Devine D-Series User manual

D-series (D-200, D-400, D-600)
digital class D power amplifiers
User manual
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

Safety instructions
This unit must be operated by, or under the supervision of an adult. This device is not suitable for children.
Every person involved with the installation, operation and maintenance of this device has to:
- Be qualified
- Follow the instructions of this manual
- Ma e sure there is no damage caused by transport. If the device seems damaged from the outside, do not
use it and contact your dealer for more information and consultation.
- To ma e sure the device maintains in perfect condition and for safe operation, it is necessary for the user to
follow the instructions and warning notes of this user manual.
- Damage caused by improper use or modifications to the device are not covered by warranty.
- This device does not have any user-serviceable parts inside. Servicing of this device needs to be done by
qualified technicians.
Important notes regarding safety and ealt :
- Always eep the power cord away from other cables. Handle the power cord and all connectors with
caution.
- Never remove any warning or informative labels from the unit
- The ground contact always needs to be connected. Do not cover or remove the ground contact.
- Never leave cables lying around
- Do not open the device and do not modify any hard- or software of this unit.
- Do not insert this object into air vents.
- Do not connect this device to a dimmerpac .
- Do not switch the system on and off frequently as this will reduce the lifespan of the device.
- Do not drive the inputs of the fixture with a signal larger than required to wor at full performance.
- Only use this device indoor, avoid contact with water, moist or other liquids. Do not place items filled with
liquids on top of the unit.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV
WARNING!
Always keep t is device away from moisture and rain! Hazardous electrical s ocks may occur!
WARNING!
Only connect t is device to a matc ing power outlet. T is device is intended to work on a
specified AC currency. Connecting t is device to power outlets wit ot er voltages may result in
permanent damage and possible azardous situations, suc as fire or electrical s ocks!
WARNING!
Be careful wit every operation of t is device. Touc ing live wires inside and outside t e unit
may cause azardous electrical s ocks!

- Avoid nearby flames or heat sources, do not place this device near flammable liquids, gas or flammable
items.
- Always disconnect the device when it is not in use for a longer period of time, when servicing is needed or
when the device needs cleaning.
- Only handle the power cord by its connectors. Never pull the cable to remove a connector from its soc et,
as this could lead to damage and electrical shoc s.
- Always operate this device with a stable AC current.
- Always operate this device with the AC ground wire connected to the electrical system's ground.
- Never use other types of cables than specified in the manual, do not use defective or bad functioning
cables. Contact your dealer when the included or required cables do not wor properly with this device.
- When the device has been exposed to large temperature differences (for example, transport from outdoor
to indoor), do not connect the device immediately. Do not activate the unit until it has reached room
temperature, as moist might build up inside the unit, which may cause short circuits and/or electrical shoc s.
Guidelines and types of use:
- This device is intended to be used by professionals on stage, in theaters, clubs and other equal venues.
- This device is not suitable for children and always needs to be operated by an adult.
- Only use the device when the environment is suitable and will not cause any damage. Do not use the
product in moist or dusty environments, or where long-term damage may occur such as:
- indoor swimming pools where chlorine is used.
- Beaches, where sand and salt are present.
- Outdoor, without roof protection
- Indoor areas where intense heat sources are present or where the temperature exceeds levels
which are comfortable for humans.
- Only use the included power cable and only connect the device to a suitable power outlet with the correct
output voltage. Connecting the device to a power outlet with the wrong type of voltage or using the product
with a wrong type of power cable may cause permanent damage to the device.
- Avoid shoc s and collision during use and transport. Do not transport the device while in use. Avoid brute
force during the installation and operation of this device.
- Familiarize yourself with the functions of the device before use. Do not allow operation of the device by
uns illed or unqualified people.
- Use of the device in other ways than described in this user manual may cause damage and injury. Devine
can not be held responsible for any damage or injury caused by improper use.
Storage and transport:
- This device is intended for mobile use. When transported, use the original pac aging of the product, or a
fitting flight case, preferably filled with foam.
- This device is not intended for permanent use. Operation brea s will ensure that the lifespan of the device
remains unchanged.
- If the device is not used for a longer period of time, disconnect it from its power source and store it in its
original pac aging, or in a fitting flight case.
- Store the device indoor, dry and do not expose the device to extreme temperature differences.
Housing:
- Inspect the housing of the device frequently. Severe dents, crac s and missing screws should be avoided
at all costs. Do not use the device when the housing is not in optimal condition. Contact your dealer or a
s illed technician when in doubt about the state of the device.
- Chec the fixture and screws for corrosion. Corrosion should not be present on the fixture. Contact your
dealer or a s illed technician when corrosion is found on the fixture.
- Every power or signal chassis/connector should be mounted tightly. Do not use the device when connectors
are loose.
- Do not use the power cord when the cores are visible. Contact your dealer for a replacement if needed.
- Avoid the buildup of dust and dirt. Clean the exterior of the fixture every month with a dry or damp cloth.
When using the device intensively, the cleaning frequency needs to be increased.
Fuses:
- The main fuse of this device is to be found on the rear of the device. In most cases, directly next to the
power inlet.
- Only replace a fuse for a new one with the same type and rating! Do not use a fuse with a higher or lower
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

