Diamond Aircraft DA 62 Technical specifications

Ice Protection System DA 62 AFM
Supplement S02
Intentionally left blank.
Page 9-S02-2 31-Jan-2019 Doc. # 11.01.05-E
Revision 0

DA 62 AFM
Supplement S02 Ice Protection System
0.1 RECORD OF REVISIONS
Rev.
No. Reason Chap- ter Page(s) Date of Revision
Approval
Note
Date of
Approval
Date
Inserted Signature
Doc. # 11.01.05-E
Revision 0
31-Jan-2019 Page 9-S02-3

Ice Protection System DA 62 AFM
Supplement S02
0.2 LIST OF EFFECTIVE PAGES
Chapter Page Date
0
9-S02-1 31-Jan-2019
9-S02-2 31-Jan-2019
9-S02-3 31-Jan-2019
9-S02-4 31-Jan-2019
9-S02-5 31-Jan-2019
9-S02-6 31-Jan-2019
1
9-S02-7 31-Jan-2019
9-S02-8 31-Jan-2019
9-S02-9 31-Jan-2019
2
DOT approved 9-S02-10 31-Jan-2019
DOT approved 9-S02-11 31-Jan-2019
DOT approved 9-S02-12 31-Jan-2019
DOT approved 9-S02-13 31-Jan-2019
3
9-S02-14 31-Jan-2019
9-S02-15 31-Jan-2019
9-S02-16 31-Jan-2019
9-S02-17 31-Jan-2019
9-S02-18 31-Jan-2019
4A
9-S02-19 31-Jan-2019
9-S02-20 31-Jan-2019
9-S02-21 31-Jan-2019
9-S02-22 31-Jan-2019
Page 9-S02-4 31-Jan-2019 Doc. # 11.01.05-E
Revision 0

DA 62 AFM
Supplement S02 Ice Protection System
Chapter Page Date
4B
9-S02-23 31-Jan-2019
9-S02-24 31-Jan-2019
9-S02-25 31-Jan-2019
5 9-S02-26 31-Jan-2019
6 9-S02-27 31-Jan-2019
7
9-S02-28 31-Jan-2019
9-S02-29 31-Jan-2019
9-S02-30 31-Jan-2019
9-S02-31 31-Jan-2019
9-S02-32 31-Jan-2019
9-S02-33 31-Jan-2019
9-S02-34 31-Jan-2019
9-S02-35 31-Jan-2019
9-S02-36 31-Jan-2019
8 9-S02-37 31-Jan-2019
9-S02-38 31-Jan-2019
Doc. # 11.01.05-E
Revision 0
31-Jan-2019 Page 9-S02-5

Ice Protection System DA 62 AFM
Supplement S02
0.3 TABLE OF CONTENTS
Page
1. GENERAL..................................................... 9-S02-7
2. OPERATING LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-S02-10
3. EMERGENCY PROCEDURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-S02-14
4A. NORMAL OPERATING PROCEDURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-S02-19
4B. ABNORMAL OPERATING PROCEDURES . . . . . . . . . . . . . . . . . . . . . . . . . . 9-S02-23
5. PERFORMANCE .............................................. 9-S02-26
6. MASS AND BALANCE.......................................... 9-S02-27
7. DESCRIPTION OF THE AIRPLANE AND ITS SYSTEMS . . . . . . . . . . . . . . . 9-S02-28
8. AIRPLANE HANDLING, CARE, AND MAINTENANCE . . . . . . . . . . . . . . . . . 9-S02-37
Page 9-S02-6 31-Jan-2019 Doc. # 11.01.05-E
Revision 0

