The following abbreviations are used throughout this document: R&S® SMA100A is abbreviated as R&S SMA100A.
Test and Measurement
Release Notes

R&S SMA100A
Release Notes for Firmware 1171.5360.52 2
Table of Contents
1INFORMATION ON THE CURRENT VERSION AND HISTORY.....4
1.1 Special hints for particular instruments and firmware versions.....................4
1.2 Version 3.50.057.29......................................................................................................6
1.3 Version 3.01.102.20......................................................................................................6
1.4 Version 3.01.102.17......................................................................................................7
1.5 Version 3.01.102.14......................................................................................................8
1.6 Version 3.01.102.11......................................................................................................8
1.7 Version 2.20.470.33......................................................................................................9
1.8 Version 2.20.470.30....................................................................................................10
1.9 Version 2.20.470.18....................................................................................................10
1.10 Version 2.15.185.25....................................................................................................12
1.11 Version 2.15.185.22....................................................................................................12
1.12 Version 2.15.185.17....................................................................................................12
1.13 Version 2.15.185.15....................................................................................................13
1.14 Version 2.15.185.13....................................................................................................13
1.15 Version 2.10.001.31....................................................................................................15
1.16 Version 2.10.001.26....................................................................................................15
1.17 Version 2.10.001.22....................................................................................................16
1.18 Version 2.05.220.13....................................................................................................17
1.19 Version 2.05.220.10....................................................................................................17
1.20 Version 2.05.220.02....................................................................................................17
1.21 Version 2.05.68.18......................................................................................................18
1.22 Version 2.05.68.17......................................................................................................19
1.23 Version 2.05.68.13......................................................................................................19
1.24 Version 2.05.04 ...........................................................................................................20

R&S SMA100A
Release Notes for Firmware 1171.5360.52 3
1.25 Version 2.04.299.02....................................................................................................21
1.26 Version 2.02.149.........................................................................................................22
1.27 Version 2.02.136.........................................................................................................23
1.28 Version 2.02.102.01....................................................................................................23
1.29 Version 2.02.91 ...........................................................................................................23
1.30 Version 2.02.76 ...........................................................................................................24
1.31 Version 2.01.11 ...........................................................................................................24
1.32 Version 2.00.43.01......................................................................................................25
2INFORMATION ON REMOTE CONTROL EMULATIONS.............26
3FIRMWARE UPDATE ....................................................................27
3.1 Update Information....................................................................................................27
3.2 Firmware update using R&S firmware update file via USB memory stick..27
3.3 Firmware update using R&S firmware update file via LAN.............................29
3.4 Firmware update using ISO image ........................................................................31
4CUSTOMER SUPPORT.................................................................33

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 4
1Information on the Current Version and
History
General information
This document describes the procedure to apply a firmware update to the
R&S®SMA100A Signal Generator. It furthermore describes the differences between the
several firmware versions. The most current firmware version can be obtained from
www.rohde-schwarz.com.
Instruments covered
This firmware version is suitable for all instruments of type R&S®SMA100A,
including all module revisions, options and firmware licenses.
Identify current firmware version
The current instrument firmware revision is displayed during the startup sequence of
the instrument. In addition, it is provided in the SETUP Software/Options dialog and it is
part of the SCPI *IDN instrument identification string.
Potential malfunction of assembly!
It is strongly recommended to do no firmware downgrade below the version the
device was originally delivered with. Improved module revisions as well as modified
structure of calibration data may not be supported by previous firmware versions.
1.1 Special hints for particular instruments and
firmware versions
Instruments with serial number 112000 or higher
It is not possible to downgrade the firmware to version less than 3.01.102.11. After a
downgrade the R&S® SMA100A does not work furthermore. The serial number of the
R&S® SMA100A could be obtained in the menu SETUP / Hardware Config .Please select
the entry SMA100A in the table Common Assembly.

