DEVA Broadcast DB6000 User manual

MAINTENANCE AND OPERATION
INSTRUCTION MANUAL
Publish Date: 04-Jan-2018
DB6000
FM and Digital Radio Audio Processor

Contents
Introduction........................................................................................................................................ 6
Typographic conventions .................................................................................................................. 7
General Information.......................................................................................................................... 8
Product Features ................................................................................................................................ 9
Technical Specications ................................................................................................................ 10
Front Panel ....................................................................................................................................... 12
OLED Display............................................................................................................................... 12
Context-sensitive Soft Buttons....................................................................................................... 12
Navigational Buttons..................................................................................................................... 12
LED Meters ................................................................................................................................... 12
Rear Panel..................................................................................................................................... 13
Rear Panel Alarm Terminal .......................................................................................................... 14
GPI Trigger Input Pins............................................................................................................. 14
Digital I/O Pins ........................................................................................................................ 14
Before you start ................................................................................................................................ 15
Safety warning............................................................................................................................... 15
Operating recommendations ......................................................................................................... 16
Unpacking and inspection............................................................................................................. 17
Radio Frequency Interference (RFI) ............................................................................................. 17
Mounting........................................................................................................................................... 18
Rack requirements ......................................................................................................................... 18
Heat Dissipation............................................................................................................................ 18
AC Mains Power .............................................................................................................................. 19
Fuse holder.................................................................................................................................... 19
Power cord .................................................................................................................................... 19
Ground Loops................................................................................................................................ 19
DB6000 Location.............................................................................................................................. 20
Source Material Quality.................................................................................................................. 20
Operation.......................................................................................................................................... 21
Processing path ............................................................................................................................. 21
Audio Processing Explained ......................................................................................................... 22
Basic Setup/Connection Example................................................................................................... 23
Referencing Analog and Digital Inputs level ................................................................................ 23
Referencing Analog and Digital Outputs level.............................................................................. 24
Setup with Analog Program Inputs ............................................................................................... 25
Setup with Digital Program Inputs ............................................................................................... 26
Analog connection with two transmitters...................................................................................... 27
Analog connection with DEVA SmartGen 6.0............................................................................... 28
Side-chain................................................................................................................................. 28
Loop through ............................................................................................................................ 29
OLED Display, Navigational & Soft Buttons ................................................................................ 30
OLED Display............................................................................................................................... 30
Header area.............................................................................................................................. 30
Main Screen working area........................................................................................................ 31
Soft Buttons............................................................................................................................... 31

Navigation Buttons ................................................................................................................... 31
Menu Pages .............................................................................................................................. 32
[Input].................................................................................................................................. 32
[Process].............................................................................................................................. 32
[Output] ............................................................................................................................... 32
[Presets]............................................................................................................................... 32
Settings.............................................................................................................................................. 36
Trigger ports.................................................................................................................................. 36
Keyboard lock................................................................................................................................ 37
Keyboard unlock ........................................................................................................................... 37
RDS ............................................................................................................................................... 38
Dayparting .................................................................................................................................... 38
Other sections ................................................................................................................................... 39
Stereo............................................................................................................................................. 39
Status ............................................................................................................................................. 39
Factory and User presets................................................................................................................. 40
Factory Presets.............................................................................................................................. 40
How to create and save a User Preset or How to customize your sound................................. 40
WEB Interface.................................................................................................................................. 42
Manual IP Address Identication.................................................................................................. 42
Network Discovery ........................................................................................................................ 43
Access............................................................................................................................................ 43
Status ............................................................................................................................................. 44
Settings .......................................................................................................................................... 45
General..................................................................................................................................... 45
Comm........................................................................................................................................ 46
Network ............................................................................................................................... 46
SNMP Agent ........................................................................................................................ 46
E-mail .................................................................................................................................. 46
HTTP Server ....................................................................................................................... 47
FTP Server .......................................................................................................................... 47
Syslog .................................................................................................................................. 47
Dayparts ................................................................................................................................... 48
Other......................................................................................................................................... 49
Firmware Update ................................................................................................................ 49
Storage ................................................................................................................................ 49
System Log .......................................................................................................................... 49
Factory Defaults ................................................................................................................. 49
Reboot ................................................................................................................................. 49
Log............................................................................................................................................ 50
Presets ........................................................................................................................................... 51
How can a user preset be made?.............................................................................................. 51
Preset Lock ............................................................................................................................... 52
Presets Export........................................................................................................................... 52
Presets Import........................................................................................................................... 53
Presets Delete ........................................................................................................................... 53
Input .............................................................................................................................................. 54
AGC............................................................................................................................................... 55