rating.
- Do not bridge the fuse with electrical wires, aluminum foil, as the fuse is used for protection against
electrical shoc s and short circuit.
- Always mount the fuse cover bac to the fuse compartment.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

Guidelines for speaker systems
- Avoid exposure to ig sound pressure levels for a longer period of time. See t e c arts on t is
page for more information about sound pressure levels and exposure to ig levels.
Continuous dB Permissible exposure time
85 8 hours
88 4 hours
91 2 hours
94 1 hour
97 30 minutes
100 15 minutes
103 7.5 minutes
106 3.75 minutes (<4 minutes)
109 1.875 minutes (<2 minutes)
112 0.9375 minutes (<1 minute)
115 0.46875 minutes (+/- 30
seconds)
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV
WARNING!
T is amplifier is intended to drive passive loudspeakers. T ese may produce a sound pressure
level w ic can be armful for umans and animals w en used incorrectly and/or wit out
protection. Possible permanent earing loss may occur w en umans or animals are exposed to
ig sound pressure levels for a longer period of time.

Introduction
Than you for purchasing this Devine amplifier. To ma e sure you use this product as intended and for
optimal performance and protection of this device, Devine recommends you read this user manual.
The Devine D-series amplifiers consist of several high quality power amplifiers. The D-series are digital class
D power amplifiers, with a digital amplifier circuit installed. Than s to this technology, the D-series are very
compact, lightweight and still very reliable and powerful. The D-series are available in three models.
Box contents:
1x D-series amplifier (D-200, D-400, D-600)
1x power cable
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

Device overview
1. Volume controls
2. Signal LED indicator
3. Limiter LED indicator
4. Power LED indicator
5. ON/OFF switch
6. Rac mount brac ets
7. Ventilation slots
8. Ground lift switch
9. Mode switch
10. Signal input section (Balanced XLR / 6.35 mm TRS jac )
11. Cooling fans
12. Spea er output section (Spea er-loc )
13. Power input connector + fuse holder
14. AC voltage switch 100 / 240V
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV
11
2
2
3
4
657
8
9
10
11
12 13
14
3
6
11
14