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 5
Instruments with firmware greater or equal than 3.01.102.11
The R&S® SMA100A firmware does not support the folder /var/sma furthermore. The
folder will be deleted by the update process. All data stored in /var/sma will be moved
to /var/user. Please use the folder /var/user to save user data in the future.
Instruments with firmware greater or equal than 2.20.470.18
It is not possible to downgrade the firmware. After a downgrade an error message
“corrupt datablock found in Eeprom memory” appears.
Instruments with firmware less than 2.15.185.13
To update these instruments to the current firmware version, the update procedure
based on the ISO image file is required, as described in chapter 3.4.
Instruments with firmware less than 2.04.299.02
To update these instruments to the current firmware version, the update procedure
based on the ISO image file is required, as described in chapter 3.4.
Instruments with firmware prior to 2.05.68.13
Due to customer demands, starting with Firmware Version 2.05.68.13 the reference
oscillator settings are moved out of the scope of PRESET and *RST. This change
has been made since the reference oscillator loop takes several seconds to
synchronize and unintentional modification following *RST lead to long measurement
times and disturbance of other instruments relying on the reference.
In general the focus of *RST is to reset states regarding internal instrument operation
while leaving settings which are associated to the measurement and remote control
environment.
So in addition to the reference oscillator the following settings are out of the scope of
*RST:
RF Level Limit
Current level unit and EMF state
Remote control settings including GPIB address and emulation mode
Network settings
Keyboard and Screen Saver settings
Start / Stop GUI update
Power On settings
Security settings
With exception of the security settings these settings can easily be reset to factory
values by means of the function Factory Preset, located at the bottom of the SETUP
Menu. Factory Preset includes the scope of PRESET. Security settings (e.g. passwords
and enable/disable states of USB and LAN) are not affected to maintain instrument
security. For remote operation the command SYST:FPReset is provided. Be aware
that executing this command likely terminates the remote connection.

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 6
Furthermore, beginning with Version 2.05.68.13 the behavior of the key WINBAR has
changed. It now directly toggles between the open setting dialogs. It is not necessary
to use the rotary knob.
1.2 Version 3.50.057.29
Released: August 2016
New Functionality
●Support of new power sensors NRP8S, NRP18S, NRP33S, NRP40S, NRP50S,
NRP6A, NRP18A, NRP18T, NRP33T, NRP40T, NRP50T, NRP67T and NRP110T
●New remote control emulation AF2042(ADF) to support the modulation ADF with
AF2042.
Modified Functionality
●The resolution of the frequency is increased from 0.01 Hz to 0.001 Hz
Fixed Issues
●DME Modulation (R&S® SMA-K26): If no R&S® SMA-K25 is installed, the error
message “Hardware missing” appears, when the parameter DME ID Code is
changed.
1.3 Version 3.01.102.20
Released: October 2014
Modified Functionality
Support of the new revision 12.00 of the RF output unit.
VOR Modulation (R&S® SMA-K25): The resolution for the following parameters
are increased:
oVAR/REF Frequency 0.1 Hz → 0.01 Hz
oSubcarrier Frequency 0.1 Hz → 0.01 Hz
oCOM/ID Frequency 0.1 Hz → 0.01 Hz
ILS-GS Modulation (R&S® SMA-K25): The resolution for the following parameters
are increased:
oUp Frequency 0.3 Hz → 0.03 Hz
oDown Frequency 0.5 Hz → 0.05 Hz
ILS-LOC Modulation (R&S® SMA-K25): The resolution for the following
parameters are increased:
oLeft Frequency 0.3 Hz → 0.03 Hz

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 7
oRight Frequency 0.5 Hz → 0.05 Hz
oCOM/ID Frequency 0.1 Hz → 0.01 Hz
MKR-BNC Modulation (R&S® SMA-K25): The resolution for the following
parameters are increased:
oCOM/ID Frequency 0.1 Hz → 0.01 Hz
ADF Modulation (R&S® SMA-K25): The resolution for the following parameters are
increased:
oCOM/ID Frequency 0.1 Hz → 0.01 Hz
Fixed Issues
Remote control emulation for AF203x / AF204x / AF205x: The preset behavior
depends on the installed options.
1.4 Version 3.01.102.17
Released: February 2014
New Functionality
●Level Settings: Added new parameter “Ignore Level Range Warnings”. If it is active
the following warnings will be suppressed:
–-221,"Settings conflict;Level Overrange"
–-221,"Settings conflict;Level Underrange"
–-221,"Settings conflict;PEP value greater than defined upper bound (fix range)"
–-221,"Settings conflict;PEP value less than defined lower bound (fix range)"
Modified Functionality
●VOR Modulation (R&S® SMA-K25): For the SCPI command
[:SOURce]:VOR:ICAO:CHANnel the selection of ICAO channels are changed from
the notation <ChannelSuffix><ChannelNumber> to
CH<ChannelNumber><ChannelSuffix>.
The old notation works furthermore for set commands.
For example:
[:SOURce]:VOR:ICAO:CHANnel CH17X
●DME Modulation (R&S® SMA-K26) : For the SCPI command
[:SOURce]:DME:ICAO:CHANnel the selection of ICAO channels are changed from
the notation the notation <ChannelSuffix><ChannelNumber> to
CH<ChannelNumber><ChannelSuffix>.
The old notation works furthermore for set commands.
For example:
[:SOURce]:VOR:DME:CHANnel CH17X