DA 62 AFM
Supplement S02 Ice Protection System
1. GENERAL
1.1 INTRODUCTION
This supplement to the AFM contains all necessary information to operate the ice protection
system of the DA 62.
The DA 62 can be equipped with an optional ice protection system in accordance with the
Optional Design Change Advisory OÄM 62-002. It distributes a thin film of de-icing fluid on the
wings, vertical stabilizer, horizontal stabilizer, propellers, and windscreen. This prevents the
formation and accumulation of ice.
NOTE
The ice protection system is not approved for flight into known or
forecast icing conditions. In case of an inadvertent icing encounter,
leave icing area immediately. Refer to Chapter 3.13.4 -
UNINTENTIONAL FLIGHT INTO ICING.
NOTE
The ice protection system is not a “de-icing” system in the usual
sense. It can remove only small accumulations of ice. Its main
purpose is to prevent the accretion of ice.
Doc. # 11.01.05-E
Revision 0
31-Jan-2019 Page 9-S02-7

Ice Protection System DA 62 AFM
Supplement S02
WARNING
Some icing conditions have the potential of producing hazardous
ice accumulations, which (1) exceed the capabilities of the airplane's
ice protection equipment, and/or (2) create unacceptable airplane
performance. Inadvertent operation in these conditions may be
detected by heavy ice accumulation on the windshield, or when ice
forms on the side areas of the canopy. Another indication is the rapid
formation and shedding of bars of ice (6 mm (1/4 in) thickness or
larger) from the porous panels. If these conditions are encountered,
the pilot should take immediate action to select HIGH/MAX flow rate,
and leave these conditions by changing altitude, turning back, or
even continuing on the same course if clear air is known to be
immediately ahead. This may best be achieved by climbing to
warmer air above the freezing rain or drizzle. Maximum climb power
with flaps retracted should be used.
1.5 DEFINITIONS AND ABBREVIATIONS
(b) Meteorological Terms
De-ice or de-icing: The periodic shedding or removal of ice accumulations from a surface,
by destroying the bond between the ice and the protection surface.
Freezing Drizzle: Drizzle is precipitation on the ground or aloft in the form of liquid water
drops that have diameters less than 0.5 mm, and greater than 0.05 mm
(50 μm to 500 μm, 0.002 in to 0.02 in). Freezing drizzle is drizzle in liquid
form that exists in air temperatures less than 0 °C (32 °F), i.e.
supercooled water, and freezes upon contact with objects on the surface
or airborne.
Freezing Rain: Rain is precipitation on the ground or aloft in the form of liquid water drops
which have diameters greater than 0.5 mm (0.02 in). Freezing rain is rain
in liquid form that exists at air temperatures less than 0 °C (32 °F), i.e.
supercooled water, and freezes upon contact with objects on the surface
Page 9-S02-8 31-Jan-2019 Doc. # 11.01.05-E
Revision 0

DA 62 AFM
Supplement S02 Ice Protection System
or airborne.
Ice Crystals: Any one of a number of macroscopic, crystalline forms in which ice
appears. Examples are hail and snow.
Icing conditions: An icing condition is defined as visually detected ice, or the presence
of visible moisture in any form at or below an indicated outside air
temperature (OAT) of +5 °C (41 °F).
Mixed Phase Icing Conditions:
A homogeneous mixture of supercooled water drops and ice crystals
existing within the same cloud environment.
Supercooled Water: Liquid water at a temperature below the freezing point of 0 °C (32 °F).
(i) Miscellaneous
Protected Surface: A surface containing ice protection, typically located at the surface’s
leading edge.
Residual Ice: Ice that remains on a protected surface immediately following the
actuation of a deicing system
Doc. # 11.01.05-E
Revision 0
31-Jan-2019 Page 9-S02-9

Ice Protection System DA 62 AFM
Supplement S02
2. OPERATING LIMITATIONS
NOTE
There is no change in existing operating limitations of the airplane.
The following information is exclusively to reflect the new indications
and information related to the ice protection system.
2.1 INTRODUCTION
2.1.1 USE OF THE AUTOPILOT
Use of the autopilot is prohibited when any ice is observed forming aft of the protected surfaces
of the wing, or when unusual lateral trim requirements or autopilot trim warnings are encountered.
NOTE
The autopilot may mask tactile cues that indicate adverse changes
in handling characteristics; therefore, the pilot should consider not
using the autopilot when any ice is visible on the airplane.
2.2 AIRSPEED
Airspeed IAS Remarks
Minimum airspeed for inadvertent
operation in icing conditions 90 KIAS These limitations do not apply for
take-off, landing, and maneuvers.
Maximum airspeed for inadvertent
operation in icing conditions 160 KIAS
Page 9-S02-10
DOT approved
31-Jan-2019 Doc. # 11.01.05-E
Revision 0

