Operator's Manual
910R/950R/950T/970T
Issue No. 2.1/OP-2/05
Part Number 754-062
Copyright 2001, 2004, 2005
by The Charles Machine Works, Inc.,
Perry, Oklahoma
Subsite is a registered trademark of The Charles Machine Works,
Inc.
U.S. Patent No. 5,065,098; 4,881,083. Other U.S. and foreign patents
pending.
Operator's Manual
910R/950R/950T/970T
Issue No. 2.1/OP-2/05
Part Number 754-062
Copyright 2001, 2004, 2005
by The Charles Machine Works, Inc.,
Perry, Oklahoma
Subsite is a registered trademark of The Charles Machine Works,
Inc.
U.S. Patent No. 5,065,098; 4,881,083. Other U.S. and foreign patents
pending.

910R/950R/950T/970T - CONTENTS 5
SERVICE PROCEDURE
910R/950R/950T/970T - CONTENTS 5
SERVICE PROCEDURE
CONTENTS
SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Serial Number Record . . . . . . . . . . . . . . . . . . . . . . . . .1
Service Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
FOREWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
RECEIVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Controls (Single Key) . . . . . . . . . . . . . . . . . . . . . . . . . .9
Controls (Double Key) . . . . . . . . . . . . . . . . . . . . . . . .11
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
950T TRANSMITTER. . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
970T TRANSMITTER. . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Controls (Single Key) . . . . . . . . . . . . . . . . . . . . . . . . .28
Controls (Double Key) . . . . . . . . . . . . . . . . . . . . . . . .30
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
CONTENTS
SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Serial Number Record . . . . . . . . . . . . . . . . . . . . . . . . . 1
Service Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
FOREWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
RECEIVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Controls (Single Key) . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Controls (Double Key) . . . . . . . . . . . . . . . . . . . . . . . . 11
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
950T TRANSMITTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
970T TRANSMITTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Controls (Single Key) . . . . . . . . . . . . . . . . . . . . . . . . . 28
Controls (Double Key) . . . . . . . . . . . . . . . . . . . . . . . . 30
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

6910R/950R/950T/970T - CONTENTS
SERVICE PROCEDURE 6910R/950R/950T/970T - CONTENTS
SERVICE PROCEDURE
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Safety Alert Classifications . . . . . . . . . . . . . . . . . . . . 36
Safety Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Choose Signal Type . . . . . . . . . . . . . . . . . . . . . . . . . 39
Choose Antenna Configuration . . . . . . . . . . . . . . . . . 41
Choose Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Recognize Common Signal Problems . . . . . . . . . . . . 44
Locate Line: Active Location . . . . . . . . . . . . . . . . . . . 46
Locate Line: Beacon . . . . . . . . . . . . . . . . . . . . . . . . . 55
Locate Line: Passive Location . . . . . . . . . . . . . . . . . . 57
CARE AND ERROR CODES . . . . . . . . . . . . . . . . . . . . . . 61
General Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
950 Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
950 Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
970 Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Safety Alert Classifications . . . . . . . . . . . . . . . . . . . . 36
Safety Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Choose Signal Type . . . . . . . . . . . . . . . . . . . . . . . . . 39
Choose Antenna Configuration . . . . . . . . . . . . . . . . . 41
Choose Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Recognize Common Signal Problems . . . . . . . . . . . 44
Locate Line: Active Location . . . . . . . . . . . . . . . . . . . 46
Locate Line: Beacon . . . . . . . . . . . . . . . . . . . . . . . . . 55
Locate Line: Passive Location . . . . . . . . . . . . . . . . . 57
CARE AND ERROR CODES . . . . . . . . . . . . . . . . . . . . . . 61
General Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
950 Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
950 Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
970 Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

910R/950R/950T/970T - RECEIVER 7
OVERVIEW
910R/950R/950T/970T - RECEIVER 7
OVERVIEW
RECEIVER
OVERVIEW
The 950R receiver is designed to locate buried pipes, lines, and
cables. Several frequencies and modes of operation are available
to suit your specific locating needs.
The 910R receiver is a configurable version of the 950R. Unit will
not have all options described due to configuration ordered.
RECEIVER
OVERVIEW
The 950R receiver is designed to locate buried pipes, lines, and
cables. Several frequencies and modes of operation are available
to suit your specific locating needs.
The 910R receiver is a configurable version of the 950R. Unit will
not have all options described due to configuration ordered.

