DeWalt XR DCH072 User manual

DCH072

B
Copyright DeWALT
English (original instructions) 4
繁體中文 14
한국어 22

1
Fig. A
Fig. B
12
9
8
XXXX XX XX
11
9
8
8
9
10
6
3
4
5
1
2
7
圖A
圖B
그림 A
그림 B

2
Fig. C
Fig. E
Fig. G
Fig. D
Fig. F
Fig. H
14
10
4
5
16
15
13
1
6
1
3
圖C
圖E
圖G
圖D
圖F
圖H
그림 C
그림 E
그림 G
그림 D
그림 F
그림 H

3
Fig. I
圖I
그림 I

4
ENGLISH
English (original instructions)
HEAVY‑DUTY SDS PLUS®ROTARY HAMMERDRILL
DCH072
Batteries Chargers/Charge Times(Minutes)
Cat # VAh
Weight
kg DCB104 DCB107 DCB110 DCB112 DCB113 DCB115 DCB116 DCB132 DCB119
DCB122 10.8(12 Max) 2.0 0.22 30 90 90 60 50 30 30 30 60
DCB124/G 10.8(12 Max) 3.0 0.25 45 140 140 90 70 45 45 45 90
DCB125 10.8(12 Max) 1.3 0.20 22 60 60 40 30 22 22 22 40
DCB126/G 10.8(12 Max) 5.0 0.44 75 240 240 150 120 75 75 75 150
DCB127 10.8(12 Max) 2.0 0.22 30 90 90 60 50 30 30 30 60
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
DCH072
Voltage VDC 10.8(12 Max)
Battery type Li‑Ion
Maximum power output W400
No‑load speed min‑1 0–910
No‑load beats per min bpm 4280
Single impact energy (EPTA 05/2009) J1.1
Optimum drilling range mm 4–10
Maximum diamter concrete mm 14
Tool holder SDS plus®
Weight (without battery pack) kg 1.7
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool
is switched off or when it is running but not actually doing
the job. This may significantly reduce the exposure level
over the total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm
(relevant for vibration), organisation of workpatterns.
aWARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.

5
ENGLISH
Batteries
Chargers/Charge Times (Minutes)
Cat #
DC
Weight
*Date code 201811475B or later
**Date code 201536or later
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE
The term “power tool” in the warnings refers to your
mains‑operated (corded) power tool or battery‑operated (cordless)
powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non‑skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off‑position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust‑relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.

6
ENGLISH
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
5) Battery Tool Use and Care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury andfire.
c ) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or afire.
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation orburns.
e ) Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk
ofinjury.
f ) Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 130°C may causeexplosion.
g ) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified range
may damage the battery and increase the risk offire.
6) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool ismaintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized serviceproviders.
Additional Safety Instructions for
RotaryHammers
• Wear ear protectors. Exposure to noise can cause
hearingloss.
• Use auxiliary handle(s), if supplied with the tool. Loss of
control can cause personalinjury.
• Hold the power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting accessory
contacting a "live" wire may make exposed metal parts of the
power tool "live" and could give the operator an electricshock.
• Be certain that the material being drilled does not
conceal electric or gas service and that their locations
have been verified with the utilitycompanies.
• Use clamps or other practical way to secure and support
the workpiece to a stable platform. Holding the work by
hand or against your body is unstable and may lead to loss
ofcontrol.
• Wear safety goggles or other eye protection. Hammering
operations cause chips to fly. Flying particles can cause
permanent eye damage. Wear a dust mask or respirator
for applications that generate dust. Ear protection may be
required for mostapplications.
• Keep a firm grip on the tool at all times. Do not attempt
to operate this tool without holding it with both hands.
It is recommended that the side handle be used at all times.
Operating this tool with one hand will result in loss of control.
Breaking through or encountering hard materials such as
re‑bar may be hazardous as well. Tighten the side handle
securely beforeuse.
• Do not operate this tool for long periods of time.
Vibration caused by hammer action may be harmful to your
hands and arms. Use gloves to provide extra cushion and limit
exposure by taking frequent restperiods.
• Do not recondition bits yourself. Chisel reconditioning
should be done by an authorized specialist. Improperly
reconditioned chisels could causeinjury.
• Wear gloves when operating tool or changing bits.
Accessible metal parts on the tool and bits may get extremely
hot during operation. Small bits of broken material may
damage barehands.
• Never lay the tool down until the bit has come to a
complete stop. Moving bits could causeinjury.
• Do not strike jammed bits with a hammer to dislodge
them. Fragments of metal or material chips could dislodge
and causeinjury.
• Slightly worn chisels can be resharpened bygrinding.
• Do not overheat the bit (discoloration) while grinding
a new edge. Badly worn chisels require reforging. Do not
reharden and temper thechisel.
Residual Risks
The following risks are inherent to the use of rotary hammers:
• Injuries caused by touching the rotating parts or hot parts of
thetool.
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of squeezing fingers when changing theaccessory.
• Health hazards caused by breathing dust developed when
working in concrete and/ormasonry.
• Risk of personal injury due to flyingparticles.
• Risk of burns due to accessories becoming hot
duringoperation.
• Risk of personal injury due to prolongeduse.