DA 62 AFM
Supplement S02 Ice Protection System
2.6 WARNING, CAUTION, AND ADVISORY ALERTS
2.6.1 WARNING, CAUTION, AND ADVISORY ALERTS ON THE G1000
NOTE
The alerts described in the following are displayed on the Garmin
G1000. Section 7.10 includes a detailed description of the alerts.
The following table shows the color and significance of the warning, caution, and advisory alert
lights on the G1000.
Color and Significance of the Caution Alerts on the G1000
Caution Alerts
(Amber) Meaning/Cause
DEIC PRES LO De-icing pressure is low.
DEIC PRES HI De-icing pressure is high.
DEICE LVL LO De-icing fluid level is low.
2.13 KINDS OF OPERATIONS
General
CAUTION
The system provides protection against icing when the pilot has
inadvertently entered icing conditions. Flights into known or forecast
icing conditions are prohibited.
Take-off
Take-off with ice or snow accumulation on the airplane is prohibited.
Doc. # 11.01.05-E
Revision 0
31-Jan-2019 Page 9-S02-11
DOT approved

Ice Protection System DA 62 AFM
Supplement S02
NOTE
The airplane must be completely cleared of ice, snow and similar
accumulations. For approved de-icing fluids, refer to AFM Section
8.7 - GROUND DE-ICING.
2.15 LIMITATION PLACARDS
Next to the filler cap:
DE-ICING
FLUID
Max. 37 liters (9.8 US gal).
Usable 36 liters (9.5 US gal).
Refer to AFM for approved fluids.
2.17 DE-ICING FLUIDS FOR SYSTEM OPERATION
Approved de-icing fluids for use in the ice protection system are:
* AL-5 (DTD 406B)
* Aeroshell Compound 07
* Kitfrost TKS 80
WARNING
The approved de-icing fluids are harmful. They are Glycol based
with different additives. Refer to the Material Safety Data Sheets
for proper handling which are available from the supplier of the de-
icing fluid.
Page 9-S02-12
DOT approved
31-Jan-2019 Doc. # 11.01.05-E
Revision 0

DA 62 AFM
Supplement S02 Ice Protection System
CAUTION
The use of other fluids will provide a correspondingly lower standard
of ice protection or may cause damage to the ice protection system.
NOTE
The maximum usable tank capacity is 36 liters (9.5 US gal). The
maximum tank capacity is 37 liters (9.8 US gal). Maximum system
operating times with maximum usable quantity of de-icing fluid:
NORM mode . . . . . . . . . . . . . . . . 3 hrs.
HIGH mode . . . . . . . . . . . . . . . . . 1 hr. 30 min.
MAX mode . . . . . . . . . . . . . . . . . . 45 min.
Doc. # 11.01.05-E
Revision 0
31-Jan-2019 Page 9-S02-13
DOT approved

Ice Protection System DA 62 AFM
Supplement S02
3. EMERGENCY PROCEDURES
3.5 G1000 FAILURES
3.5.7 ERRONEOUS OR LOSS OF DE-ICING FLUID DISPLAY
If the de-icing fluid quantity is known, the remaining system operating time can be estimated
based on the durations given in Section 2.17 - DE-ICING FLUIDS FOR SYSTEM OPERATION.
3.13 OTHER EMERGENCIES
3.13.4 UNINTENTIONAL FLIGHT INTO ICING
WARNING
If ice is observed forming aft of the protected surfaces of the wing,
or if unusual lateral trim requirements, or autopilot trim warnings are
encountered, accomplish the following:
* The flight crew should reduce the angle of attack by increasing
speed as much as the airplane configuration and weather allow,
without exceeding design maneuvering speed.
* If the autopilot is engaged, hold the control stick firmly and
disengage the autopilot. Do NOT re-engage the autopilot until the
airframe is clear of ice. The autopilot will NOT maintain airspeed
if ice accretes on the airplane. MONITOR airspeed closely.
* Leave the icing area immediately by changing altitude, turning
back, or even continuing on the same course if clear air is known
to be immediately ahead.
* Report these weather conditions to air traffic control.
Page 9-S02-14 31-Jan-2019 Doc. # 11.01.05-E
Revision 0

