Dextra Tanek User manual

Tanek Installation
DIL-71-0002 Revision - E 13/12/2022
220-240V / 50-60Hz
IP65
IK10
1.
2.
3.
4.
5.
6.
Carefully unpack the luminaire and undo the
10 x M5x20 socket screws in the frame and lift the
entire frame from the housing.
Undo the 2 x M4x10 machine screws in the ends of
the gear tray as show in the image and remove the
gear tray from the housing.
Drill suitable fixings to suit required installation.
NOTE: IT IS THE CONTRACTORS RESPONSIBILITY TO
ENSURE THE HOLES ARE SEALED.
FAILURE TO SEAL THE HOLES WILL INVALIDATE
THE LUMINAIRE'S IP RATING.
Remove the female socket from the tray as shown
and hard-wire to the mains supply.
Reconnect the plug to the tray leaving sufficient cable
length to reach.
Carefully return the gear tray into the housing and
secure into place with the 2 x M4x10 machine screws
provided. Ensure the mains cable does not become
trapped when doing so.
WARNING: Luminaire must be earthed. Risk of electric shock from LED boards if operated with cover
removed. Installation / operation outside of luminaires intended scope invalidates warranty. Suitable only for
domestic / light industrial / industrial applications within the scope of EN55015. Tested to compliance with
BSEN 60598: specification for general requirements and tests. Must beinstalled by a suitably qualified person
in accordance with all relevant legislation. Ambient operating temperature of 0°C to 25°C. If maximum
operating temperature is exceeded luminaire will automatically dim / switch off. Terminal blocks are rated to
16A unless stated otherwise. The light source is non replaceable. LUMINAIRES WITH EMERGENCY PACK:
When supply is isolated battery output terminals may be live if battery is connected. Isolate mains and battery
before servicing. Emergency luminaires require unswitched live connection taken from same phase as
switched supply. When unswitched supply is connected status indicator illuminates green, when unswitched
supply is disconnected indicator extinguishes and luminaire operates in emergency mode. 24 hour charge
period required before undertaking full discharge test. Emergency test sheets provided should be used to
record all emergency tests. Batteries should be replaced when 3 hour duration is notmet. Excessive switching
of permanent live may result in premature battery failure. Battery electrolyte can be harmful to eyes / open
wounds, do not puncture, if electrolyte touches skin / eyes flush with water. Do not incinerate batteries.
Terminal Labelling:
Power
L1 Switched Live
E Earth
N Neutral
Emergency
L2 Unswitched Live
DA/AT3 DALI Autotest
DA/AT3 DALI Autotest
Dimming
-/D1/DA Analogue/DSI/DALI
+/D2/DA Analogue/DSI/DALI
L3 Switch Dim /
Corridor Function

Tanek Installation
DIL-71-0002 Revision - E 13/12/2022
7.
8.
9.
10.
11.
12.
13.
14.
Feed the toggles on the tether wires through one of
the 7mm rounds on the end brackets inside the
housing. Hole location as shown to the right.
Reverse step 1 to secure the frame back onto the
housing. Do not over tighten the socket head screws
when replacing the frame. Tighten sufficiently so to
provide a seal between the frame gasket and the
housing.
