USER GUIDE TB-9016
718 Static Sensor
Installation, Operation and Maintenance
Made in the
United States ofAmerica
7. The SCS Static Sensor 718 has a Low Battery
indicator. Once the battery is depleted to
approximately 6.5 volts, the instrument will show
BAT in the display. At this time, the Static Sensor
718 will not produce accurate results and thebattery
should be replaced.
8. The SCS Charger 718A also has a low battery
indicator. This is an LED located at the left-hand side
of the unit. When the battery voltage drops below
operating level, the LED will light up. At thistime,
the user should replace the battery. Usage of the
Charger 718A under low battery conditions would
lead to insufficient voltage levels being generated.
Figure 1. (Left to right) SCS 718 Static Sensor and SCS
718A Air Ionizer Test Kit.
Description
The SCS Static Sensor 718 is a portable handheld
instrument used for locating and measuring electrostatic
charges. It can be used to locate ESD trouble-areas,and
is a valuable tool for the ESD-control engineer. Used in
conjunction with the SCS Air Ionizer TestKit 718A (sold
separately), it can be used for verification and auditing
of air ionizers. The Static Sensor 718 is battery-powered
and has several measurement features:
Range: measurements can be taken in a 0 to ±1.999 kV
or 0 to ±19.99 kV range.
Automatic Zero: push button feature allows easy
adjustment to zero. No screws or dials to turn.
HOLD function: allows the User to “freeze” a displayed
measurement, for later evaluation.
Automatic shutoff: conserves battery power by shutting
off the instrument after 20 minutes of inactivity.
Power Requirements and Battery Installation
1. Both the Static Sensor 718 and SCS Charger 718A
use a 9V alkaline battery.
2. Toinstall the battery on either unit:
3. Remove the battery cover, located in the lowerback
of the unit. Todo this, press down on the cover and
slide it downward.
4. Pull the battery connector out of the housing, and
align the male/female ends of the connector with the
proper terminals on the battery.
5. Connect the two and place the connected battery
into the housing by inserting the connector end first,
then following up with the other end of the battery.
6. Replace thecover.
Figure 2. SCS 718 and 718A Battery Replacement
and Indicators.
Operation of the Static Sensor 718
For accurate measurements during usage, it is
recommended that the outside housing of the Static
Sensor 718 be connected to an electrical ground.
This can be accomplished by having the user holding
the instrument connected to ground through either a
static control wrist strap, or while wearing static control
footwear. The enclosure of the Static Sensor 718 is
made of conductive plastic and is, therefore, electrically
connected to whomever is holding the instrument. In
addition, ground for the instrument can be provided
through the Voltage Monitor Output on the front of the
case.
The SCS Static Sensor 718 is a precision electronic
instrument. Improper use or rough treatment can
damage the unit, and render it incapable of providing
accurate measurements.
Turning the unit ON and OFF: To turn on the Static
Sensor 718, momentarily press down on the membrane
switch labeled POWER. Determining that the power
is on can be verified by seeing that the liquid crystal
display (LCD) is on, and that the red light-emitting diodes
in the front of the sensor are lit.
SCS - 926 JR Industrial Drive, Sanford, NC 27332
East: [phone] | West: [phone] • Website: StaticControl.com
TB-9016 Page 1 of 6 December 2016
© 2016 DESCO INDUSTRIES, INC.

TB-9016 Page 2 of 6
© 2016 DESCO INDUSTRIES, INC.
Employee Owned
To shut off the Static Sensor 718, momentarily press
down on the membrane switch labeled POWER.
Determining that the power is off can be verified by
seeing that the liquid-crystal display (LCD) is off.
Making Electrostatic Voltage Measurements: hold
the instrument 1-inch (2.54 cm) away from the object
being measured. The display will update with the voltage
measurement in kilovolts. If the measured voltage is
greater than the measurement range of the instrument,
a -1. Will be displayed. At this time, switch to a greater
range. If over-ranging occurs even with the high range
activated, the static charge on the object cannot be
measured with the Static Sensor 718.
Figure 3. Using 718 Static Sensor to take measurements.
Measurement Range: all measurements are in kilovolts
(kV) as stated on the front label of the unit. The Static
Sensor 718 has two measurement ranges: 0 to ±1.999
kV and 0 to ±19.99 kV. The unit’s current measurement
range mode can be verified by checking the display.
Three digits following the decimal point indicate that the
unit is in 0 to ±1.999 kV range. Two digits following the
decimal point indicate that the sensor is in 0 to ±19.99
kV range. To change between measurement ranges,
press the RANGE/HOLD button once, momentarily.
