Devatec ElectroVap MC2 Series User manual

Pictures for illustrating purposes only
Technical manual
Steam generator for hammam

2 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Contents
Safety information 3-4
Accreditation 5
RoHS declaration 6
Delivery contents 7
Dimensions & weights 8
Humidifier component part overview 9
Wall installation
Installation steps 10
Step 1 - Placing and wall attachement 11-12
Step 2 - Water connection 13
Step 3 - Steam nozzle positioning 14
Step 4 - Steam & Condensate outlet 15-16
Step 5 - Temperature sensor 17
Models & Optional features 18
Step 6 - Electrical connections 19 - 35
Setting up 37
System management
User information menu 38
Humidifier status menu 39
Configuration changing menu 42
Maintenance
Cylinder maintenance guide 44
Precaution 45
Maintenance
Service & Alerts 46
Main board changing 47
Steam cylinder cleaning 50
Valves maintenance 51
Spares lists 53

3 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Safety information
IMPORTANT
Please read, heed and follow the enclosed safety information and the warning labels
inside the humidifier before installation or maintenance.
Warnings & safety symbols
Warning : This symbol is used to designate a danger of injury or potential damage to the sys-
tem.
Caution : High voltages are present inside the steam generator. All works concerned with the
electrical installation must be carried out by skilled and qualified personnel.
Caution : Danger of scalding ! The ElectroVap MC2 Steam Bath generates steam during
operation and therefore surfaces and pipe-work become very hot. Ensure that equipment not
sustaining high temperatures be kept away.
Warning : the end user should ensure that the equipment be disposed of according to the
local prevailing regulations.
Delivery and storage
Any loss or damage during delivery should be reported to carrier by registered letter within 3 working
days and be advised to devatec or to authorized dealer.
It is recommended that the ElectroVap MC2 steam generator be kept in its transit packaging for as long
as possible prior to maintenance. If the humidifier is to be put into storage prior to installation, it must
be stored under cover and protected from physical damage, dust, frost, rain and humidity. More than 6
months storage is not recommended.

4 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Safety information
IMPORTANT
This section should be read carefully to ensure safe and correct installation of your steam bath generator.
GENERAL
This manual contains all details necessary for the planning and installation of the ElectroVap MC2 Steam
Bath. In addition commissioning and maintenance details are included.
The manual is intended for use by engineers and properly trained technical personnel. Maintenance, servicing
or repair work must only be carried out by suitable skilled and qualified personnel, the customer must be re-
sponsible for ensuring their suitability.
Any risks or hazards, especially when working from ladders or towers should be identified by a skilled and
Health and Safety representative and effective control measure put in place.
No liability will attach to the Distributor if any damage, injury or accident is attributable to inattentive, inappro-
priate, negligent or incorrect operation of the machinery whether or not caused deliberately. Always isolate all
electrical and water supplies before commencing any maintenance.
Every effort has been made to ensure details contained in this manual are correct, however, in view of the
wide range of conditions experienced in air handling systems, the information provided should only be used as
a guide. Please contact your Agent if any doubt.
Correct use
The ElectroVap Steam MC2 Bath is ONLY intended for use of steam inside hammam rooms and controlled by
temperature within specific working conditions . ANY OTHER APPLICATION IS NOT CONSIDERED USE
FOR THE INTENDED PURPOSE. THE MANUFACTURER CANNOT BE MADE LIABLE FOR ANY DAMAGE
OR HARM RESULTING FROM INCORRECT USE.
Water
The ElectroVap MC2 Steam Bath is designed to be used with mains, demineralized R/O with a minimum con-
ductivity of 30 µs or softened water. On no account attempt to introduce any other fluid or chemical into the
system. Water supply should not exceed 6.0 bar and installation should comply with local regulations. In case
the water pressure exceeds 6.0 bar, a water regulator valve must be used.
Electricity
All work concerned with electrical installation MUST only be performed by skilled and qualified technical per-
sonnel (eg electrician or technicians with appropriate training). The customer MUST be responsible for ensur-
ing their suitability.
It is the duty of the installer to ensure that suitable sized cables and MCB protection is provided. Please ob-
serve the local regulations concerning the provision of electrical installations.
Warranty
A one year warranty term—cost and labor—is applicable to the parts of the ElectroVap MC2 Steam Bath to
the exception of the consumable parts (valves, cylinders or parts of cylinders) provided our recommendations
of use & maintenance have been adhered to. Failure to specify and fit original parts and accessories will inva-
lidate our warranty.
NOTE
The manufacturer’s policy is one of continuous research and development. He therefore reserves the right to
amend without notice the specifications given in this document.
The photographs are for illustrating purposes only.