Use of t e amplifier
The Devine D-series amplifiers are built to last. To be able to get the most out of your spea er system, it is
recommended to read this section thoroughly, to become familiar with all the options and features of this
amplifier. Correct use of the amplifier will ensure that the expected lifespan of the amplifier remains
unchanged, as overload of this power amplifier may result in defects of your power amplifier and/or spea er
system.
Power ratings
The Devine D-series are a complete range of digital class D power amplifiers, each with their own power
ratings. This way, you are able to select the right amplifier for any job! The D-series consist of the D-200, D-
400 and D-600, each with their own different power rating. The D-200 is the most affordable version, with a
relatively low power rating. This is the ideal power amplifier for spea ers which do not need a large amount
of power. The most powerful version is the D-600, which can be used to power a large subwoofer in bridge
mode, or a couple of PA-spea ers.
To be sure that this power amplifier can be used safely to power the spea ers you wish to connect, pay
attention to the power ratings of your spea ers.
If the RMS power rating of the power amplifier is identical or max. 2x as powerful as needed to drive your
spea ers, the amplifier is suitable. It is not recommended to use a power amplifier which is not capable of
delivering full power to drive your spea ers for optimal performance.
For example, it is not recommended to drive a spea er with a 300W RMS power rating with a power amplifier
which is only capable of delivering a maximum power of 200W RMS. An amplifier with a power rating
between 300W RMS and 600w RMS would be perfect.
The reasons are:
- A more powerful amplifier does not need to perform at 100% of its capacity when the spea er is already
driven with a signal powerful enough to drive the spea er at maximum performance.
- A more powerful amplifier has more headroom when driving a spea er on its maximum level. Therefore,
pea s in the music will not cause clipping (and thus, signal distortion and possible damage when long-term
clipping exposure ta es place)
- A more powerful amplifier can often be used again if you choose to purchase new spea ers with a higher
maximum power rating.
- Defective spea ers (often described as 'blown up') are mostly caused by power amplifiers which cause too
much signal distortion due to frequent and long-term clipping.
- Most spea er ratings are based on measured or theoretically calculated sine waves. As it is li ely to play
music through your spea er system, the audio signal exists of pea s and dips in the music. Most spea ers
are capable of handling certain (short-term) pea s, even when an unexpected signal pea is produced. It is
therefore safe to use a more powerful amplifier to drive your spea ers.
- Clipping amplifiers can cause permanent damage to both your spea ers and power amplifier. A powerful
amplifier is more li ely to provide sufficient headroom and long-term exposure to excessive amplifier power
will only affect your spea er system.
How far can I turn t e amplifier volume knobs?
Keep in mind that the power ratings of your spea er system and power amplifiers are mostly measured or
theoretically calculated with sine waves. As mostly music is played through your spea er system (which has
a dynamic character), you always need to monitor your spea er performance. Audio distortion may cause a
loss of signal quality and excessive power released to your spea ers may cause signal quality issues and
possible permanent damage.
To be able to maintain optimal signal quality, ma e sure to use this chec list. This is a genuine way to adjust
your spea er system to perform at full performance, but without losing audio quality.
1. Ma e sure your signal source is not overdriving. When using a DJ or PA mixer, or a DJ controller with
audio interface, ma e sure it does not send a signal which exceeds 0dB. Any higher values than 0dB will
cause signal distortion.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