Equalizer ....................................................................................................................................... 56
Multiband Limiter ......................................................................................................................... 57
Band Mix ....................................................................................................................................... 59
Final Limiter ................................................................................................................................. 60
Clipper........................................................................................................................................... 61
MPX............................................................................................................................................... 62
RDS Data ...................................................................................................................................... 63
Output............................................................................................................................................ 64
WARRANTY TERMS AND CONDITIONS................................................................................. 65
Product Registration Card.............................................................................................................. 66
APPENDIX A ................................................................................................................................... 67
RDS: Europe vs America .............................................................................................................. 67
The RDS System ........................................................................................................................... 67
APPENDIX B.1 ................................................................................................................................ 68
RDS Applications Supported ........................................................................................................ 68
AF ............................................................................................................................................ 68
DI ............................................................................................................................................. 68
M/S ........................................................................................................................................... 68
PI ............................................................................................................................................. 68
PS ............................................................................................................................................. 68
PTY .......................................................................................................................................... 69
RT ............................................................................................................................................ 69
TA ............................................................................................................................................. 69
TP ............................................................................................................................................. 69
APPENDIX C.1................................................................................................................................ 70
PTY Code Description Used in RBDS Mode – North America..................................................... 70
APPENDIX C.2................................................................................................................................ 71
PTY Code Description Used in RDS Mode – Europe, Asia .......................................................... 71

THIS PAGE
IS INTENTIONALLY
LEFT BLANK

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 6 -
Introduction
DEVA Broadcast Ltd. is an international communications and high-technology manufacturing
organization, its corporate headquarters and facility located in Burgas, Bulgaria. The company
serves the broadcast and corporate markets worldwide – from consumers and small businesses to
the largest global organizations. It is dedicated to the research, design, development and provision
of advanced products, systems and services. DEVA launched its own brand back in 1997 and has
nowadays evolved to become known as a market leader and internationally reputed manufacturer
of user-friendly, cost-effective and innovative broadcast products.
Creativity and innovation are deeply woven into DEVA corporate culture. Through successful
engineering, marketing and management our team of dedicated professionals creates future-
oriented solutions to improve customers’ performance. You may rely that all issues communicated
to our crew would be addressed accordingly. We pride ourselves on our pre and post-sales support
and purchase services, which along with the outstanding quality of our radio gear have won us due
respect and the market authority position.
DEVA best-of-breed solutions have become the best sellers for our partners. The strategic
partnerships which have been formed with industry leaders during all these years that we have been
operating on the broadcasting market, have proved us a reliable business partner and a valuable
asset, as our dealers worldwide would conrm. In constant pursuit of precision and long-term
satisfaction, DEVA enhances the reputation of our partners and clients alike. Furthermore, we have
already a proven merit as a credible partner provider.
Our portfolio offers complete line of high quality and competitive products for FM and Digital
Radio, Radio Networks, Telecommunication Operators and regulation authorities. For almost
two decades of intensive software and hardware development, we have achieved a unique price-
performance and endurance of our product lines. Our company’s multitude of equipment and
services is in line with the latest technologies and key trends. The most recognizable characteristics
attributed to DEVA products are their clear-cut, streamlined design, easiness of use and cost-
effectiveness: simplicity of forms but multiplicity of functions.
For us there is no stage when we deem that we have reached the most satisfactory level in our
work. Our engineers are in constant pursuit of new ideas and technologies to be captured in DEVA
solutions. Simultaneously, a strict control is being exercised at each step of any new development.
Experience and hard work are our fundament but the continuous improving process is what we
never leave aside. DEVA participates on a regular basis in all landmark broadcasting events, not
only to promote its products, but to exchange valuable know-how and experience. We are also
engaged in international large-scale projects involving radio and audio solutions which makes us
even more competitive on the global market.
All DEVA products are developed and produced in accordance with the latest ISO 9001 quality
control standards.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 7 -
Typographic conventions
This manual uses the following typographic conventions:
Style Used for
NOTE Important notes and recommendations
Example Used when example text is cited
“Menu” on page XX. References
[OK] Interface Interactive buttons.
Settings Menu paths are represented as follows: Settings> General> Backup