DA 62 AFM
Supplement S02 Ice Protection System
CAUTION
Do not delay activation of the ice protection system if icing conditions
are encountered.
CAUTION
The stall warning in icing conditions may not be reliable and must
not be relied upon in icing conditions.
WARNING
Flight in freezing rain, freezing drizzle, or mixed phase icing
conditions (supercooled water and ice crystals) may result in
hazardous ice build-up on protected surfaces exceeding the
capability of the ice protection system, or may result in ice forming
aft of the protected surfaces. This ice may not be shed using the
ice protection systems, and it may seriously degrade the
performance and controllability of the airplane.
CAUTION
Move ailerons, elevator, and rudder periodically to mitigate potential
control locking due to ice accretion.
During Climb and Cruise
1. DE-ICE .............................HIGH
2. MAX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . press push button, to dissipate ice
build-up
3. Pitot heating.......................... ON
4. ICE LIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . ON, as required
5. Cabin heat & defrost . . . . . . . . . . . . . . . . . . . ON
6. WINDSHIELD . . . . . . . . . . . . . . . . . . . . . . . . press push button, as required
CONTINUED
Doc. # 11.01.05-E
Revision 0
31-Jan-2019 Page 9-S02-15

Ice Protection System DA 62 AFM
Supplement S02
If the system does not work properly
Continue with Section 3.15.1 - FAILURE OF THE ICE PROTECTION SYSTEM.
If the system works properly, proceed as follows
7. Leave the icing area (by changing altitude, turning back, even continuing on the
same course if clear air is known to be immediately ahead).
8. De-icing fluid level . . . . . . . . . . . . . . . . . . . . . check periodically
9. DE-ICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NORM, HIGH, or MAX, as required.
Monitor ice build-up.
After leaving icing conditions
10. DE-ICE..............................OFF
11. ICE LIGHT...........................OFF
12. Pitot heating . . . . . . . . . . . . . . . . . . . . . . . . . . OFF, as required
13. Cabin heat & defrost . . . . . . . . . . . . . . . . . . . OFF, as required
END OF CHECKLIST
During Approach and Landing
1. DE-ICE..............................HIGH
2. MAX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . press push button if no shedding in
HIGH mode. Repeat as required.
NOTE
The MAX push button activates the maximum possible system flow
rate for 120 seconds.
CONTINUED
Page 9-S02-16 31-Jan-2019 Doc. # 11.01.05-E
Revision 0

DA 62 AFM
Supplement S02 Ice Protection System
CAUTION
If ice fails to shed, proceed with Section 3.15.1 - FAILURE OF THE
ICE PROTECTION SYSTEM.
3. ICE LIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . ON, as required
4. WINDSHIELD . . . . . . . . . . . . . . . . . . . . . . . . press push button, as required
NOTE
De-icing fluid will remain on the windshield for a period after
operating windshield de-ice. For an unobstructed view, do not
operate the windshield de-ice within 30 seconds prior to landing.
5. Airspeed . . . . . . . . . . . . . . . . . . . . . . . . . . . Maintain 90 to 160 KIAS
6. FLAPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . UP or T/O, as required
CAUTION
Do not set the flaps to the LDG position. Climb performance and
flight characteristics are significantly degraded with ice accretion.
END OF CHECKLIST
Doc. # 11.01.05-E
Revision 0
31-Jan-2019 Page 9-S02-17

