Diamond D2CM-XP User manual

01/2022
Mod: D4GP-XP
Production code: 31TR040102

INSTRUCTION MANUAL
TOASTERS

Página 2de 11
SYMBOLS USED IN THIS MANUAL
Read the instructions before using the appliance.
Important safety instructions. Risk of imminent accident if not observed
Practical note for the user.
Instructions for duly qualified persons only
1. Safety and proper use
1.1. Security instructions
The equipment is safe to use and complies with current European safety
requirements. However, improper use can lead to personal injury and property
damage. To ensure proper and safe operation, read this manual before operating the
equipment. This manual contains important warnings about the installation, safety, use
and care of the equipment.
Save this manual for future reference. Provide the manual with the
equipment to a new owner of the equipment.
The manufacturer cannot be held liable for damages resulting from improper
or incorrect use. Please note that the instructions in this manual do not replace the
technical characteristics recorded on the rating plate on the equipment.
Read the safety instructions carefully!

Página 3de 11
During installation: do not place on surfaces or near walls, partitions,
kitchen furniture or the like unless they are made of non-combustible
material or covered by thermally insulating and non-combustible
material and that attention is paid to the prevention regulations against
fire
Before using the equipment, check that there are no visible damages.
Never use damaged equipment.
Connect the equipment to a grounded electrical circuit. The electrical
safety of the equipment is only guaranteed if it has a correct
connection.
This equipment is supplied with an equipotential bonding terminal on
the back, which must be properly connected to the ground circuit by
an authorized installer.
Do not connect the equipment to the power supply with a multiple plug
or an extension cord. These do not guarantee the safety of the
equipment
Only qualified and accredited personnel may install and repair the
equipment. The manufacturer is not liable for damages resulting from
repairs and other interventions by unqualified persons
The installation and repair operations must comply strictly with the
local and national safety regulations in force.
Keep the equipment clean at all times. Food waste increases the risk of
fire!
Risk of burns! Do not touch work surfaces and metal parts while the
equipment is in operation
Danger of burners! Do not leave the forceps inside the toaster while it
is running. Insert only to remove bread.
The bread may burn so do not use the toaster near or underneath
combustible material, such as curtains.

Página 4de 11
The device is not intended to be operated by means of an external
timer or a separate remote control system.
Risk of Electrocution! Do not insert objects into the bread cavity; in
particular metallic objects; otherwise it will cause dangerous damage
to the appliance and to the user.
1.2. Purpose of use
Toasters are used to toast or heat bread. The manufacturer does not
recommend any other use, as this may be dangerous.
Toasters are for domestic use. Do not use outdoors
1.3. User requirements
•This appliance may be used by children 8 years of age or older and persons
whose physical, sensory or mental capacities are reduced, or by persons
without experience or knowledge if they have been given supervision or
instructions regarding the use of the appliance. a safe way and understood
the dangers involved.
•Children should not play with the appliance.
•Cleaning and maintenance by the user must not be carried out by children
unless they are over 8 years of age and supervised.
•Keep the appliance and the power cord out of the reach of children under 8
years of age.

Página 5de 11
1.4. Recycling
Treatment of packaging material: Before using the equipment for the first
time, remove the protective plastics from stainless steel. Recycle the shipping carton
and all protective materials.
Check for safe disposal of all plastic packaging. Keep plastic
containers out of the reach of children. Danger of suffocation!
Electrical and electronic equipment contain materials that, when
improperly handled, endanger human health and the environment. Do
not dispose of any part or component of the equipment in household
waste; place them in collection / recycling centers or contact your
supplier or local authorities for advice.

Página 6de 11
8
2. Description
Horizontal Toaster
1. Grids ;
2. Bread extraction lever ;
3. Tray scraps crumbs;
4. Timer 0-15min;
5. Rubber feet;
6. Heating indicator;
7. Heating zone selector switch
(4 and 6 space models only)
8. Bread manual extraction forceps
(only models without lever extraction)
2
3
4
6
7
1
5