5 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Product accreditation
DIRECTIVES APPLIED
Electromagnetic Compatibility Directive : 89/336/EEC, 2014/30/UE
Low Voltage Directive : 73/23/EEC, 2014/35/UE
«Machinery » Directive: 98/37/EC, 2006/42/CE
The humidifier complies with :
EN 61000-6-3: Electromagnetic compatibility generic requirements (residential, commercial
and light industries)
- EN 55022 class B; conducted and radiated emission limits
EN 61000-6-2: Electromagnetic compatibility (EMC) - Generic standards—Immunity for in-
dustrial environments;
- EN 61000-4-3: Radiated, radio frequency, electromagnetic field immunity test
- EN 61000-4-6: Immunity to conducted distrubances induced by radio frenquen-
cy fields
- EN 61000-4-4: Electrical fast transient/burnt immunity test
- EN 61000-4-5: Surge immunity test
- EN 61000-4-2: Electrostatic discharge immunity test.
EN 60335-1: Low voltage : safety of electrodomestical devices and similar
EN 60335-2-88: Low voltage : safety of electrodomestical devices and similar, concerning
humidifiers
EN 60204-1: Safety of machinery - Electrical Equipment of machines - Part 1 : General re-
quirements
Manufacturer’s name & address
devatec SAS
185 bd des Frères Rousseau
76550 Offranville - France
Type of equipment Steam humidifier
Model name & series ELECTROVAP MC / ELMC
Year of manufacturing 2001
We the undersigned, hereby declare that the equipment specified above complies
with the above-mentioned Directive(s) and Standard(s).
Name : FRAMBOT Jean-François
Position : General Manager
Date : 01.06.2016
Signature:

6 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
RoHS declaration
devatec sas
185 bd des Frères Rousseau
76550 Offranville - France
Confirms that the ElectroVap ELMC steam generator is manufactured in compliance with
the European regulations 2002/95/EU (RoHS).
This guideline regulates after July 1st 2006 the use of mercury, cadmium, lead (soldering
processes), chrome VI as well as PBB and PBDE. ELMC steam humidifiers manufactured
previously to this date may contain above materials.
Name : MINFRAY Jean-Marie
Position : R&D Engineer
Date : 05.06.2008
Signature:

7 Pictures for illustrating purposes only
What is in the box :
1. One temperature controlled ElectroVap MC2 steam bath fitted with disposable or cleanable
cylinder(s) (at purchaser’s request) and one user’s manual.
2. 3 wire temperature sensor with 10 m. long connecting cable.
3. One 500mm long flexible hose with 3/4” thread (with washers) for tap water connection.
4. Ø 25 mm drain hose :
ELMC 1 cylinder : 1 m. long
ELMC 2 cylinders : 2 hoses of 1 m. long and 1.2 m. long respectively
ELMC 3 cylinders : 3 hoses of 1 m. long, 1.2 m. long and 1.8 m. long
4. Hose clamps :
ELMC 1 cylinder : 3 clamps (2 pieces for the steam hose & 1 piece for the drain hose)
ELMC 2 cylinders : 6 clamps (4 pieces for the steam hoses & 2 pieces for the drain hoses)
ELMC 3 cylinders : 9 clamps (6 pieces for the steam hoses & 3 pieces for the drain hoses)
ELECTROVAP MC2 STEAM BATH
Delivery contents
1
435
Any loss or damage during delivery should be reported to carrier by registered letter
within 3 working days and be advised to devatec or to authorized dealer.
It is recommended that the ElectroVap Steam MC2 Bath be kept in its transit
packaging for as long as possible prior to maintenance. If the generator is to be put
into storage prior to installation, it must be stored under cover and protected from
physical damage, dust, frost, rain and humidity. More than 6 months storage is not
recommended.
2

