2 / 32
250S-UK1.DOC
C
ONTENTS
1. PRESENTATION ..........................................................................................................................................................................3
1.1
TELEPHONE
TYPES ...................................................................................................................................................................4
1.2
GENERAL
CHARACTERISTICS ................................................................................................................................................5
1.3
CONTENTS
OF
THE
PACKAGE.................................................................................................................................................5
1.4
GENERALE
DESCRIPTION
OF
TLS
TELEPHONES ................................................................................................................5
1.5
TECHNICAL
CHARACTERISTICS
OF
TLS
TELEPHONE..................................................................................................6 - 7
1.6
DESCRIPTION
OF
DIA-250
S
TYPE
TELEPHONE ...................................................................................................................8
1.7
DESCRIPTION
OF
TYPE
DIA-250
S1
CLD
TYPE
TELEPHONE..............................................................................................9
1.8
DESCRIPTION
OF
KEYPAD.....................................................................................................................................................10
2. INSTALLATION OF TELEPHONES.......................................................................................................................................11
2.1
INSTALLATION
OF
DIA-250
S.................................................................................................................................................11
2.2
DIA-250
S1
CL
MOUNTING
INSTRUCTIONS ........................................................................................................................12
2.3
INSTALLATION
OF
DIA-250
S.................................................................................................................................................13
2.4
DIA-250S1
CLD
MOUNTING
INSTRUCTION.........................................................................................................................14
3. LAYOUT OF THE TELEPHONE CARD ................................................................................................................................15
3.1
FUNCTIONS
AND
JUMPER
SETTINGS ..................................................................................................................................15
4. CONNECTION OF THE TELEPHONE SET ..........................................................................................................................16
4.1
OPENING
THE
TELEPHONE
SET............................................................................................................................................16
4.2
CONNECTION
OF
THE
TELEPHONE
LINE............................................................................................................................16
5. USAGE OF THE TELEPHONE WITH FULL KEYPAD.......................................................................................................17
6. OPTIONS .....................................................................................................................................................................................20
6.1
RELAY
BOARD
-
DOOR
ENTRY
/
PUBLIC
ADDRESS
WK026CRG ....................................................................................20
6.2
AMPLIFIER
CARD
WK087CRA ...............................................................................................................................................21
7. PROGRAMMING.......................................................................................................................................................................22
8. OPERATIONAL COMMAND CODES....................................................................................................................................30
9. MAINTENANCE.........................................................................................................................................................................31
10. IN THE EVENT OF A PROBLEM .........................................................................................................................................31
11. SPARE PARTS LIST ................................................................................................................................................................31