Página 7de 11
2.1. Technical specifications
Model
Product
Dimensio
ns
WxDxH
(mm)
Weig
ht
Gros
s
(Kg)
Wei
ght
Líq.
(Kg)
Power
(W)
Tens.
(V/Hz)
Dimensions
Inside
Camera
WxDxH
(mm)
Dimensio
ns Grids
WxDxH
(mm)
Nº
Toast
Dimensio
ns
Packaging
WxDxH
(mm)
D2CM-XP
320x200x
210
4.8
4
1300
230/5
0
2x
28x150x180
4x
168x7x14
0
2
375x265x
250
D4CM-XP
430x200x
210
5.8
5
2150
230/5
0
4x
28x150x180
8x
168x7x14
0
4
480x265x
250
D4GP-XP
390x200x
210
5.8
5
2150
230/5
0
4x
28x150x180
8x
168x7x14
0
4
480x265x
250
D6GP-XP
480x200x
210
7
6
3000
230/5
0
6x
28x150x180
12x
168x7x14
0
6
530x265x
250
2.2. Required links
Electrical connection with protective earthing
Equipotential bonding to protective earth
2.3. Usage location
Choose a dry place where the equipment cannot come in direct contact with
water..
Never direct jets of water to the equipment.
Place the equipment on a stable, level surface..
Keep equipment away from flammable or heat-deformable materials. If this
is not possible, insulate the space around the equipment with a non-
flammable, heat-resistant insulation material.

Página 8de 11
2.4. Unpacking
Remove all protective material from the packaging. Check the equipment.
Remove the protective plastics from stainless steel. Clean the outside of the
machine with a damp cloth.
Dispose of the protective material and the packaging material safely as
potential sources of danger.
2.5. Electrical installation
Check that the data indicated on the equipment nameplate matches the
voltage and frequency of the power supply.
Connect the equipment to a grounded electrical circuit !
Connect the equipment to a fixed installation. Never connect the machine to
multiple plugs, T-type adapters, or extensions.
Follow the rules in force in the country where you are
At the back of the device there is a terminal marked with the symbol that
allows equipotential bonding between several devices
3. Operating Instructions
•Before using the appliance, you must remove all the protective plastic wrap
and clean the glue particles with non-abrasive products, so as not to
damage the appliance.
•When choosing where to place the appliance, make sure that it is level and
that its surface is non-combustible. Likewise, the appliance should be away
from walls and other materials that may be released or ignited under heat.

Página 9de 11
•Before connecting the appliance to the mains, make sure that the supply
voltage on the nameplate corresponds to the mains voltage and check that
the mains socket supports the appliance.
•Never operate the toaster with wet hands!
•The pan should always be placed in the toaster when it is in operation.
•Select the zones required for use in the commutator. Then set the cycle time
to turn the timer knob and select the desired time.
•Do not place cloths or other objects that may be damaged during use, or
cause danger.
•Make sure that the power cord does not come into contact with the heater, or
other hot parts.
•Never insert metal objects in a special area for bread.
4. Cleaning
•Whenever cleaning the appliance, make sure that the power cord is disconnected
from the mains and that the appliance is completely cold.
•Clean the outside of the toaster with a damp cloth and a little liquid detergent
•Tweezers and tray can be lifted in water for more effective cleaning.
Do not use water jets during the cleaning of the appliance
as it may

Página 10 de 11
5. Maintenance
Only qualified and accredited personnel may install and repair the
equipment.
The manufacturer is not liable for damages resulting from repairs and other
interventions by unqualified persons.
The installation and repair operations must comply strictly with the local and
national safety regulations in force.
Only original accessories should be used for repairs.
5.1. Replacing the power cord
If the power cable is damaged, it must only be replaced by an authorized
repairer or by the manufacturer.
•Models 2 spaces: Cable type H07RN-F 3G 1 mm2;
•Models 4 and 6 spaces: Cable type H07RN-F 3G 1,5 mm2.

Página 11 de 11
6. WARRANTY
❑The equipment is guaranteed for a period of 12 months from the date of
purchase.
❑The guarantee is valid against defects of origin, whether of material or of
manufacture.
❑Whenever there is an anomaly in the equipment, it must be returned as soon as
possible, with the purchase document.
❑When the warranty is triggered, damaged parts will be repaired or replaced, as
the manufacturer understands. In the event of their replacement, the damaged
parts will become the supplier's property.
❑Any defects resulting from improper installation or use / handling of the equipment
are excluded from the warranty.
❑The equipment will lose its warranty whenever any change / modification or even
repair made by the user is
NV DIAMOND EUROPE S.A
CHAUSSÉE DE VILVORDE 92
1120 BRUSSELS - BELGIUM