2. Ma e sure that after you chec ed step 1, the amplifier volume controls are carefully turned up as far as
possible.
WARNING: When increasing the volume controls of your amplifier, always listen carefully to the connected
spea ers and eep an eye on the clip indicators of your amplifier. You need to decrease the volume level of
the amplifier channels when any of the following situations are noticed:
- Amplifier channel Clip LED lights up frequently
- Spea er produces a slight distorted sound / noticable loss of audio quality and clarity
To be sure that slight pea s in music do not affect your signal quality and performance, let your signal source
send an audio signal at +3 dB. Then, set the optimal volume control settings on your amplifier and pay
attention to your spea ers and amplifiers (as described above in step 2). When your spea er system
performs on full output without audio quality issues, decrease the audio signal of your signal source bac to
0dB. Now, when a slight audio pea is sent out through your signal source, it will not affect your spea er
system.
Signal source = mostly problem source!
The signal source of your system (mostly a DJ or PA mixer, or a DJ controller) is the source of audio quality
problems in most cases. This is mostly caused by improper gain structure and can be caused by excessive
input signals on your channels. Ma e sure to monitor every processed audio signal in your system for perfect
audio performance. Please note that every fault in your signal source, will be processed and amplified by
your spea er system.
Always ma e sure that the master output of your signal source is not exceeding the 0dB point. If so,
noticeable audio quality loss and possible distortion could be present. Even when your master volume setting
does not exceed the 0dB point, it is possible that an overloaded signal is present on your channel inputs with
a gain set too high. Pay close attention to gain settings on your channel inputs and do not let the input signal
exceed 0dB as well.
Front panel
The front panel of any D-amplifier is equipped with just a few buttons
and LED indicators. This ma es it possible for professionals and
amateurs to wor with any of the D-series amplifiers. The front panel
has the following controls and indicators on board:
Controls:
- volume control for each channel, 0-10 (used to set the desired
volume for each channel)
- Power on/off switch (to switch the device on and off)
Indicators:
- Green signal LED (Lights up when an incomingaudio signal is noticed by the amplifier)
- Red Limiter LED (Lights up when the limiter is active and overloading of the amplifier components is
noticed)
- Blue Power LED (Power On status indicator)
Input section
The Devine D-series amplifiers is equipped with a signal input
section on the rear of the amplifier, clearly mar ed. This input
section is suitable for one stereo input signal, while using the input
of your choice. Examples of proper inputs are available from PA-
mixers, DJ mixers, DJ controllers, audio interfaces and many other
devices which provide high quality stereo line output signals. The D-
series are equipped with balanced XLR inputs, as well as balanced
6.35 mm TRS (jac ) inputs. This ensures optimal quality and will
help to prevent hum and buzz noise issues.
Devine does not recommend to connect a signal source without clear volume setting display (such as an
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

MP3-player or smartphone) directly, as it is not possible to see if the signal is below or above the 0dB line.
However, it is possible to connect such a device to an audio mixer, to be able to see how high the outgoing
volume level of your device is set.
The inputs of this power amplifier may be used as 'signal pass' connections, to be able to connect multiple
amplifiers in a daisy chain setup. Devine recommends to lin no more than three D-series power amplifiers in
a daisy chain setup, to prevent the loss of signal level and quality.
WARNING! Do not send two signal inputs to the amplifier at the same time, as the combination of two signal
inputs will drive the preamp section of the amplifier with a signal higher than allowed. Wrong use of the
inputs may cause loss of quality or even permanent damage.
Ground lift option
The Ground Lift option is used to remove the ground connection of any incoming balanced input signal. This
may help to remove noise, caused by a flowing current in the ground shield. Mostly this is caused by
unearthed equipment which is connected to the chain, or the use of different power circuits. Ma e sure all
your connected audio equipment is connected to the same grounded power circuit. Do not use ground lift
when not necessary to ensure optimal signal quality. The default setting on your power amplifier should be
'Ground'.
WARNING! Please be aware that removing the ground shield of your equipment may be dangerous. The
ground shield of your signal inputs ma es sure that excessive currents will be eliminated and removed
through the ground shield. Removing the ground shield improves the ris of (hazardous) electrical shoc s on
conducting materials such as metal microphone housings.
Output section
The rear of the D-series amplifiers is equipped with a spea er
output section on the rear of the amplifier, clearly mar ed. These
outputs can be connected to the inputs of passive spea ers or
subwoofers (when used correctly – explained later on in this user
manual).
The output section of the amplifier ma es use of spea er-loc
connectors (two blac connectors, one red connector).
Speaker-lock
The blac Spea er-loc connectors are used for regular spea ers in a standard stereo setup and are Neutrik
Speakon© compatible. These connectors are used for mobile use, where the connectors will be plugged in
and removed frequently. To connect one of these plugs, insert the connector in the Spea er-loc chassis and
turn the connector cloc wise. You will hear a 'clic ', which means that the connector is loc ed in place and
perfectly connected.
This ind of connector is usually equipped with 4 pins (2 pin versions are available as well), divided in +1/-1
and +2/-2. The outputs for all D-amplifiers are wired on +1/-1 for each channel.
T e red Speaker-lock connector is used for Bridge mode, but technically identical to the blac Spea er-
loc connectors. Please be aware t at t e wiring is different!
The Bridge output ma es use of the two amplifier channels and combines its power to one signal output.
This ma es it possible to use all of the power from one D-series amplifier to drive one full range spea er or
subwoofer (when used correctly – explained later on in this user manual).
The Bridge output is also wired on +1/-1.
Bridge mode
The Devine D-series amplifiers are equipped with a switch to activate bridge mode. Also the output
connectors of the amplifier are prepared for bridge mode setups. Bridge mode ma es it possible to combine
the power from two channels on one amplifier, to be able to provide sufficient power for one large spea er or
subwoofer (when used correctly – explained later on in this user manual). This way, one single power
amplifier provides power for one spea er, where in normal setups two spea ers would be connected to one
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