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 8
Fixed Issues
●DME Modulation (R&S® SMA-K26): Changing the pulse repetition rate has no
effect, when DME mode is reply and squitter is on.
●In rare cases the level of the R&S® SMA100A is too high. Only if attenuator mode
is set to High Power Mode and ALC state is set to off.
1.5 Version 3.01.102.14
Released: October 2013
Modified Functionality
●Attenuator Settings: The lower limit of the level range is shifted around -5 dB (only
for R&S® SMA-B103 and R&S® SMA-B106)
Fixed Issues
●NRP-Z Power Viewer:
–After a factory preset the NRP-Z Power Viewer could not be switched on.
–In rare cases the NPR-Z Power Viewer in the block diagram is not readable.
●The dialog Software Options open up very slow.
●After a firmware update via LAN a message box appears.
●The display seems to be diffuse.
●The firmware update using ISO image does not create the directory /var/user.
1.6 Version 3.01.102.11
Released: October 2013
New Functionality
●Support of new synthesis extension board (R&S®SMA-B20, SYNEX) with part
number 1413.1800.06
●Support of new synthesis extension board (R&S®SMA-B22, SYNEX) with part
number 1413.1800.02
●Support of new rf output unit board with part number 1400.1707.07
●New remote control emulation for R&S® SME02, R&S® SME03, R&S® SME06
●New remote control emulation for Panasonic PA8303
●Remote update via LAN. For details see chapter 3.3
●Security Settings:

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 9
–New selection Write Nonvolatile Memory: If it is set to disable, no data will be
written to the mass memory storage of the device.
–New selection User Interface: If it is set to disable, the display and the
keyboard of the R&S® SMA100A is locked. To unlock enter the security
password.
●LAN Services:
–New selection Software Update: If it is set to disable, the remote update via
LAN is disabled.
●Network Settings:
–New parameter DNS Suffix
–New parameter DNS Server
●RF Frequency Sweep, Level Sweep and LF Frequency Sweep:
–New parameter Retrace (only for sweep mode Single or Extern Single)
Modified Functionality
●The settings for instrument emulations are moved from the dialog Setup  Remote
Channel Settings to the new dialog Setup  Instrument Emulations
●Improved display update repetition rate
●For level values less than -120 dBm, the message “Level under range” appears.
●The folder /var/sma to save user data is not supported anymore and will be deleted
by the update process. All data stored in /var/sma will be moved to /var/user/.
Please use the folder /var/user to save user data in the future.
1.7 Version 2.20.470.33
Released: July 2013
New Functionality
●New remote control emulation HP 8657
●Added support of dual sine and noise waveform to remote emulation Agilent E4428
Fixed Issues
●R&S® SMA-B20 and R&S® SMA-B22: If FM modulation with Lf Gen 2 and shape
Square is active, the error message “Synthesis extension: Overvoltage at external
modulation input detected” appeared.
●In rare cases, the error message “Verify failed during reading eeprom data from
device” appeared.

