DGS Retail NESTING User manual

THREAD LEG LEVELER (ITEM 2) INTO LEG •
(ITEM 4).
PLACE LEG ON UNDERSIDE OF TABLE TOP •
ASSEMBLY, AGAINST STEEL BRACE.
2
4
3
B
DETAIL B
SCALE 1 : 6
1
4
3
NESTING TABLE
assembly instructions
ATTACH LEG TO TABLE USING (2) 1/4" X •
1.25" LAG SCREWS (ITEM 1)
REPEAT (3 TIMES) FOR EACH TABLE •
BOM
#
PART# QTY. TITLE
1
A190-1011-0002 8 1/4" X 1.250 LAG SCREW
2
14-20 X 1.000 LEVELER 4 LEG LEVELER
31138190710 1
Table Top SubAssm
41038404025 4
NESTING TABLE LEG
51138404054 2
NESTING TABLE SIDE SKIRT
6
BO-.625 4 #8x0.625 WOOD SCREW
7
BO-1.750 2 #8x1.750 WOOD SCREW

5
C
C
ATTACH TOP OF SIDE SKIRT TO TABLE TOP •
USING (2) #8 X 1.75" WOOD SCREWS (ITEM 7).
USE PILOT HOLES FOR SCREW LOCATION.
ATTACH BOTTOM OF SIDE SKIRT TO TABLE •
LEGS USING (2) L-BRACKETS AND (4) #8 X
.625" SCREWS (ITEM 6). USE PILOT HOLES
FOR SCREW LOCATION IN LEGS AND BOTTOM
OF SIDE SKIRT
REPEAT FOR OTHER SKIRT SIDE. •
77
6
6
6
6
NESTING TABLE
assembly instructions
PLACE SIDE SKIRT (ITEM 5) ON INSIDE OF •
SKIRT ON TABLE TOP ASSEMBLY.
OPTIONAL SIDE SKIRT INSTALLATION
BOM
#
PART# QTY. TITLE
1
A190-1011-0002 8 1/4" X 1.250 LAG SCREW
2
14-20 X 1.000 LEVELER 4 LEG LEVELER
31138190710 1
Table Top SubAssm
41038404025 4
NESTING TABLE LEG
51138404054 2
NESTING TABLE SIDE SKIRT
6
BO-.625 4 #8x0.625 WOOD SCREW
7
BO-1.750 2 #8x1.750 WOOD SCREW