power amplifier. To use bridge mode, the switch which normally states Stereo mode needs to be switched to
Bridge mode. Stereo inputs can be connected to the amplifier, as well as mono inputs.
When using the amplifier in bridge mode, only connect spea ers through the Bridge connectors.
Crossover information for subwoofers
Please be aware that the D-series amplifiers do not have an on-board switchable crossover. This means that
it is not recommended to connect a subwoofer without internal filter to the outputs of this power amplifier.
Doing so may cause damage to your subwoofer.
It is however possible to use an external 19 inch crossover, a D-series amplifier and a subwoofer without
internal filter, connected in this particular order. This way, any incoming signal must go through the crossover
first, thus removing any high frequencies from the signal (these will be sent to different outputs for your
fullrange spea ers).
The crossover output for your subwoofer will send a signal to your amplifier inputs, containing frequencies
not higher than the level you have set. This particular small group of frequencies will be amplified through the
D-amplifiers and sent to your subwoofer through the spea er outputs. Never cross any signals for
subwoofers higher than 300 Hz.
Impedance
The Devine D-series are tough professional PA-amplifiers, built to deliver power to your spea ers
continuously.
However, the impedance of your connected loudspea ers is very important, as an impedance which is too
low, may cause serious damage.
T e minimum impedance of a connected loudspeaker (c ain) s ould be no less t an 4 O ms, t e D-
amplifiers are not 2 O ms stable!
This means, that there should never be any spea er or spea er chain connected which has a smaller
impedance than 4 Ohms each side. In bridge mode, only a spea er or spea er chain with a total minimum
impedance of 8 Ohms should be connected.
In stereo mode, it is possible to connect:
- two PA-spea ers, each with a minimum impedance of 4 Ohms, each connected to one of the amplifier
channels.
- four PA-spea ers, each with a minimum impedance of 8 Ohms, whereas two spea ers are directly
connected to the amplifier (each connected to one channel), the two others are connected to the first two
spea ers.
In bridge mode, it is possible to connect:
- One PA-spea er or subwoofer, with a minimum impedance of 8 Ohms
Installing t e amplifier
To install the D-series amplifiers in a 19 inch rac or flight case, practical
mounting brac ets are provided. There are only mounting points at the front
panel installed, due to the low weight of the amplifiers. Than s to the minimal
depth of 18 cm, the amplifiers can be installed in rac s or flight cases with
limited depth. Each D-amplifier is only 1U high.
Stac ing multiple amplifiers while mounted in a 19 inch rac is possible, the
position of the amplifiers in the rac is not important than s to the low weight of
each amplifier. If you have heavier equipment than these power amplifiers, it is
recommended to install them as low as possible into a rac , as the turnover
point for gravity will be positioned lower (thus preventing the case from tipping
over).
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