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 8 -
General Information
We, at DEVA, are enterprising, extremely driven and hardworking professionals, passionate
about what we do. Our expertise built on almost two decades of work in the broadcasting industry
inspired us to enter a whole new level of prociency, where technology and innovation work
together in a critical importance.
It was the real-world know-how of the broadcasting equipment that led DEVA in every step
of DB6000’s process of creation. It stands for cutting-edge design which meets cutting-edge
engineering. Containing a combination of features with no equal on the market, this audio processor
was built to obtain the perfect balance between power and performance.
By continuously developing new features and capabilities for our devices, we have managed to
enhance the DB6000 even more by integrating a DSP-based Stereo encoder assures an extremely
precise MPX Signal with advanced peak control and two independently congurable composite
MPX outputs. We have also added a feature never incorporated in an audio processor of this price
class before – the built-in IP Audio player supporting MP3 and PCM audio formats. Another
complimentary feature is the fully dynamic RDS/RBDS encoder.
The ultra-low latency DSP based design guarantees the broadcasters control over the most
important sonic parameters and assures clean, artifact free audio. The processing includes dual
stage wideband AGC with “intelligent gating”, multiband adjustable range equalizer, sophisticated
multiband peak limiter and advanced distortion controlled pre-emphasized nal clipper. Thus,
DB6000 will guarantee you perfect sound quality, regardless of the source material.
DB6000 combines unique merits contained in a single product, Fallback function included. If
silence in the main (default) audio input is detected, the DB6000 will automatically switch to the
fallback input, which can be any of the ones utilized by the device. Most importantly, DB6000 is
the industry’s rst audio processor to have an independent back-up audio source – fresh audio will
always be delivered by the built-in audio player. An e-mail notication will be sent immediately
upon change in the main audio input, thus, allowing your technical support team to react on the
very instant. The back-up content is easily updated via any PC, using standard FTP client. The
fallback function works the other way round-when the signal at the default input is restored the
DB6000 will automatically switch back to it. All silence sense parameters are user-dened.
As all DEVA products are designed with the idea of user friendly operation, the DB6000 comes
with a very clean, intuitive and well-organized user interface. It allows easy setup and full control
via the front panel and remote control access via TCP/IP. The HTML 5 based WEB interface
allows the unit to be accessed remotely through iOS, Android or any other mobile device.
Make use of the extensive set of factory presets of the device, optimized for popular radio
formats and several user-dened presets. Thanks to DB6000’s great processing power not only
the music, but also the speech will be enhanced to perfection. An exceptionally clean audio is
invariably achieved without compromise, at an affordable price.
DB6000 is the perfect combination of exibility and reliability to meet the most demanding
broadcasters’ requirements.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 9 -
Product Features
• Ultra low latency, all-digital DSP based design
• 4 bands of adjustable dynamic range compression and ‘graphic-EQ’
• Extensive set of factory presets and several customizable user presets
• L/R Analog inputs and outputs and two independent Composite MPX outputs.
• Integrated digital stereo generator with advanced peak control
• Built-in web server for remote control access via TCP/IP connection
• Software Control (over local network or the Internet using any Windows® PC)
• Advanced, fully distortion-controlled pre-emphasized nal limiter/clipper
• Built in DSP-based RDS/RBDS encoder
• Bright, wide view angle OLED and full-time LED meters
• Easy setup and control via the front panel
• Remotely upgradable rmware to ensure improved operation
• Headphone output with front panel level control
• Advanced Multiband Limiter
• Adjustable wide-band AGC with “intelligent” gating
• Externally synchronized output sample rate
• Intelligent Silence Detector
• Fallback function in case of Audio Loss
• Variety of Audio Sources
• Multi-format IP Audio Player
• Built-in MP3 Player
• SD Card for Audio Backup Storage
• Tight peak control at all outputs
• EMI-suppressed XLR connectors
• Stereo encoder integrated with audio processing
• Bypass and Test tone Mode
• Embedded SNMP agent permitting full device management
• Easy to use WEB interface
• Apple and Android devices support
• SNTP for automatic synchronization of the built-in clock
• Notications on input/preset change via E-mail and SNMP
• Protected access to the device settings
• Professional AES/EBU Digital audio inputs
• Level Adjustable, Balanced Analog and Digital Audio Outputs
• LAN port for full TCP/IP remote control and monitoring
• USB communication interface for local connectivity
• Restore Factory Parameters option
• Easy Installation and Setup
• Wide operating voltage range: 100-240V AC
• 19” Professional Case for high RF immunity