7
ENGLISH
Chargers
DeWALT chargers require no adjustment and are designed to be
as easy as possible tooperate.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of yourmains.
iYour DeWALT charger is double insulated in
accordance with IEC60335; therefore no earth wire
isrequired.
If the supply cord is damaged, it must be replaced only by
DeWALT or an authorised serviceorganisation.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for
the power input of your charger (see Technical Data). The
minimum conductor size is 1mm2; the maximum length
is30m.
When using a cable reel, always unwind the cablecompletely.
Important Safety Instructions for All
BatteryChargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for compatible battery
chargers (refer to TechnicalData).
• Before using charger, read all instructions and cautionary
markings on charger, battery pack, and product using
batterypack.
WARNING: Shock hazard. Do not allow any liquid to get
inside charger. Electric shock mayresult.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.
CAUTION: Burn hazard. To reduce the risk of injury,
charge only DeWALT rechargeable batteries. Other
types of batteries may burst causing personal injury
anddamage.
CAUTION: Children should be supervised to ensure that
they do not play with theappliance.
NOTICE: Under certain conditions, with the charger
plugged into the power supply, the exposed charging
contacts inside the charger can be shorted by foreign
material. Foreign materials of a conductive nature such
as, but not limited to, steel wool, aluminum foil or any
buildup of metallic particles should be kept away from
charger cavities. Always unplug the charger from the
power supply when there is no battery pack in the cavity.
Unplug charger before attempting toclean.
• DO NOT attempt to charge the battery pack with any
chargers other than the ones in this manual. The charger
and battery pack are specifically designed to worktogether.
• These chargers are not intended for any uses other than
charging DeWALT rechargeable batteries. Any other uses
may result in risk of fire, electric shock orelectrocution.
• Do not expose charger to rain orsnow.
• Pull by plug rather than cord when disconnecting
charger. This will reduce risk ofdamage to electric plug
andcord.
• Make sure that cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage orstress.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in risk
of fire,electric shock, orelectrocution.
• Do not place any object on top of charger or place
the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat.
Place the charger in a position away from any heat source. The
charger is ventilated through slots in the top and the bottom
of thehousing.
• Do not operate charger with damaged cord or plug—
have them replacedimmediately.
• Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. Take it
to an authorised servicecentre.
• Do not disassemble charger; take it to an authorised
service centre when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution
orfire.
• In case of damaged power supply cord, the supply cord must
be replaced immediately by the manufacturer, its service agent
or similar qualified person to prevent anyhazard.
• Disconnect the charger from the outlet before
attempting any cleaning. This will reduce the risk of
electric shock. Removing the battery pack will not reduce
thisrisk.
• NEVER attempt to connect two chargerstogether.
• The charger is designed to operate on standard 220‑
240V household electrical power. Do not attempt to
use it on any other voltage. This does not apply to the
vehicularcharger.
Charging a Battery (Fig.B)
1. Plug the charger into an appropriate outlet before inserting
batterypack.
2. Insert the battery pack 8 into the charger, making sure the
battery pack is fully seated in the charger. The red (charging)
light will blink repeatedly indicating that the charging
process hasstarted.
3. The completion of charge will be indicated by the red
light remaining ON continuously. The battery pack is fully
charged and may be used at this time or left in the charger.
To remove the battery pack from the charger, push the
battery release button 9 on the batterypack.
NOTE: To ensure maximum performance and life of lithium‑ion
battery packs, charge the battery pack fully before firstuse.
Charger Operation
Refer to the indicators below for the charge status of the
batterypack.

8
ENGLISH
Charge Indicators
FCharging I
GFully Charged J
HHot/Cold Pack Delay* K
*The red light will continue to blink, but a yellow indicator light
will be illuminated during this operation. Once the battery pack
has reached an appropriate temperature, the yellow light will
turn off and the charger will resume the chargingprocedure.
The compatible charger(s) will not charge a faulty battery pack.
The charger will indicate faulty battery by refusing tolight.
NOTE: This could also mean a problem with acharger.
If the charger indicates a problem, take the charger and battery
pack to be tested at an authorised servicecentre.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot or too
cold, it automatically starts a Hot/Cold Pack Delay, suspending
charging until the battery pack has reached an appropriate
temperature. The charger then automatically switches to the
pack charging mode. This feature ensures maximum battery
packlife.
A cold battery pack will charge at a slower rate than a warm
battery pack. The battery pack will charge at that slower rate
throughout the entire charging cycle and will not return to
maximum charge rate even if the battery packwarms.
Electronic Protection System
XR Li‑Ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deepdischarge.
The tool will automatically turn off if the Electronic Protection
System engages. If this occurs, place the lithium‑ion battery
pack on the charger until it is fullycharged.
Wall Mounting
These chargers are designed to be wall mountable or to sit
upright on a table or work surface. If wall mounting, locate the
charger within reach of an electrical outlet, and away from a
corner or other obstructions which may impede air flow. Use
the back of the charger as a template for the location of the
mounting screws on the wall. Mount the charger securely using
drywall screws (purchased separately) at least 25.4mm long
with a screw head diameter of 7–9mm, screwed into wood to
an optimal depth leaving approximately 5.5mm of the screw
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in theslots.
Charger Cleaning Instructions
WARNING: Shock hazard. Disconnect the charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using a
cloth or soft non‑metallic brush. Do not use water or any
cleaning solutions. Never let any liquid get inside the tool;
never immerse any part of the tool into aliquid.
Battery Packs
Important Safety Instructions for All
BatteryPacks
When ordering replacement battery packs, be sure to include
catalogue number andvoltage.
The battery pack is not fully charged out of the carton. Before
using the battery pack and charger, read the safety instructions
below. Then follow charging proceduresoutlined.
READ ALL INSTRUCTIONS
• Do not charge or use battery in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Inserting or removing the battery from the charger may
ignite the dust orfumes.
• Never force battery pack into charger. Do not modify
battery pack in any way to fit into a non‑compatible
charger as battery pack may rupture causing serious
personalinjury.
• Charge the battery packs only in DeWALTchargers.
• DO NOT splash or immerse in water or otherliquids.
• Do not store or use the tool and battery pack in locations
where the temperature may fall below 4˚C (39.2˚F)
(such as outside sheds or metal buildings in winter), or
reach or exceed 40˚C (104˚F) (such as outside sheds or
metal buildings insummer).
• Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium‑ion battery packs areburned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open eye
for 15minutes or until irritation ceases. If medical attention
is needed, the battery electrolyte is composed of a mixture of
liquid organic carbonates and lithiumsalts.
• Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persists, seek
medicalattention.
WARNING: Burn hazard. Battery liquid may be flammable
if exposed to spark orflame.
WARNING: Never attempt to open the battery pack for
any reason. If battery pack case is cracked or damaged,
do not insert into charger. Do not crush, drop or damage
battery pack. Do not use a battery pack or charger that
has received a sharp blow, been dropped, run over or
damaged in any way (i.e., pierced with a nail, hit with
a hammer, stepped on). Electric shock or electrocution
may result. Damaged battery packs should be returned to
service centre forrecycling.
WARNING: Fire hazard. Do not store or carry the
battery pack so that metal objects can contact
exposed battery terminals. For example, do not place
the battery pack in aprons, pockets, tool boxes, product kit
boxes, drawers, etc., with loose nails, screws, keys,etc.

