ebike will not work when riding around without using the
battery.
When you start biking, be aware of the electricity the motor will instantly provide. We advise
using the lowest power level when riding for the first time.
4

2. Assembly
2.1. What’s in the box
15
13
10
8
5

2.2. Assembly Process
1: Cut the wire harness on the tire, take out the front wheel, pay attention to the crank, and take it out diagonally.
2: Unwrap all harnesses: be careful not to puncture the tires or scratch the paint.
6

Adjust the front fork angle, rotate 180°.
a. b.
7

Use the 5mm allen wrench to remove the four screws on
the stem counterclockwise.
Put the handlebars in place and tighten the four screws
(not too tight, still needs to adjust).
c. d.
e.
8