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 10 -
TECHNICAL SPECIFICATIONS
ANALOG AUDIO INPUT
Connectors Main - Two XLR, EMI suppressed, electronically balanced;
Auxiliary - DB9, EMI suppressed, electronically balanced
Conguration Stereo
Input level (0 dBFS) Software selectable -8 dBu to +24 dBu peak
Impedance Jumper selectable 600Ω / >10kΩ
A/D Conversion 24 bit; 48 kHz sample rate; Differential inputs
ANALOG AUDIO OUTPUT
Connectors Two XLR, EMI suppressed, electronically balanced
Conguration Stereo. Software selectable at, pre-emphasized or de-emphasized
Output Level (0 dBFS) Software selectable -12 dBu to +24 dBu peak into ≥ 600Ω load
Source Impedance 20Ω
Load Impedance ≥ 600Ω, balanced/unbalanced
Signal-to-Noise ≥ 110 dB unweighted (Bypass mode, digital input, at, 20Hz-15kHz
bandwidth, referenced to +12 dBu output level)
Distortion ≤ 0.01 THDN (Bypass mode, digital input, at, 20Hz-15kHz
bandwidth, referenced to +12 dBu output level)
D/A Conversion 24 bit; 192 kHz sample rate; Differential outputs
DIGITAL AUDIO INPUT
Connectors Main - XLR, EMI suppressed, transformer balanced and oating;
110Ω impedance; Auxiliary - DB9, EMI suppressed, transformer
balanced and oating; 110Ω impedance
Conguration Stereo AES3 standard, up to 24 bit resolution
Sampling Rate 22 kHz to 192 kHz
Input Gain -20 dB to 20 dB, referenced to 0 dBFS, software selectable
DIGITAL AUDIO OUTPUT
Connector XLR, EMI suppressed, transformer balanced and oating;
110Ω impedance
Conguration Stereo AES3 standard, 24 bit resolution.
Software selectable at, pre-emphasized or de-emphasized
Sample Rate Internal - 32, 44.1, 48, 88.2, 96, 176.4, 192 kHz. Externally synced to
Main AES3 digital input at 32 to 192 kHz. Software selectable.
Word Length 24 bit
Output Reference Level -20 to 0 dBFS software selectable

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 11 -
COMPOSITE BASEBAND OUTPUT
Connectors BNC unbalanced, chasis oating, EMI suppressed
Conguration Two outputs. Independent level control.
MPX+MPX, MPX+PILOT or BYPASS mode
Source impedance 75Ω
Load impedance 50Ω or greater
Output level -18dBu to +18dBu
Pilot level 0% to 15%
D/A conversion 24 bit, differential
SNR > 80 dB (Bypass mode, at, 20Hz - 15kHz bandwidth, Digital input
referenced to -10dBFS, unweighted)
THD < 0.01% (Bypass mode, at, 20Hz - 15kHz bandwidth, Digital input
referenced to -10dBFS, unweighted)
Stereo Separation >60dB
Crosstalk >70dB
Pilot protection >90dB relative to 9% pilot injection, ±250 Hz
38 kHz suppression >80dB (referenced to 100% modulation)
REMOTE ACCESS INTERFACE
Conguration TCP/IP via USB or Ethernet interface
USB Connector USB type B connector
Ethernet Connector Female RJ45 shielded connector for 10/100 Mbps CAT5 ethernet
networks
REMOTE CONTROL INTERFACE (GPI)
Connector DB-9 male
Conguration Eight LED optocoupler, current limited cathode inputs. Anodes are
connected to VCC internally.
Control Selects corresponding user preset if connected to GND
POWER
Voltage 100-240 VAC, 50-60 Hz, 30VA
Connector IEC, Fused and EMI-suppressed.
Detachable 3-wire power cord supplied
ENVIRONMENTAL
Operating Temperature 0° to 50°C / 32° to 122°F
Humidity 0–95% RH, non-condensing
Dimensions (W x H x D) 19” x 1.875” x 7 ” / 483 mm x 44 mm x 180 mm. One rack unit high

