Dexing DX3316 User manual

DX3316 IP QAM Modulator
User Manual
SW Version: 1.02
HW version: 0.70.0.0
Web NMS version: 1.02
20142014
DEXIN DIGITAL TECHNOLOGY CORP. LTD.

About This Manual
Intended Audience
This user manual has been written to help people who have to use, to integrate
and to install the product. Some chapters require some prerequisite knowledge in
electronics and especially in broadcast technologies and standards.
Disclaimer
No part of this document may be reproduced in any form without the written
permission of the copyright owner.
The contents of this document are subject to revision without notice due to
continued progress in methodology, design and manufacturing. DEXIN shall have
no liability for any error or damage of any kind resulting from the use of this
document.
Copy Warning
This document includes some confidential information. Its usage is limited to the
owners of the product that it is relevant to. It cannot be copied, modified, or
translated in another language without prior written authorization from DEXIN.

Directory
Chapter 1 Product Overview............................................................................................1
1.1 Outline..........................................................................................................................1
1.2 Inner Structure............................................................................................................1
1.5 Specifications................................................................................................................2
Chapter 2 Physical Presentational Statement.................................................................2
2.1 Front panel Illustration: .............................................................................................4
2.2 Rear panel Illustration:...............................................................................................4
Chapter 3 Installation Guide............................................................................................5
3.1 Acquisition Check........................................................................................................5
3.2 Installation Preparation..............................................................................................5
Chapter 4 Web NMS Management..................................................................................8
4.1 Login.............................................................................................................................8
4.2 Operation......................................................................................................................8
Chapter 5 Troubleshooting.............................................................................................18
Chapter 6 Packing list..................................................................................................19

DX3316 IP QAM Modulator User Manual
1
Chapter 1 Product Overview
1.1 Outline
NDS3316 IP Mux-Scrambling modulator is the latest generational Mux-scrambling-modulating
all-in-one device developed by DEXIN. It has 16 multiplexing channels, 16 scrambling
channels and 16 QAM (DVB-C) modulating channels, and supports maximum 1024 IP input
through the GE port and 16 non-adjacent carriers (50MHz~960MHz) output through the RF
output interface. The device is also characterized with high integrated level, high performance
and low cost. This is very adaptable to newly generation CATV broadcasting system.
1.4 Key Features
2 GE input, SFPinterface
Supports up to 1024 channels TS over UDP/RTP, unicast and multicast, IGMP v2\v3
Max 840Mbps for each GE input
Supports accurate PCR adjusting
Supports CA PID filtering, remapping and PSI/SI editing
Supports up to 180 PIDS remapping per channel
Support DVB general scrambling system (ETR289), simulcrypt standards ETSI 101 197
and ETSI 103 197
Support 16 multiplexed or scrambled TS over UDP/RTP/RTSP output
16 non-adjacent QAM carriers output, compliant to DVB-C (EN 300 429) and ITU-T
J.83A/B
Supports RS (204,188) encoding
Support Web-based Network management
1.3 Inner Structure

DX3316 IP QAM Modulator User Manual
2
1.4 Carrier Setting Illustration
1.5 Specifications
Input
Input
512×2 IP input, 2 100/1000M Ethernet Port (SFP)
Transport Protocol
TS over UDP/RTP/RTSP, unicast and multicast,
IGMP V2/V3
Transmission Rate
Max 840Mbps for each GE input
Mux
Input Channel
1024
Output Channel
16
Max PIDs
180 per channel
Functions
PID remapping(auto/manually optional)
PCR accurate adjusting
PSI/SI table automatically generating
Scrambling
Parameters
Max simulscrypt CA
4
Scramble Standard
ETR289, ETSI 101 197, ETSI 103 197
Connection
Local/remote connection

DX3316 IP QAM Modulator User Manual
3
Modulation
Parameters
QAM Channel
16 non-adjacent carrier
Modulation Standard
EN300 429/ITU-T J.83A/B
Symbol Rate
5.0~7.0Msps, 1ksps stepping
Constellation
16, 32, 64 , 128, 256QAM
FEC
RS (204, 188)
RF Output
Interface
1 F typed output port for 16 carriers, 75Ω
impedance
RF Range
50~960MHz, 1kHz stepping
Output Level
-20dBm~+10dBm(87~117dbµV), 0.1dB stepping
MER
≥ 40dB
ACLR
-60 dBc
TS output
16 IP output over UDP/RTP/RTSP, unicast/multicast, 2 100/1000M
Ethernet Ports
System
Network management software (NMS) supporting
General
Demission
420mm×440mm×44.5mm (WxLxH)
Weight
3kg
Temperature
0~45℃(operation), -20~80℃(storage)
Power Supply
AC 100V±10%, 50/60Hz or AC 220V±10%,
50/60Hz
Consumption
15.4W