8 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Dimensions & Weight
469
A
533,
4
B
214,5
C
300 275
262
414
D
G
357
357
G
E
414,31
E
271,5
D
402
552
275 382
521
401,69300,61 381,78275,22275,22
G
E
G
E
DD
H
F F F
HH
Dimensions in mm Weight in Kg
Humidifier Water
inlet Steam outlet
Steam
outlet
spacing
Drain
outlet
Drain
outlet
spacing Empty Opera-
ting
Model ABCDEFGH
ELMC 1 SM CYL 475 540 217 215 355 355 15 23
ELMC 1 LG CYL 550 680 272 270 410 410 22 37
ELMC 2 CYL 845 680 272 270 400 300 400 300 30 60
ELMC 3 CYL 1075 680 272 270 380 275 380 275 45 90
ELMC
1 small
cyl.
ELMC
2 cylinders ELMC
3 cylinders
ELMC
1 large
cyl.
• SM CYL = small cylinder, LG CYL = large cylinder

9 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Humidifier component parts
20
15
5
6
17
21
18
19
16
8
14
11
13
10
12
9
24
22
23
7
2
3
3
1
1Steam hose
2Water feed hose 12x16mm
3Hose clamp 16x25mm
4Overflow water hose 18x22m
5On/off rocker switch
6Stand-by lamp
7Grommet
8Drain cup (upper)
9Water inlet valve
10 LCD display board
11 Remote information board (option)
12 Power contactor
13 Main circuit board
14 Filling cup
15 Drain valve
16 Cylinder strainer
17 Steam cylinder
18 Stainless steel electrode plate
19 High water level electrode
20 High water level electrode cable
21 Electrode live power cable
22 Cylinder water feed hose 18x22 mm
23 Flexible water feed hose 3/4” F
24 Hose clamp 12x22 mm
ELMC 5-30 humidifier split view

10 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation steps
All works concerned with electrical installation must be carried out by a skilled and
qualified personnel.
Please read, heed and follow the enclosed information for the installation of the
humidifier and the steam, water and electrical networks.
For further technical assistance, feel free to call devatec.
Failure to adhere to manufacturer’s installation recommendations will invalidate
your warranty.
Installation steps
Step 1 - Placing and wall attachment
Step 2 - Water connection
Step 3 - Steam nozzle and temperature sensor positioning
Step 4 - Draining outlet
Step 5 - Temperature sensor and options
Step 6 - Electrical connections
Step 2
Step 3
Step 4
Step 6
Step 1
Step 5

11 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 1
Installation tips :
The steam generator should be operated within 5°C and 40°C in a room with less than 80% of
humidity.
When in operation, the rear panel becomes hot (60°C) so do not hang the generator on a heat
sensitive surface.
The devatec steam generators have been developped to be hanged on wall. Before
installation, make sure that the surface material is strong enough to hold the steam bath.
Consider free space around the generator to allow easy access for maintenance purposes
(s.a. here under sketches).
How to install the humidifier on wall
600 mm 600 mmmini
500 m
m m
in
i
1000 m
m m
in
i
1250 mm

12 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 1
Nota :
Use installation equipment and material appropriate to the surface on which the unit
should be hanged .
The dimensions mentioned underneath are for cabinets without doors.
A
DETAILA
R4
R6
10
20
Drilling distances in mm
Model ABCDEFGH
ELMC 1 SM CYL 21 110 425 40 21 425 385
ELMC 1 LG CYL 41 110 467 40 21 507 525
ELMC 2 CYL 41 110 760 40 21 800 525
ELMC 3 CYL 41 110 455 535 40 21 1030 525
40
507 1030
467
41
110 110
41
40
21
41 41
455 535
O6
2x
O6
2x
AAAA
BB
CCD
G
G
F
EE
21
F
525
H
525 H
Method:
Mark and drill the mounting holes for 6 mm screws (s.a. the drilling distance table) :
ELMC 1 & 2 cylinders : 4 mounting screws - ELMC 3 cylinders : 5 mounting screws
Insert pegs in holes and the upper screws. Allow about 10 mm for hanging the cabinet.
Hang the cabinet and level it vertically and horizontally. Screw up the upper screws and
then screw up the lower screws.
Détail
fixation haut
Installation on wall
ELMC 1 & 2 CYL ELMC 3 CYL
• CYL= Cylinder
• SM CYL = small cylinder, LG CYL = large cylinder (s.a. electrical table)
Detail of
hanging hole