9
ENGLISH
CAUTION: When not in use, place tool on its side on
a stable surface where it will not cause a tripping
or falling hazard. Some tools with large battery packs
will stand upright on the battery pack but may be easily
knockedover.
Transportation
WARNING: Fire hazard. Transporting batteries can
possibly cause fire if the battery terminals inadvertently
come in contact with conductive materials. When
transporting batteries, make sure that the battery
terminals are protected and well insulated from
materials that could contact them and cause a short
circuit. NOTE: Lithium‑ion batteries should not be put in
checkedbaggage.
DeWALT batteries comply with all applicable shipping
regulations as prescribed by industry and legal standards which
include UN Recommendations on the Transport of Dangerous
Goods; International Air Transport Association (IATA) Dangerous
Goods Regulations, International Maritime Dangerous Goods
(IMDG) Regulations, and the European Agreement Concerning
The International Carriage of Dangerous Goods by Road
(ADR). Lithium‑ion cells and batteries have been tested to
section 38.3of the UN Recommendations on the Transport of
Dangerous Goods Manual of Tests andCriteria.
In most instances, shipping a DeWALT battery pack will be
excepted from being classified as a fully regulated Class
9Hazardous Material. In general, only shipments containing a
lithium‑ion battery with an energy rating greater than 100Watt
Hours (Wh) will require being shipped as fully regulated Class 9.
All lithium‑ion batteries have the Watt Hour rating marked on
the pack. Furthermore, due to regulation complexities, DeWALT
does not recommend air shipping lithium‑ion battery packs
alone regardless of Watt Hour rating. Shipments of tools with
batteries (combo kits) can be air shipped as excepted if the Watt
Hour rating of the battery pack is no greater than 100Wh.
Regardless of whether a shipment is considered excepted
or fully regulated, it is the shipper's responsibility to consult
the latest regulations for packaging, labeling/marking and
documentationrequirements.
The information provided in this section of the manual is
provided in good faith and believed to be accurate at the time
the document was created. However, no warranty, expressed or
implied, is given. It is the buyer’s responsibility to ensure that its
activities comply with the applicableregulations.
Storage Recommendations
1. The best storage place is one that is cool and dry away
from direct sunlight and excess heat or cold. For optimum
battery performance and life, store battery packs at room
temperature when not inuse.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool, dry place out of the charger for
optimalresults.
NOTE: Battery packs should not be stored completely
depleted of charge. The battery pack will need to be recharged
beforeuse.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the
labels on the charger and the battery pack may show the
followingpictographs:
LRead instruction manual beforeuse.
p See Technical Data for chargingtime.
q Do not probe with conductiveobjects.
r Do not charge damaged batterypacks.
s Do not expose towater.
t Have defective cords replacedimmediately
u Charge only between 4˚C and 40˚C.
v Only for indooruse.
x Discard the battery pack with due care for
theenvironment.
y Charge DeWALT battery packs only with designated
DeWALT chargers. Charging battery packs other than
the designated DeWALT batteries with a DeWALT
charger may make them burst or lead to other
dangeroussituations.
z Do not incinerate the batterypack.
Battery Type
The following tools operate on a 12 volt battery pack: DCH072
These battery packs may be used: DCB122, DCB124, DCB124G,
DCB125, DCB126G, DCB127, . Refer to Technical Data for
moreinformation.
Package Contents
The package contains:
1 Cordless rotary hammerdrill
1 Side handle and depth rod
1 Battery Charger
1 Li‑Ion battery pack (C1, D1, G1, L1, M1, P1, S1, T1, X1,
Y1models)
2 Li‑Ion battery packs (C2, D2, G2, L2, M2, P2, S2, T2, X2,
Y2models)
3 Li‑Ion battery packs (C3, D3, G3, L3, M3, P3, S3, T3, X3,
Y3models)

10
ENGLISH
1 Kit box (not included for XE models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
a Read instruction manual beforeuse.
g Wear earprotection.
f Wear eyeprotection.
n Visible radiation. Do not stare intolight.
Date Code Position (Fig.B)
The date code 6, which also includes the year of manufacture,
is printed into thehousing.
Example:
2021XX XX
Year and Week of Manufacture
Description (Fig.A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Side handle
2 Depth rod
3 Trigger switch
4 Forward/reverse control button (Lock‑off button)
5 Mode selector
6 Main handle
7 Worklight
8 Battery pack
9 Battery release button
10 Utility hook
Intended Use
This heavy‑duty cordless rotary hammer is designed for
professional concrete, wood and metal drillingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This heavy‑duty cordless rotary hammer is a professional
powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
WARNING: Use only DeWALT battery packs andchargers.
Inserting and Removing the Battery Pack
from the Tool (Fig.B)
NOTE: Make sure your battery pack 8 is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack 8 with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button 9 and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig.B)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button12. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑userapplication.
Electronic Overload Protection
If the drill bit becomes jammed, the power to the drill spindle
will be interrupted by the activation of the electronic overload
protection. To reactivate the power to the drive spindle, the
tool's trigger should be released and then depressed. Due to the
resulting forces, always hold the tool with both hands and take
a firmstance.

11
ENGLISH
Side Handle and Depth Rod (Fig.A, C)
WARNING: To reduce the risk of personal injury, ALWAYS
operate the tool with the side handle properly installed.
Failure to do so may result in the side handle slipping
during tool operation and subsequent loss of control. Hold
tool with both hands to maximizecontrol.
The side handle1 clamps to the front of the gear case and may
be rotated 360˚ to permit right‑ or left‑hand use.
The side handle clamps to the collar13 and has 12tightening
locations. The side handle can be tightened by rotating the
grip of the side handle clockwise. The side handle must be
tightened sufficiently to resist the twisting action of the tool if
the accessory bind or stall. Be sure you moved the side handle
against the end of the collar end to have the clamping piece
fully engaged.
To Adjust the Depth Rod (Fig.A)
Loosen the side handle1 and move the depth rod2 so that
the distance between the end of the rod and the end of the bit
equals the desired drilling depth. When drilling with depth rod,
stop when end of rod reaches surface ofmaterial.
Utility Hook (Fig. D)
WARNING: To reduce the risk of serious personal
injury, ONLY use the tool’s ultilty hook to hang the
tool from a work belt. DO NOT use the ultilty hook
for tethering or securing the tool to a person or
object during use. DO NOT suspend tool overhead or
suspend objects from the ultilty hook.
WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the ultilty hook
issecure.
IMPORTANT: When attaching or replacing the ultilty hook10,
use only the screw14 that is provided. Be sure to securely
tighten thescrew.
The ultilty hook can be be attached to either side of the tool
using only the screw provided, to accommodate left‑ or right‑
handed users. If the hook is not desired at all, it can be removed
from the tool.
To move ultilty hook, remove the screw that holds the ultilty
hook in place then reassemble on the opposite side. Be sure to
securely tighten thescrew.
Bit and Bit Holder
WARNING: Burn Hazard. ALWAYS wear gloves when
changing bits. Accessible metal parts on the tool and bits
may get extremely hot during operation. Small bits of
broken material may damage barehands.
The hammerdrill can be fitted with different bits depending on
the desired application. Use sharp drill bitsonly.
Bit Reccomendations
• For wood, use twist bits, spade bits, power auger bits or
holesaws.
• For metal, use high‑speed steel twist drill bits or holesaws.
Use a cutting lubricant when drilling metals. The exceptions
are cast iron and brass which should be drilleddry.
SDS plus® Bit Holder (Fig.H)
NOTE: Special adapters are needed to use the SDS plus® bit
holder with straight shank bits and hexagonal screwdriver bits.
Refer to OptionalAccessories.
To insert a drill bit or other accessory:
1. Insert the shank of the bit about 19mm into SDS plus® tool
holder15.
2. Push and rotate bit until it locks in place. The bit will be
securelyheld.
3. To release bit, pull the sleeve16 back and remove thebit.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Proper Hand Position (Fig.E)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the side handle1,
with the other hand on the main handle6.
Trigger Switch (Fig.A)
To turn the tool on, squeeze the trigger switch3. To turn the
tool off, release the trigger switch. Your tool is equipped with
a brake. The chuck will stop as soon as the trigger switch is
fullyreleased.
Variable Speed Trigger Switch
The variable speed trigger switch enables you to select the best
speed for a particular application. The farther you squeeze the
trigger switch, the faster the tool will operate. For maximum
tool life, use variable speed only for starting holes orfasteners.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the trigger switch and should
beavoided.
Forward/Reverse Control Button (Fig.F)
A forward/reverse control button4 determines the direction of
bit rotation and also serves as a lock‑offbutton.
To select forward rotation, release the trigger switch3 and
depress the forward/reverse control button on the right side of
thetool.
To select reverse, depress the forward/reverse control button
on the left side of thetool.