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 10
1.8 Version 2.20.470.30
Released: June 2013
Fixed Issues
●DME Modulation (R&S® SMA-K26)
–The selection of the ICAO channels was too long.
–The parameter Range Delay was wrong, if ICAO channels were selected.
–In rare cases, the entered squitter rate was not accepted, if it was entered
using the front panel keys.
–In rare cases, the parameter Range Distance was rounded in a wrong way.
●In rare cases, the error message ‘CWOP6 PLL unlocked’ appeared, if the
frequency was changed from a value below 3 GHz to a value above 3 GHz.
●Phase Modulation (R&S® SMA-B20 or R&S® SMA-B22): The parameter PhiM Int
Deviation could not be completed by the *1/Enter key.
●LF Generator: The SCPI command [:SOURce]:LFOutput<ch>:INTernal:VOLTage
does not work for <ch> greater than 1.
1.9 Version 2.20.470.18
Released: August 2012
New Functionality
●NRP-Z Level Control: Level can be continuously controlled using NRP-Z power
sensors.
●New Setting “Frequency Multiplier” enables the instrument to modify the displayed
frequency value by a user definable factor.
●Support of IVI-6.1 High Speed LAN instrument protocol (HiSLIP)
●LAN Services can be enabled and disabled individually to prevent unintended
access to instrument
●Frequency and Level displays can be annotated in SETUP Security in order to
conceal the current frequency and level and showing only asterisks instead.
●New remote control emulation R&S® SMT03
●New remote control emulation R&S® SMY01 and R&S® SMY02
Modified Functionality
●VOR Modulation (R&S® SMA-K25): Added ICAO channels, if Carrier Freq. Knob
Step is set to Defined.

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 11
●ILS-Loc/ILS-Gs Modulation (R&S® SMA-K25): The parameters are sorted in a
different order for improved usability.
●DME Modulation (R&S® SMA-K26): The parameters are sorted in a different order
for improved usability.
●DME Modulation (R&S® SMA-K26): Channel Suffix enhanced with ICAO channels.
●Phase settings: The resolution for delta phase changed to 0.01 deg
●Improved stability and performance of USBTMC
●Directory /var/user, that is intended for user data storage, is no longer used by any
instrument files. Former instrument directories like “Lists” may be removed if
appropriate.
●Support of wildcards ‘*’ and ‘?’ in mass memory system MMEM
●Remote control emulation Aeroflex 202x: Added suffix 2 as an alias for suffix 1 in
AM, FM and PM subsystem
●Remote control emulation Aeroflex 203x/204x: Added subsystem SWEEP
●Remote control emulation Agilent E44xx/N51xx: Added file selection for the
variants “file@msus”, “msus:file” and “absolute path to file” to the MMEM/MEM
subsystem. Valid data for msus are “UFLT” and “LIST”.
●Remote control emulation Agilent E44xx/N51xx: Added subsystem LIST and
SWEEP
Fixed Issues
●VOR Modulation (R&S® SMA-K25): Missing SCPI
command :SOURce:VOR:FREQuency:STEP to set the Carrier Freq Knob Step to
Defined.
●All Sweeps: In mode Single with shape Triangle, the R&S® SMA100A ignores
Execute Single commands while the sweep is running
●All Sweeps: In mode Extern Single with shape Triangle, the R&S® SMA100A
jumps back to the beginning and stops (like reset) on external trigger signals
applied during the triangle return slope.
●Listmode: In mode Single, the R&S® SMA100A ignores Execute Single commands
while the listmode is running
●viClear() over USBTMC blocks further communication
●Communication break, after applying viClear() to USBTMC interface
●*CLS did not clear error queue
●Some message boxes did not accept ENTER/x1
●NRP-Z Power Viewer indicator could not be configured to display peak values
●Socket connection might lose data packages send in a fast sequence
●Several issues around the data/time dialog

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 12
●IEEE488 GTL message potentially outruns last command header causing the
instrument to re-enter the remote state (looks like GTL does not work)
1.10 Version 2.15.185.25
Released: September 2011
New Functionality
●New parameter RF OFF Mode in dialog “Level”, section “Attenuator Settings”. The
two modes “Full Attenuated” and “Unchanged” are available. The mode “Full
Attenuated” is the default and the R&S SMA100A has the same RF OFF behavior
as before. With the mode “Unchanged” it is possible to prevent switching of the
attenuator relais. The SCPI command is POWer:ATTenuation:RFOFf:MODE
UNCHanged | FATTenuated.
Fixed Issues
●Option R&S® SMA-K26 (DME): Changing the pulse repetition rate has no effect,
when DME mode is reply and squitter is on.
1.11 Version 2.15.185.22
Released: March 2011
New Functionality
●Remote control emulation Aeroflex 2040: For ILS-LOC modulation the COM-ID
code is programmable via sequence generator
Fixed Issues
●Adjust DME Pulse Slope: In rare cases, the DME Pulse Slope adjustment failed
due to corrupt calibration files
●External Level Adjustment: In rare cases, the external level adjustement failed due
to low level
1.12 Version 2.15.185.17
Released: December 2010
Fixed Issues
●External Level Adjustment: Customer data will not be used after power on