13 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 2
Recommendations :
The operating principle of the electrode steam generator is the electrolyse
where an electrical current runs through stainless steel electrode plates
immersed in water made conductive by the mineral salts it contains.
The ElectroVap MC2 Steam Bath can produce steam from 3 water qualities
having the following characteristics :
Town water or raw water : the water TH should be between 0 and 40°
French grade for a conductivity between 1000µ and 350µS/cm (Micro
Siemens per centimetre).
Softened water: water treated by sodium/calcium permutation on resins.
The titration value TH should be kept as constant as possible and between
0° and 2°.
It is essential that the salt maintenance of softeners be programmed for the
water volume consummed in order to prevent an excessive salt
concentration to humidifer once the regeneration cycle is finished (please
refer to the softener’s user manual). Duplex softeners are best suited to
your humidifier in this regard. In doubt, please consult devatec.
Demineralised water: this is a water treatment by reverse osmosis or
running through resins.
The ElectroVap MC2 Steam Bath can work with demineralised waters
having a minimum water quality of 30µS/cm. A tea spoon of bicarbonate of
soda must be added on start-up to initiate steam production.
No chemical agent whatsoever (chlorine, disinfectant, ozone… ) must
be added to the water. Some water qualities may generate foam that
can disturb the correct functionning of the generator. If this occurs to
your humidifier, please refer to devatec for further assistance.
WATER CONNECTION
Recommendations on water tapping :
A fresh mains cold water service should be used to supply the unit. The
water pressure should not exceed 6 bar and should not be inferior to 1 bar
with a temperature less than 40°C. In case the water pressure exceeds 6.0
bar, a water regulator valve must be used.
The water supply connection is on the bottom of the unit. All the ELMC are
supplied with a 500 mm long water inlet hose with a 3/4” female
connection to the cold water supply. A check valve should be located on
the mains and cold water service connection to the unit.
The ELMC2 Steam Bath uses water to produce steam so leakage may
happen causing potential damage. Ensure that the floor below the
generator is constructed from waterproof materials (with draining
facilities) to withstand any water spilling during servicing or if a
problem occurs.
ba
The water level must be
between « a» and « b» for
the maximum capacity of
the cylinder.

14 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 3
Steam from the cylinder enters the hammam via a steam distribution nozzle. This nozzle is
made of material designed to prevent scalding. In order to obtain optimum performance of your
generator, it is recommended that these instructions be adhered to as far as possible.
There are two steam inlet diameters available : Ø 25 mm and Ø 40 mm
STEAM DISTRIBUTION NOZZLE
ELMC model 1 SM CYL 1 LG CYL 2 CYL 3 CYL
10 single
phase
Number of steam nozzle(s) 11231
Steam inlet diamenter Ø 25mm Ø 40mm Ø 40mm Ø 40mmØ 25mm
Steam nozzle selection table
The number of distribution nozzles and the diameters depend on the steam generator model.
1Steam inlet Ø 25mm
2Steam inlet Ø 40mm
• SM CYL = small cylinder, LG CYL = large cylinder (s.a. electrical tables)
12
Wall installation
• The installation wall should be no thicker
than 90 mm.
• Bore a hole of Ø 41mm
• Insert the nozzle body in the hole
• And tighten the 1"1/2 nut to secure the
nozzle on wall
90 mm maxi
Ecrou 1" 1/2 fourni

15 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 3
1. We would recommend to use the steam hose from Devatec supply.
NB : when the steam generator is started up for the first time, a smell of burning may be smelt
especially when brand new hoses are installed. This is normal and will eventually dispel.
2. Steam hose selection :
4. Please adhere to the recommendations given underneath for the installation of the steam
hose . A set of hose clamps is supplied for ensuring a correct installation.
The steam generator should be located within 6 m. of the steam distribution nozzle. If the
distance is superior to 6 m., insulated steel or copper pipe of a slightly larger diameter must be
used.
Steam outlet
ELMC model 1 SM CYL 1 LG CYL 2 CYL 3 CYL
Nb of steam
outlets 1123
Steam outlet Ø Ø 25mm Ø 40mm Ø 40mm Ø 40mm
Radius of bend for steam hose :
- Ø 25 mm hose = 250 mm minimal radius
- Ø 40 mm hose = 400 mm minimal radius
• SM CYL = small cylinder, LG CYL = large cylinder (s.a. electrical tables)
Steam hose
Do not create
pockets of water