12
ENGLISH
The center position of the control button locks the tool in
the off position. When changing the position of the control
button, be sure the trigger isreleased.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate aproblem.
Worklight (Fig.A)
CAUTION: Do not stare into worklight. Serious eye
injury couldresult.
There is a worklight7 located on the front of the tool. The
worklight is activated when the trigger switch is depressed, and
will automatically turn off 20seconds after the trigger switch is
released. If the trigger switch remains depressed, the worklight
will remainon.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as aflashlight.
Operation Modes (Fig.G)
WARNING: Do not select the operating mode when the
tool isrunning.
CAUTION: Never use in Rotary Drilling or Rotary
Hammering mode with a chisel bit in the bit holder.
Personal injury and damage to the the tool mayresult.
Your tool is equipped with a mode selector dial5 to selectthe
mode appropriate to desiredoperation.
Symbol Mode Application
Rotary Drilling
Screwdriving
Drilling into steel, wood
andplastics
Rotary Hammering Drilling into concrete
andmasonry
To select an operating mode:
1. Rotate the mode selector dial so that the arrow points to the
symbol corresponding for the desiredmode.
NOTE: The arrow on the mode selector dial5 must be pointing
at a mode symbol at all times. There are no operable positions
inbetween. It may be necessary to briefly run the motor after
having changed from 'hammering only' to 'rotary' modes in
order to align thegears.
Performing an Application (Fig.A, G)
WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, ALWAYS ensure workpiece is anchored or
clamped firmly. If drilling thin material, use a wood
“back‑up” block to prevent damage to thematerial.
WARNING: Always wait until the motor has come to
a complete standstill before changing the direction
ofrotation.
1. Choose and install the appropriate chuck, adapter, and/or
bit onto to the tool. Refer to Bit and BitHolder.
2. Using the mode selector dial5, selectthe mode appropriate
to desired application. Refer to OperationModes.
3. Adjust the side handle1 asnecessary.
4. Select the direction ofrotation using the forward/reverse
button4. When changing the position of the control
button, be sure the trigger isreleased.
‑To select forward rotation, press the forward/reverse
control button on the right side of thetool.
‑To select reverse, press the forward/reverse control
button on the left side of thetool.
NOTE: The center position of the control button locks
the tool in the offposition.
5. Place the bit/chisel on the desiredlocation.
6. Depress the trigger switch3. The farther you depress
the trigger switch, the faster the tool will operate. For
maximum tool life, use variable speed only for starting holes
orfasteners.
7. To stop the hammer, release theswitch.
Recommendations for Tool Operation
• Large (8 mm to 13mm) holes in steel can be made easier if
a pilot hole (4 mm to 5mm) is drilledfirst.
• When drilling, always apply pressure in a straight line with
the bit, but do not push hard enough to stall the motor or
deflect thebit. A smooth even flow of material indicates the
proper drillingrate.
• If drilling thin material or material that is prone to splinter,
use a wood “back‑up” block to prevent damage to
theworkpiece.
WARNING:
• Do not use this tool to mix or pump easily combustible
or explosive fluids (benzine, alcohol,etc.).
• Do not mix or stir inflammable liquids
labelledaccordingly.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
The charger and battery pack are notserviceable.
C
Lubrication
Your power tool requires no additionallubrication.
D
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around

13
ENGLISH
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories
WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Dust Extraction System (Fig.I)
The use of a dust extraction system is recommended to reduce
potentially harmful airborne dust and to prolong tool and
accessorylife.
Consult your dealer for further information on suitable dust
extractionsystems.
Protecting the Environment
wSeparate collection. Products and batteries marked
with this symbol must not be disposed of with
normal householdwaste.
Products and batteries contain materials that
can be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails
to produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for
ourenvironment:
• Run the battery pack down completely, then remove it from
thetool.
• Li‑Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.
SDS plus® and SDS max® are registered trade marks of
RobertBoschGmbH
AFTER SERVICE AND REPAIR
DEWALT service centers are staffed with trained personnel to
provide customers with efficient and reliable product service.
We do not take any responsibility when you have repaired
in unauthorized service center. You can refer to the leaflet of
CONTACT CENTER LOCATOR in product package and contact
us through hotline, website or social media to find the nearest
DEWALT service center around you.

