Dextra EXI XL User manual

EXI XL Installation
DIL-0473-0001 Revision - A 25/11/2022
220-240V / 50-60Hz
IP20
1.
2.
3.
4.
5.
6.
Pass suspension wire
through the clutch and
adjust to the required
height. Cut off excess
suspension cable.
Remove LED tray to
access housing
Rear fixings
Remove screws
Top (suspended) fixings
Fix the suspension points to the
ceiling at the specified centres
Fit suspension clutch as shown
WARNING: Luminaire must be earthed. Risk of electric shock from LED boards if operated with cover
removed. Installation / operation outside of luminaires intended scope invalidates warranty. Suitable only for
domestic / light industrial / industrial applications within the scope of EN55015. Tested to compliance with
BSEN 60598: specification for general requirements and tests. Must beinstalled by a suitably qualified person
in accordance with all relevant legislation. Ambient operating temperature of 0°C to 25°C. If maximum
operating temperature is exceeded luminaire will automatically dim / switch off. Terminal blocks are rated to
16A unless stated otherwise. The light source is non replaceable. LUMINAIRES WITH EMERGENCY PACK:
When supply is isolated battery output terminals may be live if battery is connected. Isolate mains and battery
before servicing. Emergency luminaires require unswitched live connection taken from same phase as
switched supply. When unswitched supply is connected status indicator illuminates green, when unswitched
supply is disconnected indicator extinguishes and luminaire operates in emergency mode. 24 hour charge
period required before undertaking full discharge test. Emergency test sheets provided should be used to
record all emergency tests. Batteries should be replaced when 3 hour duration is notmet. Excessive switching
of permanent live may result in premature battery failure. Battery electrolyte can be harmful to eyes / open
wounds, do not puncture, if electrolyte touches skin / eyes flush with water. Do not incinerate batteries.
Terminal Labelling:
Power
L1 Switched Live
E Earth
N Neutral
Emergency
L2 Unswitched Live
DA/AT3 DALI Autotest
DA/AT3 DALI Autotest
Dimming
-/D1/DA Analogue/DSI/DALI
+/D2/DA Analogue/DSI/DALI
L3 Switch Dim /
Corridor Function
Remove frame and legend
EXI XL Installation
DIL-0473-0001 Revision - A 25/11/2022
7.
8.
9.
10.
11.
12.
13.
14.
Locate legend in-between the frame and housing when
replacing the frame. Fasten frame in place with original
screws.
3 cable entry options
Connect incoming
power cable as per
diagram on leaflet
and use the strain
relief provided
Re-assemble fitting