8910R/950R/950T/970T - RECEIVER
OVERVIEW 8910R/950R/950T/970T - RECEIVER
OVERVIEW
Available passive modes include 50Hz, 50P, 60Hz, and 60P
power, radio, and 31 kHz CATV.
Available active modes include 512 Hz, 1 kHz, 8 kHz, 29 kHz, 80
kHz, and 200 kHz for use with Subsite Electronics transmitters.
400 Hz, 560 Hz, and 815 Hz modes also are available with the
950R, but are not transmitted by the 950T or 970T.
Available beacon modes include 512 Hz, 29 kHz, and 33 kHz for
locating non-metallic pipes.
The 950R has six keypad buttons and a display. Descriptions of
the buttons and display follow.
Available passive modes include 50Hz, 50P, 60Hz, and 60P
power, radio, and 31 kHz CATV.
Available active modes include 512 Hz, 1 kHz, 8 kHz, 29 kHz, 80
kHz, and 200 kHz for use with Subsite Electronics transmitters.
400 Hz, 560 Hz, and 815 Hz modes also are available with the
950R, but are not transmitted by the 950T or 970T.
Available beacon modes include 512 Hz, 29 kHz, and 33 kHz for
locating non-metallic pipes.
The 950R has six keypad buttons and a display. Descriptions of
the buttons and display follow.

910R/950R/950T/970T - RECEIVER 9
CONTROLS (SINGLE KEY)
910R/950R/950T/970T - RECEIVER 9
CONTROLS (SINGLE KEY)
CONTROLS (SINGLE KEY)
ON/OFF
Turns unit on and off.
• Press once to turn on.
• Press again to turn off.
ANT SEL
Selects single, twin, null, or left/right arrow
antenna modes.
Up Arrow
Press to increase manual gain incrementally
from 20% to 80%.
If signal is below 20%, press once to raise
gain (increase signal) to approximately 50%.
To disable this feature:
1. Ensure that unit is off.
2. Press and hold the down arrow.
3. Turn unit on.
CONTROLS (SINGLE KEY)
ON/OFF
Turns unit on and off.
• Press once to turn on.
• Press again to turn off.
ANT SEL
Selects single, twin, null, or left/right arrow
antenna modes.
Up Arrow
Press to increase manual gain incrementally
from 20% to 80%.
If signal is below 20%, press once to raise
gain (increase signal) to approximately 50%.
To disable this feature:
1. Ensure that unit is off.
2. Press and hold the down arrow.
3. Turn unit on.

10 910R/950R/950T/970T - RECEIVER
CONTROLS (SINGLE KEY) 10 910R/950R/950T/970T - RECEIVER
CONTROLS (SINGLE KEY)
Down Arrow
Press to decrease manual gain incrementally
from 20% to 80%.
If signal is above 80%, press once to lower
gain (decrease signal) to approximately 50%.
To disable this feature:
1. Ensure that unit is off.
2. Press and hold the down arrow.
3. Turn unit on.
MODE
Selects operating frequency.
DEPTH
Estimates depth of signal or shows amount of
current on the target line.
• Press once to estimate depth of properly
located signal source.
• Press and hold to show amount of current
on the target line in milliamps (mA).
See OPERATION for information on locating signals.
Down Arrow
Press to decrease manual gain incrementally
from 20% to 80%.
If signal is above 80%, press once to lower
gain (decrease signal) to approximately 50%.
To disable this feature:
1. Ensure that unit is off.
2. Press and hold the down arrow.
3. Turn unit on.
MODE
Selects operating frequency.
DEPTH
Estimates depth of signal or shows amount of
current on the target line.
• Press once to estimate depth of properly
located signal source.
• Press and hold to show amount of current
on the target line in milliamps (mA).
See OPERATION for information on locating signals.

910R/950R/950T/970T - RECEIVER 11
CONTROLS (DOUBLE KEY)
910R/950R/950T/970T - RECEIVER 11
CONTROLS (DOUBLE KEY)
CONTROLS (DOUBLE KEY)
Press and hold DEPTH and press the indicated button to use the
functions below.
DEPTH + ANT SEL
Turns on backlight.
DEPTH + Up Arrow
Changes volume.
CONTROLS (DOUBLE KEY)
Press and hold DEPTH and press the indicated button to use the
functions below.
DEPTH + ANT SEL
Turns on backlight.
DEPTH + Up Arrow
Changes volume.

12 910R/950R/950T/970T - RECEIVER
CONTROLS (DOUBLE KEY) 12 910R/950R/950T/970T - RECEIVER
CONTROLS (DOUBLE KEY)
DEPTH + Down Arrow
Changes the units of measurement in which the depth displays.
Available displays are ft/in, in, cm, or m.
DEPTH + MODE
Shows percent of battery life remaining.
DEPTH + Down Arrow
Changes the units of measurement in which the depth displays.
Available displays are ft/in, in, cm, or m.
DEPTH + MODE
Shows percent of battery life remaining.