14
繁體中文
4
繁體中文
無碳刷四溝二用電鎚鑽
DCH072
電池 充電器/充電時間（分鐘）
目錄號 伏特 安時 重量(kg) DCB104 DCB107 DCB110 DCB112 DCB115 DCB119
DCB122 10.8(12 Max) 2.0 0.22 30 90 90 60 30 60
DCB124/G 10.8(12 Max) 3.0 0.25 45 140 140 90 45 90
DCB125 10.8(12 Max) 1.3 0.20 22 60 60 40 22 40
DCB126/G 10.8(12 Max) 5.0 0.44 75 240 240 150 75 150
DCB127 10.8(12 Max) 2.0 0.22 30 90 90 60 30 60
恭喜！
感謝您選購
DeWALT
工具。憑藉多年的經驗、完善的產品開發與創
新，
DeWALT
已成為專業電動工具使用者最可靠的合作夥伴之一。請
注意！各地區上市產品/配件不盡相同，請依台灣繁體中文說明書的
內容為主。
最大初始電池電壓（在無工作負荷的情形下進行測量）為12伏 特 。標
稱電壓為10.8伏特。
技術資料
DCH072
電壓 VDC 10.8(12 Max)
電池類型 鋰離子
最大功率輸出 W400
空載轉速 min‑1 0–910
空載打擊次數/分 bpm 4280
單次衝擊能量 (EPTA 05/2009) J1.1
最優鑽孔範圍 mm 4–10
最大直徑 混凝土 mm 14
工具支架 SDS plus®
重量（不含電池組） kg 1.7

警告：宣稱的振動和/或噪音釋放水準所代表的是工具主要
應用所發出的振動和/或噪音。然而，如果將工具用於不同
應用，搭配不同附件或保養不當，那麼振動和/或噪音的情
況就會有所不同。這可能會在整個工作期間大幅提升振動
和/或噪音的暴露水準。
當工具關閉或在空轉時，還應預估振動和/或噪音暴露水
準。這可能會在整個工作期間大幅降低振動和/或噪音的
暴露水準。
確認額外的安全措施，保護操作人員免受振動和/或噪音的
影響，例如：保養工具和附件，保持雙手溫暖（與振動有關），
工作形式的組織安排。
警告：為了降低受傷的風險，必須仔細閱讀使用手冊。
定義：安全指南
以下定義描述了每一個詞彙的嚴重程度。請閱讀本手冊並注意這
些符號。

危險：表示緊急危險狀況，若未能避免，將導致死亡或嚴
重傷害。

警告：表示潛在危險情況，若未能避免，可能導致死亡或嚴
重傷害。

小心：表示潛在危險情況，若未能避免，可能導致輕微或中
度傷害。

注意：表示一種非人身傷害的行為，若未能避免，可能導致
財產損失。

表示觸電危險。

表示火災危險。
電動工具一般安全警告

警告！請閱讀安全警告及所有指示。不遵循下列的這些警告
和指示可能會導致觸電、火災及/或嚴重傷害。

15
繁體中文
5
繁體中文
請保存所有警告與指示以備將來查閱。
以下列示所有警告中的術語「電動工具」是指電源驅動（插電）電動
工具或電池驅動（充電）電動工具。
1） 工作場地安全
a ) 請保持工作場地清潔明亮。混亂或黑暗的場地會引發事故。
b ) 請勿在易爆環境，如有易燃液體、氣體或粉塵的環境中操作
電動工具。電動工具產生的火花可能會引燃粉塵或煙霧。
c ) 請等待兒童和旁觀者離開之後才操縱電動工具。分心會導
致您疏於控制。
2） 電氣安全
a ) 電動工具插頭必須與插座相符。切勿以任何方式改裝插頭。
需接地的電動工具不能使用任何配接器插頭。使用未經改
裝的插頭與相符的插座可降低觸電風險。
b ) 避免人體接觸接地表面，如管道、散熱片、爐灶和冰箱。若您
的身體接地，會增加觸電的風險。
c ) 不得將電動工具暴露在雨中或潮濕環境中。水進入電動工
具會增加觸電風險。
d ) 切勿濫用電線。請勿使用電線來搬運、拉動電動工具或拔出
插頭。讓電線遠離熱、油、銳邊和活動部件。受損或纏繞的電
線會增加觸電危險。
e ) 若要在戶外使用電動工具，請使用適合戶外使用的延長電
線。採用適合室外使用的電線可降低觸電危險。
f ) 若必須在潮濕環境中操作電動工具，請使用受漏電保護器
(RCD) 保護的電源供應器。使用RCD可降低觸電風險。
3） 人身安全
a ) 保持警覺；在操作電動工具時，請留意所執行的操作並按照
一般的程式執行。請勿在疲倦或在受到毒品、酒精或藥品的
影響時使用電動工具。操作電動工具時，一時的注意力分散
可能會導致嚴重人身傷害。
b ) 使用個人防護裝置。始終佩戴護目裝置。防護設備 (例如在
適當條件下使用的防塵面具、防滑安全鞋、安全帽或聽力保
護裝置) 可減少人身傷害。
c ) 避免意外啟動。連接電源及/或電池組、舉抬或搬運電動工
具之前，請確定開關處於關閉位置。若搬運電動工具時將手
指放在開關上，或者在電動工具開關開啟時將插頭插入電
源插座，這兩種行為都會引發事故。
d ) 啟動電動工具之前，請卸下所有的調整鑰匙或扳手。遺留在
電動工具旋轉部件上的扳手或鑰匙會導致人身傷害。
e ) 不要過度伸張雙手。時刻注意腳下與身體的平衡。如此可在
意外情況下更好地控制電動工具。
f ) 適當穿著。請勿穿寬鬆衣服或佩戴飾品。讓您的頭髮、衣服
和手套遠離活動部件。寬鬆衣服、佩飾或長髮可能會捲入
活動部件中。
g ) 若配備用於連接排屑裝置、集塵設備的裝置，請確定正確
連接和使用這些裝置。使用集塵設備可減少與粉塵有關
的危險。
h ) 請勿因頻繁使用而對工具特別熟悉，讓你變得自滿而忽略
工具的安全原則。粗心操作可以在片刻間造成嚴重傷害。
4) 電動工具的使用與注意事項
a ) 請勿超負荷使用電動工具。請根據您的應用使用正確的電
動工具。若使用的電動工具正確無誤，該工具能以設計額定
值更有效、更安全地執行工作。
b )
若開關不能開啟或關閉電源，切勿使用該電動工具。若開關
無法控制電動工具，則電動工具存在危險，必須予以維修。
c ) 在執行任何調整、更換配件或儲存工具之前，必須從電源上
拔掉插頭及/或卸下電池組。此類防護性安全措施可降低電
動工具意外啟動的風險。
d ) 將閒置的電動工具儲存在兒童無法接觸的地方，並且不要
讓不熟悉電動工具或對這些使用指示不瞭解的人員操作電
動工具。未經訓練的使用者操作電動工具會發生危險。
e ) 維護電動工具。檢查活動部件是否對準或卡住、是否存在任
何破損情況，或任何能影響電動工具運行的其他情況。若有
損毀，必須在使用之前修理電動工具。許多事故都是由於電
動工具欠缺維護所導致。
f ) 保持切削工具鋒利和清潔。妥善維護、刀刃鋒利的刀具卡住
的可能性更低，更易於控制。
g ) 使用電動工具、配件和工具刀頭等時，請遵循這些指示使
用，且指示須包含工作環境和所要執行工作的注意事項。若
使用電動工具執行與設計用途不相符的操作，會導致危險。
h ) 手柄和抓握表面都應保持乾燥、清潔及遠離油脂。光滑手
柄和抓握表面不便於在意外情況下對工具進行安全處理
與控制。
5) 電池工具的使用與注意事項
a ) 只能使用製造廠商指定的充電器為電池充電。使用僅適
合一種電池組的充電器為其他類型的電池組充電會導致
火災危險。
b ) 請使用原廠的電動工具電池組。使用其他非原廠的電池組
會導致人身傷害和火災危險。
c ) 不使用電池組時，請將其遠離如迴紋針、硬幣、鑰匙、釘子、
螺絲以及其他可連通電池兩極的金屬物品。將電池兩極短
路會導致灼傷或火災。
d ) 濫用電池的情況下，液體會從電池中噴出；避免與液體接
觸。若不小心接觸液體，請用清水沖洗。若液體噴濺到眼睛
上，沖洗之後還應進行治療。從電池噴出的液體會刺激皮
膚或造成灼傷。
e ) 請勿使用已經損壞或改動的電池組或工具。損壞或改動
的電池可能表現出不可預計的行為，導致火災、爆炸或傷
害風險。
f ) 請勿讓電池組或工具暴露於火中或過高溫度的環境中。暴
露於火中或溫度超過 130°C的環境中可能導致爆炸。
g ) 請遵循所有充電說明，請勿在說明中規定的溫度範圍以外
的環境對電池組或工具充電。不當或在指定範圍以外的溫
度下充電，可能導致電池損壞並增加火災風險。
6) 檢修
a ) 本電動工具必須由合格的維修人員並只採用相同的原廠零
件來執行檢修。這將確保電動工具的安全性。
b ) 切勿維修損毀的電池組。電池組的維修應僅由製造商或授
權服務提供商執行。
面向轉動錘鑽的額外安全說明
• 請佩戴聽力保護器。暴露在噪音中可能會導致聽力喪失。
• 請使用辅助手柄（如隨附）。失控會導致人身傷害。
• 當在切割附件有可能切割到暗線的场所進行操作時，只能通
過绝缘握持面来握住電动工具。切割附件碰到一根带電导線
可能會使電动工具的外露金屬零件带電，並讓操作者面臨電
击危險。