HOLD Function: in the event that the user wishes to
freeze the current measurement, the HOLD function of
the Static Sensor 718 may be used. Simply press the
HOLD switch momentarily and the currently displayed
voltage will be frozen. A HOLD notice will also be
displayed to alert the user that the instrument is currently
in HOLD status. To unfreeze the display and return to
floating measurement, momentarily press the HOLD
switch once again.
Note: During HOLD condition the distance indicating
LED’s are turned off.
Zero Adjustment: the SCS Static Sensor 718 has a
zero adjustment function, which sets a zero reference
point for all subsequent measurements. This zero
reference can be set by pointing the instrument at a
known zero-voltage surface, and holding down the
RANGE/ZERO button for longer than 3 seconds. After
3 seconds, the display will flash and adjust to zero.
Repeat this step for both the low and the high ranges.
The zero adjustment should be performed every time the
unit is turned on.
Measurement Accuracy: Distance Indicator: the
Static Sensor 718 is factory calibrated to give accurate
measurements when it is placed one inch (2.54 cm)
away from the object to be measured. To assist the
user in gauging this distance, two light-emitting diodes
(LED’s) are present on the front face of the instrument.
These LED’s emit two red, bull’s-eye targets on the
surface of the object being measured. As the instrument
gets closer to the one inch measurement distance, the
bull’s-eyes begin to converge. When they converge
and become one, the instrument is approximately one
inch away, and the measurement can be made. For
more accurate measurements, it is recommended that
the user manually measure the distance between the
front housing of the instrument and the object being
measured.
Accuracy and Size of Object to be Measured: the
minimum surface area on an electrostatically charged
object which can be accurately measured is a 5 square
inch (32.3 cm2) area.
Measurements from Greater than One Inch (2.54 cm)
Away: in the event that a one inch separation between
object-to-be measured and the Static Sensor 718 cannot
be achieved, it is possible to get approximate readings.
Continuous Output: an output jack is provided on
Figure 5. 718 Static Sensor has a continuos output range.
the front of the SCS Static Sensor 718. This output
can be used to feed a continuous signal into a data
storage device for continuous monitoring of measured
voltages. Please use a 3/32 inch (2.5 mm) mono-phone
plug to connect into the output jack. The output signal
is dependent on the measurement range currently
selected. For the low range, the output signal is 1/1000
of the measured electrostatic voltage. For the high
range, the output signal is 1/10,000 of the measured
voltage.
Figure 4. 718 Static Sensor showing hold function and
floating measurement function. SCS - 926 JR Industrial Drive, Sanford, NC 27332
East: [phone] | West: [phone] • Website: StaticControl.com

TB-9016 Page 3 of 6
© 2016 DESCO INDUSTRIES, INC.
Employee Owned
Automatic Shut-Off: the Static Sensor 718 will
automatically shut-off 20 minutes after the last switch
activity. This is done in order to conserve battery power.
In the event that the user needs to have the unit stay ON
continuously, when turning the unit on press thePOWER
AND RANGE switches simultaneously. This deactivates
the Automatic Shut-Off feature. The BAT indicator will
then flash three times to indicate that the automatic shut-
off features has been disabled. The Automatic Shut-Off
feature will reset itself the next time the instrument is
turned on.
Operation and Use of SCS Air Ionizer
Kit 718A
It is recommended that the user be familiar with ionizer
test standards ANSI/ESD S3.1 and draft standard ANSI/
ESD SP3.3 if the Air Ionizer Test Kit 718A is used to
perform verification testing on ionizer performance.
Assembly: slide the charge plate over the Static Sensor
718 until it stops. The charge plate slides onto the lower
groove, on the sides of the Static Sensor 718.
Figure 6. 718 Static Sensor charging plate in use.
Charging the Plate: holding the Static Sensor 718 (with
charge plate attached) in one hand, use the other hand
to touch the probe of the SCS Air Ionizer Test Kit 718A
to the charge plate. Press either the + button (for a
positive voltage) or the –button (for a negative voltage),
then remove the probe from the charge plate. Be sure
to keep the button pressed while removing the probe
from the charge plate. The display on the Static Sensor
718 will indicate a positive or negative charging voltage
(1.1kV minimum). If a voltage of less than ±1.1kV is
displayed, check to see if the low battery indicator on
the SCS Charger 718A is illuminated. If illuminated,
replace the battery in the charger. If the unit continues
to supply an incorrect voltage to the charge plate,
please contact SCS for additional instructions.