Ice Protection System DA 62 AFM
Supplement S02
3.15 ICE PROTECTION SYSTEM EMERGENCIES
3.15.1 FAILURE OF THE ICE PROTECTION SYSTEM
A “failure” of the ice protection system is any condition in which the system fails to remove ice
from protected surfaces, including the propellers.
1. Leave the icing area (by changing altitude or turning back or even continuing on
the same course if clear air is known to be immediately ahead).
2. Maintain airspeed above 90 KIAS until final approach and landing.
3. Flap extension is limited to the T/O position.
WARNING
With an inoperative ice protection system, set both POWER levers
to MAX, and leave icing conditions as soon as possible. In heavy
icing conditions, it may not be possible to maintain altitude or proper
glide path on approach; in this case, it is imperative that a safe
airspeed be maintained; the stall warning system may not function,
and there may be little or no pre-stall buffet with heavy ice loads on
the wing leading edges.
4. Increase landing distance from AFM Section 5.3.12 by a factor of 1.4.
END OF CHECKLIST
Page 9-S02-18 31-Jan-2019 Doc. # 11.01.05-E
Revision 0

DA 62 AFM
Supplement S02 Ice Protection System
4A. NORMAL OPERATING PROCEDURES
4A.6 CHECKLISTS FOR NORMAL OPERATING PROCEDURES
4A.6.1 PRE-FLIGHT INSPECTION
I. Cabin Check
Ice protection system
a) ELEC MASTER.......................ON
b) DEICE FLUID . . . . . . . . . . . . . . . . . . . . . . . . check quantity
c) DOORS.............................closed
d) WINDSHIELD . . . . . . . . . . . . . . . . . . . . . . . . press push button
e) Spraybar . . . . . . . . . . . . . . . . . . . . . . . . . . . . evidence of de-icing fluid
NOTE
If the system has been inoperative for a while, has been drained,
or has run dry, trapped air - suspected in the feeder lines to the main
pumps - can be removed from the feeder lines to the main pumps
by activating the windshield pumps several times.
NOTE
Do not operate the main pumps with an empty de-icing fluid tank.
Operating the main system pumps with an empty de-icing fluid tank
can cause a future system malfunction. To re-establish full system
function, special maintenance action is required.
f) ANNUN-TEST........................ ON
NOTE
The ANNUN-TEST mode activates the DEICE LVL LO caution
immediately if the de-ice fluid quantity is low, and the DEIC PRES
LO caution after 120 seconds.
CONTINUED
Doc. # 11.01.05-E
Revision 0
31-Jan-2019 Page 9-S02-19

Ice Protection System DA 62 AFM
Supplement S02
g) DEIC PRES HI . . . . . . . . . . . . . . . . . . . . . . . . verify NOT ILLUMINATED
h) DEICE LVL LO . . . . . . . . . . . . . . . . . . . . . . . . check (must be annunciated if de-icing
fluid quantity is below 11 liters (2.9
US gal)
i) DEIC PRES LO. . . . . . . . . . . . . . . . . . . . . . . . check, ILLUMINATED (refer to NOTE)
j) DE-ICE..............................HIGH
k) DEIC PRES LO . . . . . . . . . . . . . . . . . . . . . . . verify NOT ILLUMINATED
l) DEIC PRES HI . . . . . . . . . . . . . . . . . . . . . . . . verity NOT ILLUMINATED
m) ICE LIGHT...........................ON
n) Ice lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . visual inspection, check
NOTE
If at ambient temperature above 10 °C (50 °F) and below 20 °C
(68 °F) DEIC PRES LO warning appears in HIGH mode, switch to
max mode to cancel the warning. Above 20 °C (68 °F) ambient
temperature, warning cancellation may not be possible.
o) DE-ICE..............................OFF
p) ICE LIGHT...........................OFF
q) ANNUN-TEST........................OFF
r) ELECT MASTER . . . . . . . . . . . . . . . . . . . . . . OFF
END OF CHECKLIST
II. Walk-Around Check, Visual Inspection
Ice protection system
a) De-icing fluid tank . . . . . . . . . . . . . . . . . . . . . . visually check quantity through filler
cap on top of the LH nose baggage
compartment
CONTINUED
Page 9-S02-20 31-Jan-2019 Doc. # 11.01.05-E
Revision 0