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 12 -
Front Panel
OLED DISPLAY
DB6000 has easy to read, high-resolution OLED graphical display that visualizes all
measurements of the received signal and DB6000’s settings.
CONTEXT-SENSITIVE SOFT BUTTONS
Used for navigation through the menus, quick access to the parameters, modes, functions and to
alter their values. The Soft Buttons indicators are placed on the bottom side of the OLED display.
Depending on the currently selected menu context the indicators change their function. The Soft
Buttons will be referred as (left-to-right) [SB1], [SB2], [SB3] and [SB4].
NAVIGATIONAL BUTTONS
[UP], [DOWN], [LEFT], [RIGHT] and [OK] buttons, as the Soft Buttons, are used to navigate
through the menus selecting various functions and parameters of DB6000.
LED METERS
The full-time LED meters allow quick and easy monitoring of the metering, making the setup,
adjustment and programming easy.

- 13 -
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
REAR PANEL
1
2
3 4
56 7 8
9
10
11 12
13 14 15
1. Mains connector, 100-240 VAC, 50-60 Hz, 30VA, IEC-320 C14 type, EMI-suppressed;
2. Fuse holder;
3. MPX Output 1 - BNC;
4. MPX Output 2 - BNC;
5. Analog Audio Left Input - XLR;
6. Analog Audio Right Input - XLR;
7. Analog Audio Left Output - XLR;
8. Analog Audio Right Output - XLR;
9. GPI
10. DIGITAL I/O
11. Digital Audio Input - XLR;
12. Digital Audio Output - XLR;
13. Ethernet T-BASE10/100 - RJ45;
14. USB – type B;
15. MICRO SD

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 14 -
REAR PANEL ALARM TERMINAL
9876
5 4 3 2 1
1 2 3 4
56789
GPI Trigger Input Pins
Trigger Input Pin User Preset Number
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
NOTE: Pin 9 is connected to GND.
PIN 1
GND
PIN 1
GND
Digital I/O Pins
Pin Signal
1 Right Aux In - positive
2 Right Aux In - negative
3 Right Aux In - GND
7 Left Aux In - positive
8 Left Aux In - negative
6 Left Aux In - GND
4 Digital Aux In - positive
5 Digital Aux In - negative
9 Digital Aux In - GND