16
繁體中文
6
繁體中文
• 請確保被鑽孔的材料中並未隱藏電氣或天然氣服務，而且材料
的位置已通過了公用事業公司的驗證。
• 使用夾具或其他实用方法，將工件固定、支撑到穩定的平台上。
手持或用身體頂住工件都是不穩定的，會導致操作失控。
• 請佩戴護目鏡或其他護目裝置。錘鑽操作會導致碎屑飛濺。飛
濺顆粒會對眼睛造成永久損傷。在會產生粉塵的作業中，請佩
戴防塵面具或呼吸面具。在大多數應用中，均需佩戴聽力保護
裝置。
• 請始終緊握工具。請勿嘗試在未用雙手握住工具的情況下操作
該工具。建議始終都要使用側手柄。單手操作該工具會導致失
控。突破或遭遇硬質材料，例如鋼筋，同樣會造成危險。請在使
用前擰緊側手柄。
• 請勿長時間操作此工具。錘鑽所產生的震動會有害您的雙手和
雙臂。請使用手套為您提供額外緩衝，同時請頻繁休息，以限制
自己對震動的暴露程度。
• 請勿自行修復鑽頭。應由獲得授權的專門人員進行鑿子維修。
維修不當的鑿子會導致受傷。
• 在操作工具或更換鑽頭時請戴好手套。工件上可接觸的金屬部
件以及鑽頭會在運行中變得極度燙手。破碎材料的碎屑可能會
損傷裸露的雙手。
• 直到鑽頭完全停止运动後才可放下電动工具。轉動的鑽頭會
導致受傷。
• 請勿用錘子敲打卡住的鑽頭以使其脫落。金屬片或金屬碎屑可
能會導致阻塞並使人受傷。
• 可通過研磨對輕微磨損的鑿子進行重新打磨。
• 打磨新邊沿時，請勿使鑽頭過熱（變色）。嚴重磨損的鑿子需要
重新修整。請勿重新打磨鑿子。
剩餘風險
使用旋轉錘鑽存在以下固有風險：
•
由於觸碰工具的轉動部件或發熱部件而導致的受傷。
尽管遵守了相关的安全法規並采用了安全裝備，某些剩余風險仍然
是無法避免的。這些風險包括：
•
听力損伤。
• 更換附件時擠壓手指的風險。
• 由於吸入在混凝土和/或磚石結構中作業時產生的粉塵而導致
的健康危害。
• 飛濺颗粒造成的人身傷害風險。
• 使用時附件发热導致的灼伤風險。
• 長時间使用引起的人身傷害風險。
充電器
DeWALT
充電器無需調節，專為盡可能輕鬆使用而設計。
電氣安全
電動馬達只適用一種電壓。請務必檢查電池組電壓是否與銘牌一
致，並且確保充電器的電壓與電源電壓一致。
DeWALT
充電器符合 IEC60335 雙重絕緣要求，因此無需使
用接地線。
如果電源線損壞，必須由
DeWALT
或授權的維修機構負責更換。
使用延長電纜
如非絕對必要，否則不要使用延長電線。請使用與充電器的輸入功
率相配的認可延長電纜（請參閱
技術資料 ）。導電體的最小橫截面尺
寸為 1 平方公釐，最長為 30 米。
使用電纜捲筒時，每次必須把電纜完全展開。
所有電池充電器之重要安全指示
請妥善保管好這些說明：本手冊包含重要的相容電池充電器安全和
操作說明（請參閱
技術資料 ）。
• 在使用充電器之前，請先閱讀所有指示以及充電器、電池組和
使用電池組的產品上的警告標記。