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 13
●No valid DME pulse will be generated, if DME NRP trigger normalization failed due
to missing connection between RF output and R&S® NRP-Z81
●Wrong FM deviation, if the DME modulation was active before
●DME modulation: Mode “Reply”, Trigger Mode “Ext. Power Sensor”: Trigger does
not work after changing the frequency
●DME Modulation: After execution of “Normalize Setup” in DME Analysis the system
will hang for several minutes.
1.13 Version 2.15.185.15
Released: October 2010
Fixed Issues
●Adjustment after firmware update is not working due to restrictions in the file
system. This effect could only show up when updating older instruments with rsu-
files. Newer instuments (shipped from mid 2009) are not affected.
●Entering new license keys may lead to misleading error messages.
●Remote commands *IDN? and *OPT? are not working correctly when code
emulation is active, i.e. SCPI language is not native ("SCPI").
1.14 Version 2.15.185.13
Released: October 2010
New Functionality
●Support of new wide screen display (this version is necessary for all SMA with
serial number higher than 103000)
●Remote control emulation Agilent E4428 and E4438 (ESG)
●Remote control emulation Agilent E8257 and E8267 (PSG)
●Remote control emulation Agilent E8663
●Remote control emulation Agilent N5161, N5162, N5181, N5182, N5183 (MXG)
●Remote control emulation Racal 9087
●Remote control emulation Aeroflex 2051/2052
●Option R&S® SMA-K28 (Power Analysis): New trigger modes “Internal” and
“External”
●Option R&S® SMA-K28 (Power Analysis): User specific level offset
●Option R&S® SMA-K28 (Power Analysis): Added mathematical functions and
reference trace

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 14
●Annotation of Frequency and Level displays can be disabled and enabled in SETUP
Security
●Display can be deactivated to hide instrument settings. Configuration in SETUP
Security or by SYSTem:DLOCk ON|OFF.
●Keyboard can be deactivated to prevent unauthorized modification of instrument
settings. Configuration in SETUP Security or by SYSTem:KLOCk ON|OFF
Modified Functionality
●RF leakage improved if RF OFF
●NRP-Z Power Viewer will be switch on by default if a power sensor is plugged in
●Support of up to four power sensors in Power Viewer and Power Analysis. New
SETUP NRP-Z Info dialog provides properties of all power sensors connected. In
addition, sensor firmware can be updated via instrument.
●Level unit is preserved during power off
●All sweeps: Maximum dwell time increased to 100s
●Revised and simplified configuration of emulation settings in Remote Channel
Settings dialog.
●External USB keyboards: Support of international keyboard layouts
●Revised and simplified network settings dialog including connection state indicator.
Option “Peer to Peer” removed since this feature is covered by the “Auto(DHCP)”
mode now.
●Improved Security concept (menu SETUP Security Settings)
●Improved file selector and file manager
●To avoid unintentional instrument settings, values entered by keyboard or front
panel will be discarded when input is aborted without confirmation by ENTER or unit
key
●OCXO Adjustment: Calibration value is not affected by PRESET or *RST
●Remote control emulation HP 8643: FMpreemphasis and LFSource:xyz2
implemented
●Improved firmware update process in case of less free flash memory
Fixed Issues
●Option R&S® SMA-K27 (Pulse Train): Repetition count does not work for last table
entry in trigger mode “Ext Triggered”
●SCPI command SENS:POW:SOUR returns RF instead of “A”
●SCPI command CORR:CSET:DATA:SEND:POW:SONC does not work
●AM Modulation: For frequencies <= 30 MHz the error message “Level Overrange”
appears

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 15
●The SCPI commands FREQ:CENT? MAX/MIN and FREQ:SPAN? MAX/MIN
returns always the maximum/minimum RF frequency
●Level user step does not work correct as expected
●Remote control emulation Rohde & Schwarz SMGU: Ignore white spaces
●Remote control emulation HP 8662: Errors while mixing different modulations
●Remote control emulation HP 8662: Command FR causes an error “Value out of
range”
●Network settings (e.g. IP-Address) were lost when configured while no network is
attached
●Missing error message when attempting to disable USB mass storage usage while
storage is attached
●Sporadic lockups in raw ethernet channel
●Several issues regarding SCPI MMEM subsystem
●If the screensaver is disabled by SCPI the display is not switched on
1.15 Version 2.10.001.31
Released: October 2009
New Functionality
●Composite AM (15 Hz/135 Hz) included in DME modulation (Option R&S® SMA-
K26)
Fixed Issues
●ILS Modulation: Wrong LF Output Level
●In rare cases, an error message “Settings Conflict” occurs after PRESET
1.16 Version 2.10.001.26
Released: June 2009
New Functionality
●Remote control emulation Rohde & Schwarz SMGU/SMHU
Modified Functionality
●All avionics modulation (Options R&S® SMA-K25: VOR/ILS and R&S® SMA-K26:
DME): COM/ID code supports numerics