910R/950R/950T/970T - RECEIVER 13
DISPLAY
910R/950R/950T/970T - RECEIVER 13
DISPLAY
DISPLAY
Mode
The receiver can be configured to operate in five modes:
• cable TV
• power
• beacon
•radio
• transmitter
The icon for the currently selected mode is shown along the
bottom of the display.
IMPORTANT: Your unit might not contain all options. See your
Subsite Electronics dealer for upgrade information.
Cable TV
Allows receiver to passively trace cable TV
lines (31 kHz) as long as TV is on.
IMPORTANT:IfTVisoff,useatransmitterand
actively locate line.
DISPLAY
Mode
The receiver can be configured to operate in five modes:
•cableTV
• power
• beacon
•radio
• transmitter
The icon for the currently selected mode is shown along the
bottom of the display.
IMPORTANT: Your unit might not contain all options. See your
Subsite Electronics dealer for upgrade information.
Cable TV
Allows receiver to passively trace cable TV
lines (31 kHz) as long as TV is on.
IMPORTANT:IfTVisoff,useatransmitterand
actively locate line.

14 910R/950R/950T/970T - RECEIVER
DISPLAY 14 910R/950R/950T/970T - RECEIVER
DISPLAY
Power
Allows receiver to trace live 50 Hz or 60 Hz
power lines.
IMPORTANT:Currentmustbeflowingthrough
the line.
Beacon
Allows receiver to trace nonmetallic pipes and
conduits with 29 kHz, 33 kHz, or 512 Hz
beacon.
Radio
Allows receiver to trace lines that pick up and
radiate very low frequency (VLF) radio waves.
Transmitter
Allows receiver to trace lines that have had a
512 Hz, 1 kHz, 8 kHz, 29 kHz, 80 kHz, or 200
kHz signal placed on them by a transmitter.
Power
Allows receiver to trace live 50 Hz or 60 Hz
power lines.
IMPORTANT:Currentmustbeflowingthrough
the line.
Beacon
Allows receiver to trace nonmetallic pipes and
conduits with 29 kHz, 33 kHz, or 512 Hz
beacon.
Radio
Allows receiver to trace lines that pick up and
radiate very low frequency (VLF) radio waves.
Transmitter
Allows receiver to trace lines that have had a
512 Hz, 1 kHz, 8 kHz, 29 kHz, 80 kHz, or 200
kHz signal placed on them by a transmitter.

910R/950R/950T/970T - RECEIVER 15
DISPLAY
910R/950R/950T/970T - RECEIVER 15
DISPLAY
Frequency
The receiver can be configured to recognize
nine transmitter frequencies: 400 Hz, 512 Hz,
560 Hz, 815 Hz, 1 kHz, 8 kHz, 29 kHz, 80
kHz, and 200 kHz.
IMPORTANT: 400 Hz, 560 Hz, and 815 Hz
cannot be transmitted by the 950T or 970T.
Selected frequency is displayed in the lower right corner of the
display.
Antenna
The receiver has four antenna modes described below. The
selected antenna mode is indicated by an arrow on the left side of
the display.
Single
Use in congested areas and to locate deeper
lines. Signal strength peaks when receiver is
over the line being located. Is less precise
than other modes.
Frequency
The receiver can be configured to recognize
nine transmitter frequencies: 400 Hz, 512 Hz,
560 Hz, 815 Hz, 1 kHz, 8 kHz, 29 kHz, 80
kHz, and 200 kHz.
IMPORTANT: 400 Hz, 560 Hz, and 815 Hz
cannot be transmitted by the 950T or 970T.
Selected frequency is displayed in the lower right corner of the
display.
Antenna
The receiver has four antenna modes described below. The
selected antenna mode is indicated by an arrow on the left side of
the display.
Single
Use in congested areas and to locate deeper
lines. Signal strength peaks when receiver is
over the line being located. Is less precise
than other modes.

16 910R/950R/950T/970T - RECEIVER
DISPLAY 16 910R/950R/950T/970T - RECEIVER
DISPLAY
Twin
Gives sharper location than single antenna.
Signal strength peaks when receiver is over
the line being located.
Null
Gives precise response when locating lines in
uncongested areas. Signal drops to minimum
strength when receiver is over the line being
located. In congested areas, confirm location
by using single or twin peak antenna.
Left/Right
Indicates position of receiver relative to the
line being located. Used primarily for active
mode, but can also be used as a fore/aft
indicator in beacon mode.
• Move receiver in the direction of the arrow.
• When receiver is over the line, both arrows display and two
beeps sound.
Twin
Gives sharper location than single antenna.
Signal strength peaks when receiver is over
the line being located.
Null
Gives precise response when locating lines in
uncongested areas. Signal drops to minimum
strength when receiver is over the line being
located. In congested areas, confirm location
by using single or twin peak antenna.
Left/Right
Indicates position of receiver relative to the
line being located. Used primarily for active
mode, but can also be used as a fore/aft
indicator in beacon mode.
• Move receiver in the direction of the arrow.
• When receiver is over the line, both arrows display and two
beeps sound.