警告：觸電危險。切勿讓任何液體進入充電器，否則可能會
導致觸電。

警告：建議使用漏電流額定值不超過 30mA 的漏電流保護
裝置。

小心：燒傷危險。為了減低受傷風險，只可以使用
DeWALT
可充電電池。其他非原廠電池可能會爆裂，導致人身傷害
和損害。

小心：必須監督兒童，確保他們沒有耍玩器具。
注意：在某些情況下，充電器連接到電源後，充電器內暴露
的充電觸頭會被異物導致短路。導電的異物，包括但不限於
鋼絲絨、鋁箔紙或任何由金屬粒子組成的物件，必須要遠離
充電器範圍。充電器裡沒有電池組時，一定要拔掉充電器的
電源。請先拔掉電源插頭後再清潔充電器。
• 請勿嘗試使用本手冊未提到的充電器為電池組充電。充電器
和電池組是專為搭配使用而特別設計。
• 除了為
DeWALT
可充電電池充電之外，這些充電器不可以用於
其他用途。否則可能會導致火災、觸電或觸電致死。
• 請勿將充電器暴露在雨或雪中。
• 中斷充電器的電源時，請拔除插頭而非拉扯電線。這樣會減低
電源插頭和電線損壞的風險。
• 請確保電線的位置不會遭踐踏、令人絆倒或容易受到其他方
式的損壞或受壓。
• 除非絕對需要，否則請勿使用延長電線。使用不適當的延長電
線會引起火災、觸電或觸電致死。
• 請勿將任何物件放在充電器上面，或是把充電器放在可能會
堵住通風槽的柔軟表面，導致充電器的內部過熱。請將充電器
放到遠離熱源的位置。充電器透過外殼頂部及底部的槽散熱。
• 請勿操作電線或插頭損壞的充電器，請立即予以更換。
• 如果充電器受到重擊、墜落或出現其他損壞情況，請勿使用充
電 器，並應拿到授權維修中心修理。
• 請勿自行拆卸充電器。需要維護或修理時，請拿到授權維修中
心。重新組裝不當可能會導致觸電、觸電致死或火災。
• 若電源線損毀，必須由製造商、服務代理或同等資質的人員立
即更換以避免發生危險。
• 在清潔之前，請將充電器的插頭從電源插座上拔掉，這樣可以
減低觸電風險。拆除電池組並不能夠降低這種風險。切勿試圖
將2 個充電器連接在一起。
• 充電器是為標準 110 伏特的家用電源而設計。請勿試圖使用其
他電壓。本規定不適用於車載充電器。
為電池充電 (圖B)
1. 放入電池組前，先將充電器的插頭插入適當的插座。
2. 將電池組 8 放進充電器，確保電池組已完全放入。紅燈（充電
中）會不斷閃爍，這表示充電程序已經開始。

17
繁體中文
7
繁體中文
3. 當紅燈持續亮起時，代表充電完成。此時，電池組的電力全滿，
可以立即使用或是留在充電器裡。要從充電器上取下電池組，
請按下電池組上的電池釋放按鈕 9。
註：為了確保鋰離子電池組的效能及使用壽命最大化，在第一次使
用電池組之前必須完全充電。
充電器操作
如需瞭解電池組的充電狀態，請參閱以下指示燈。
充電狀態指示燈
充電中
已完全充電
電池組熱/冷延遲*
*紅燈會繼續閃爍，但在執行此操作期間黃色指示燈將亮起。電池組
達到適當溫度後，黃色指示燈將熄滅，充電器將恢復充電程序。相
容的充電器不會為有故障的電池組充電。充電器會透過不亮燈來
表示電池組故障。
相容的充電器不會為有故障的電池組充電。充電器會透過不亮燈來
表示電池組故障。
註：亦有可能是充電器發生故障。
如果充電器指示故障，請將充電器和電池組拿到授權維修中心進
行測試。
電池組熱/冷延遲
若充電器偵測到電池組過熱或過冷，會自動啟動電池組熱/冷延遲，
在電池組達到適合的溫度之前暫停充電。然後，充電器會自動轉換
到電池組充電模式。此功能可確保電池組的使用壽命最大化。
冷電池組的充電速度大約是暖電池組的一半。在整個充電週期，電
池組會以較慢的充電速度進行充電，即使電池組變暖，充電速度亦
不會回復至最大充電速度。
電子保護系統
XR 鋰離子工具的設計具有電子保護系統，可保護電池組，避免過載、
過熱或深度放電。
如果電子保護系統啟動，本工具會自動關閉。如果出現此情況，請將
鋰離子電池組放進充電器直到電力全滿。
牆面安裝
這些充電器經過精心設計，可以安裝在牆面上或立在工作臺或工作
表面上。若採用牆面安裝，請將充電器安裝在電源插座連接範圍內
的位置，並遠離角落或可能阻礙空氣流動的障礙。將充電器的背面
用作在牆面上確定安裝螺絲位置的型板。使用長度至少 25.4 公釐、
螺頭直徑為7–9 公釐的牆用螺絲(另售)牢固安裝充電器，旋進木料
的最佳深度為螺絲大約有5.5 公釐長度露在木料外。將露出的螺絲
與充電器背面的槽對齊，並完全接合到槽中。
充電器清潔指示

警告：觸電危險。在清潔之前，請將充電器的插頭從電源
插座上拔掉。使用軟布或非金屬軟刷，去除充電器外部的污
垢和油脂。切勿讓任何液體滲入工具，切勿讓工具的任何部
件浸在液體中。
電池組
所有電池組之重要安全指示
在訂購更換電池組時，請務必附上目錄型號和電壓。
包裝箱內的電池組並未完全充電。使用電池組和充電器之前，請閱
讀下列安全指示，然後遵循所述的充電程式。
請閱讀所有指示
• 不要在易爆環境，如有易燃液體、氣體或粉塵的環境中進行充
電或使用電池組。將電池組放進充電器或從充電器中取出電
池組可能會點燃粉塵或氣體。
• 切勿強行將電池組放進充電器。請勿以任何方式改裝電池組
以在不相容的充電器中使用，否則電池組可能會破裂，導致嚴
重人身傷害。
• 請僅使用指定的
DeWALT
充電器為電池充電。
• 請勿將水分或其他液體飛濺到電池組或將電池組浸沒 。
•
請勿在溫度可能低於 4˚C (39.2˚F) （如冬天戶外的棚子或金屬
建築物中）, 或在溫度可能達到或超過
40˚C (104˚F) 的地方（如
夏天戶外的棚子或金屬建築物中）存儲或使用工具和電池組。
• 即使電池組已嚴重損毀或磨損，也請勿焚燒電池組。電池組
可能會在火中爆炸。焚燒鋰離子電池組時會產生有毒氣體和
物料。
• 若電池液體接觸到皮膚，請立即以中性肥皂與清水沖洗接觸
範圍。若電池液體進入眼睛，請睜開眼睛，用清水沖洗 15 分鐘
或直到不適感消失為止。如果需要接受治療，電池的電解質由
液化有機碳酸鹽和鋰鹽構成。
• 開啟的電池中的物質可能會導致刺激呼吸道。請轉移至空氣流通
處。如果症狀持續，請尋求醫療救助。