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 15 -
Before you start
SAFETY WARNING
• The servicing of electronic equipment should be performed only by qualied personnel;
• Before removing the covers DB6000 must be switched off and the mains cable unplugged;
• When the equipment is open, the power supply capacitors should be discharged using a
suitable resistor;
• Never touch the wires or the electrical circuits;
• Use insulated tools only;
• Never touch the metal semiconductor. They might carry high voltages;
• For removing and installing electronic components, follow the recommendations for
handling MOS components.
ATTENTION: DB6000 has an internal Lithium battery. Do not try to re-charge this battery!
Please contact us for detailed instructions in case the battery should be changed.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 16 -
OPERATING RECOMMENDATIONS
For normal operation of DB6000, we recommend following the instructions listed below.
• Install the unit in places with good air conditioning. DB6000 is designed to operate within the
ambient temperature range of 10° to 50°C. The equipment rack should be ventilated in order
for the device to keep its internal temperature below the maximum ambient temperatures;
• We do not recommend installation in rooms with high humidity, dusty places or other
aggressive conditions;
• Locate the device away from abnormally high RF elds;
• Use only checked power supply cables. We strongly recommend the usage of shielded
cables;
• Connect DB6000 only to reliable power supply sources. In case of unstable power supply,
please use Uninterruptible Power Supply (UPS);
• Use the device only with its top cover on to avoid electromagnetic anomalies. Otherwise,
this may cause problems with the normal functionality of the unit;
• For the normal remote operation of the unit, connect DB6000 to a good quality Internet
connection;
• For the normal operation of DB6000, check if the network settings past through all the
required data trafc.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 17 -
UNPACKING AND INSPECTION
Upon receipt, the equipment should be inspected for possible shipping damages. If such are
found or suspected, notify the carrier at once and contact DEVA Broadcast Ltd. The original
shipping carton box and packing materials should be kept for possible reuse, in case of return for
Warranty repair, for example. Shipping damages as a result of improper packing for return may
invalidate the Warranty!
IT IS VERY IMPORTANT that the “Product Registration Card” on page 66 included in the
Manual be completed accurately and returned. This will assure coverage of the terms of the
Warranty and it will provide a means of trace in case of lost or stolen equipment. In addition,
the user will automatically receive SERVICE OR MODIFICATION INSTRUCTIONS from
DEVA Broadcast Ltd.
RADIO FREQUENCY INTERFERENCE (RFI)
Although we have made provision for DB6000 installation in the immediate proximity of
broadcast transmitters, please do practice some care using the unit near abnormally high RF elds.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 18 -
Mounting
RACK REQUIREMENTS
The DB6000 mounts in a standard 19-inch equipment rack and requires only 1¾ inches (1U) of
vertical rack space. In order the painted nish around the mounting holes to be protected, the use
of plastic washers is recommended.
HEAT DISSIPATION
Having very low electricity consumption, the DB6000 itself generates negligible heat. The
unit is intended for operation within an ambient temperature range, extending from freezing to
120°F/50°C. But because adjacent, less efcient equipment may radiate substantial heat, be sure
that the equipment rack is adequately ventilated to keep its internal temperature below the specied
maximum ambient.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 19 -
AC Mains Power
FUSE HOLDER
The fuse holder is placed inside the unit, next to the voltage selector. Apply downward pressure
and pull the cap outward to access the 5mm mains fuse. Apply inward pressure to insert the cap in.
POWER CORD
The detachable IEC-type power cord is supplied with the unit. The individual cord conductors
may be color-coded in either of two ways:
1) In accordance with US standards:
BLACK = AC “HOT”
WHITE = AC NEUTRAL
GREEN = EARTH GROUND
2) To European CEE standards:
BROWN = AC “HOT”
BLUE = AC NEUTRAL
GREEN/YELLOW = EARTH GROUND
GROUND LOOPS
Because the unbalanced MPX OUTPUTS of the DB6000 are chassis-ground-referenced, a
mains frequency or RF ground loop could be formed between the input or output cable shield
grounds and the AC power cord ground. A ‘ground-lifting’ AC adapter may well remedy such a
situation, although the chassis somehow must be returned to earth ground for safety. Generally,
being screwed-down in the equipment rack will satisfy the safety requirement.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 20 -
DB6000 Location
The best location for DB6000 is as near as possible to the transmitter, so that its stereo encoder
output can be linked to the transmitter through a circuit path. If this conguration is not possible,
the DB6000’s AES3 digital audio output can be fed through an all-digital, uncompressed path to
the transmitter exciter.
The usage of left and right analog audio outputs is recommended in the situations when the
stereo encoder and exciter are under the jurisdiction of an independent transmission authority, and
the programming agency’s jurisdiction ends at the interface between the audio facility and the link
connecting the audio facility to the transmitter. (The link might be telephone / post lines, analog
microwave radio, or various types of digital paths.)
Source Material Quality
The DB6000 is designed to achieve perfect sound quality, regardless of the source material.
Though, it is very important that the source audio to be as clean as possible, as upon processing the
poor-quality source material will cause distortion and unpleasant audio defects.