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 16
Fixed Issues
●DME Modulation: ID Rate not correct
1.17 Version 2.10.001.22
Released: June 2009
New Functionality
●Pulse Train (Option R&S® SMA-K27)
●Remote control emulation Aeroflex 2023/2024
●Remote control emulation Aeroflex 2050
●Remote control emulation HP 8643/8644
●Remote control via RS232 by means of a standard external USB to RS232 adapter
Modified Functionality
●Improved NRP-Z Power Analysis (Option R&S® SMA-K28) including Pulse Data
Analysis capabilities and gate mode
●All avionics modulation (Options R&S® SMA-K25: VOR/ILS and R&S® SMA-K26:
DME): COM/ID code supports up to 4 characters
●VOR modulation (Option R&S®SMA-K25): Subcarrier frequency resolution
changed from 10 Hz to 0.1 Hz
●ILS-GS and ILS-LOC modulation (Option R&S® SMA-K25): DDM can be entered
in %
●DME modulation (Option R&S® SMA-K26): Variable squitter rate
●Improved frequency offset setting
●Instrument can be switched off by remote command: SYSTem:SHUTdown
●Instrument firmware can be restarted by remote command: SYSTem:RESTart
●New dialog SETUP / NRP-Z Info provides information of attached power sensors
and the feasibility to update the firmware of attached power sensors
●Improved file selector and file manager
●USB Resource String: Product ID displayed as HEX-value
Fixed Issues
●Remote control: Sporadic locks in raw Ethernet channel
●Storing files using MMEM instructions failed if file already exists (affects SAV/RCL)
●Values of 0.0 sometimes displayed with too much digits and improper unit

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 17
1.18 Version 2.05.220.13
Released: December 2008
Fixed Issues
●File manger shows invalid directories
●Bugfix for selftest
1.19 Version 2.05.220.10
Released: November 2008
Modified Functionality
●Remote control emulation: The selected remote control emulation will be displayed
in the info line
Fixed Issues
●The button “Adjust DME Pulse Slope” in the dialog “Internal Adjustemnts” does not
have any function until the DME dialog would be opened for the first time
●During the DME analysis the error message “Err-222 Value out of range” appears
●SMA-B103L and SMA-B106L does not support DME
●The tooltip does not display the correct values and units
●Changes at the level units does not work
●The BUSY indicator does not appear during the whole preset time
●Some read only parameters are not marked as read only parameters
●Downgrade to a firmware version 2.05.68.18 or lower does not work
1.20 Version 2.05.220.02
Released: October 2008
New Functionality
●New feature DME Modulation (Option R&S® SMA-K26)
●New feature Power Analysis (Option R&S® SMA-K28)
●New feature remote control emulation HP 8642
●New feature remote control emulation HP 8645
●New feature remote control emulation HP 8647/8648

