Dialog ROOM CONTROLLER WPP-INT User manual

Occupancy and Vacancy Sensors
®
ROOM CONTROLLER*™
DAYLIGHT SENSOR
WPP-INT
INSTALLATION GUIDE
A UDLA Company A UDLA Company

2A UDLA Company A UDLA Company
Part Number: WIR-3110

3
A UDLA Company A UDLA Company
WARNING!
SYSTEM MUST BE INSTALLED IN ACCORDANCE
WITH LOCAL AND NATIONAL ELECTRICAL CODES
INDOOR USE ONLY
Risk of Electric Shock. More than one disconnect switch is required to de-energize the device before servicing. All Servicing should be
performed by qualified service personnel. This unit has more than one power supply connection point. To reduce the risks of electric shock
disconnect both the branch circuit breakers / fuses & emergency power supplies before servicing.
SAVE THESE INSTRUCTIONS
• READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
• Do not use outdoors.
• Do not mount near gas or electric heaters.
• Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Do not use this equipment for other than intended use.

4A UDLA Company A UDLA Company
Part Number: WIR-3110
1. INTRODUCTION Page 5
1.1. GENERAL DESCRIPTION Page 5
2. DESIGN FEATURES Page 5
3. PART NUMBERS Page 5
4. COMPATIBLE DEVICES Page 6
5. SPECIFICATIONS Page 7
5.1. MOUNTING Page 7
5.2. OPERATIONS Page 7
5.3. POWER REQUIREMENTS Page 7
5.4. OPERATION ENVIRONMENT Page 7
5.5. APPROVALS Page 7
5.6. WARRANTY Page 7
6. DIMENSIONS Page 8
7. INSTALLATION Page 8
9. WIRING AND START-UP Page 9
10. LED STATUS INDICATORS Page 9
Table of Contents

5
A UDLA Company A UDLA Company
1.1. General Description
The Dialog Room Controller Daylight Sensor is a peripheral devices in a Dialog Room Controller Kit.
1. INTRODUCTION
2. DESIGN FEATURES
3. PART NUMBERS
• The Dialog Room Controller Daylight Sensor is powered by and communicated with, via our Dialog 2-wire low voltage data line.
• The low profile design and 30° tilting lens provides a clean looking installation while allowing the lens to be directed to or away from specific
areas.
• Plug ‘N Control™ ready out-of-the-box
• Daylight level set-point is field adjustable.
Part Number Description
WPP-INT Interior Daylight Sensor Single Room
WPP-INT-1A Interior Daylight Sensor Single Room A Type
WPP-INT-1B Interior Daylight Sensor Single Room B Type
WPP-INT-2A Interior Daylight Sensor Two Room A Type
WPP-INT-2B Interior Daylight Sensor Two Room Type B

6A UDLA Company A UDLA Company
Works in conjunction with the following Part Numbers:
4. COMPATIBLE DEVICES
Device Type Description PN
Dialog Room Controller Digital 4 Channel ON/OFF Room Controller w/ Receptacle Control, BACnet WRC-3160
Dialog Room Controller UL924 /
Relay Expansion Pack
Digital 2 Channel UL924 Emergency Lighting Controller / Relay Expansion Pack WUL-3924
Digital Occupancy Sensor Recessed Ceiling Standard Range w/ Time Delay Dial & Aux Relay, No Photo WORSDG1-R-T
Digital Occupancy Sensor Recessed Ceiling Extended Range w/ Time Delay Dial & Aux Relay, No Photo WORXDG1-R-T
Digital Vacancy Sensor Recessed Ceiling Standard Range w/ Time Delay Dial & Aux Relay, No Photo WVRSDG1-R-T
Digital Vacancy Sensor Recessed Ceiling Extended Range w/ Time Delay Dial & Aux Relay, No Photo WVRXDG1-R-T
1 Channel Dimmer & Switch Digital Dimmer & Switch, 1 Channel WSD-3501
1 Button Switch Digital 1 Gang 1 Button Switch WSW-3511
2 Button Switch Digital 1 Gang 2 Button Switch WSW-3512
3 Button Switch Digital 1 Gang 3 Button Switch WSW-3513
4 Button Switch Digital 1 Gang 4 Button Switch WSW-3514
8 Button Switch Digital 1 Gang 8 Button Switch WSW-3518

7
A UDLA Company A UDLA Company
5. SPECIFICATIONS
5.1. Mounting
• Dialog Ceiling Mount Sensors will fit a standard (2-1/8” deep) octagon box. They can also be attached with the included mounting ring. For
octagon box installations, conduits should be attached to the sides with the larger wiring space.
5.2. Operations
• Plug ‘N Control ready out-of-the-box
• Natural Daylight Harvesting via closed loop control dimming
• Range 0 to 65,000 lux
5.3. Power
• Current Draw: 3mA
5.4. Power Requirements
• Powered by Dialog 2-wire, non-polarized low voltage data bus
5.5. Operation Environment
• Indoors, stationary, non-vibrating, non-corrosive atmosphere and non-condensing humidity
• Ambient Operation Temperature: 14°F to 140°F (-10°C to 60°C)
5.6. Approvals
• ASHRAE 90.1 2010 Compliant
• California Energy Commission Title 24 Compliant
• NY Local Law 48 Compliant
5.7. Warranty
• 1-year

8A UDLA Company A UDLA Company
6. DIMENSIONS
7. INSTALLATION
• Ceiling Sensors mounting into a 2-1/8” deep or more, octagonal junction box. Install by recessing the device into the octagon box; lining
up the mounting holes and securing it using the screws provided. If too shallow, use the spacer ring is provided.
• Closed loop Daylight Sensors are best placed within the primary daylighting zone midway between rows and should be directed in a way
that limits the signal from uplight luminaries.
2.0”
(52mm)
0.88”
(22mm)
4.17”
(106mm)
2.95”
(75mm)
2.36”
(60mm)
30° Tilt

9
A UDLA Company A UDLA Company
8. WIRING AND START-UP
9. LED STATUS INDICATORS
CAUTION
Risk of Electric Shock. More than one disconnect switch is required to de-energize the device before servicing. All Servicing
should be performed by qualied service personnel. This unit has more than one power supply connection point. To reduce the
risks of electric shock disconnect both the branch circuit breakers / fuses & emergency power supplies before servicing.
A 24Vac data line source is used for the Dialog Occupancy Sensors, Daylight Sensors and Digital Wall Station Switches. All switches or loads
supported by the sensor must be included in the loading capacity of the Dialog Room Controller. Controller can support up to 100mA of
peripheral devices.
Use appropriate sized wire-nuts to connect the Dialog 2-wire network and external source to the auxiliary relay wires.
When using field-installed conductors ensure a 60ºC minimum rating.
1. Connect wiring as shown on appropriate Kit Wiring Diagram
2. Power up system
3. Wait 15 seconds for system to start-up and run system checks
4. Check sensor functionality
5. Set Daylight level
a. Remove face plate
b. Press commissioning button (green LED flashes)
c. Adjust dial to desired light level
d. Step away from sensor until orange light flashes
6. Installation & configuration complete!
! !
• The sensor has green and orange LED lights in the lens to indicate “Commissioning in Progress” and “Commissioning Complete”.

toll free: 877-873-2797
direct: 604-873-2797
[e-mail]
www.douglaslightingcontrols.com
Rev. 11/30/17