Power input, fuse and electrical information
The Devine D-series are identical in power connection, they all wor with a standard IEC
input, also found on devices such as a des top computer. The protective fuse is installed
directly next to the power input, as connected power signals will transfer through the fuse
first. When the fuse blows for any reason, disconnect the device from any power source
and inspect the unit before replacing the fuse. If the fuse needs replacement, use a fuse
of the same type and rating and never bridge any gaps with any other conducting
materials. Doing otherwise may cause very dangerous situations and possible (lethal)
injury. Devine can not be held responsible for any injuries or damage caused by replacing
fuses with wrong types/ratings or other conducting materials.
Furthermore, there is a 115 / 230V AC switch provided. The default setting is 230V AC, do not change this
unless you are going to connect the amplifier to a 115V AC outlet! Do not remove the cover in front of the
switch unless you have to change the switch.
Ventilation and cooling
D-series amplifiers from Devine can perform all day or night without cooling-down time. Than s to large
conventional heat sin s and fan cooling, the amplifiers will not overheat in normal environment conditions. To
ma e sure fresh, cool air is delivered to the amplifier and hot air is blown away from the fan, there are
ventilation holes perforated in the housing of the amplifier. Do not in any way bloc any of the ventilation
gaps, to ensure perfect performance. All ventilation slots are equipped with some foam behind the slots. This
prevents the buildup of dust, dirt and influences of small particles such as confetti inside the unit and will
eep the inside of the amplifier clean. It is recommended to use a vacuum cleaner to clean the ventilation
slots regularly, to provide a perfect airflow.
When mounted in a 19 inch flight case or rac , also ensure that there is sufficient ventilation for the power
amplifiers. Keep in mind that most flight cases and rac s have closed bac sides and hot air rises. Therefore,
it is always recommended to install a ventilation panel above your amplifiers, to get rid of excessive heat.
The installed cooling fan is temperature controlled and will only wor at full potential when full power is
required from your amplifier.
Stac ing amplifiers directly (when mounted in a rac or in use as des top stac ) is possible. No more than
three Devine amplifiers should be stac ed, unless there is some included space between every three
amplifiers. This to ensure proper heat dissipation and perfect performance during use.
Built-in protection
The D-series amplifiers are equipped with different types of protection measures, to ensure they eep on
performing in optimal condition and are protected against any influence which may cause serious damage to
the internal electronics.
The following measures are provided:
- Temperature monitoring and protection (prevents from overheating)
- Electronical protection (protects from short circuits)
- DC current prevention on the outputs (DC current on your spea er may cause permanent damage)
- AC protection (fuse)
- Limiter (prevents from overloading)
- VHF distortion (prevents wireless microphone systems from interrupting the signals inside the amplifier)
- Soft Start (prevents a large amount of drawn current from your power circuit when turning a complete
amplifier rac or stac on – which could activate your circuit brea er)
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

Power amplifier troubles ooting
If you have any problems with your power amplifier, consult this troubleshooting section to solve any
difficulties with your product. If this troubleshooting section does not solve your problem, contact your dealer
for more information and help.
This troubleshooting section contains the most frequent problems and is not a complete collection of possible
faults, defects and solutions. The troubleshooting section applies for power amplifiers. It is possible that not
all described problems, causes and solutions apply to your situation as product details may vary from
product to product.
Problem Possible Cause Solution
Product can not be activated ON/OFF switch set to OFF Turn on the amplifier with the
ON/OFF switch, to the ON position
Power not plugged in Connect the included power cable
to the power inlet and a wall outlet
or power soc et.
Fuse blown Disconnect power, inspect the unit
and your power supply for
technical malfunctions. If nothing is
damaged, replace the fuse with
one of the same type and rating
and plug the device bac into your
power outlet.
No sound produced Signal source level set to minimum Increase signal source level
Signal source level on the device
panel set to minimum
Increase volume of signal source
on the amplifier with the volume
nobs
Defective cable Change cable
Spea er not connected properly Chec the connection from your
amplifier to your spea ers
Wrong wor ing mode selected Select the correct wor ing mode
(stereo or bridge) and apply the
correct cabling
Distorted sound Signal source level too high Decrease signal source level
Signal source level on the amplifier
set too high
Decrease signal source level on
the amplifier
Spea ers can't handle the
supplied amplifier power
Decrease volume level on your
signal source or amplifier to avoid
damage
Clipping amplifier channels Decrease volume level on your
signal source or amplifier to avoid
damage
Lac of bass Playbac of a trac without low
frequencies
Try another reference trac to play
through the spea er system.
Bass level set to minimal level on
your signal source
Increase Bass level until neutral
position is achieved
Lac of high frequencies Playbac of trac without high
frequencies
Try another reference trac to play
through the spea er system
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