16 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 4
Condensate draining
The following drawing shows the water draining connections that should be made.
1. The devatec supplied steam hose should be used :
ELMC 1 cylinder : 1m Ø25mm hose with 1 hose clamp (supplied).
ELMC 2 cylinders : 1m + 1.2m Ø25mm hose with 2 clamps (supplied).
ELMC 3 cylinders : 1m + 1.2m + 1.8m Ø25mm hose with 3 clamps (supplied).
These hoses are designed to be connected to the draining system. Regular replacement is
recommended.
2. If rigid piping is used, it must be heat (100°C) and pressure resistant PVC material and have a 60
mm wide diameter.
3. The discharge hose must be free from any obstacle. It is recommended that each steam cylinder
has its own drain pipe and tank arrangement.
4. Use water tanks with a lid that have water collecting facilities.
5. A funnel can also be used but it should be offset from the underside of the unit to prevent any
steam and/or condensation from getting into the cabinet. The installation of a siphon (as per the
draining hose) is recommended and arrangements for holding water spilling should also be made.
6. CAUTION : keep a minimum pitch of 10° for both the draining hose of the generator and for
general drain pipe (s.a. picture 1).
Fig.1

17 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 5
A temperature sensor located inside the hammam measures the temperature value which is
sent to the steam generator for command.
Temperature sensor
Attachement
• Bore a hole of Ø 25mm.
• Pass the sensor cable through the hole from
inside the hammam.
• Mark and drill three holes and insert pegs.
• Apply a silicon film between the Ø 60 mm disk
and the wall. Screw up the three screws.
• To prevent any steam leakage, the cable hole
can be stuffed with silicon.
O60
O4
3 trous
Positioning
Recommended installation Exceptional installation
If the temperature sensor is installed
on the hammam ceiling, a little water
may appear at the end of the sensor
white strainer. So we would
recommend to cut the butt end of this
strainer.
Part to cut

18 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Models & Optional features
This model includes a Steam Bath remote control, a 12V supply transformer
together with a 3 dry contact control board. The 12V supply transformer
powers the light (12V bulb or skylike ceiling) and the remote control.
The Remote Control (IP54) makes it possible to communicate with the
steam generator and to display information. As well, the steam production,
the hammam light, the pre-set temperature together with the perfume
diffusion (if this option has been activated in the menu) can be programmed on a weekly basis. For
further information, please revert to the Remote Control manual.
This option is an Emergency Button to be installed inside the Hammam room. A push on
this button stops immediately the steam generator, starts the ventilation device or the
exhaust air system and shuts a relay that can be linked to a warning light, a bell alarm or
to some other warning device. Please revert to the Optional feature documentation for
further information.
Option - Emergency button
The model includes a push button, a 3 dry contact control board and a two-colour
green/red lamp. When there is no Remote Control, a mere push on this button
powers the steam generator for about 30 minutes (adjustable time). A red ligth is
shown when the steam bath steams up and it turns green when it is ready for use.
Further details can be found in our time bath documentation.
Time bath
This optional perfume dispensor consists in a dosing pump, a 7L perfume tank and a
coil assy to be connected to the steam hose. This option is powered by the steam
generator through terminals 3 & 4. The injection time and period can be selected either
in the steam bath « changing parameters » menu or through the Steam Bath Remote
Control (option 1 or 2 compulsory). Please consult the Perfume Dispensor manual for
further information.
Perfume dispensor
Disinfection dispensor
This optional disinfection dispensor consists in a dosing pump, a 7L disinfectant tank and a check
valve assy to be connected onto the water piping . This option is powered by the steam generator
through terminals 3 & 4 or trough the 3 or 8 dry contact board (if option 1 or 2 is installed). The
disinfection time and period can be selected in the steam bath « changing parameters » menu.
Please consult the Perfume Dispensor manual for further information.
3 contact remote control model

19 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 6
RECOMMENDATION:
All works concerned with the electrical installation must be carried out by skilled
and qualified personnel (eg electrician with appropriate training). The customer
is responsible for ensuring their suitability. Please observe local regulations
concerning the provision of electrical installations.
Check all electrical terminal screws at commissioning, after 50 hours operation
and at every service thereafter.
Take care : the ElectroVap MC2 Steam Bath electronic components are very
sensitive to electrostatic shocks. Appropriate steps must be taken before any
operation.

20 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 6
ELECTRICAL TABLES
MC2 Steam Bath Generator in 2 X 220V - 50/60 Hz
ELMC Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW ) diameter Transformer
wiring
5 5,00 17 18,4 4,05 Small 25 Straight through
10 10,00 34 36 7,92 25 large 25 Split
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
MC2 Steam Bath Generator in 2 X 230V - 50/60 Hz
ELMC Steam production(KG/
Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW ) diameter Transformer
wiring
5 5,00 16,3 17,6 4,05 Small 25 Straight through
10 10,00 32,7 34,8 8,00 25 large 25 Split