Testing ionizer discharge time: after charging the plate,
hold the SCS Static Sensor 718 approximately one foot
(30.5 cm) away from the ionizer. Monitor the display to
see how quickly the 1.1 kV charge is dissipated to 0.1
kV. The speed at which this occurs (the discharge time)
indicates how well the ionizer is operating. Please refer
to the specific ionizer’s operating manual or consult
with the ionizer manufacturer to determine whatthis
discharge time should be. Repeat this procedure for both
a positively and a negatively charged plate.
Figure 7. Testing Ionizer Offset Balance.
Testing Ionizer Discharge Time: after charging the
plate, hold the SCS Static Sensor 718 approximately one
foot (30.5 cm) away from the ionizer. Monitor the display
to see how quickly the 1.1 kV charge is dissipated to
0.1 kV. The speed at which this occurs (the discharge
time) indicates how well the ionizer is operating. Please
refer to the specific ionizer’s operating manual or consult
with the ionizer manufacturer to determine what this
discharge time should be. Repeat this procedure for both
a positively and a negatively charged plate.
Testing ionizer offset balance: zero the charge plate
by touching it with a grounded object. This can either
be the finger of a grounded person or some other item
which is connected to electrical ground. In either case,
zeroing the charge plate should make the display on the
Static Sensor 718 read zero. Hold the Static Sensor 718
approximately one foot (30.5 cm) in front of the ionizer.
Monitor the display. The value displayed is the offset
balance of the ionizer, which is the difference between
the number of positive and negative ions being emitted.
Please refer to the specific ionizer’s operating manual or
consult with the ionizer manufacturer to determine what
this offset balance should be.
Service/Calibration
Service and Repair: in the event that you believe the
Static Sensor 718 or the SCS Air Ionizer Test Kit 718A
is in need of repair, please contact your local SCS
representative for troubleshooting help, and, as needed,
repair information. There are no user-serviceable parts
on either product.
Figure 8. 718 Static Sensor on test fixture.
SCS - 926 JR Industrial Drive, Sanford, NC 27332
East: [phone] | West: [phone] • Website: StaticControl.com

TB-9016 Page 4 of 6
© 2016 DESCO INDUSTRIES, INC.
Employee Owned
Calibration: the SCS Static Sensor 718 and SCS Air
Ionizer Test Kit 718A products are supplied by the
factory pre-calibrated. SCS does not specify a minimum
calibration cycle for the Static Sensor 718 or Air Ionizer
Test Kit 718A products. The user, usually according
to internal Quality procedures, determines calibration
cycles. In the event that the user wishes to perform a
self-calibration, the following steps should be followed
for the Static Sensor 718 (user-calibration not possible
on the Air Ionizer Test Kit 718A).
SCS Static Sensor 718 Specifications
(All values typical)
(At 1in. (2.54cm) distance from sensor to target)
Dimensions .94" H x 2.75" W x 4.94" L
(24 mm H x 70 mm W x 126 mm L)
Weight 4.9 oz. (140 g) withbattery
Equipment Needed: Test Fixture High-Voltage Power
Supply, capable of supplying voltages up to 10,000V.
Voltmeter, with > 50 kilohms input impedance, capable
of measuring voltages down to the μV range. Cable
with a 3/32 inch (2.5 mm) mono plug and secondary
connector to interface with voltmeter.
Test Fixture: Metal plate of at least 5 square inches
Operating
Conditions 50ºF to 86ºF (10ºC to 30ºC) Up to 80% RH, non-condensing
Indoor use only
For use at altitudes below 6,562 ft.
(2,000 m).
Pollution Degree II Class III
area (38.7 cm2) area. Metal stand capable of supporting
Static Sensor 718, and holding it one inch (2.54 cm) Enclosure Conductive Housing
away from the metal plate, centered. Connectors on the
plate with which it can interface with the high voltage
power supply. Connections on the metal stand with
which it can be connected to electrical ground.
Procedure: Place the Static Sensor Static Sensor
718 on the metal stand. Verify that it is exactly one
Power
Requirements
Measurement
Ranges
One (1) 9-volt alkaline battery
Low Range: 0 to ±1.999 kV / inch
High Range: 0 to ±19.99 kV / inch
inch (2.54 cm) away from the metal plate, and that its
position is centered relative to the plate. Connect the Voltage Display Liquid Crystal Display
stand to ground. Turn on the Static Sensor 718 and set
it to the low range. Ground the plate. Zero the display.
Remove the ground from the plate, and connect it to the
high voltage power supply. Apply a 1 kV charge to the
plate.
The instrument should now be reading 1.000. If it is not,
remove the battery door and use a screwdriver to turn
the small screw located inside the battery compartment.