Treble level set to minimal level Increase Treble level until neutral
position is achieved
Too much bass Bass level set to high level Decrease Bass level until neutral
position is achieved
Too much high frequencies Treble level set to high level Decrease Treble level until neutral
position is achieved
CLIP limiter indicator eeps on
flic ering or is constantly lit
CLIP limiter circuit is active to
prevent overloading of internal
components
Decrease volume settings (signal
source, signal source on mixer
panel or master volume)
Also try to set Treble and Bass to
neutral levels.
Protect LED is active Protection of the internal
components and bloc ing the
incoming/outgoing signals due to
overloading of internal
components
Turn off the amplifier and chec if
your spea er impedance is
correct, if your signal source is
sending an overloading signal or if
the amplifier has been turned up
over its maximum capacity.
Buzzing noise coming from the
spea er
Unearthed power connection Connect the spea er to a
grounded outlet
Unearthed signal source Connect the signal source to a
grounded outlet
Interference from power cables Avoid placing power and signal
cables in a parallel structure and
eep them as far apart as
possible. If needed, cross cables
only in a X-shape.
Bad cables Remove/replace the cable or
increase/decrease the volume of
the spea er. If the noise is gone,
the problem is somewhere in your
signal chain.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV

Tec nical specifications
The Devine D-series amplifiers (D-200, D-400 and D-600) share almost the same electronic circuit. The
differences in the series are mostly the power ratings and in addition to this, the larger power supplies
installed in the devices. As the technical details are nearly identical, the table below describes the
specifications and values for all amplifiers next to each other. Some values and descriptions may be identical
for more than 1 amplifier. Please pay close attention to the power amplifier which you have purchased, by
comparing the type number shown on the front panel of your amplifier with this technical detail scheme.
D-200 D-400 D-600
8 O m stereo output (RMS) 2x 100W 2x 200W 2x 300W
4 O m stereo output (RMS) 2x 180W 2x 360W 2x 540W
8 O m bridge output (RMS) 1x 360W 1x 720W 1x 1080W
Frequency response (+/-1.5 dB) 20 Hz – 20.000 Hz
Minimum c annel impedance 8 Ohms
Input sensitivity 1V
Input impedance (Balanced) 20 Ohm
Input impedance (unbalanced) 10 Ohm
SMPTE 0.05%
S/N ratio (A-weig ted) >100 dBA
T.H.D. (Total Harmonic Distortion) 0.05%
Damping factor @ 1 kHz – 8 OHm >200
Slew rate 20V/uS
Built-in protection measures Soft start, DC current, Short circuit, Limiter, Overheat
Cooling Temperature controlled fans, heatsin s, ventilation slots
Connections (input) Balanced XLR and 6.35 mm TRS jac plug, stereo inputs
Connections (outputs) 2x blac Spea er-Loc for channel outputs
1x red Spea er-Loc output for bridge mode
Input voltage 115/230V AC, 50/60 Hz
Stand-by power consumption <1W
Net. weig t 3.2 g
Dimensions 483 x 160 x 44 mm
Dimensions (rack install) 19 inch, 1U
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-06-2014 RV Revision date + author initials: 02-06-2014 RV