警告：灼燒危險。電池液如遇到火花或火焰可能會引起
燃燒。

警告：不論是因為任何理由，都不要嘗試打開電池。如果電
池組的外殼破裂或損毀，請勿放進充電器。切勿撞擊、摔落
或損毀電池組。切勿使用受到重擊、墜落或出現其他損壞情
況的電池組或充電器（例如釘子刺穿、以鎚子敲打或踩踏）。
否則可能會引起觸電或觸電致死。損毀的電池組應該送回
維修中心進行回收。

警告：火災危險。請勿在儲存或搬運電池組時讓金屬物件接
觸暴露的電池兩極。例如，不要將電池組放在帶有鬆動的釘
子、螺絲、鑰匙等的地方。

小心：不使用工具時，請將工具平放在沒有絆倒或跌落危險
的穩定平面上。一些具有大型電池組的工具可以直立但可
能會輕易被撞到。
運輸 
警告：火災危險。搬運電池時若電池兩極意外接觸導電材
料。運輸個別電池組時，請確保電池兩級受到保護並與可能
接觸兩級並導致短路的材料隔絕。
注： 鋰離子電池不應放在託運行李中。
DeWALT
電池符合行業和法律標準（包括聯合國危險貨物運輸建議
書、國際航空運輸協會 (IATA) 危險物品處理規則、國際海運危險物
品(IMDG) 處理規則以及國際公路運送危險物品歐洲協議 (ADR)）
規定的所有適用運輸規章。鋰離子電池和電池組均已根據《聯合國
危險貨物運輸建議書測試與標準手冊》第 38.3 節的規定進行測試。
大多數情況下，不會將運輸
DeWALT
電池組分歸為完全管制的第
9 類危險品。一般只有在運輸中包含額定能量大於100 瓦時 (Wh)
的鋰離子電池時，才會將其分歸為完全管制的第 9 類危險品。所
有鋰離子電池外殼上均標註有瓦時等級。此外，由於規章的複雜
性，
DeWALT
不建議對鋰離子電池組單獨採用空運，不論其額定能
量是多少瓦時，都是如此。若電池組的額定能量不超過 100 瓦時，
可以同時空運工具與電池組（組合套件）。
無論運輸是否納入完全管制範圍內，運輸方均有責任諮詢瞭解針
對包裝、標籤/標記及單據要求的最新規定。手冊本節資訊基於良

18
繁體中文
8
繁體中文
好商譽原則提供，在編製文件時被視為準確無誤，但不提供任何明
示或暗示的保證。買方負有確保其行為遵 守適用法規的責任。
儲存建議
1. 乾燥、涼爽、太陽不會直接照射、不會過熱或過冷的地方是電池
組的最佳存放地點。為達到最大效能和使用壽命，不使用電池時
請以室溫儲存電池組。
2. 如需長期儲存，建議將電力全滿的電池組從充電器卸下，儲存於
涼爽、乾燥處，使電池組效能達到最佳。
註：電池組不應在電力耗盡的情況下儲存。在使用之前，電池組必
須再次充電。
充電器和電池組上的標籤
除了本手冊的圖示之外，充電器及電池組上的標籤包含以下圖示：
使用前請閱讀使用手冊。
充電時間請見 技術資料 。
切勿插入導電體。
切勿為損毀的電池組充電。
切勿暴露在水中。
立即更換損壞的電線。
只在溫度介於 4˚C 至40˚C 之間充電。
僅供室內使用
棄置電池組時要顧及環保。
只使用指定的
DeWALT
充電器為
DeWALT
電池組充電。使
用
DeWALT
充電器對指定的
DeWALT
電池以外的電池組
充電會爆裂或導致其他危險情形。
切勿焚化電池組。
電池類型
以下工具可在 12 伏特電壓下運行: DCH072
這些電池組可用於：DCB122, DCB124, DCB124G, DCB125, DCB126G,
DCB127。更多資訊請見
技術資料 。
套裝內的物件
本套裝包括：
1 無碳刷四溝二用電鎚鑽
1 側手柄和深度調整桿
1
電池充電器
1 鋰電池組 (C1, D1, G1, L1, M1, P1, S1, T1, X1, Y1型號)
2 鋰電池組 (C2, D2, G2, L2, M2, P2, S2, T2, X2, Y2型號)
3 鋰電池組 (C3, D3, G3, L3, M3, P3, S3, T3, X3, Y3型號)
1 個工具盒 (XE型號中未包含)
1 使用手冊
注意：電池組、充電器和工具箱沒有隨N型號附送。電池組和充電器
沒有隨NT型號附送。B型號包括Bluetooth®電池組。
注意Bluetooth®標誌和徽標是註冊商標，歸Bluetooth®，SIG，Inc.所 有 ，而
且
DeWALT
對該標誌的任何使用均獲得許可。其他商標和商標名均歸
各自所有者所有。
•
檢查集塵器、部件或附件是否在運輸過程中損壞。
• 操作前，請抽空仔細閱讀並掌握本手冊。
工具上的標誌
工具上會附帶下列圖示：
使用前請閱讀使用手冊。
請佩戴聽力保護器。
請佩戴護目鏡。
肉眼可見的輻射。請勿直視光照。
日期代碼位置 (圖B)
日期代碼 6包括製造年份，已經印刷在工具外殼上。
範例：
2021XX XX
製造的年份和週
說明 (圖A)

警告：請勿改動本電動工具或其任何部件，否則可能導致損
壞或人身傷害。
1 側手柄
2 深度調整桿
3 扳機開關
4 正向/反向控制按鈕（鎖止按鈕）
5 模式選擇器
6 主手柄
7 工作燈
8 電池組
9 電池釋放按鈕
10 掛鉤
設計用途
這款重型無碳刷四溝二用電鎚鑽被設計用於專業的混凝土、木材和
金屬鑽孔應用。
請勿在潮濕環境中或在易燃液體或氣體存在的環境中使用本工具。
這款重型無碳刷四溝二用電鎚鑽是一款專業電動工具。
请勿讓兒童接觸本工具。缺乏經驗的操作員需要在監督下使用本
工具。