Use a small screwdriver to turn the small screw, located
on the front right side of the instrument. This screw
Display
Resolution
Measurement
Stability
Voltage Output
Jack
1V / inch @ low range
10V / inch @ high range
± 10 counts
2.5 mm monophone jack
Tip: Signal
Sleeve: Ground
should adjust the reading on the display. Once the
display has been adjusted to read 1.000, the low range
of the SCS Static Sensor 718 is now calibrated. Repeat
procedures 5.5.2 - 5.5.6 for the high of the meter, using
a test voltage of 5,000 volts.
Voltage Output 1/1000 of measured
voltage @ low range
1/10,000 of measured
voltage @ high range
Automatic Shutoff 20 minutes after last switch activity
Distance Indicator LED targets. Aligned targets
indicate 1 in. (2.54 cm)
measurement distance.
Certifications cULus, CE
Figure 9. 718 Static Sensor adjustable screw for display.
SCS - 926 JR Industrial Drive, Sanford, NC 27332
East: [phone] | West: [phone] • Website: StaticControl.com

TB-9016 Page 5 of 6
© 2016 DESCO INDUSTRIES, INC.
Employee Owned
SCS Air Ionizer 718A Specifications
(All values typical)
(At 1in. (2.54cm) distance from sensor to target)
The SCS Air Ionizer Test Kit 718A is a set of
accessories for use in conjunction with the Static Sensor
718. Their intended use is for verifying the operation
of air ionizers by measuring the neutralization time
for a static charge placed on a stationary metal plate.
Charge Plate
Assembly Per ESD Association Draft Standard ANSI/ESD SP3.3.
Aluminum bracket, bare
stainless steel plate and teflon
spacers isolate plate from
bracket
Any deviation from this intended use could impair the
instrument’s effectiveness and possibly lead to an
unsafe operating condition.
Caution:
The Static Sensor 718 and SCS Charger 718A use
9VDC power supplied by a 9V alkaline battery. Usage
Voltage Output 1/1000 of measured
voltage @ low range
1/10,000 of measured
voltage @ high range
Charge Plate Area 3.25" W x 1.25" L
8.3 cm W x 3.2 cm L
of any other power source may cause damage to the
instruments.
The Static Sensor 718 and Air Ionizer Test Kit 718A
have no user-serviceable parts. Do not disassemble the
products for any reason. UNAUTHORIZED SERVICE
WILL VOID THE WARRANTY.
The Static Sensor 718 and Charger 718A are NOT
Charge Plate
AssemblyWeight
Charger
Dimensions
2.5 oz. (70 g)
0.87" H x 2.4" W x 4.9" L
2.2 cm H x 6.1 cm W x 12.4
cm L
designed for usage in hazardous environments where
the possibility of explosion or fire exists.
Regulatory Information
WEEE Statement
The following information is only for EU-members
States: The mark shown to the right is in compliance
Charger Weight 5 oz. (140 g) with battery with Waste Electrical and Electronic Equipment
Directive 2002/96/EC (WEEE). The mark indicates the
Charger Power
Requirements
Charger Output
(using Static Sensor
718 with charge plate)
1 - 9 volt alkaline battery
1.1kV minimum for +/- voltage
requirement NOT to dispose the equipment as unsorted
municipal waste, but use the return and collection
systems according to local law.
cULus Statement
Meets UL Safety Requirements.
FCC
Certifications cULus, CE
Parts Included for SCS Static Sensor
718
1 - Static Sensor 718
Parts Included for SCS Air Ionizer
718A
1 - Charge Plate Assembly 718A
1 - Charger 718A
Safety Information
Intended Use:
The SCS Static Sensor 718 is a portable, handheld
instrument designed for measuring voltages associated
with electrostatic charge. Its intended use is for
measuring the amount of voltage, in a range from 19.99
kilovolts, associated with an electrostatic charge buildup
on a surface. Any deviation from this intended use could
impair the instrument’s effectiveness and possibly lead
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
to an unsafe operating condition. SCS - 926 JR Industrial Drive, Sanford, NC 27332
East: [phone] | West: [phone] • Website: StaticControl.com

TB-9016 Page 6 of 6
© 2016 DESCO INDUSTRIES, INC.
Employee Owned
•Consult the dealer or an experienced radio/TV
technician for help. Restriction of the use of certain
hazardous substances (RoHS): Meets 2011-65-EU
Directive.
SCS - 926 JR Industrial Drive, Sanford, NC 27332
East: [phone] | West: [phone] • Website: StaticControl.com
Limited Warranty,WarrantyExclusions, Limit of
LiabilityandRMARequestInstructions
See the SCS Warranty -
http://staticcontrol.descoindustries.com/warranty.aspx