DX3316 IP QAM Modulator User Manual
4
Chapter 2 Physical Presentational Statement
2.1 Front panel Illustration:
2.2 Rear Panel Illustration:
1
NMS/CAS: network management port and CA data port
2
RF output port
3
Reset IP: Reset webmaster IP address, recover it to default IP address
4
Link/Act Indicators
5
Data Input/Output 1/2 (SFP)
6
Power switch
7
AC Power Socket
8
Grounding
3
4
5
6
7
8
1
2

DX3316 IP QAM Modulator User Manual
5
Chapter 3 Installation Guide
3.1 Acquisition Check
When user opens the package of the device, it is necessary to check items according to packing
list. Normally it should include the following items:
DX3316 IP QAM Modulator
User‟s Manual
Power Cord
If any item is missing or mismatching with the list above, please contact local dealer.
3.2 Installation Preparation
When users install device, please follow the below steps. The details of installation will be
described at the rest part of this chapter. Users can also refer rear panel chart during the
installation.
The main steps of the installation include:
Checking the possible device missing or damage during the transportation
Preparing relevant environment for installation
Installing DX3316 IP Mux-Scrambling QAM Modulator
Connecting signal cables
Connecting communication port (if it is necessary)
3.2.1 Device’s Installation Flow Chart Illustrated as follows：
Connecting
Grouding
Wire and
Power
Cord
Acquisition
Check Fixing Device Setting Parameter Running Device
Connecting
Signal Wire
3.2.2 Environment Requirement

DX3316 IP QAM Modulator User Manual
6
3.2.3 Grounding Requirement
All function modules‟ good grounding is the basis of reliability and stability of devices.
Also, they are the most important guarantee of lightning arresting and interference
rejection. Therefore, the system must follow this rule.
Coaxial cables‟ outer conductor and isolation layer should keep proper electric conducting
Item
Requirement
Machine Hall Space
When user installs machine frame array in one machine hall, the
distance between 2 rows of machine frames should be 1.2~1.5m and
the distance against wall should be no less than 0.8m.
Machine Hall Floor
Electric Isolation, Dust Free
Volume resistivity of ground anti-static material: 1X107~1X1010,
Grounding current limiting resistance: 1M (Floor bearing should be
greater than 450Kg/㎡)
Environment
Temperature
5~40℃(sustainable ), 0~45℃(short time)
installing air-conditioning is recommended
Relative Humidity
20%~80% sustainable 10%~90% short time
Pressure
86~105KPa
Door & Window
Installing rubber strip for sealing door-gaps and dual level glasses
for window
Wall
It can be covered with wallpaper, or brightness less paint.
Fire Protection
Fire alarm system and extinguisher
Power
Requiring device power, air-conditioning power and lighting power
are independent to each other. Device power requires AC power
220V ±10% 50/60Hz or 110V ±10% 50/60Hz. Please carefully
check before running.

DX3316 IP QAM Modulator User Manual
7
with the metal housing of device.
Grounding conductor must adopt copper conductor in order to reduce high frequency
impedance, and the grounding wire must be as thick and short as possible.
Users should make sure the 2 ends of grounding wire well electric conducted and be
antirust.
It is prohibited to use any other device as part of grounding electric circuit
The area of the conduction between grounding wire and device‟s frame should be no less
than 25mm2.
3.2.4 Frame Grounding
All the machine frames should be connected with protective copper strip. The grounding wire
should be as short as possible and avoid circling. The area of the conduction between
grounding wire and grounding strip should be no less than 25mm2.
3.2.5 Device Grounding
Connecting the device‟s grounding rod to frame‟s grounding pole with copper wire.
3.3 Wire’s Connection
3.3.1 Power cord connection
The power socket is located on the right of rear panel, and the power switch is on the left of
front panel. User can plug one end of the power cord to the socket and insert the other end to
AC power. When the device solely connects to protective ground, it should adopt independent
way, say, share the same ground with other devices. When the device adopts united way, the
grounding resistance should be smaller than 1Ω.
Caution: Before connecting power cord to DX3316 IP QAM Modulator, user should set the
power switch to “OFF”.
3.3.2 Signal and NMS Cable Connection
The signal connections include the connection of input signal cable and the connection of output
signal cable.