910R/950R/950T/970T - RECEIVER 17
DISPLAY
910R/950R/950T/970T - RECEIVER 17
DISPLAY
Signal Strength
Signal strength is shown by bars
at top of display and in numeric
display.
Gain
Gain (amount of signal
amplification) is shown by bars
below signal strength indicator.
Gain increases to the right.
Signal Strength
Signal strength is shown by bars
at top of display and in numeric
display.
Gain
Gain (amount of signal
amplification) is shown by bars
below signal strength indicator.
Gain increases to the right.

18 910R/950R/950T/970T - RECEIVER
DISPLAY 18 910R/950R/950T/970T - RECEIVER
DISPLAY
Depth
Estimated depth displays when DEPTH
button is pressed.
Receiver can display in four units of
measurement: feet/inches, inches, cm, or m.
To select units, press and hold DEPTH and
press the down arrow.
IMPORTANT: If four dashes
appear in the display, the receiver
is detecting a signal above it and
cannot estimate depth. This
message is usually caused by
interferingsignalsoraweaksignal.
Try relocating target signal.
Current
Estimated current on target line is
displayed in mA when DEPTH
button is pressed and held.
The higher the number, the higher the current on the target line.
IMPORTANT: Current reading should be stable or drop as line is
located, except at the ends where current may be higher.
Depth
Estimated depth displays when DEPTH
button is pressed.
Receiver can display in four units of
measurement: feet/inches, inches, cm, or m.
To select units, press and hold DEPTH and
press the down arrow.
IMPORTANT: If four dashes
appear in the display, the receiver
is detecting a signal above it and
cannot estimate depth. This
message is usually caused by
interferingsignalsoraweaksignal.
Try relocating target signal.
Current
Estimated current on target line is
displayed in mA when DEPTH
button is pressed and held.
The higher the number, the higher the current on the target line.
IMPORTANT: Current reading should be stable or drop as line is
located, except at the ends where current may be higher.

910R/950R/950T/970T - RECEIVER 19
DISPLAY
910R/950R/950T/970T - RECEIVER 19
DISPLAY
Volume Level
Receiver has four volume levels: off, low,
medium, and high. To select volume setting,
press and hold DEPTH and press the up
arrow.
IMPORTANT: Lower volume to conserve
battery life.
Receiver Battery Level
Receiver battery level is shown by battery
icon on right side of display.
• Three segments mean that batteries are
at full power.
• One segment means that batteries are at
low power.
• No segments and a flashing outline means that you should
change batteries immediately.
IMPORTANT: To see percentage of battery life remaining, press
and hold DEPTH and press MODE.
Volume Level
Receiver has four volume levels: off, low,
medium, and high. To select volume setting,
press and hold DEPTH and press the up
arrow.
IMPORTANT: Lower volume to conserve
battery life.
Receiver Battery Level
Receiver battery level is shown by battery
icon on right side of display.
• Three segments mean that batteries are
at full power.
• One segment means that batteries are at
low power.
• No segments and a flashing outline means that you should
change batteries immediately.
IMPORTANT: To see percentage of battery life remaining, press
and hold DEPTH and press MODE.

20 910R/950R/950T/970T - RECEIVER
SETUP 20 910R/950R/950T/970T - RECEIVER
SETUP
SETUP
Install Batteries
Use six C-cell alkaline batteries in
receiver.
To install:
1. Unscrew battery cover.
2. Insert batteries as shown.
3. Close cover and tighten
screw.
4. Check operation.
Check Operation
Always check that receiver is
operating before leavingfor jobsite
and after every battery change.
To check operation:
1. Turn on receiver.
2. Entire display will light briefly.
3. Display will show battery level
and last used setting.
SETUP
Install Batteries
Use six C-cell alkaline batteries in
receiver.
To install:
1. Unscrew battery cover.
2. Insert batteries as shown.
3. Close cover and tighten
screw.
4. Check operation.
Check Operation
Always check that receiver is
operating before leaving for jobsite
and after every battery change.
To check operation:
1. Turn on receiver.
2. Entire display will light briefly.
3. Display will show battery level
and last used setting.