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 18
●New feature remote control emulation HP 8664/8665
Modified Functionality
●ILS-GS and ILS-LOC: New parameter DDM Polarity. In the default state this value
is 90 Hz – 150 Hz
●All avionics modulation (Options R&S® SMA-K25 and R&S® SMA-K26):
Enhanced COM/ID settings, with the possibility to set individual dot, dash, symbol
space and letter space length.
●NRP-Z Power Viewer: Support of up to three R&S NRP-Zxx power sensors. The
different R&S NRP-Zxx power sensors can be selected via a combobox at the top
of the dialog NRP-Z Power Viewer.
●The summary screen (large frequency and level display) can be activated and
deactivated in the menu Setup → Display Settings. In the default state the
summary screen is deactivated. This setting is not affected by pressing the
PRESET button or sending *RST.
●The RF output can be deactivated, if the reference oscillator source is set to
external and no reference signal is connected. In this case the RF output can be
deactivate in the menu RF → Ref Oscillator. In the default state the RF output is
not deactivated. This setting is not affected by pressing the PRESET button or
sending *RST.
Fixed Issues
●LF Output: The LF generator frequency differs for more than 5 mHz
●Dialog of the online help window too large
●Adjustment: If the internal adjustments are executed with external reference, and
no external reference is connected, no error message occurs. Phase continuous
frequency settings: In rare cases the frequency synthesis could be work in an
undefined state. Only with R&S SMA-B20
●ILS-GS and ILS-LOC: Improvements for DMM input in µA
●Remote control emulation: No remote sign in emulation mode
●Remote control emulation Aeroflex 203x/4x: The command MODE does not work
1.21 Version 2.05.68.18
Released: July 2008
Fixed Issues
●External Pulse Modulation: Unwanted double pulse at rising pulse edge

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 19
1.22 Version 2.05.68.17
Released: May 2008
Fixed Issues
●Modulation ILS-GS/ILS-LOC: Entering DDM values less then -0.8 (ILS-GS) or less
then -0.4 (ILS-LOC) crashes the software, if DMM is coupled to SDM
1.23 Version 2.05.68.13
Released: April 2008
New Functionality
●Support of NRP-Zxx power sensors (power viewer and user correction)
●Chirp modulation, this feature is available only for interface boards with part
number 1400.0530.02
●Phase Continuous Frequency Settings
●Remote control emulation for HP 8643/8644
Modified Functionality
●Support of new standard synthesis (SSYN) with part number 1141.4220.02
●Support of new synthesis extension (SMA-B20, SYNEX) with part number
1142.0270.02
●Support of new clock synthesis (SMA-B29, ClkSyn) with part number
1400.2749.02
●DC offset for clock synthesis (SMA-B29), this feature is available only for clock
synthesis with part number 1400.2749.02
●LF generator: LF generator frequency resolution changed from 0.1 Hz down to
0.01 Hz
●RF Frequency Sweep: Support of new shape ‘triangle’
●RF Level Sweep: Support of new shape ‘triangle’
●LF Frequency Sweep: Support of new shape ‘triangle’
●The behaviour of the WINBAR key has been modified. The WINBAR key toggles
through all open windows
●The behaviour of the DIAGRAM key has been modified. The DIAGRAM key toggles
between diagram, the summary screen and the last open dialog
●Dialog File Manger: Handling improved
●Support of up to four USB mass memory devices (e.g. USB memory sticks) for
user data

R&S SMA100A Information on the Current Version and History
Release Notes for Firmware 1171.5360.52 20
●New function “Factory Preset” (Setup-Menu) resets settings not covered by
PRESET Key
●PRESET (*RST) does not affect reference oscillator settings any more
Fixed Issues
●Remote Control: The command SOURce:POWer UP does not work
●Modulation ILS-GS/ILS-LOC: The DDM could not be entered in µA
●Remote Control Emulation: A user defined selection of *IDN? does not have any
effect
●Remote Control Emulation: *IDN? selection does not saved while firmware
shutdown
●Remote Control Emulation Aeroflex203x/4x: CFRQ? Does not return the current
frequency
●Remote Control: Time parameters do not work in exponential description
●Listmode: Listmode does not work for f > 3GHz, if SMA-B106 and SMA-B20
installed
●Modulation ILS-GS/ILS-LOC: No coupling between GS and LOC
●Modulation ILS-LOC: Setting of modulation frequency does not have any effect
●MenuSetupEthernet does not open the remote settings for Ethernet
●Online Help: Missing help pages for few pulse generator and listmode parameters
●Save/Recall: Could not recall saved setups
1.24 Version 2.05.04
Released: November 2007
New Functionality
●New feature remote control emulation for Aeroflex
2030/2031/2032/2040/2041/2042
●New feature remote control emulation for Racal 3102
Modified Functionality
●Support of new interface board (IfBoard) with part number 1400.0530.02
●Sweep: Minimum dwell time change from 10 ms down to 3 ms
●Pulse generator: New limits for pulse period (20 ns to 100 s), pulse width (5 ns to
100 s), pulse Delay (10 ns to 100 s), double pulse width (5 ns to 100 s), double
pulse delay (10 ns to 100 s) and resolution (5 ns)
